Alto-Shaam 767-SK Installation, Operation And Maintenance Manual

Cook, hold, smoke oven simple control
Hide thumbs Also See for 767-SK:
Table of Contents

Advertisement

Quick Links

See also: Installation Operation & Maintenance , Installation, Operation & Maintenance Manual
1767-SK
1000-SK-I
shown with optional
burgundy exterior
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 • 800.558.8744
.
.
.
p r i n t e d i n u
s
a
Co ok , H ol d, S mok e O v e n
767-SK
1000-SK/II
/
USA
CANADA
www.alto-shaam.com
S i m p l e C o n t r o l
Models:
767-SK
1767-SK
1000-SK-I
1000-SK/II
• InstallatIon
• operatIon
• MaIntenance
FAX: 262.251.7067 • 800.329.8744
.
.
.
U
S
A
ONLY
M N - 2 9 7 6 0 • 1 2 / 1 1
