3.
Replace the screw (3).
4.
Replace the antenna, if you are using one.
Removing and Replacing the Side Access Panel and Metal
Side Cover
Removing the Side Access Panel and Metal Side Cover
WARNING!
power cord is disconnected from the electrical outlet.
To remove the access panel:
1.
Remove the secure compartment cover (1). For more information, see
Compartment Cover on page
2.
Remove the access panel screw in the secure USB compartment that secures the access panel
to the chassis (2).
3.
Slide the access panel about 6.35 mm (1/4 inch) toward the rear of the unit (3), and then lift the
access panel up and off the unit (4).
To remove the metal side cover:
10
Chapter 2 Hardware Changes
Before removing the side access panel, ensure that the thin client is turned off and the
8.
Removing the Secure USB
