System Map: Left View

Model A
1
3
2
*Floppy Disk Drive &
Optional Modules
If you have either the 6-
in-1 Card Reader, or
Video Capture Card
options, then the op-
tional module will re-
place the floppy disk
drive module in the slot
1
at point .
Concise User's Guide
Model B
1. Floppy Disk Drive*
2. Hard Disk Drive (HDD) Bay
3. Optical CD/DVD Device
(Model A only)
1
2
System Map: Left View - 11
Figure 3
Left View
Drive Warning
Don't try to remove the
hard disk (HDD) while
the system is on. This
could cause data loss or
damage.
Unauthorized removal
or tampering with the
HDD may violate your
warranty. If you are in
doubt, consult your ser-
vice representative.
