- Page 1 FLM lamp house Installation manual R5976922/03 18/11/2008...
- Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: sales.events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
- Page 3 FLM projector). The FLM projector will not recognize the Universal Lamp House and will fail to start up the xenon bulb lamp when neglecting this software upgrade. Use the Projector Toolset, which is also available on the secured Barco web site, to upgrade the projector software.
- Page 4 This procedure may only be performed by qualified technical service personnel. AUTION Never attempt to disassemble the lamp from its housing or to dispose of it. Return it to Barco. Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled.
- Page 5 This procedure may only be performed by qualified technical service personnel. AUTION Never attempt to disassemble the lamp from its housing or to dispose of it. Return it to Barco. Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled.
- Page 6 1. Installation process 3. Clasp the lamp house by its handles and gently slide the lamp house into its socket. Note that the compartment is provided with guides (G) to position the lamp house correctly. Image 1-5 4. Push the lamp house forward until it slides fully into the projector. 5.
- Page 7 1. Installation process Image 1-7 2. Secure the lamp cover by locking the two captive screws at the right side of the lamp cover. Image 1-8 R5976922 FLM LAMP HOUSE 18/11/2008...
