LANVIEW LEDs
The functions of the System Management Bus (SMB) and CPU LEDs are listed in
Table 4-1.
Green
Yellow
Yellow/Green
Red
Red (Flashing)
Off
The function of the FNB Receive LEDs is listed in Table 4-2.
Yellow (Flashing)
Off
The function of the FNB Transmit LEDs is listed in Table 4-2.
Green (Flashing)
Off
4-2
Table 4-1. SMB and CPU LEDs
LED Color State
Functional
Crippled
Booting
Reset
Failed
Power off
Table 4-2. FNB Receive LEDs
LED Color
Activity
No Activity
Table 4-3. FNB Transmit LEDs
LED Color
Activity
No Activity
Description
Fully operational
Not fully operational (i.e., one bad port)
Blinks yellow and green while booting
Normal power-up reset
Fatal error has occurred
Module powered off
State
State
