3Com 3CRWPS10075-US - OfficeConnect Wireless 54Mbps 11g Print Server User Manual page 50

50 C 5: W -B
HAPTER EB
M
ASED ANAGEMENT
Logical Printers
Logical Printers (ports) can be used under Unix. For each Logical Printer,
the following fields are available:
Logical Printer Select the Logical Printer Port you wish to configure. (for example,
No L1)
Click the Get Data button to update the display with the current
data for the selected logical printer.
Physical Port Select the Printer Port which the Logical printer will use.
Pre-string The printer control string (in hex) to be sent to the printer before
(Hex) each print job. This string cannot exceed 15 characters.
Post-String The printer control string (in hex) to be sent to the printer after each
(Hex) print job. This string cannot exceed 15 characters.
Convert LF to If checked, LF (line feed) characters are changed to CR+LF (carriage
CR/LF return + line feed).
