- Page 1 Instruction Manual HI 83414 Turbidity and Free/Total Chlorine Meter w w w. h a n n a i n s t . c o m...
-
Page 2: Table Of Contents
Dear Customer, Thank you for choosing a Hanna Instruments product. This manual will provide you with the necessary information for correct use of the instrument. Please read this instruction manual carefully before using the instrument. If you need additional technical information, do not hesitate to e-mail us at tech@hannainst.com or see the back side of this manual for our worldwide sales and technical service contacts. -
Page 3: Preliminary Examination
PRELIMINARY EXAMINATION PRELIMINARY EXAMINATION PRELIMINARY EXAMINATION PRELIMINARY EXAMINATION PRELIMINARY EXAMINATION Please examine this Product carefully. Make sure the instrument is not damaged. If any damage has occurred during the shipment, please notify your dealer. This HI 83414 Bench Turbidity and Free/Total Chlorine meter is supplied complete with: •... -
Page 4: General Description
GENERAL DESCRIPTION GENERAL DESCRIPTION GENERAL DESCRIPTION GENERAL DESCRIPTION GENERAL DESCRIPTION GENERAL DESCRIPTION HI 83414 is a high accuracy, combined meter that benefits from Hanna’s years of experience as manufacturer of analytical instruments. The HI 83414 successfully combines turbidity and colorimetric measurements to meet the needs of measuring the most important parameters of drinking water: turbidity and free/total chlorine. -
Page 5: Abbreviations
A B B R E V I A T I O N S A B B R E V I A T I O N S A B B R E V I A T I O N S A B B R E V I A T I O N S A B B R E V I A T I O N S Nephelometric Turbidity Units Real Time Clock... - Page 6 For the ratio turbidimeter range, the microprocessor of the instrument calculates the NTU value, from the signals that reaches the two detectors, by using an effective algorithm. This algorithm corrects and compensates for interferences of color, making the HI 83414 instrument color-compensated. The optical system and measuring technique compensate also for the lamp intensity fluctuations, minimizing the need of frequent calibration.
- Page 7 Where: –log I/I = Absorbance (A) = intensity of incident light beam = intensity of light beam after absorption = molar extinction coefficient at wavelength = molar concentration of the substance = optical path through the substance Therefore, the concentration “c” can be calculated from the absorbance of the substance as the other factors are known.
-
Page 8: Functional Description
FUNCTIONAL DESCRIPTION FUNCTIONAL DESCRIPTION FUNCTIONAL DESCRIPTION FUNCTIONAL DESCRIPTION FUNCTIONAL DESCRIPTION INSTRUMENT DESCRIPTION 1) Liquid Crystal Display (LCD). The LCD has backlight for better visibility in dark environments. 2) Keypad. Splash proof resistant. 3) Cuvet Lid. Close the cuvet lid prior to start a measurement. 4) Lamp lid and the related fixing screw 5) USB connector 6) Fuse holder... - Page 9 DISPLAY DESCRIPTION The display contains the following fields: 1) The current time in selected format 2) Information related to the measurement 3) Functional keys 4) Currently selected parameter 5) Measuring units 6) Measured value KEYBOARD DESCRIPTION The keyboard contains 8 direct keys and 3 functional keys with the following functions: The function of each of the three functional keys depends on the name displayed on the LCD above them.
-
Page 10: Specifications
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS Turbidity 0.00 to 9.99; 10.0 to 40.0 NTU Range - non ratio mode 0.0 to 99.9; 100 to 268 Nephelos 0.00 to 9.80 EBC Resolution - non ratio mode 0.01; 0.1 NTU 0.1; 1 Nephelos 0.01 EBC Range - ratio mode 0.00 to 9.99;... -
Page 11: General Tips For An Accurate Measurement
Standards 1 mg/L free chlorine, 1 mg/L total chlorine Calibration One-point calibration Other Tungsten filament lamp Light Source Lamp life greater than 100,000 readings Display 40 x 70mm graphic LCD (64x128 pixels) with backlight LOG Memory 200 records Serial Interface Environment 0°C (32°F) to 50°C (122°F);... - Page 12 Note: In colorimetric measurements, when it is possible use the same cuvet both for zeroing and measurement. If this is not possible always match the cuvets. In turbidimetric measurements, if you are using multiple cuvets, always match the cuvets. CUVET HANDLING The cuvets should be free of scratches or cracks.
- Page 13 Note: The supplied cloth for oiling should be stored together with the silicone oil bottle and cuvets, taking care to avoid contamination with dirt. After a few oiling procedures, the cloth will contain enough oil to wipe the bottle with it without adding more oil. From time to time add some drops of oil on the cuvet to provide the necessary oil quantity in the cloth.
- Page 14 • Insert the cuvet into the instrument and press “Read” functional key. Record the reading. • Open the instrument lid, slightly rotate the cuvet and take a new reading. • Repeat the last step until you read the lowest NTU value.
- Page 15 • Turn the instrument ON. • Insert the first cuvet into the instrument and press “Read” functional key. Record the reading. • Mark this position on the thicker white band on the top of the cuvet with a water resistant pencil. •...
- Page 16 • Alternatively, keep the “Read” functional key pressed and, after the first value is displayed, open the lid and start rotating the cuvet until the read value matches the first cuvet. • Mark this position on the second cuvet with a water resistant pencil. •...
- Page 17 ADDITION OF SURFACTANT Surfactant addition works by changing the surface tension of the water. In this way bubbles are released from the sample. This method is effective in samples that are supersaturated with air. The procedure consists in the addition of a drop of surfactant in the cuvet before adding the sample to be analyzed.
- Page 18 REAGENT ADDING (COLORIMETRY only) • Because the reagent quantity is set up to react with 10mL of sample is very important to fill the cuvet correctly. The liquid in the cuvet forms a convexity on the top; the bottom of this convexity must be at the same level with the 10 mL mark.
-
Page 19: Start Up
S T A R T U P S T A R T U P S T A R T U P S T A R T U P S T A R T U P The HI 83414 Turbidity / Free & Total Chlorine bench is supplied with all necessary accesories for making measurements. -
Page 20: Tutorial Mode
T U T O R I A L M O D E T U T O R I A L M O D E T U T O R I A L M O D E T U T O R I A L M O D E T U T O R I A L M O D E The HI 83414 has a unique Tutorial Mode that provides additional information to help the unexperienced user during the measurements. -
Page 21: Measurement Procedure For Ratio/Non Ratio Turbidity Range
MEASUREMENT PROCEDURE FOR RATIO / MEASUREMENT PROCEDURE FOR RATIO / NON MEASUREMENT PROCEDURE FOR RATIO / NON RATIO RATIO RATIO RATIO MEASUREMENT PROCEDURE FOR RATIO / MEASUREMENT PROCEDURE FOR RATIO / RATIO TURBIDITY RANGE TURBIDITY RANGE TURBIDITY RANGE TURBIDITY RANGE TURBIDITY RANGE When taking turbidity measurements, several basic rules should be followed: •... - Page 22 NORMAL MEASUREMENT This type of measurement is best suited for regular readings, when the sample is stable and normal accuracy is required. In normal mode, the measurement takes about 10 seconds and the lamp is ON for a minimum period of time (about 7 seconds). •...
- Page 23 averaged value remains on the display at the end of the measurement. HI 83414 automatically selects the correct turbidity range to display the results with the highest accuracy. If the measured value is higher than 4000 NTU (980 EBC or 26800 Nephelos), the display will show the maximum value blinking and the message “Out of range”...
-
Page 24: Calibration Procedure For Ratio/Non Ratio Turbidity Range
C A L I B R A T I O N P R O C E D U R E F O R R A T I O C A L I B R A T I O N P R O C E D U R E F O R R A T I O C A L I B R A T I O N P R O C E D U R E F O R R A T I O / / / / / N N N N N ON R A T I O R A T I O... - Page 25 To enter calibration, press CAL CHECK key while in main screen. The first screen of GLP information is displayed. Press “Cal” functional key to start calibration. It is possible to interupt calibration procedure at any time by pressing CAL CHECK key . TWO-POINT CALIBRATION (Ratio and Non Ratio Turbidity) •...
- Page 26 • Close the lid and press “Read” functional key. The display will show the value blinking and the lamp icon during measurement. • If Non ratio Turbidity range is selected, the display will briefly show “Store...” and the two point calibration is saved.
- Page 27 • Close the lid and press “Read” functional key. The display will show the value blinking and the lamp icon during measurement. • At the end of the measurement, the fifth proposed calibration point (2000 NTU) is displayed. • At this moment it is possible to exit calibration by pressing “End”...
-
Page 28: Measurement Procedure For Free/Total Chlorine
OUT CAL RANGE FUNCTION The instrument has a mechanism to prevent taking measurements in a range where the calibration does not assure the best results. The message “Out of Calibration Range” is displayed on the message line in the following situations: •... - Page 29 • Place the cuvet into the instrument. Align the mark on the cuvete with the sign on the instrument top and close the lid. • Press “Zero” functional key. The dashes and the lamp icon will blink on the LCD, depending on the measurement phase.
- Page 30 • Press the “Timer” functional key. The display will show the stopwatch icon and the countdown prior to measurement. Alternatively wait for: Free Chlorine Total Chlorine 1 minute or 2 minutes and 30 seconds and then just press “Read” functional key. Dashes and the lamp icon will blink on the LCD, depending on the measurement phase.
-
Page 31: Cal Check Procedure For Free/Total Chlorine
Note: It is recommended to make a zero before each measurement. INTERFERENCES The colorimetric measurements are affected by the following interfering agents: • Bromine (positive error). • Chlorine dioxide (positive error). • Iodine (positive error). • Oxidized Manganese and Chromium (positive error). •... - Page 32 • Place the zero cuvet (A) in the instrument with the mark aligned with the mark on the instrument top. • Close the lid • Press the “Zero” functional key. The dashes and the lamp icon will blink on the LCD, depending on the measurement phase.
-
Page 33: Calibration Procedure For Free/Total Chlorine
CALIBRATION PROCEDURE FOR FREE/TOTAL CHLORINE CALIBRATION PROCEDURE FOR FREE/TOTAL CHLORINE CALIBRATION PROCEDURE FOR FREE/TOTAL CHLORINE CALIBRATION PROCEDURE FOR FREE/TOTAL CHLORINE CALIBRATION PROCEDURE FOR FREE/TOTAL CHLORINE To calibrate the free or total chlorine range of the HI 83414 the provided standard solution must be used. -
Page 34: Restore Factory Calibration
stor the calibration without warning and return to the measurement screen. CALIBRATION ERROR MESSAGES • The calibration is successfully performed if the reading is in certain limits. If the CAL CHECK™ standard value is too high, the display will show a high standard message. -
Page 35: Good Laboratory Practice (Glp)
GOOD LABORATORY PRACTICE (GLP) GOOD LABORATORY PRACTICE (GLP) GOOD LABORATORY PRACTICE (GLP) GOOD LABORATORY PRACTICE (GLP) GOOD LABORATORY PRACTICE (GLP) The HI 83414 has built in complete GLP information. The calibration date and the calibration points are displayed in a comprehensive mode for each range. To display the GLP information, simply press CAL CHECK key. -
Page 36: Log & Log Recall
LOG AND LOG RECALL LOG AND LOG RECALL LOG AND LOG RECALL LOG AND LOG RECALL LOG AND LOG RECALL The HI 83414 has a powerful log function that could store up to 200 records. Each record contains: • the measuring range, •... -
Page 37: Setup
S E T U P S E T U P S E T U P S E T U P S E T U P In the Setup mode, the instrument’s parameters, could be changed. Some parameters affect the measuring sequence and others are general parameters that change the behaviour or appearence of the instrument. - Page 38 The partial average is displayed during measurement. Press the functional key to enable or disable this option. Date / Time This option is used to set the instrument’s date and time. Press “Modify” to change the date/time. Press “Left” or ”Right” functional keys to highlight the value to be modified (year, month, day, hour, minute or second).
- Page 39 Tutorial This option is used to enable/disable tutorial mode. If enabled this option will provide the user short guides on the screen. Press the “Enable” functional key to select this option. Beep On Option: Enabled or Disabled. This option is used to enable/disable the beeper. Press the “Enable”...
-
Page 40: Lamp Replacement
L A M P R E P L A C E M E N T L A M P R E P L A C E M E N T L A M P R E P L A C E M E N T L A M P R E P L A C E M E N T L A M P R E P L A C E M E N T The instrument tungsten lamp has a life longer than 100,000 measurements. -
Page 41: Pc Interface
PC INTERFACE PC INTERFACE PC INTERFACE PC INTERFACE PC INTERFACE Log data download from the instrument to the PC can be done with the HI 92000 Windows compatible software (optional). HI 92000 also offers graphing and on-line help features. Data can be exported to the most popular spreadsheet programs for further analysis. -
Page 42: Warranty
If the repair is not covered by the warranty, you will be notified of the charges incurred. If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization Number from the Customer Service Department and then send it with shipment costs prepaid. When shipping any instrument, make sure it is properly packaged for complete protection. - Page 44 SALES AND TECHNICAL SERVICE CONTACTS SALES AND TECHNICAL SERVICE CONTACTS SALES AND TECHNICAL SERVICE CONTACTS SALES AND TECHNICAL SERVICE CONTACTS SALES AND TECHNICAL SERVICE CONTACTS Australia: Tel. (03) 9769.0666 • Fax (03) 9769.0699 China: Tel. (10) 88570068 • Fax (10) 88570060 Egypt: Tel.
