NETGEAR WG302v1 - ProSafe 802.11g Wireless Access Point Product Specifications

• Help is there when you need it!
NETGEAR provides 24x7
technical support* in English,
with selected local language
support during office hours.
Security
Management
Aptitude
Usability
108
WG302
ProSafe™ Wireless Access Point 802.11g
Intelligent Networking Features for a Scalable, Secure Solution
NETGEAR's ProSafe 802.11g Wireless Access Point WG302 delivers the secure, reliable,
high performance wireless local area networks (WLANs) today's mobile workforce demands.
This powerful device provides the ultimate in industry standard access to corporate network
resources, email and the Internet. Fully compatible with IEEE 802.11g, (2.4 GHz), it can
also be set for dynamic 108 Mbps 802.11g. With its robust security measures, simplified
management and configuration, extended range, integrated IEEE 802.3af power over Ethernet
(PoE), and Wi-Fi certification, the WG302 brings standards-based enterprise-level functionality
at a mid-market price.
And, with AutoCell™ RF management technology, RF patterns are monitored and automatically
tuned to balance signals across the network, thus minimizing channel interference and optimizing
WLAN performance. AutoCell-enabled WG302s provide dynamic transmit power control,
automatic channel selection and load balancing.
Complies with industry security standards for wireless data encryption, and user authorization. 802.11i, WPA2 Enterprise
provides enhanced, interoperable wireless networking security. WPA and 802.1x support enables strong mutual authentication
to ensure that only legitimate clients associate with corporate RADIUS servers. Supports MAC address authentication with
256-user Access Control List (ACL) and VPN pass-through.
Integrated IEEE 802.3af-based Power over Ethernet (PoE) support eliminates extra cables and the need to locate near a
power outlet, as the access point is powered over the Ethernet cable. Supports Simple Network Management Protocol
(SNMP) MIB I, MIB II, and 802.11 MIB using SNMP-based network management software, such as HP OpenView
Supports all popular 802.1x port-based authentication protocols, including Extensible Authentication Protocol (EAP)
Transport Layer Security (TLS), Protected EAP (PEAP), and Tunneled TLS (TTLS). Console port facilitates local
configuration and monitoring. Users can remotely configure, update, and monitor multiple WG302's simultaneously
via FTP.
IEEE 802.11g wireless standard – with optional speeds up to 108 Mbps – takes care of business communications with great
dispatch and skill. Delivers functionality for point-to-point and point-to-multi-point bridging and repeater modes. AutoCell
provides dynamic transmit power control, automatic channel selection and load balancing when used in conjunction with the
ProSafe 802.11a/b/g Dual Band PC Card WAG511, to optimize WLAN performance.
Cost effective, simple to install and use. Plenum rated – appropriate for placement above drop-down ceilings and under
raised floors. Equipped with convenient Smart Wizard
antennas – obtain NETGEAR's antenna and flexible point placement accessories separately for expanded wireless capacity
and range. IEEE 802.11e-based Quality of Service (QoS) support is available via future firmware upgrade. Protected with
a NETGEAR 3-year warranty.
Everybody 's connecting. ™
NMS100 ProSafe Network Management System
Version 1.0 Software CD Instructions: run when inserted into your This CD should automatically
CD-ROM drive. If the CD does not start automatically, browse to the CD drive and click on NMSsetup.exe
All rights reserved ALL RIGHTS RESERVED © 2004 NETGEAR, INC. 240-10041-01 © 2004 NETGEAR, Inc.
240-10129-01
Notebook PC with
ProSafe VPN Client Software
and WG511T 108 Mbps
Wireless PC Card
browser-based interface. Fitted with two external, detachable 5 dBi
™
Desktop PC Notebook PC Desktop PC
with WAG311 with WAG511 with WG311T
108 Mbps Dual 108 Mbps 108 Mbps Wireless
Band Wireless Dual Band PCI Adapter
PCI Adapter Wireless PC Card
FVS338 ProSafe™
Desktop PC
VPN Firewall 50
with FA311
Ethernet card
ANT2405 5 dBi
Omni-directional Antenna
.
™
