42 C 5: W
HAPTER EB
Connecting to the
Print Server
Configuration
Screens

Configure Server

-B M
ASED ANAGEMENT
Example (Unix):
arp -s 192.168.0.21
Example (Windows):
arp -s 192.168.0.21
The MAC address of the Print Server is shown on a sticker on the base of
the device.
1 Start your Web Browser.
2 In the Address box, enter http:// followed by the IP Address of the
Print Server.
for example, http://192.168.0.100
3 You will then be prompted for the password. If no password has been
set, just press Enter.
4 Use the menu bar to move from one screen to another. Remember to
save each screen before changing to a different screen.
The following configuration screens are available.
Figure 20 Configure Server Screen
00:0B:AC:E6:5A:81
00−0B−AC−E6−5A−81
