Cabletron Systems SmartSwitch Router User's Reference Manual page 18

Chapter 1: SmartSwitch Router Product Overview
The following table lists the basic hardware and software specifications for the SSR:
Table 1. SSR Hardware and software specifications
Throughput
Capacity
Routing protocols
Bridging and VLAN
protocols
Media Interface protocols
Quality of Service (QoS)
RMON
Management
18
Feature
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Specification
16-Gbps non-blocking switching fabric
15 million packets-per-second routing throughput
Up to 250,000 routes
Up to 2,000,000 Layer-4 application flows
400,000 Layer-2 MAC addresses
4,096 Virtual LANs (VLANs)
20,000 Layer-2 security and access-control filters
3MB input/output buffering per Gigabit port
1MB input/output buffering per 10/100 port
IP: RIPv1/v2, OSPF, BGP 2,3,4
IPX: RIP, SAP
Multicast: IGMP, DVMRP
802.1d Spanning Tree
802.1Q (VLAN trunking)
802.3 (10Base-T)
802.3u (100Base-TX, 100BASE-FX)
802.3x (1000Base-SX, 1000Base-LX)
802.3z (1000Base-SX, 1000Base-LX)
Layer-2 prioritization (802.1p)
Layer-3 source-destination flows
Layer-4 source-destination flows
Layer-4 application flows
RMONv1/v2 for each port
SNMP
CoreWatch Element Manager (GUI)
Emacs-like Command Line Interface (CLI)
SmartSwitch Router User Reference Manual
