The function of the ATM Receive LED is listed in Table 4-2.
LED Color
Yellow (Flashing)
Off
The function of the ATM Transmit LED is listed in Table 4-2.
LED Color
Green (Flashing)
Off
The function of the ATM Link LED is listed in Table 4-1.
LED Color
Green
Off
The function of the ATM Status LEDs is listed in Table 4-1.
LED Color
Green
Yellow
Red
Off
Table 4-4. ATM Receive LEDs
Activity
No Activity
Table 4-5. ATM Transmit LEDs
Activity
No Activity
Table 4-6. ATM Link LEDs
Link
No Link
Table 4-7. ATM Status LEDs
Port Enabled and OK
Standby
Port Enabled and Error
-
LANVIEW LEDs
State
State
Link
Status
4-3
