Cabletron Systems 9A656-04 Addendum page 4

Changing the values of the ILMI Configuration screen will cause all current
!
connections on the system to be dropped.
CAUTION
Figure 2 displays how the ILMI Configuration Menu screen may be used to change the
SmartSwitch 9500 from the default settings. The settings entered in
shown in Figure 3.
4095
VPI Range
Max. SVPC VPI 4
3
Max. SVCC VPI
0
9033126-01
Figure 2 Modified ILMI Configuration Menu Screen
VCI
0-31
VPI
0-4095
VCI
32-199
VPI
0-4095
0
31 200
Min SVCC VCI=200
Min CTM SVCC VCI=200
Figure 3 User-Defined ILMI Configuration
PVC Addendum to the 9A686-04/9A656-04 Configuration Guide
VCI 32-16K
VPI 5-4095
VCI 200-16k, VPI 4
VCI 200-16k, VPI 0-3
VCI Range
16k
Figure 2 result in the configuration
Reserved by the
ATM Forum
VCI Values 32-16K
VPI Values 5-4095
Available for Use by
PVCs Only
VCI Values 32-199
VPI Values 0-4095
Available for Use by
PVCs Only
VPI Values 1-4 Available for SVPCs,
VPI 4 is also available for PVCs
With VCI Range 32-16k
VCI Values 200-16k
VPI Values 0-3 Available
for SVCs and SVPCs. This is
the ONLY Available Range for SVCs
Page 4 of 43
