Configure Mode - Cabletron Systems SmartSwitch Router User's Reference Manual

Chapter 1: SmartSwitch Router Product Overview
To exit Enable mode and return to User mode, use one of the following commands:
Exit Enable mode.

Configure Mode

Configure mode provides the capabilities to configure all features and functions on the
SSR. You can configure features and functions within Configure mode including router
configuration, access control lists and spanning tree.
To list the Configure commands, enter:
List the Configure commands.
The Configure mode command prompt consists of the SSR name followed by the pound
sign (#):
ssr(config)#
To list the commands available in Configure mode, enter a question mark (?) as shown in
the following example:
ssr(config)# ?
acl
acl-edit
aging
arp
bgp
cli
dvmrp
exit
filters
http
igmp
interface
ip
ip-router
ipx
ospf
port
qos
rip
snmp
stp
system
24
exit
Ctrl+Z
?
- Configure L3 Access Control List
- Edit an ACL in the ACL Editor
- Configure L2 and L3 Aging
- Configure ARP entries
- Configure Border Gateway Protocol (BGP)
- Modify the command line interface behavior
- Configure DVMRP related parameters
- Exit current mode
- Configure L2 security filters
- Configure SNMP related parameters.
- Configure IGMP related parameters
- Configure interface related parameters
- Configure IP related parameters
- Configure Unicast Routing Protocol related
parameters
- Configure IPX related parameters
- Configure Open Shortest Path Protocol (OSPF)
- Configure Port parameters
- Configure Quality of Service parameters
- Configure Routing Information Protocol (RIP)
- Configure SNMP related parameters.
- Configure STP parameters
- Configure system-wide parameters
SmartSwitch Router User Reference Manual
