Muratec F-116 Field Engineering Manual page 5

4.2 Troubleshooting............................................................ 4-26
4.2.1 Procedure of Checking the Symptoms ........................ 4-26
4.2.2 The cause and solution of Bad image ........................ 4-27
4.2.3 The cause and solution of the bad discharge ............... 4-43
4.2.4 The cause and solution of the malfunction .................. 4-50
4.2.5 The cause and solutions of
4.2.6 Fax & Phone Problems .......................................... 4-62
4.2.7 Copy Problems ...................................................... 4-71
4.2.8 Scanning Problems ................................................ 4-75
chapter 5 System Diagram
5.1 Block Diagram ............................................................ 5-1
5.2 Connection Diagram...................................................... 5-2
chapter 6 Reference Information
6.1 Tool for Troubleshooting ................................................ 6-1
6.2 Acronyms and Abbreviations .......................................... 6-2
6.2.1 Acronyms ............................................................ 6-2
6.2.2 Service Parts ......................................................... 6-4
6.3 The Sample Pattern for the Test ....................................... 6-8
6.3.1 A4 ISO 19752 Standard Pattern ................................. 6-8
6.4 Selecting a location ...................................................... 6-9
bad environment of the software .............................. 4-59
Contents
