PTP Printer Port Setup

1 The program will search for Printer Servers on the network, and a screen
like that shown in will be displayed.
a If desired, click Refresh.
b The name of the attached printer will be displayed if possible. If No
printer is displayed, check that the printer is properly connected and
powered on.
Figure 10 Print Port Setup (Peer-to-peer Printing)
If your Print Server is not listed:
Click Refresh.
■
Check that both the Print Server and the printer are properly
■
connected, and powered on.
Check that the Print Server has been configured. Use the Setup
■
Wizard on the CD-ROM.
If using TCP/IP, try installing the NetBEUI protocol, then try again. See
■
the earlier section for details.
2 Select the desired port on a Print Server, then click Next. A pop-up
message will inform you if the port has been created successfully.
If you see the following error message, either install Internet Explorer 4 or
later, or follow the procedure in
Chapter 7.
Windows Peer-to-peer Printing
"Windows Printing Problems"
31
