  • Page 1 Instruction Manual HI 83205 Multiparameter Bench Photometer for Boilers and Cooling Towers This Instrument is in w w w . h a n n a i n s t . c o m Compliance with the CE Directives...

  • Page 2: Table Of Contents

    Dear Customer, PRELIMINARY EXAMINATION Thank you for choosing a Hanna product. Please read this instruction manual carefully before using the instrument. This manual will provide you with the necessary information for the correct use of the Please examine this product carefully. Make sure that the instrument is not damaged. If any damage occurred during shipment, please notify your Dealer.

  • Page 3: Specifications

    Where: SPECIFICATIONS -log I/I =Absorbance (A) =intensity of incident light beam Light Life Life of the instrument I =intensity of light beam after absorption Light Detector Silicon Photocell ε =molar extinction coefficient at wavelength λ λ Environment 0 to 50°C (32 to 122°F); =molar concentration of the substance max 90% RH non-condensing =optical path through the substance...

  • Page 4: Functional Description

    KEYPAD DESCRIPTION FUNCTIONAL DESCRIPTION The keypad contains 8 direct keys and 3 functional keys with the following functions: INSTRUMENT DESCRIPTION Press to perform the function displayed above it. The functions are screen related. Press to exit the current screen. Press to access the select method menu. Press to move up in a menu or a help screen, to increment a set value, to access second level functions.

  • Page 5: Tips For An Accurate Measurement

    USING LIQUID AND POWDER REAGENTS TIPS FOR AN ACCURATE MEASUREMENT • Proper use of the dropper: The instructions listed below should be carefully followed during testing to ensure most accurate results. (a) for reproducible results, tap the dropper on the table for several times and wipe the outside of the dropper tip with a cloth.

  • Page 6: Nitrite Hr

    Pay attention to push the cuvette completely down in the holder. HEALTH & SAFETY The chemicals contained in the reagent kits may be hazardous if improperly handled. Read the Material Safety Data Sheet (MSDS) before performing tests. Safety equipment: Wear suitable eye protection and clothing when required, and follow instructions carefully. Reagent spills: If a reagent spill occurs, wipe up immediately and rinse with plenty of water.

  • Page 7: Operational Guide

    • After the desired method was selected, follow the measurement described in the related section. OPERATIONAL GUIDE • Before performing a test you should read all the instructions carefully. POWER CONNECTION AND BATTERY MANAGEMENT The meter can be powered from an AC/DC adapter (included) or from the built-in rechargeable battery. Note: Always turn the meter off before unplugging it to ensure no data is lost.

  • Page 8: Setup

    Date / Time S E T U P S E T U P S E T U P S E T U P S E T U P This option is used to set the instrument’s date and time. Press Modify functional key to change the date/time. In the Setup mode the instrument’s parameters can be changed.

  • Page 9: Aluminum

    Instrument ID ALUMINUM Option: 0 to 9999. This option is used to set the instrument’s ID (identification number). SPECIFICATIONS The instrument ID is used while exchanging data with a PC. Range 0.00 to 1.00 mg/L Press Modify functional key to access the instrument ID screen. Press the Resolution 0.01 mg/L keys in order to set the desired value.

  • Page 10: Ammonia Mr

    • Add the content of one packet of HI 93712C-0 Bleaching AMMONIA MEDIUM RANGE Powder to one of the two cuvettes. Replace the cap and shake vigorously until completely dissolved. This is the blank. SPECIFICATIONS Range 0.00 to 10.00 mg/L Resolution 0.01 mg/L •...

  • Page 11: Ammonia Lr

    • Remove the cuvette. AMMONIA LOW RANGE SPECIFICATIONS • Add 4 drops of HI 93715A-0 First reagent (6 drops for seawater Range 0.00 to 3.00 mg/L analysis). Replace the cap and mix the solution. Resolution 0.01 mg/L Accuracy ±0.04 mg/L ±4% of reading Typical EMC ±0.01 mg/L Deviation...

  • Page 12: Bromine

    • Remove the cuvette. BROMINE SPECIFICATIONS • Add 4 drops of HI 93700A-0 First reagent (6 drops for seawater Range 0.00 to 8.00 mg/L analysis). Replace the cap and mix the solution. Resolution 0.01 mg/L Accuracy ±0.08 mg/L ±3% of reading Typical EMC ±0.01 mg/L Deviation...

  • Page 13: Free Chlorine

    • Remove the cuvette and add the content of one packet of HI 93716-0 FREE CHLORINE FREE CHLORINE FREE CHLORINE FREE CHLORINE FREE CHLORINE FREE CHLORINE DPD reagent. Replace the cap and shake gently for about 20 seconds to dissolve most of the reagent. SPECIFICATIONS Range 0.00 to 2.50 mg/L...
  • Page 14 • Press ZERO key. The meter will show “-0.0-” when the meter is zeroed and ready for measurement. • Reinsert the cuvette into the instrument. • Press READ to start the reading. The instrument displays the results • Remove the cuvette. in mg/L of free chlorine.

  • Page 15: Total Chlorine

    • Press ZERO key. The meter will show “-0.0-” when the meter is zeroed and ready for measurement. TOTAL CHLORINE SPECIFICATIONS Range 0.00 to 3.50 mg/L Resolution 0.01 mg/L Accuracy ±0.03 mg/L ±3% of reading • Remove the cuvette. Typical EMC ±0.01 mg/L Powder reagents procedure Deviation...

  • Page 16: Chlorine Dioxide

    • Press TIMER and the display will show the countdown prior to the measurement or, alternatively, wait CHLORINE DIOXIDE for 2 minutes and 30 seconds and press READ. When the timer ends the meter will perform the reading. SPECIFICATIONS Range 0.00 to 2.00 mg/L Resolution 0.01 mg/L...
  • Page 17 • Add the content of one packet of HI 93738B-0 Dechlorinating Reagent to one of the two cylinders • Press ZERO key. The meter will show “-0.0-” when the meter is zeroed and ready for measurement. (#1), close and invert it several times until it is totally dissolved. This is the blank. •...
  • Page 18 CHROMIUM VI HIGH RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 0 to 1000 µg/L • Press TIMER and the display will show the countdown prior to the Resolution 1 µg/L measurement or, alternatively, wait for 6 minutes and press READ. Accuracy ±5 µg/L ±4% of reading When the timer ends the meter will perform the reading.
  • Page 19 CHROMIUM VI LOW RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS • Press TIMER and the display will show the countdown prior to the Range 0 to 300 µg/L measurement or, alternatively, wait for 6 minutes and press Resolution 1 µg/L READ.
  • Page 20 • Remove the cuvette. COPPER HIGH RANGE • Add the content of one packet of HI 93702-0 Bicinchoninate. Replace SPECIFICATIONS the cap and shake gently for about 15 seconds. Range 0.00 to 5.00 mg/L Resolution 0.01 mg/L Accuracy ±0.02 mg/L ±4% of reading Typical EMC ±0.01 mg/L Deviation...
  • Page 21 • Remove the cuvette. COPPER LOW RANGE • Add the content of one packet of HI 93747-0 Bicinchoninate. SPECIFICATIONS Replace the cap and shake gently for about 15 seconds. Range 0 to 1000 μg/L Resolution 1 μg/L Accuracy ±10 μg/L ±5% of reading Typical EMC ±1 μg/L Deviation...
  • Page 22 HYDRAZINE SPECIFICATIONS Range 0 to 400 µg/L Resolution 1 µg/L • Add 12 drops of the HI 93704-0 reagent to each x 12 x 12 Accuracy ±4% of full scale cuvette. Replace the caps and shake gently to mix. Typical EMC ±2 µg/L Deviation Light Source...
  • Page 23 IRON HIGH RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 0.00 to 5.00 mg/L Resolution 0.01 mg/L • Press TIMER and the display will show the countdown Accuracy ±0.04 mg/L ±2% of reading prior to the measurement or, alternatively, wait for 3 Typical EMC ±0.01 mg/L minutes and press READ.
  • Page 24 • Press ZERO key. The display will show “-0.0-” when the meter is zeroed and ready for measurement. IRON LOW RANGE SPECIFICATIONS Range 0 to 400 µg/L Resolution 1 µg/L Accuracy ±10 µg/L ±8% of reading Typical EMC ±1 µg/L •...
  • Page 25 INTERFERENCES MOLYBDENUM Interference may be caused by: Cadmium above 4.0 mg/L SPECIFICATIONS Chromium above 0.25 mg/L Range 0.0 to 40.0 mg/L Chromium above 1.2 mg/L Cobalt above 0.05 mg/L Resolution 0.1 mg/L Copper above 0.6 mg/L Accuracy ±0.3 mg/L ±5% of reading Cyanide above 2.8 mg/L Typical EMC ±0.1 mg/L...
  • Page 26 • Press TIMER and the display will show the countdown prior to the measurement or, alternatively, wait for five minutes and press READ. When the timer ends the meter will perform the reading. The • Fill one graduated mixing cylinder up to the 25 mL instrument displays concentration in mg/L of molybdenum.
  • Page 27 NITRATE • Replace the cap and immediately shake vigorously up and down for exactly 10 seconds. Continue to mix by SPECIFICATIONS inverting the cuvette gently for 50 seconds, while taking Range 0.0 to 30.0 mg/L care not to induce air bubbles. Powder will not com- Resolution 0.1 mg/L pletely dissolve.
  • Page 28 NITRITE HIGH RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 0 to 150 mg/L • Press TIMER and the display will show the countdown prior Resolution 1 mg/L to the measurement or, alternatively, wait for 10 minutes Accuracy ±4 mg/L ±4% of reading and press READ.
  • Page 29 NITRITE LOW RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 0.00 to 0.35 mg/L • Press TIMER and the display will show the countdown prior Resolution 0.01 mg/L to the measurement or, alternatively, wait for 6 minutes Accuracy ±0.02 mg/L ±4% of reading and press READ.
  • Page 30 DISSOLVED OXYGEN • Let the sample stand and the flocculent agent will start to settle. SPECIFICATIONS x 10 • After approximately 2 minutes, when the upper half of the bottle becomes Range 0.0 to 10.0 mg/L limpid, add 10 drops of HI 93732C-0. Resolution 0.1 mg/L Accuracy...
  • Page 31 • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 6.5 to 8.5 pH Resolution 0.1 pH • Press the READ key to start the reading. The instrument displays Accuracy ±0.1 pH the pH value. Typical EMC ±0.1 pH Deviation Light Source Tungsten lamp with narrow band interference filter @ 525 nm Method Adaptation of the Phenol Red method.
  • Page 32 • Add the content of one packet of HI 93717B-0 Phosphate PHOSPHATE HIGH RANGE HR Reagent B to the cuvette. Replace the cap and shake gently until completely dissolved. SPECIFICATIONS Range 0.0 to 30.0 mg/L Resolution 0.1 mg/L • Reinsert the cuvette into the instrument. Accuracy ±1 mg/L ±4% of reading Typical EMC Dev.
  • Page 33 PHOSPHATE LOW RANGE • Reinsert the cuvette into the instrument. SPECIFICATIONS Range 0.00 to 2.50 mg/L Resolution 0.01 mg/L • Press TIMER and the display will show the countdown prior to the Accuracy ±0.04 mg/L ±4% of reading measurement or, alternatively, wait for 3 minutes and press READ. Typical EMC Dev.
  • Page 34 SILICA • Place the cuvette into the holder and close the lid. SPECIFICATIONS • Press ZERO key. The display will show “-0.0-” when the Range 0.00 to 2.00 mg/L meter is zeroed and ready for measurement. Resolution 0.01 mg/L Accuracy ±0.03 mg/L ±3% of reading Typical EMC ±0.01 mg/L...
  • Page 35 INTERFERENCES ZINC Interference may be caused by: Phosphate above 60 mg/L SPECIFICATIONS Phosphate above 75 mg/L Range 0.00 to 3.00 mg/L Sulfide and high concentration of iron Resolution 0.01 mg/L Accuracy ±0.03 mg/L ±3% of reading Eliminate color and turbidity interferences by zeroing the meter with the original water sample. Typical EMC ±0.01 mg/L Deviation...
  • Page 36 ERRORS AND WARNINGS • Place the cap and insert the cuvette into the instrument and close the lid. • Press ZERO key. The display will show “-0.0-” when the The instrument shows clear warning messages when erroneous conditions appear and when measured values are meter is zeroed and ready for measurement.

  • Page 37: Phosphate Hr

    6.5 to 8.5 pH Phenol Red DATA MANAGEMENT Phosphate HR 0.0 to 30.0 mg/L Amino Acid Phosphate LR 0.00 to 2.50 mg/L Ascorbic Acid Silica 0.00 to 2.00 mg/L Heteropoly Blue The analyzed data can be managed using Hanna’s product HI92000, Windows Compatible Software.

  • Page 38: Hanna Literature

    HI 93749-01 100 chromium VI LR tests If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization Number HI 93749-03 300 chromium VI LR tests from the Customer Service Department and then send it with shipment costs prepaid. When shipping any OTHER ACCESSORIES instrument, make sure it is properly packaged for complete protection.
  • Page 39 SALES AND TECHNICAL SERVICE CONTACTS Australia: Tel. (03) 9769.0666 • Fax (03) 9769.0699 e-mail: hannains@hannainst.com.au China: Tel. (10) 88570068 • Fax (10) 88570060 e-mail: hannachina@vip.sina.com Egypt: Tel. & Fax (02) 2758.683 e-mail: hannaegypt@go.com.eg Germany: Tel. (07851) 9129-0 • Fax (07851) 9129-99 e-mail: hannager@aol.com Greece: Tel.
