2.4.1

Floppy Drives

To configure the first floppy drive (drive A), highlight the Floppy Drive
A parameter. Press
appropriate value.
Possible settings for the Floppy Drive parameters:
[ None
[360 KB, 5.25-inch]
[1.2 MB, 5.25-inch]
[720 KB, 3.5-inch]
[1.44 MB, 3.5-inch]
[2.88 MB, 3.5-inch]
Follow the same procedure to configure floppy drive B. Choose
if you do not have a second floppy drive.
2.4.2

IDE Drives

There are four IDE drive option items under the Disk Drives menu.
Select the IDE Primary Channel Master item (or the IDE Secondary
Channel Master) if you want to configure an IDE device set as
master. Select the IDE Primary Channel Slave item (or the IDE
Secondary Channel Slave) if you want to configure an IDE device set
as slave.
To configure an IDE device designated as master:
1. Select the IDE Primary Channel Master (or the IDE Secondary
Channel Master) option to display its menu.
2. Highlight the parameter Type, then press
IDE drive types with their respective values for cylinder, head,
sector, and size.
2-12
or key to view the options, then select the
]
None
or to display the
