PCM-9570/S
®
Socket 370 Celeron™/Pentium
III
SBC with LCD, Ethernet and SCSI
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCM-9570/S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PCM-9570/S

Summary of Contents for Advantech PCM-9570/S

  • Page 1 PCM-9570/S ® Socket 370 Celeron™/Pentium SBC with LCD, Ethernet and SCSI User's Manual...

  • Page 2: Copyright Notice

    Copyright notice This document is copyrighted, 2000. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 3 Windbond is a trademark of Winbond Electronics Corp. All other product names or trademarks are properties of their respec- tive owners. For more information on this and other Advantech products please visit our websites at: http://www.advantech.com http://www.advantech.com/epc For technical support and service for please visit our support website at: http://support.advantech.com...

  • Page 4: Packing List

    Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCM-9570/S all-in-one single board computer • 1 CD disc with utility and drivers • 1 Startup Manual If any of these items are missing or damaged, contact your distributor or sales representative immediately.

  • Page 5: Table Of Contents

    Contents Chapter 1 General Information ....... 1 Introduction ................2 Highly integrated Socket 370 SBC ........2 Features ................3 Specifications ..............3 Standard SBC functions ............3 PCI SVGA/flat panel interface ..........4 PCI bus Ethernet interface ...........5 Ultra2 SCSI (PCM-9570S only) ..........5 Solid state disk ..............5 PanelLink (optional) ............5 Mechanical and environmental ..........5 Board layout and dimensions ..........6...
  • Page 6 Floppy drive connector (CN9) ........17 2.9.1 Connecting the floppy drive........18 2.10 Parallel port connector (CN12) ........18 2.11 Keyboard and PS/2 mouse connector (CN5) ....19 2.12 Front panel connector (CN18) ........19 2.12.1 Speaker ..............19 2.12.2 LED interface ............19 2.12.3 Watchdog output .............19 2.12.4 Reset switch ............20 2.13 Power connectors (FAN1, CN14, CN6) ......20 2.13.1 Peripheral power connector, -5 V, -12 V (CN14) ...20...
  • Page 7 Chapter 3 Software Configuration ....31 Introduction ..............32 Ethernet software configuration ........33 Chapter 4 Award BIOS Setup ......35 System test and initialization .......... 36 4.1.1 System configuration verification ......36 Award BIOS setup ............37 4.2.1 Entering setup ............37 4.2.2 Standard CMOS setup ..........38 4.2.3 BIOS features setup ..........39 4.2.4 Chipset features setup ..........40 4.2.5 Power management setup .........41...
  • Page 8 Chapter 6 SCSI Setup and Configurations .. 59 Introduction ..............60 Before you begin ...............61 Basic rules for SCSI host adapter and device installation ................61 Configuring the SCSI adapter ........62 SCSI terminators .............63 SDMS drivers ..............64 Utility user's guide and installation instructions ..65 Driver and utility installation .........67 Chapter 7 PCI Bus Ethernet Interface ..
  • Page 9 IDE hard drive connector (CN11) ........92 Parallel port connector (CN12) ........93 C.10 Backlight connector (CN13) ..........94 C.11 Peripheral power connector (CN14) ......94 C.12 CRT display connector (CN15) ........95 C.13 24-bit LCD display connector (CN16) ......96 C.14 Ext. LCD display connector (CN17) ....... 97 C.15 LCD signal mapping ............
  • Page 10 Tables Table 2-1: Jumpers ................8 Table 2-2: Connectors ................. 9 Table 2-3: CMOS clear (J1) ............... 15 Table 2-4: Buzzer enable/disable (J9) ..........15 Table 2-5: ATW power on function select (J11) ......... 22 Table 2-6: COM2 RS-232/422/485 setting (J10) ........ 23 Table 2-7: Serial port default settings ..........
  • Page 11 Table C-20: CompactFlash card connector (CN21) ......102 Table C-21: PanelLink connector (CN22) ........103 Table C-22: Fan power connector (FAN1) ........104 Table D-1: System I/O ports ............106 Table D-2: 1st MB memory map ............107 Table D-3: DMA channel assignments ..........107 Table D-4: IRQ mapping chart ............
  • Page 12 Figures Figure 1-1: PCM-9570/S dimensions ........... 6 Figure 2-1: Locating jumpers ............. 10 Figure 2-2: Locating connectors (component side) ......11 Figure 2-3: Locating connectors (solder side) ........12 Figure 2-4: Wiring for ATX power switch function ......21 Figure 4-1: Setup program initial screen ..........37 Figure 4-2: CMOS setup screen ............

  • Page 13: Chapter 1 General Information

    General Information This chapter gives background information on the PCM-9570/S. Sections include: • Introduction • Features • Specifications • Board layout and dimensions...

  • Page 14: Introduction

    5.25" floppy drive. Major on-board devices adopt PCI technology to achieve outstanding computing performance when used ® ® with Intel Celeron /Pentium III processors, making the PCM-9570/S the world's smallest and most powerful all-in-one Socket 370 board. PCM-9570/S User's Manual...

  • Page 15: Features

    1.2 Features • Ultra2 SCSI interface: Supports up to 80 MB/sec transfer rates (PCM-9570S only) • 3D VGA/LCD interface: Supports a 2x AGP interface, 3D 64-bit engine, as well as a 2.5 MB embedded Trident 9525 DVD chip • Display resolution: Up to 1024 x 768 @ 64 K colors, for both LCD and CRT displays •...

  • Page 16: Pci Svga/Flat Panel Interface

    • Interface: 2x AGP, Accelerator Graphics Ports 1.0 compliant • Display mode: LCD panel supports up to 800 x 600 @ 24 bpp, 1024 x 768 @ 24 bpp. CRT displays support up to 800 x 600 @ 24 bpp, 1024 x 768 @ 24 PCM-9570/S User's Manual...

  • Page 17: Pci Bus Ethernet Interface

    PCI bus Ethernet interface • Chipset: Realtek RTL8139 PCI-bus Ethernet controller • Ethernet interface: PCI 100/10 Mbps, IEEE 802.3U compatible • Remote boot ROM: For diskless system Ultra2 SCSI (PCM-9570S only) • Chipset: SYM 53C895 chips • Performance: Ultra2 SCSI interface, up to 80 MB/sec transfer rates Solid state disk •...

  • Page 18: Board Layout And Dimensions

    1.4 Board layout and dimensions Figure 1-1: PCM-9570/S dimensions PCM-9570/S User's Manual...

  • Page 19: Chapter 2 Installation

    Installation This chapter tells how to set up the PCM-9570/S hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 20: Jumpers

    CMOS clear Watchdog timer action SCSI terminator power enable/disable ATX power switch button COM port RI pin setting PanelLink control Buzzer enable/disable COM2 RS-232/422/485 setting ATX power on function select LAN controller power select Panel type select PCM-9570/S User's Manual...

  • Page 21: Connectors

    2.2 Connectors On-board connectors link the PCM-9570/S to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors: Table 2-2: Connectors Label Function Ethernet 100/10Base-T connector ATX feature connector SCSI connector Keyboard and PS/2 mouse connector...

  • Page 22: Locating Jumpers

    2.3 Locating jumpers Figure 2-1: Locating jumpers PCM-9570/S User's Manual...

  • Page 23: Locating Connectors

    2.4 Locating connectors 2.4.1 Component side Figure 2-2: Locating connectors (component side) Chapter 2 Installation...

  • Page 24: Solder Side

    2.4.2 Solder side Figure 2-3: Locating connectors (solder side) PCM-9570/S User's Manual...

  • Page 25: Setting Jumpers

    2.5 Setting jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 26: Cpu Installation And Upgrading

    3. Press the lever down. The plate will slide forward. You will feel some resistance as the pressure starts to secure the CPU in the socket. This is normal and will not damage the CPU. PCM-9570/S User's Manual...

  • Page 27: Cmos Clear (J1)

    When the CPU is installed, the lever should snap into place at the side of the socket. Note: To remove a CPU, pull the lever out to the side a little and raise it as far as it will go. Lift out the CPU chip. 2.6.2 CMOS clear (J1) Warning: To avoid damaging the computer, always turn off the...

  • Page 28: Installing Dram (Sodimms)

    You can attach one or two Enhanced Integrated Device Electronics hard disk drives to the PCM-9570/S’s internal controller. The PCM-9570/S’s IDE controller uses a PCI local-bus interface. This advanced IDE controller supports faster data transfer, PIO mode 3, mode 4. PCM-9570/S User's Manual...

  • Page 29: Connecting The Hard Drive

    2.8.1 Connecting the hard drive Connecting drives is done in a daisy-chain fashion and requires one of two cables (not included in this packing), depending on the drive size. 1.8" and 2.5" drives need a 1 x 44-pin to 2 x 44-pin flat-cable connector. 3.5"...

  • Page 30: Connecting The Floppy Drive

    The parallel port is designated as LPT1 and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup. The parallel port interrupt channel is designated to be IRQ7. You can select ECP/EPP DMA channel via BIOS setup. PCM-9570/S User's Manual...

  • Page 31: Keyboard And Ps/2 Mouse Connector (Cn5)

    2.11 Keyboard and PS/2 mouse connector (CN5) The PCM-9570/S board provides a keyboard connector that supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. The standard PC/AT BIOS will report an error or fail during power-on self-test (POST) after a reset if the keyboard is not present.

  • Page 32: Reset Switch

    Supplies main power to the PCM-9570/S (+5 V) and devices that require +12 V. 2.13.3 Fan power supply connector (FAN1) Provides power supply to optional CPU cooling fan. Only present when +5 V and +12 V power is supplied to the board. PCM-9570/S User's Manual...

  • Page 33: Atx Power Control Connector (Cn2, J4)

    2.14 ATX power control connector (CN2, J4) 2.14.1 ATX feature connector (CN2) and power button (J4) The PCM-9570/S can support an advanced power button if an ATX power supply is used. To enable the power button: 1. Take the specially designed optional ATX-to-PS/2 power cable (part no.

  • Page 34: Atx Power On Function Select (J11)

    You can find the pin assignments for the COM port connector in Appendix C. 2.17.1 COM2 RS-232/422/485 setting (J10) COM2 can be configured to operate in RS-232, RS-422, or RS-485 mode. This is done via J10. PCM-9570/S User's Manual...

  • Page 35: Com3/Com4 Ri Pin Setting (J6)

    Table 2-6: COM2 RS-232/422/485 setting (J10) * RS-232 RS-422 RS-485 * default setting The IRQ and the address range for COM1, 2, 3, 4 are fixed. However, if you wish to disable the port or change these parameters later you can do this in the system BIOS setup.

  • Page 36: Table 2-8: Com1 Ri Pin Setting (J6)

    Table 2-8: COM1 RI pin setting (J6) +5 V +12 V * RI (default setting) Table 2-9: COM2 RI pin setting (J6) +5 V +12 V * RI (default setting) PCM-9570/S User's Manual...

  • Page 37: Table 2-10: Com3 Ri Pin Setting (J6)

    Table 2-10: COM3 RI pin setting (J6) +5 V +12 V * RI (default setting) Table 2-11: COM4 RI pin setting (J6) +5 V +12 V * RI (default setting) Chapter 2 Installation...

  • Page 38: Vga Interface Connections

    2.18.3 Ext. flat panel display connector (CN17) CN17 consists of a 20-pin header, which is Hirose’s product no. DF13A-20DP-1.25V. The PCM-9570/S supports a 36-bit LCD panel with connections to both CN16 and CN17. For details of pin assignments, refer to Appendix C. PCM-9570/S User's Manual...

  • Page 39: Panel Type Select (Sw1)

    2.18.4 Panel type select (SW1) SW1 is a 6-pin dip switch for selecting the type of panel and display mode. Table 2-12: Panel type select (SW1) Panel type Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 TFT 640 x 480 18-bit TFT 800 x 600 18-bit TFT 1024 x 768 24-bit...

  • Page 40: Ethernet Configuration

    2.19.3 LAN controller power select (J12) Table 2-13: LAN controller power select (J12) +5 V* Standby 5 V *default setting Note: PCM-9570/S supports wake-on LAN. For wake-on LAN, J12 has to select standby 5 V (2-3) position. PCM-9570/S User's Manual...

  • Page 41: Watchdog Timer Configuration

    2.20 Watchdog timer configuration An on-board watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup involves one jumper and running the control software (refer to Appendix A).

  • Page 42: Scsi Connectors (Cn4)

    The PCM-9570/S optional PanelLink function uses Silicon Image Inc.’s Universal Transmitter SiI150 chip. It can support 25 ~ 112 MHz clock speeds, for VGA through to SXGA LCD panels. The 20-pin PanelLink transmitter connector is Hirose Electric Co., Ltd.’s product no. DF13A-20DP-1.25V. PCM-9570/S User's Manual...

  • Page 43: Chapter 3 Software Configuration

    Software Configuration This chapter details the software configuration information. It shows you how to configure the card to match your application requirements. AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Ethernet interface configuration...

  • Page 44: Introduction

    Boot ROM image. The display can be configured via CMOS settings. This method minimizes the number of chips and difficultly of configuration. To set different types of LCD panels please choose “panel type” from the “Intergrated Peripherals” menu in CMOS setup. PCM-9570/S User's Manual...

  • Page 45: Ethernet Software Configuration

    3.2 Ethernet software configuration The PCM-9570/S’s on-board Ethernet interface supports all major network operating systems. To configure the medium type, to view the current configuration, or to run diagnostics, do the following: 1. Power the PCM-9570/S on. Make sure that the RSET8139.EXE file is located in the working drive.
  • Page 46 PCM-9570/S User's Manual...

  • Page 47: Chapter 4 Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 48: System Test And Initialization

    The PCM-9570/S’s CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit. PCM-9570/S User's Manual...

  • Page 49: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 50: Standard Cmos Setup

    This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is highlighted, on-line help information is displayed in the left bottom of the Menu screen. Figure 4-2: CMOS setup screen PCM-9570/S User's Manual...

  • Page 51: Bios Features Setup

    4.2.3 BIOS features setup By choosing the BIOS FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9570/S. Figure 4-3: BIOS features setup Chapter 4 Award BIOS Setup...

  • Page 52: Chipset Features Setup

    4.2.4 Chipset features setup By choosing the CHIPSET FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9570/S. Figure 4-4: Chipset features setup PCM-9570/S User's Manual...

  • Page 53: Power Management Setup

    4.2.5 Power management setup By choosing the POWER MANAGEMENT SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9570/S. Figure 4-5: Power management setup Chapter 4 Award BIOS Setup...

  • Page 54: Pnp/Pci Configuration

    4.2.6 PnP/PCI configuration By choosing the PnP/PCI CONFIGURATION option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9570/S. Figure 4-6: PnP/PCI configuration PCM-9570/S User's Manual...

  • Page 55: Integrated Peripherals

    4.2.7 Integrated peripherals By choosing the INTEGRATED PERIPHERALS option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9570/S. The PANEL TYPE by default supports an 18-bit 640 x 480 TFT LCD panel display.

  • Page 56: Load Bios Defaults

    LOAD BIOS DEFAULTS loads the default system values directly from ROM. If the stored record created by the Setup program becomes corrupted (and therefore unusable), these defaults will load automatically when you turn the PCM-9570/S on. Figure 4-8: Load BIOS defaults PCM-9570/S User's Manual...

  • Page 57: Change Password

    4.2.9 Change password To change the password, choose the PASSWORD SETTING option form the Setup main menu and press <Enter>. 1. If the CMOS is bad or this option has never been used, a default password is stored in the ROM. The screen will display the following messages: Enter Password: Press <Enter>.

  • Page 58: Auto Detect Hard Disk

    This record is required for the system to operate. 4.2.12 Exit without saving Selecting this option and pressing <Enter> lets you exit the Setup program without recording any new values or changing old ones. PCM-9570/S User's Manual...

  • Page 59: Chapter 5 Pci Svga Setup

    PCI SVGA Setup • Introduction • Installation of SVGA driver for - Windows 95 - Windows 98 - Windows NT...

  • Page 60: Introduction

    The BIOS setup can be used to configure the display. In BIOS, select “Integrated Peripherals”, then “Boot-up display type.” You can then choose one of the following modes: “CRT only”, “Panel only”, or “Simultaneous.” PCM-9570/S User's Manual...

  • Page 61: Dual/Simultaneous Display

    5.1.4 Dual/simultaneous display The PCM-9570/S uses a Trident Cyber 9525DVD LCD controller that is capable of providing multiple views and simultaneous display with mixed video and graphics on a flat panel and CRT. To set up dual display under Windows 98, follow these steps: 1.

  • Page 62: Installation Of Svga Driver

    Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Note: <Enter> means pressing the “Enter” key on the keyboard. PCM-9570/S User's Manual...

  • Page 63: Installation For Windows 95/98

    5.2.1 Installation for Windows 95/98 a. Select "Start" , "Settings" , "Control Panel" , "Display" , "Settings". b. Press "Advanced Properties". a. Choose the "Adapter" label. b. Press the "Change..." button. a. Select the second item. a. Press the "Have Disk"...
  • Page 64 For Windows 98, select "Trident Cyber 9525DVD PCI/AGP (W98.23)". For Windows 95, select "Trident Cyber 9525 DVD PCI/AGP(95mV)". Click the "OK" button. a. Click the "Next" button. "Trident Cyber9525DVD PCI/AGP" appears in the Adapter. Click the "Apply" button. PCM-9570/S User's Manual...
  • Page 65 P re s s "Ye s " to re b o o t. a . R e p e a t S te p 1 o n th e p re v io u s p a g e o f th is m a n u a l. The "Trident"...

  • Page 66: Installation For Windows Nt

    5.2.2 Installation for Windows NT a. Select "Start", "Settings", "Control Panel". b. Double click the "Display" icon. a. Choose the "Settings" label. b. Press the "Display Type" button. a. Press the "Change..." button. a. Click the "Have Disk..." button. PCM-9570/S User's Manual...
  • Page 67 a . In s e rt th e d is c into th e C D -R O M d riv e . Type "D:\Biscuit\9570\ VGA.100\Winnt" in the blank. c . P re s s th e "O K " b u tto n . D:\Biscuit\9570\VGA.100\Winnt a .
  • Page 68 Repeat Step 1 in this manual, to select the "Settings" label. b. Adjust resolution and color. c. Click "Test" to see the result. d. Click "OK" to save the setting. E N D PCM-9570/S User's Manual...

  • Page 69: Further Information

    5.3 Further information For further information about the PCI/SVGA installation in your PCM-9570/S, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Trident website: www.trid.com Advantech websites: www.advantech.com www.advantech.com.tw Chapter 5 PCI SVGA Setup...
  • Page 70 PCM-9570/S User's Manual...

  • Page 71: Chapter 6 Scsi Setup And Configurations

    SCSI Setup and Configurations The PCM-9570/S features an on-board SCSI interface. This chapter provides basic SCSI concepts and instructions for installing the software drivers with the SCSI driver disks/CD included in your package.

  • Page 72: Introduction

    SE mode, one or more Ultra/Ultra Wide peripherals will be attached to the Ultra2 SCSI segment and will cause the Ultra2 SCSI segment to run at speeds up to 40 MBytes/sec instead of 80 MBytes/sec. PCM-9570/S User's Manual...

  • Page 73: Before You Begin

    6.2 Before you begin SDMS software requires an IBM PC/AT or compatible computer with an 80486 or higher microprocessor. An understanding of basic operating system commands is assumed. In addition, users should have a general knowledge of the SCSI standard. Before using the SDMS software, you should configure the Symbios SCSI controller into your system, taking into account the configuration of other host adapters and system resources (see Section...

  • Page 74: Configuring The Scsi Adapter

    The SCSI Select screen will come up. Instructions on how to move the cursor and select options are listed on the bottom of the program windows. You can select either Configure/View Host Adapter Settings or SCSI CD Utilities. PCM-9570/S User's Manual...

  • Page 75: Scsi Terminators

    6.5 SCSI terminators To ensure reliable communication, the SCSI bus must be properly terminated. Termination is controlled by a set of electrical resistors, called terminators. Terminators must be placed (or enabled) at the two extreme ends of the SCSI bus. All devices that lie between the ends must have their terminators removed (or disabled).

  • Page 76: Sdms Drivers

    F6 key. Windows NT setup will allow a SCSI driver to be added before the second disk is requested. Add the appropriate driver from a prepared floppy disk. Follow the rest of the instructions to finish the installation. PCM-9570/S User's Manual...

  • Page 77: Utility User's Guide And Installation Instructions

    6.7 Utility user's guide and installation instructions The utility user's guide and installation instructions are provided in HTM format in the driver CD-ROM. Users can browse the instructions by using a java-aware browser such as Microsoft Internet Explorer v3.0 or later, or Netscape 2.0 or later. To utilize the full functionality of the CD, Microsoft Internet Explorer is recommended.
  • Page 78 • NETWDMI.HTM: NetWare DMI 1.0 SDMS component instrumentation • NWPA.HTM: Installation guide for the Symbios NetWare NWPA drivers SYM8XXNW.HAM and SYMHINW.HAM For OS/2: • OS2.HTM: Driver installation for OS/2 For Solaris: • SOLARIS.HTM: Installation guide for the Solaris device driver PCM-9570/S User's Manual...

  • Page 79: Driver And Utility Installation

    Other tools and utilities: • BIOS.HTM: User's guide for SCSI BIOS configuration utility • FLASH.HTM: SDMS host adapter Flash utility • FORMAT.HTM: SDMS SCSI low-level format utility • RAWRITE.HTM: Description of RaWrite 1.3 • UTILMAIN.HTM: SDMS utilities user's guides 6.8 Driver and utility installation The device drivers and utilities of the SCSI interface are provided in the \Biscuit\9570\SCSI.100\ directories of the driver CD-ROM.
  • Page 80 PCM-9570/S User's Manual...

  • Page 81: Chapter 7 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet driver for Windows 95/98/NT • Further information...

  • Page 82: Introduction

    Windows 3.1 environment, you should first check your server system model. For example, MS-NT, IBM-LAN server, and so on. Then choose the correct driver to install in your panel PC. The installation procedures for various servers can be found on CD-ROM, the correct path being: D:\Biscuit\9570\Lan.100\8139B\wfw311 PCM-9570/S User's Manual...

  • Page 83: Installation For Windows 95/98

    7.2.2 Installation for Windows 95/98 a. Select "Start", "Settings", "Control Panel". b. Double click "Network". a. Click "Add" and prepare to install network functions. a. Select the "Adapter" item to add the Ethernet card. a. Click "Have Disk" to install the driver. Chapter 7 PCI Bus Ethernet Interface...
  • Page 84 Click "OK" to reboot. E N D Note 1: The correct file path for Windows 98 is: Biscuit\9570\Lan.100\8139b\Win98 Note 2: In the file path, choose "8139a" or "8139b" according to the type of Ethernet chip used. PCM-9570/S User's Manual...

  • Page 85: Installation For Windows Nt

    7.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel". b. Double click "Network". a. Choose the "Adapters" label. b. Click the "Add" button. a. Press "Have Disk". a. Type "D:". b. Press "OK". Chapter 7 PCI Bus Ethernet Interface...
  • Page 86 Fill in "D:\Biscuit\ 9570\Lan.100\ 8139b\Winnt\". c. Click "OK". D:\Biscuit\9570\Lan.100\8139b\Winnt\ a. Choose the "Realtek" item. b. Click "OK". a. Make sure the configurations of relevant items are set correctly. b. Click "OK" to reboot. E N D PCM-9570/S User's Manual...

  • Page 87: Further Information

    7.3 Further information Realtek website: www.realtek.com Advantech website: www.advantech.com www.advantech.com.tw Chapter 7 PCI Bus Ethernet Interface...
  • Page 88 PCM-9570/S User's Manual...

  • Page 89: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCM-9570/S is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial standalone, or unmanned, environments.

  • Page 90: Programming The Watchdog Timer

    After data entry, your program must refresh the watchdog timer by rewriting the I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). PCM-9570/S User's Manual...
  • Page 91 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data REM Start and restart the watchdog GOSUB 1000 REM Your application task #1 OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2 OUT &H443, data...
  • Page 92 PCM-9570/S User's Manual...

  • Page 93: Appendix B Installing Pc/104 Modules

    Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules.

  • Page 94: Installing Pc/104 Modules

    (Refer to the diagram on the following page.) 4. Mount the PC/104 module onto the CPU card by pressing the module firmly but carefully onto the mounting connectors. 5. Secure the PC/104 module onto the CPU card using the four mounting spacers and screws. PCM-9570/S User's Manual...

  • Page 95: Figure B-1: Pc/104 Module Mounting Diagram

    P C /1 0 4 M o u n tin g S u p p o rt M a le F e m a le P C /1 0 4 m o d u le P C M -9 5 70 /S Figure B-1: PC/104 module mounting diagram 8 .9 8 2 .5...

  • Page 96: Table B-1: Pc/104 Connectors (Cn10)

    SA10 IRQ7 — — IRQ6 — — IRQ5 — — IRQ4 — — IRQ3 — — DACK2* — — — — BALE — — +5 V — — — — — — — — * active low PCM-9570/S User's Manual...

  • Page 97: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Ethernet 10/100Base-T connector • ATX power feature connector • SCSI connector • Keyboard and PS/2 mouse connector • Main power connector • IR connector • Floppy drive connector •...

  • Page 98: Ethernet 10/100Base-T Connector (Cn1)

    C.1 Ethernet 10/100Base-T connector (CN1) Table C-1: Ethernet 10Base-T connector (CN1) Signal CRS LED RCV+ RCV- BNC LED XMT+ XMT- C.2 ATX power feature connector (CN2) Table C-2: ATX power feature connector (CN2) Signal 5 V SB (stand-by voltage) VPSON PCM-9570/S User's Manual...

  • Page 99: Scsi Connector (Cn4)

    C.3 SCSI Connector (CN4) ..36 35 Table C-3: SCSI connector (CN4) Function Function SD12+ SD12- SD13+ SD13- SD14+ SD14- SD15+ SD15- SDP1+ SDP1- SD0+ SD0- SD1+ SD1- SD2+ SD2- SD3+ SD3- SD4+ SD4- SD5+ SD5- SD6+ SD6- SD7+ SD7- SDP0+ SDP0-...

  • Page 100: Table C-3: Scsi Connector (Cn4) [Continued]

    Table C-3: SCSI connector (CN4) [continued] Function Function ATN+ ATN- BSY+ BSY- ACK+ ACK- RST+ RST- MSG+ MSG- SEL+ SEL- REQ+ REQ- SD8+ SD8- SD9+ SD9- SD10+ SD10- SD11+ SD11- PCM-9570/S User's Manual...

  • Page 101: Keyboard And Ps/2 Mouse Connector (Cn5)

    C.4 Keyboard and PS/2 mouse connector (CN5) Table C-4: Keyboard and mouse connector (CN5) Signal MS VCC MS DATA MS CLOCK KB VCC KB DATA KB CLOCK Appendix C Pin Assignments...

  • Page 102: Main Power Connector (Cn6)

    C.5 Main power connector (CN6) Table C-5: Main power connector (CN6) Signal +12 V +5 V C.6 IR connector (CN8) Table C-6: IR connector (CN8) Signal IR IN IR OUT PCM-9570/S User's Manual...

  • Page 103: Floppy Drive Connector (Cn9)

    C.7 Floppy drive connector (CN9) Table C-7: Floppy drive connector (CN9) Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active...

  • Page 104: Ide Hard Drive Connector (Cn11)

    DATA 14 DATA 0 DATA 15 SIGNAL GND HDD 0 IO WRITE IO READ HD READY HDACK 0* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCM-9570/S User's Manual...

  • Page 105: Parallel Port Connector (Cn12)

    C.9 Parallel port connector (CN12) Table C-9: Parallel port connector (CN12) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active Appendix C Pin Assignments...

  • Page 106: Backlight Connector (Cn13)

    C.10 Backlight connector (CN13) Table C-10: Backlight connector (CN13) Signal +12 V Enable Reserved N.C. C.11 Peripheral power connector (CN14) Table C-11: Peripheral power connector (CN14) Function -5 V -12 V PCM-9570/S User's Manual...

  • Page 107: Crt Display Connector (Cn15)

    C.12 CRT display connector (CN15) Table C-12: displ ay c onnector (CN15) Signal Signal SIGNAL GND DDC POWER H-SYNC GREEN SIGNAL GND SIGNAL GND V-SYNC BLUE SIGNAL GND SIGNAL GND DDT_DAT CHASSIS GND Appendix C Pin Assignments...

  • Page 108: 24-Bit Lcd Display Connector (Cn16)

    PD1 (R6) PD0 (R7) SHIFT CLOCK DCLK (reserved) ENAVEE Note 1: The model number of the CN16 connector is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) Note 2: The signals shown in parentheses are for 24-bit TFT color bits. PCM-9570/S User's Manual...

  • Page 109: Ext. Lcd Display Connector (Cn17)

    C.14 Ext. LCD display connector (CN17) 20 18 ..4 2 19 17 ..3 1 Table C-14: Ext. LCD display connector (CN17) Signal Signal PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35 Note 1: The model number of the CN17 connector is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.).

  • Page 110: Lcd Signal Mapping

    Table C-15: LCD signal mapping Pin Name 16-bit DSTN 18-bit TFT 24-bit TFT 36-bit TFT PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35 PCM-9570/S User's Manual...

  • Page 111: Front Panel Connector (Cn18)

    C.16 Front panel connector (CN18) Table C-16: Front panel connector (CN18) Signal HDD LED- (HARD DISK ACTIVE) HDD LED+ (V SPEAKER+ SPEAKER- (GND) WATCHDOG OUTPUT* RESET SWITCH- (GND) RESET SWITCH+ * low active C.17 USB connectors (CN19) Table C-17: USB connectors (CN19) Signal Signal +5 V...

  • Page 112: Com Port Connector (Cn20)

    DTR2 DCD3 DSR3 RTS3 CTS3 DTR3 DCD4 DSR4 RTS4 CTS4 DTR4 Note: The cable of serial port (CN20) comes with four DSUB-9 male connectors. The pin assignments of each DSUB-9 connector are listed below for your reference: PCM-9570/S User's Manual...

  • Page 113: Table C-19: Com2 Port For Rs-232, Rs-422 And Rs-485 (Cn20)

    Table C-19: COM2 port for RS-232, RS-422 and RS-485 (CN20) Signal RS-232 RS-422 RS-485 DCD2 DATA- RxD2 DATA+ TxD2 DTR2 DSR2 DSR2 (not used) DSR2 (not used) RTS2 RTS2 (not used) DSR2 (not used) CTS2 CTS2 (not used) DSR2 (not used) RI2 (not used) DSR2 (not used) Appendix C Pin Assignments...

  • Page 114: Compactflash Card Connector (Cn21)

    C.19 CompactFlash card connector (CN21) Table C-20: CompactFlash card connector (CN21) Signal Signal -CS0 -ATA SEL -IOCS16 -CD2 -CD1 -CS1 -VS1 -IORD -IOWR INTRQ -CSEL -VS2 -RESER IORDY -INPACK -REG -DASP -PDIAG PCM-9570/S User's Manual...

  • Page 115: Panellink Connector (Cn22)

    C.20 PanelLink connector (CN22) Table C-21: PanelLink connector (CN22) Signal Signal TX1+ TX1- TX1 GND TXC GND TXC+ TXC- DDC GND VDD 5 V VDD 5 V VDD 5 V TX2+ TX2- TX2 GND TX0 GND TX0+ TX0- DDC/SDA (reserved) DDC/SCL (reserved) Appendix C Pin Assignments...

  • Page 116: Fan Power Connector (Fan1)

    C.21 Fan power connector (FAN1) Table C-22: Fan power connector (FAN1) Signal +12 V PCM-9570/S User's Manual...

  • Page 117: Appendix D System Assignments

    System Assignments • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments...

  • Page 118: System I/O Ports

    3A0-3AF Bisynchronous 1 3B0-3BF Monochrome display and printer adapter(LPT1) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3E8-3EF Serial port 3 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 Watchdog timer * MPU-401 select from 300 ~ 330H (2 bytes) PCM-9570/S User's Manual...

  • Page 119: 1St Mb Memory Map

    D.2 1st MB memory map Table D-2: 1st MB memory map Addr. range (Hex) Device F000h - FFFFh System ROM E000h - EFFFh Unused D000h - DFFFh SCSI ROM *CC00h - CFFFh Ethernet ROM C000h - CBFFh Expansion ROM B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused...

  • Page 120: Irq Mapping Chart

    PS/2 mouse INT from co-processor Primary IDE Secondary IDE (reserved for CompactFlash) * Ethernet interface IRQ select: 9, 11, 12, 15 * PnP USB IRQ select: 9, 11, 12, 15 * SCSI IRQ select: 9, 11, 12, 15 PCM-9570/S User's Manual...

  • Page 121: Appendix E Optional Extras

    Optional Extras...

  • Page 122: Pcm-10586-4 Cable Kit For Pcm-9570/S

    " 5 " 8 , n i , n i o l f " 5 o l f " 5 e l l ) l i , n i PCM-9570/S User's Manual...

  • Page 123: Usb Cable

    E.2 USB cable Optional USB cable, part no: 1703100260 E.3 SCSI cables Optional Ultra Wide SCSI cable, 60 cm, part no: 1701680600 (HPP68M/HPP68M/HPP68M) Optional Ultra2 Wide SCSI cable, 120 cm, part no. 1701060000 E.4 24-bit LCD cable adapter This converts from the Hirose “DF20A” type connector transfer to a 20 x 2-pin header.
  • Page 124 PCM-9570/S User's Manual...

  • Page 125: Appendix F Mechanical Drawings

    Mechanical Drawings...

  • Page 126: Component Side

    F.1 Component side Figure F-1: PCM-9570/S mechanical drawing - component side PCM-9570/S User's Manual...

  • Page 127: F.2 Solder Side

    F.2 Solder side Figure F-2: PCM-9570/S mechanical drawing - solder side Appendix F Mechanical Drawings...
  • Page 128 PCM-9570/S User's Manual...

This manual is also suitable for:

Pcm-9570

Table of Contents
