• All WG302 Access Points use the same SSID, Channel, authentication mode, if any, and
encryption in use.
• All Point-to-Point APs must have AP2's MAC address in its Remote AP MAC address
field.
Verify connectivity across the LANs.
3.
• A PC on any LAN segment should be able to connect to the Internet or share files and
printers with any other PCs or servers connected to any of the three LAN segments.
• Wireless stations will not be able to connect to the WG302 Access Points in the
illustration above. If you require wireless stations to access any lan segment, you can
additional WG302 Access Points configured in Wireless Access Point mode to any LAN
segment.
Note: You can extend this multi-point bridging by adding additional WG302s configured in
Point-to-Point mode for each additional LAN segment. Furthermore, you can extend the range of
the wireless network with NETGEAR wireless antenna accessories.

How to Configure Wireless Repeating

Wireless PC
Associated with AP1
192.168.0.1
LAN
Segment 1
Figure 5-5: Multi-Point bridging
Configure the Operating Mode of the WG302 Access Points.
1.
– WG302 (AP1) on LAN Segment 1 in Repeater mode with the Remote MAC Address of
AP2.
– Configure WG302 (AP2) in Repeater mode with MAC addresses of AP1 and AP3.
Advanced Configuration
Reference Manual for the WG302 802.11g ProSafe Wireless Access Point
AP1
E T H E R N E T
5 - 1 2 V D C
R E S E T
AP in Repeater Mode
with client associations
Router
December 2003
AP in Repeater Mode
with client associations
AP2
E T H E R N E T
5 - 1 2 V D C
R E S E T
AP in Repeater Mode
with client associations
Wireless PC
Associated with AP2
AP3
E T H E R N E T
5 - 1 2 V D C
R E S E T
Wireless PC
Associated with AP3
5-5
