IP200
Portable Ice Maker
Owner's Manual
http://www.edgestar.com
This owner's manual provides
instructions on safe installation,
use, and maintenance.
Please read it carefully and
save it for reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP200 and is the answer not in the manual?

Questions and answers

Related Manuals for EdgeStar IP200

Summary of Contents for EdgeStar IP200

  • Page 1 IP200 Portable Ice Maker Owner’s Manual http://www.edgestar.com This owner’s manual provides instructions on safe installation, use, and maintenance. Please read it carefully and save it for reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS…………………………………………………1 PREPARING YOUR ICE MAKER FOR USE IMPORTANT SAFETY TIPS.……………………………………………………………….2 GETTING TO KNOW YOUR UNIT OPERATING PROCEDURES & MAINTENANCE UNPACKING YOUR ICE MAKER ..………….…………………………………………...4 CONNECTING YOUR ICE MAKER……………….……….……………………………..4 CLEANING AND MAINTAINING YOUR ICE MAKER….……………………………….4 USING YOUR ICE MAKER……………….……..………………………………………...5 TROUBLESHOOTING...……………………….……………………………………………5...

  • Page 3: Important Safety Instructions

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol: All safety messages will follow the safety alert symbol and the word “DANGER”...

  • Page 4: Preparing Your Ice Maker For Use

    Do not clean your ice maker with flammable fluids. The fumes can create a fire hazard or explosion. Do not tip over. If the ice maker is brought in from outside in wintertime, give it a few hours to warm up to room temperature before plugging it in.

  • Page 5: Getting To Know Your Unit

    GETTING TO KNOW YOUR UNIT 1. Cover: Features a transparent window for interior visibility. 2. Control Panel: Easy to use touch display setting with function indicators. A) Starts or stops the ice-making cycle. B) Selects the ice cube size. 3. Water drain cap: For draining water from water reservoir.

  • Page 6: Operating Procedures & Maintenance

    3. Find a location for your ice maker that is protected from direct sunlight and other sources of heat (i.e.: stove, furnace, radiator). Place the ice maker on a level surface. Maker sure that there is at least 5 inches of space between the back and sides of your ice maker and the wall.

  • Page 7: Using Your Ice Maker

    7. Change the water in the water reservoir periodically to ensure cleanliness and hygiene. 8. It is best to use tap water or bottled drinking water in the ice maker. Distilled water may not work. If you do use distilled water and the ice maker will not function, try adding a little salt into the water (a small amount of salt added to the water should be imperceptible).
  • Page 8 A pipe in the cooling system is blocked. Check if the ice is blocking the ice pusher, otherwise, consult service. Stop the ice maker, and restart it when the ice blocks melt. Select the small ice button. Change the water in the inner tank.

  • Page 9: Technical Specifications & Circuit Diagram

    TECHNICAL SPECIFICATIONS & CIRCUIT DIAGRAM TECHNICAL SPECIFICATIONS CIRCUIT DIAGRAM White Pressure Switch Black Yellow/Green Black Transformer Control Panel Select water Power Black Compressor Pump Yellow/Green Overload Protector Yellow White Black Mainboard Blue Synchronous Motor Valve Blue White Blue Purple Black Water-check Switch Ice Sensor...

  • Page 10: Parts Breakdown Diagram

    PARTS BREAKDOWN DIAGRAM 1. Control Panel 2. Display PCB 3. Panel 4. Inner Liner 5. Handle 6. Ice Shovel 7. Ice Case 8. Evaporator 9. Steel Water Supply Pipe 10. Steel Shell 11. Component Of Switch 12. Cover 13. Left Board 14.

  • Page 11: Limited Warranty

    LIMITED WARRANTY This EdgeStar product is warranted to be free from defective workmanship and materials for the first year following the date of original purchase. Replacement parts will be supplied free of charge for the first year following the date of original purchase. Labor will be performed free of charge for the first 90 days following the date of original purchase.
  • Page 12 Contact EdgeStar for troubleshooting assistance and warranty service authorization at 1-866-319-5473. Please have your order receipt available to confirm the date of purchase. Once an EdgeStar authorized representative has confirmed that your product is eligible for warranty service, the product must be returned to an EdgeStar authorized repair facility.
  • Page 13 For information on EdgeStar and to view our full line of products, please visit our website: http://www.edgestar.com EdgeStar Box 81336 Austin, Texas 78708-1336 Toll Free: 1-866-319-5473...
