A-2 A
PPENDIX
Voice Connector Interface (521 & 531)
The Voice interface is an RJ11 socket. This allows analog telephony
equipment to be connected to the unit. The socket is touch-tone
(AT&T 2500) compatible. An adapter may be required for some
telephone equipment connections.

Management Connector Interface

The management interface is a 9-way D-type connector for use
with a VT100 compliant terminal or PC. This supports the following:
Local and remote terminal management with TCP/IP Telnet
menu driven management interface for remote management.
Software upgrades, enhancements and configurations
downloadable from network attached terminal or PC.
SNMP MIB II with private extensions for management of
unique features.

Protocol Support

TCP/IP – routing or bridging.
Novell IPX – routing or bridging.
Other – bridging.

Bridge Characteristics

802.3 MAC layer bridge.
802.1D spanning tree algorithm.
Support for bridge triangulation and link load sharing.

Performance

LAN filtering rate: 14880 frames per second.
LAN forwarding rate: 4000 frames per second.
ISDN and WAN forwarding rates are dependent on the link speed.
A: T I
ECHNICAL NFORMATION
