Acer M19A System User Manual page 56

From the Disk Drives screen, select the IDE Primary Channel Master,
IDE Primary Channel Slave, the IDE Secondary Channel Master, or
IDE Secondary Channel Slave items to display their respective
menus.
Selecting the IDE Primary Channel Master item displays the following
menu.
IDE Primary Channel Master
Type .................................. [Auto]
Cylinder .......................... [
Head .............................. [
Sector ............................ [
Size .............................. [
Hard Disk Block Mode ................. [Auto]
Advanced PIO Mode .................... [Auto]
Hard Disk Size > 504MB ............... [Auto]
Hard Disk 32 Bit Access .............. [Enabled]
CD-ROM Drive DMA Mode ................ [Auto]
= Move Highlight Bar,
The parameters for the IDE Primary Channel Slave, the IDE
Secondary Channel Master, and IDE Secondary Channel Slave
menus are the same as in the above screen.
BIOS Utility
Page 1/1
]
]
]
] MB
= Change Setting, F1 = Help
2-11
