Right-side View
Figure 1-7
Battery Pack
The DeskNote comes with a rechargeable battery pack that lets you
operate the computer without an external power source.
Removable 5.25" CD-ROM Drive
The DeskNote comes standard with a 24-speed 5.25" CD-ROM drive. The
removable CD-ROM drive module can be replaced with the optional drive units,
such as a 12.7mm high DVD-ROM drive. (Please refer to the Chapter 2:
Operation for more information on using the CD-ROM.)
Infrared
The DeskNote is equipped with an infrared feature that allows the
communication with an infrared-compatible device. The Infrared port supports
IrDA (HPSIR) 1.1 mode, Amplitude Shifted Keyed IR (ASKIR) mode, and Fast
IR (FIR) mode.
Line-in Jack
External audio source can be fed into the DeskNote through this jack.
Microphone-in Jack
Use this jack to connect a microphone to the system.
Speaker-out Jack
Headphone and speakers can be attached to the system through this jack.
Phone Jack (option)
The phone jack is used to support the built-in modem. You can attach a
phone line to the jack and insert a modem card (optional) into the modem
socket on the mainboard.
Chapter 1—Getting Started 1-10
