Front Panel Components

Drive configuration may vary by model.
Table 1-1 Front Panel Components
1 Dual-State Power Button
2 5.25-inch Optical Drive (some models)
3 Sliding Drive Door Lock
4 Power On Light
NOTE: An optical drive is a DVD-ROM or DVD+R/RW drive.
The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with the computer
and it is displaying a diagnostic code. Refer to the Troubleshooting Guide on the Documentation and Diagnostics DVD
to interpret the code.
Some models have a bezel blank covering the 5.25-inch drive bay.
1
2 Chapter 1 Product Features
5 Hard Drive Activity Light
1 6 Optical Drive Activity Light
7 Sliding Drive Door
8 Optical Drive Eject Button
