12
Feature Overview

CONTROL PAD FUNCTIONS - MODEL B

1
8
15
16
1
Bake Pad- Used to enter the normal baking mode temperature.
2
Broil Pad- Used to select the variable broil mode.
3
Convection Bake Pad- Used to select the convection baking mode.
4
Convection Roast Pad- Used to select the convection roasting mode.
5
Convection Broil Pad- Used to select the convection broil mode.
6
Warm Pad- Used to select the warm oven mode.
7
Upper Oven Pad- Used to activate the upper oven for cooking operation.
8
Slow Cook Pad- Used to select the slow cook mode.
9
Multi Stage Pad- Used to enter up to three subsequent modes.
10
Defrost Pad- Used to select the defrost mode.
11
Dehydrate Pad- Used to select the dehydrate mode.
12
Bread Proof Pad- Used to select the bread proof mode.
13
Clean Pad- Used to select the self-cleaning mode.
14
Lower Oven Pad- Used to activate the lower oven for cooking operation.
15
Light Pad- Used to turn the oven light on and off.
16
Control Lock Pad- Used to disable all oven function.
17
Lite Pad- Used to start a 2 hours self-clean cycle.
18
Med Pad- Used to start a 3 hours self-clean cycle.
19
Heavy Pad- Used to start a 4 hours self-clean cycle.
20
User Preference Pad- Used to bring the user preference menu in the display.
2
3
4
11
9
10
17
5
6
12
13
18
19
7
14
20
