mirroring port, and enable ingress monitoring:
TP-LINK(config)# mirror add 2,5-7,9 10 ingress 1
mirror remove mirrored
Description
The mirror remove mirrored command is used to remove mirrored ports from
a mirror group.
Syntax
mirror remove mirrored port-list group-num
Parameter
port-list —— List of mirrored port.
group-num —— Configure the mirror group number you want to configure.
Command Mode
Global Configuration Mode
Example
Remove the mirrored port 2 from mirror group 1:
TP-LINK(config)# mirror remove mirrored 2 1
mirror remove group
Description
The mirror remove group command is used to remove a mirror group.
Syntax
mirror remove group group-num
Parameter
group-num —— Configure the group number you want to remove
Command Mode
Global Configuration Mode
Example
Remove the mirror group 1:
TP-LINK(config)# mirror remove group 1
132
