Chapter 2 Creating Provisioning Scripts
Proprietary Plain-Text Configuration File
During macro expansion, expressions of the form $NAME and $(NAME) are replaced by the contents
of the named variables. See the "Macro Expansion Variables" section on page 4-7 for the complete list
of variables available for macro expansion. These include general purpose parameters, several product
identifiers, certain event timers, and provisioning state values.
For example, for a SPA with MAC address 000E08012345, the expression:
spa$(MAU)config.cfg
macro-expands into the following string:
spa000E08012345config.cfg
If a macro name is not recognized, it remains unexpanded. For example,
The name STRANGE is not recognized as a valid macro name, while MAU is recognized as a
valid macro name; so the expression:
spa$STRANGE$MAU.cfg
macro-expands into the string:
spa$STRANGE000E08012345.cfg
Macro expansion is not applied recursively. For example, $$MAU" expands into $MAU" (the $$ is
expanded), and not 000E08ABCDEF", for a SPA with the indicated MAC address.
The special purpose parameters (GPP_SA through GPP_SD), whose contents are mapped to the macro
expressions $SA through $SD, are only macro expanded as the argument of the --key option in a resync
URL.
Also, the macro expression can qualify the expansion so that only a substring of the macro variable is
used instead of its full value, such as a portion of the MAC address.
The syntax for substring macro expansion is $(NAME:p) and $(NAME:p:q), where p and q are
non-negative integers. The resulting expansion results in the macro variable substring starting at
character offset p, and of length q (or till end-of-string if q is not specified). For example, for an SPA
with MAC address 000E08012345, the expression $(MAU:4) macro-expands into the string 08012345,
while the expression $(MAU:8:2) macro-expands into the string 23

Conditional Expressions

Conditional expressions can trigger resync events and select from alternative URLs for resync and
upgrade operations.
Conditional expressions consist of a list of comparisons, separated by the and operator. All comparisons
must be satisfied for the condition to be true.
Each comparison can relate one of three types of literals: integer values, software or hardware version
numbers, and doubled-quoted strings.
Note that version numbers take the form of three non-negative integers separated by periods (major,
minor, and build numbers), plus an optional alphanumeric string in parentheses. No intervening spaces
are allowed.
The following are examples of valid version numbers:
1.0.31(b)
1.0.33
2.0.3(G)
2.0.3(0412s)
