Stacked
Washer and Dryer
Metered
Electric and Gas Models
NOTA: El manual en
español aparece después
del manual en inglés.
SWD446C
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 801539R3
www.comlaundry.com
July 2005

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWD447C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alliance Laundry Systems SWD447C

  • Page 1 Stacked Washer and Dryer Metered Electric and Gas Models NOTA: El manual en español aparece después del manual en inglés. SWD446C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 801539R3 www.comlaundry.com July 2005...
  • Page 3: For Your Safety

    A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance. This appliance must not be installed in a bedroom or bathroom. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801539...
  • Page 4 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801539...
  • Page 5: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801539 Replacement Parts ...
  • Page 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Water Supply Requirements ... 40 Water Temperature ... 40 Water Pressure ... 40 Risers... 40 Location Requirements... 41 Dryer Exhaust Requirements... 42 Exhaust System Materials... 42 Make-Up Air Requirements... 43 Make-Up Air Dos and Don’ts...
  • Page 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801539 Operation Instructions for NetMaster Dryers ... 59 Step 1: Clean Lint Filter... 59 Step 2: Load Laundry... 59 Step 3: Close Loading Door... 59 Step 4: Determine Proper Controls for Dryer ... 60 Step 5: Set Fabric Selector ...
  • Page 8 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801539...
  • Page 9: Replacement Parts

    Replacement Parts If replacement parts are required, contact the source from which you purchased your unit or contact: 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A.
  • Page 10 Notes 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 11: Safety Information

    801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Safety Information Important Safety Instructions Save These Instructions To reduce the risk of fire, electric shock,...
  • Page 12 State of California to cause cancer, birth defects or other reproductive harm. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 19. Washer and dryer will not operate with the loading door open. DO NOT bypass the door safety switches by permitting the washer or dryer to operate with the doors open.
  • Page 13 35. DO NOT bypass any safety devices. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 36. Failure to install, maintain, and/or operate this machine according to the manufacturer’s instructions may result in conditions which can produce bodily injury and/or property damage.
  • Page 14 Notes 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 15: Installation

    NOTE: Side and rear exhaust openings are 4 inch (10.2 cm) ducting. Gas models cannot be vented out left side of cabinet because of burner housing. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Installation 8.0 in. (20.3 cm) 28 in.
  • Page 16 NOTE: Side and rear exhaust openings are 4 inch (10.2 cm) ducting. Gas models cannot be vented out left side of cabinet because of burner housing. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 8.0 in. (20.3 cm) 28 in.
  • Page 17: Gravity Drain Models

    NOTE: Side and rear exhaust openings are 4 inch (10.2 cm) ducting. Gas models cannot be vented out left side of cabinet because of burner housing. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 8.0 in. (20.3 cm) 28 in.
  • Page 18: Before You Start

    Place the unit on a solid floor with an adequate air supply. For more detailed information, refer to section on Location Requirements. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Exhaust Use rigid metal duct and exhaust the dryer to the outside by the shortest route possible.
  • Page 19: Installing The Unit

    Figure 3 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 2: Connect Water Fill Hoses NOTE: Refer to section on Water Supply Requirements before connecting water fill hoses.
  • Page 20 COLD Water Faucet Fill Hoses Rubber Washer (Plain) Filter Screens Figure 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Water Supply Faucets Cold Water Connection Hot Water Connection Water Fill Hoses TLW1976N IMPORTANT: Hoses and other natural rubber parts deteriorate after extended use.
  • Page 21: Step 3: (Non-Gravity Drain Models Only) Connect Drain Hose To Drain Receptacle

    Shipping Tape Figure 6 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Standpipe Installation Place the drain hose into the standpipe. Remove the beaded tie-down strap from accessories bag and place around standpipe and drain hose and tighten strap to hold hose to standpipe.
  • Page 22: Step 4: (Gravity Drain Models Only) Connect Drain Outlet To Drain System

    Drain Trough Drain Outlet Figure 8 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 5: (Gas Dryer Only) Connect Gas Supply Pipe For further assistance, refer to section on Gas Requirements.
  • Page 23 Equipment Shut-Off Valve – Installed within 6 ft. (1.8 m) of dryer 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Black Iron Pipe Shorter than 20 ft. (6.1 m) – Use 3/8 in. pipe Longer than 20 ft. (6.1 m) – Use 1/2 in. pipe 3/8 in.
  • Page 24: Step 6: (Electric Dryer Only) Connect Electrical Plug

    Electric Dryer Electrical Requirements. NOTE: Four-wire cord is required for mobile homes or where codes do not permit grounding through neutral. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT THREE-WIRE CONNECTION D275I FOUR-WIRE CONNECTION...
  • Page 25: Step 7: Connect Dryer Exhaust System

    Failure to exhaust dryer properly will void warranty. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT W116 Figure 12 NOTE: Venting materials are not supplied with the unit (obtain locally).
  • Page 26: Step 8: Position And Level The Unit

    © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Remove rubber feet from accessories bag and place on all four leveling legs.
  • Page 27: Step 9: (Washer Only) Remove The Shock Sleeves And Shipping Brace

    Hooked End of Shipping Brace Figure 14 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 10: Wipe Out Inside of Washer Drum and Dryer Drum Before using the washer and dryer for the first time,...
  • Page 28: Step 11: Plug In The Washer And Dryer

    GAS DRYER Plug cord into separately fused 15 Amp circuit. Figure 19 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 12: Check Installation Refer to Installer Checklist on the back cover and make sure that unit is installed correctly.
  • Page 29: Heat Source Check

    Air Shutter Lockscrew Air Shutter 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT After dryer has operated for approximately five minutes, observe burner flame. Adjust the air shutter to obtain a soft, uniform blue flame. (A lazy yellow- tipped flame indicates lack of air.
  • Page 30: Electrical Requirements

    110/120 Volts AC (alternating current) 15 Amps. Refer to Figure 23 to determine correct polarity of the wall receptacle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING To reduce the risk of an electric shock or...
  • Page 31: Electric Dryer

    DO NOT use an extension cord or an adapter to connect the washer to the electrical power source. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Electric Dryer (120/240 Volt, 60 Hertz, 3-Wire Installation) (120/208 Volt, 60 Hertz, 3-Wire Installation)* *Alternative Heating Element Required V.A.C.
  • Page 32 (Refer to NOTE above) 30 Ampere Fuses or Circuit Breaker Neutral Wire © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT The power cord (pigtail) connection between wall receptacle and dryer terminal block IS NOT supplied with dryer. Type of pigtail and gauge of wire must conform to local codes and with instructions mentioned on the following pages.
  • Page 33: Electrical Connection

    Grounding Pin Ground Screw on Back of Cabinet 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: Use only a U.L. listed No. 10 A.W.G. (copper wire only) three conductor power supply cord kit rated 240 Volts (minimum) 30 Amperes and labeled as suitable for use in a clothes dryer.
  • Page 34: Three-Wire Connection

    NEVER operate the dryer unit with the access cover removed. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Neutral (White or Center Wire) Strain Relief (Not supplied with dryer)
  • Page 35: Four-Wire Power Cord

    Install the strain relief nut from the inside of the cabinet and tighten firmly. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 7. Attach the green ground wire (from the four-wire power cord) to the terminal block mounting bracket using the hex head screw removed in step 4.
  • Page 36 Installation Typical Four-Wire Receptacle Four-Wire Power Cord (Not supplied with dryer) Strain Relief Nut Strain Relief Figure 27 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT D815I 801539...
  • Page 37: Four-Wire Connection

    To reduce the risk of an electric shock, NEVER operate the dryer unit with the access cover removed. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Figure 28 W150 Installation D683I...
  • Page 38: Electrical Requirements

    Do not cut or remove the grounding prong from this plug. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: A qualified electrician should check the polarity of the wall receptacles. If a voltage reading is measured other than that illustrated, the qualified electrician should correct the problem.
  • Page 39 Round Grounding Prong Neutral Figure 30 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Grounding Instructions The dryer must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
  • Page 40: Gas Requirements

    6 feet (1.8 m) of the dryer. An 1/8" N.P.T. pipe plug must be installed as shown. Refer to Figure 31. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To reduce the risk of gas leaks, fire or explosion: •...
  • Page 41 Equipment Shut-Off Valve – Installed within 6 ft. (1.8 m) of dryer 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Black Iron Pipe Shorter than 20 ft. (6.1 m) – Use 3/8 in. pipe Longer than 20 ft. (6.1 m) – Use 1/2 in. pipe 3/8 in.
  • Page 42: Water Supply Requirements

    Order hoses as follows: No. 20617 Fill Hose (8 feet) (2.44 m) No. 20618 Fill Hose (10 feet) (3.05 m) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT W029 Water Supply Faucets Cold Water Connection...
  • Page 43: Location Requirements

    Exhaust Duct Clearance to Combustible Materials NOTE: Shaded areas indicate adjacent structure. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: Unless completely assembled, DO NOT slide the unit across the floor. DO NOT slide...
  • Page 44: Dryer Exhaust Requirements

    Never install flexible duct in concealed spaces, such as a wall or ceiling. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT DO NOT use sheet metal screws on exhaust pipe joints or other fastening means which extend into the duct that could catch lint and reduce the efficiency of the exhaust system.
  • Page 45: Make-Up Air Requirements

    Draw make-up air from a room containing a dry cleaner or a hair salon. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Exhaust Direction The dryer can be exhausted to the outdoors through the back, left or right of the dryer. EXCEPTION: Gas dryers cannot be vented out the left side because of the burner housing.
  • Page 46: Exhaust System

    Maximum length of 4 in. (10.2 cm) diameter flexible metal duct NOTE: Deduct 6 feet (1.8 m) for each additional elbow. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To prevent backdraft when dryer is not in operation, outer end of exhaust pipe must have a weather hood with hinged dampers (obtain locally).
  • Page 47: Exhaust System Maintenance

    521P3 FLEXIBLE METAL VENT KIT Figure 37 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Dryer Airflow Efficient dryer operation requires proper dryer airflow. Proper dryer airflow can be evaluated by measuring the static pressure.
  • Page 48: Multi-Dryer Installation Exhaust Requirements

    The dryer interior and the complete exhaust system should be cleaned periodically by a qualified service person to remove any lint build-up. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT SWD749N Weather Hood or Sweep Elbow...
  • Page 49 Figure 41 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT EXHAUST AIR FLOW MAXIMUM LENGTH OF DUCT 30 feet (9.1 m) HORIZONTAL EXHAUST INSTALLATION 2 in.
  • Page 50: Lint Filter

    Lint Filter Figure 42 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Dryer Motor Overload Protector The motor overload protector stops the motor in the event of an overload. After cooling, the overload protector will reset itself.
  • Page 51: Operation

    Step 1: Load Laundry Load items loosely into wash drum. Figure 43 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operation Step 2: Close Loading Door Close loading door tightly. The washer will not operate with the loading door open.
  • Page 52: Step 3: Add Laundry Supplies

    Detergent Bleach Fabric Softener Figure 45 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 4: Determine Proper Controls for Washer The direction of the arrow indicates which controls are for the washer.
  • Page 53: Step 6: Insert Coin(S) Or Card

    To Insert Card Insert card into opening. Figure 49 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 7: Start Washer After vend price has been satisfied, push the START keypad. DOOR MUST BE CLOSED TO START WASHER.
  • Page 54: Indicator Lights

    DOOR LOCKED is lit whenever the door is locked. The door cannot be opened when this light is on. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: If washer fails to operate properly after installation, make sure electrical service and water supply faucets are turned on.
  • Page 55: Operation Instructions For Netmaster Washers

    Figure 52 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 3: Add Laundry Supplies Open dispenser drawer. Measure and add low sudsing detergent (1), bleach (2) and fabric softener (3) to the dispenser drawer.
  • Page 56: Step 4: Determine Proper Controls For Washer

    DELICATES PRESS WARM COLD Figure 55 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 6: Set Wash Temperature Push keypad for HOT, WARM or COLD. Light indicates selection. NOTE: Always follow manufacturer’s care labels. NORMAL...
  • Page 57: Step 8: Start Washer

    WARM COLD Figure 59 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Indicator Lights WASH WASH is lit at the beginning of a Wash cycle and will remain lit until the Wash cycle is complete.
  • Page 58: Operation Instructions For Mdc Dryers

    Step 1: Clean Lint Filter Clean lint filter before each use. Figure 60 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 2: Load Laundry Load clothes loosely into dryer drum. Add fabric softener sheet if desired.
  • Page 59: Step 4: Determine Proper Controls For Dryer

    NOTE: Always follow manufacturer’s care label instructions. Figure 64 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 6: Insert Coin(s) or Card To Insert Money Insert coin(s) in coin slot. Check pricing as seen on digital display.
  • Page 60: Copyright, Alliance Laundry Systems Llc – Do Not Copy Or Transmit

    START keypad. Cycle is completed when time remaining reaches 00 minutes. Figure 67 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Indicator Lights START START is lit when the dryer is not in a cycle, the full vend price has been satisfied and the dryer door is closed.
  • Page 61: Step 3: Close Loading Door

    Clean lint filter before each use. Lint Filter Figure 68 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 2: Load Laundry Load clothes loosely into dryer drum. Add fabric softener sheet if desired. IMPORTANT: To avoid damage to dryer, do not use more than one fabric softener sheet per load.
  • Page 62: Step 4: Determine Proper Controls For Dryer

    NOTE: Always follow manufacturer’s care label instructions. Figure 72 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Step 6: Insert Coin(s) or Card To Insert Money Insert coin(s) in coin slot. Check pricing as seen on digital display.
  • Page 63: Step 7: Start Dryer

    Cycle is completed when time remaining reaches 00 minutes. Figure 75 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Indicator Lights INSERT COINS/CARD INSERT COINS/CARD is lit to prompt the user to insert coins or card to satisfy the vend price. When...
  • Page 64 Notes 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 65: User-Maintenance Instructions

    All hoses should be replaced every five years. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Maintenance Filter Screen Check the filter screens for debris or damage annually.
  • Page 66: Exhaust System

    Do not obstruct the flow of combustion and ventilation air. NOTE: Verify proper operation after servicing. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT For Energy Conservation Make sure the lint filter is always clean. Do not overload dryer.
  • Page 67: Before You Call For Service

    • • • • • • • 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Won’t Won’t Possible Reason Spin Drain Be sure power cord is plugged all the way into the electrical outlet. •...
  • Page 68: If Service Is Required

    Phone: (920) 748-3121 Nameplate Figure 76 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT When calling or writing about your unit, PLEASE GIVE THE MODEL AND SERIAL NUMBERS. The model and serial numbers are located on the nameplate.
  • Page 69: Information For Handy Reference

    Service Agency Address NOTE: Record the above information and keep your sales slip. Model and serial numbers are located on the nameplate. 801539 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Serial Number Phone Number Phone Number...
