- Page 1 F90 Dust Filter Installation and Maintenance 601–0456/00 14/08/2017...
- Page 2 Barco Fredrikstad AS Habornveien 53, N-1630 Gamle Fredrikstad, Norway Phone: +47 6930 4550 Fax: +47 6930 4580 Support: Support.fre@barco.com Visit us at the web: www.barco.com Printed in...
- Page 3 Image 1-2 Applying the filter frame Image 1-1 Entering the captive screws 3. Ensure that the micro switch at the top of the side cover is engaged by the stud on the filter frame. 601–0456 F90 DUST FILTER 14/08/2017...
- Page 4 4. Hold the filter frame in position, and enter the screws in each corner in the corresponding threads in the side cover. Tighten the screws in a cross pattern. Enter and tighten the two last screws 601–0456 F90 DUST FILTER 14/08/2017...
- Page 5 If the filter becomes clogged, the reduced airflow may result in a thermal warning and the projector is at risk of shutting down. If this occurs, please clean the filter before attempting to turn the projector back on. 601–0456 F90 DUST FILTER 14/08/2017...
