C Configuring a PXE Server

Prerequisites

The services listed below must be running, and they may be running on different servers:
1. Domain Name Service (DNS)
2. Active Directory DHCP
3. Remote Installation Services (RIS) on Microsoft Windows 2000 Server
This documentation covers RIS setup, and assumes that servers 1, 2, and 3 (above) are already set
up. The RIS PXE Server must be equipped with two or more hard drives. Remote Installation Services
and Windows 2000 Server cannot be installed on the same drive; nor will RIS work on a double partition
of Windows 2000 Server. You must first format the drive on which RIS is installed using NTFS.

Installing Remote Installation Services (RIS PXE Server)

1. From the Windows 2000 Server, log on to the domain using an account that has Administrator
privileges on the server.
2. From the Windows Control Panel, double-click on Add/Remove Programs.
3. Double-click Add/Remove Windows Components.
4. Select Remote Installation Services, then click Next. (Insert Windows 2000 Server CD into the
CD-ROM drive, if prompted.)
5. Restart the computer after the wizard has finished installing the service.
Authorizing Remote Installation Services (RIS PXE
Server)
If you have installed RIS on a server other than the server running DHCP, authorize PXE with DHCP
as follows:
1. Record the IP address of the RIS PXE Server.
2. Log on to the DHCP Server as administrator.
3. From the Control Panel, double-click Administrative Tools.
4. Double-click DHCP.
5. Right-click DHCP (just above the domain name) and select Manage Authorized Servers.
Prerequisites 35
