Summary of Contents for Eaton PXES4P Series
- Page 1 Corporate Headquarters Eaton Electrical, Inc. 1000 Cherrington Parkway Moon Township, PA 15108 Phone: 1.800.525.2000 Website: http://www.eatonelectrical.com Power Xpert Ethernet Switch Series PXES4P User Guide Installation and...
- Page 2 PXES4P Switches Installation and User Guide (10/06) PXES4P Series Switches Installation and User Guide Trademarks Ethernet is a trademark of Xerox Corporation NEBS is a registered trademark of Telcordia Technologies UL is a registered trademark of Underwriters Laboratories Important: The PXES4P, 10/100 Mb/s Convenient Switches contain no user serviceable parts.
- Page 3 PXES4P Switches Installation and User Guide (10/06) Federal Communications Commission Radio Frequency Interference Statement This equipment generates, uses and can radiate frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when operated in a commercial...
- Page 4 PXES4P Switches Installation and User Guide (10/06) Contacting EATON EATON ELECTRICAL, INC For Technical Support please call 800-809-2772 414-449-7100 Or visit our Website http://www.eatonelectrical.com...
-
Page 5: Table Of Contents
Technical Specifications ... 7 INTRODUCTION ... 14 Inspecting the Package and the Product... 14 Product Description ... 16 PXES4P Series, with four (RJ-45) Copper ports ... 18 Frame Buffering and Latency ... 20 Features and Benefits... 22 Applications ... 24 For PXES4P Series ... - Page 6 The architecture supports a dual speed switching environment, with auto-negotiation capability..38 Auto-cross (MDIX), Auto-negotiation and Speed-sensing... 40 4.3: Dual LEDs, Front-panel and side-panel ( PXES4P Series ) ... 41 Troubleshooting Before Calling for Assistance ... 44 When Calling for Assistance ... 45...
- Page 7 PXES4P Switches Installation and User Guide (10/06) Return Material Authorization (RMA) Procedure ... 46 Shipping and Packaging Information... 47 Appendix A: Warranty Information……………………………………………...
-
Page 8: Specifications
PXES4P Switches Installation and User Guide (10/06) SPECIFICATIONS Technical Specifications Ports Performance When a port is operating at 100Mbps: Data Rate: 100Mbps When a port is operating at 10 Mbps: Data Rate: 10 Mbps Network Standards 100Mb: Ethernet IEEE 802.3u, 100BASE-TX, IEEE 802.1p 10 Mb: Ethernet IEEE 802.3, 10BASE-T Power Over Ethernet: IEEE 802.3af (PPXES4PP model only) Auto-sensing for speed: IEEE 802.3u... - Page 9 PXES4P Switches Installation and User Guide (10/06) Packet-Processing Between Domains Filter / Forwarding Rate from 100Mbps ports: 148,800 pps max Filtering and Forwarding Rate from 10 Mbps ports: 14,880 pps max. Processing type: Store and Forward, non-blocking Auto-learning: 2K address table Address buffer age-out time: 300 sec.
- Page 10 Packaging: Enclosure: Robust sheet metal (Steel). Dimensions, Switch unit: Height x Width x Depth PXES4P Hardened: 3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm) Weight: 4.6 oz. (130g);...
-
Page 11: Power Supply
PXES4P Switches Installation and User Guide (10/06) Cooling Method: The case is used as a heat sink on this model. POWER SUPPLY : These products are intended to be supplied by a Listed, Direct Plug-In power unit, marked “Class 2”, or a Listed ITE Power Supply, marked “LPS”, which has suitably rated output voltage (i.e. - Page 12 PXES4P Switches Installation and User Guide (10/06) Input: 100-240V AC at 47-63Hz, for “-Pd” high temp. 100-240V AC at 47-63Hz, “-Pi” models that have IEC320 power connector built-in the PS unit. Out put- 12vdc, 2 Amps DC to unit: 12V DC, 2.5mm jack, center +ve, 6ft. cord Power Supply ( Direct DC ): built-in screw terminal block for +, -, ground.
- Page 13 PXES4P Switches Installation and User Guide (10/06) Note 2: Internal DC power floats, user may ground “+” or “-” if desired. Port Connectors: RJ-45 Port: Auto-cross(MDIX), 100BASE-TX and 10BASE-T:shielded 8-pin female. Three RJ-45 ports provided in front, and one on the rear. Supports shielded (STP) and unshielded (UTP) Cat 3, 4, 5 cable.
- Page 14 PXES4P Switches Installation and User Guide (10/06) Metal Mounting clips for panel mounting : included DIN-Rail mounting option: Model :#PXESDINRL Rack-mount option: #PXESTRAY Mean Tine Between Failure (MTBF ) – 15+ years, Telcordia (Bellcore SR-332) Method Agency Approvals and Standard Compliance: UL Listed (UL 60950), cUL, CE, Emissions meet FCC Part 15, Class A.
-
Page 15: Introduction
PXES4P-48VDC = Same as PXES4P-24VDC model, except for -48VDC power input. PXESTRAY = 19” Rack-mount tray for 14-series Switch models, up to 16 units PXESDINRL = Metal DIN-Rail mounting bracket for one PXES4P Series INTRODUCTION This section describes PXES4P Series models, including appearance, features and typical applications. - Page 16 Inspect the contents of this package for any signs of damage and ensure that the items listed below are included. This package should contain: PXES4P Series Switch Unit External Power Supply (d, i model only) 1 set Metal panel mounting clips and screws, 2 each User Guide, i.e., this manual...
-
Page 17: Product Description
PXES4P Switches Installation and User Guide (10/06) Remove the PXES4P Series Switch from the shipping container. Be sure to keep the shipping container should you need to ship the unit at a later date. In the event there are items missing or damaged contact your supplier. If you need to return the unit use the original shipping container. - Page 18 PXES4P Switches Installation and User Guide (10/06) The PXES4P as shown above in Fig 2.2c is a hardened unit designed for factory floor and other industrial applications. The PXES4P models are built with high-grade components and use special thermal techniques and a rugged metal case for extended temperature industrial applications.
-
Page 19: Pxes4P Series, With Four (Rj-45) Copper Ports
PXES4P left side view 2.3 PXES4P Series, with four (RJ-45) Copper ports The PXES4P Series chassis house one main PC board. The power supply is an external AC unit or internal DC via a screw terminal block. The front side of the chassis has three twisted-pair switched ports and one port is provided on the rear side. - Page 20 PXES4P Switches Installation and User Guide (10/06) ports of the PXES4P Series convenient switch support auto-cross (MDIX), and perform the auto-cross in the auto-negotiation mode only. Dual LEDs indicating the operating status of ports are mounted on the top as well as end for convenience and may be viewed from any direction.
-
Page 21: Frame Buffering And Latency
Installation and User Guide (10/06) 2.4 Frame Buffering and Latency The PXES4P Series Switches are store-and-forward switches. Each frame (or packet) is loaded into the Switch’s memory and inspected before forwarding can occur. This technique ensures that all forwarded frames are of a valid length and have the correct CRC, i.e., are good packets. - Page 22 This flow-control sequence occurs in a small fraction of a second and is transparent to an observer. See Section 4.6 for additional details. Another feature implemented in PXES4P Series Switches is a collision-based flow-control mechanism (when operating at half-duplex only). When the Switch detects that its free buffer queue space is low, the Switch prevents more frames from entering by forcing a collision signal on all receiving half-duplex ports in order to stop incoming traffic.
-
Page 23: Features And Benefits
The latency (the time the frame spends in the Switch before it is sent along or forwarded to its destination) of the PXES4P Series Switches varies with the port-speed types. The length of the frame is a variable here as it is with all store-and-forward switches. - Page 24 EMI noise sites; e.g industrial or outdoor applications. AC and DC Power Supplies with extended temperature ratings PXES4P Series power input may be a variety of types, external AC and internal DC at 12V, 24V, or -48VDC. AC may be at extreme temperatures.
-
Page 25: Applications
Applications For PXES4P Series PXES4P Series Switch unit fits in any environment where users need to add a few RJ-45 ports to a LAN quickly and cost effectively. The edge-of–the-network connectivity product makes challenging industrial applications easier, more economical, and more reliable. The... - Page 26 PXES4P Switches Installation and User Guide (10/06) compact PXES4P Series 10/100 Mbps switch functions support a mixed environment of 10 Mbps and 100Mbps users. The switching full / half duplex capability on all four ports provide bandwidth for high performance. Port #1 (on the back end) is typically used for an up-stream connection.
-
Page 27: Installation
3.1 Locating the Convenient Switch Unit All the PXES4P Series Switches operate in transparent half-and full-duplex mode. The store and forward switch easily take care of the network traffic and can be used as a useful... - Page 28 An option DIN-Rail bracket is available. clips for Panel- Installation of the PXES4P Series Switches is a simple procedure. The installation location is dependent upon the physical layout of the Ethernet network and associated cabling. Make sure the unit is installed in a location that is easily accessible to an AC power outlet or power strip and where convection cooling is not inhibited.
-
Page 29: Pxestray For Rack Mounting Of Pxes4P Series Switches
PXES4P Switches Installation and User Guide (10/06) 3.2 PXESTRAY for Rack Mounting of PXES4P Series Switches For 19” rack mounting of PXES4P Series Switches, a rack-mount tray is available, the part number is PXESTRAY. The Convenient Switches along with Media Converter units are... -
Page 30: Din-Rail Mounting Option
PXES4P Switches Installation and User Guide (10/06) three to eight) PXES4P Series Switches, with their power supplies plugged into power strips (not included) in the rear area of the tray. Metal mounting screws in the bottom-front hold the Media Converters firmly in place. The beveled-top edge of the units permit the LEDs of each unit to be viewed for operational status, even when the units are very close together. -
Page 31: Power Requirements, Power Supply Types For Pxes4P Series Switches
PXES4P Series Switches are power-efficient and can work with an external AC power supply. PXES4P Series require a nominal 12VDC input (range 8 to 15V, see Specifications) at the jack in the rear. The extended temperature –Hd version is used for heavy duty and industrial applications, up to 55`C ambient. -
Page 32: Powering The Pxes4Ph With 12V, 24V Or -48Vdc Power Input
PXES4P Switches Installation and User Guide (10/06) The PXES4P Series are designed to provide reliable operation, withstand higher temperature environments, and provide the Direct DC power choices to the user to deploy in uncontrolled temperature environments. 12VDC 24VDC -48VDC The Internal 12V DC (8 – 15V DC) has a built-in terminal block for +, -, ground. The 9V DC jack is also present. - Page 33 PXES4P Switches Installation and User Guide (10/06) The PXES4P is reliably equipped with a Direct DC power supply, and have built- in screw terminals for secure attachment of the power leads. Three models support a range of power input types. The three model choices are for use with 12VDC, 24VDC or -48VDC power.
-
Page 34: Pxes4P, Dc-Powered, -48Vdc, 24Vdc And 12Vdc Installation
PXES4P Switches Installation and User Guide (10/06) 0.4 amp max.(24V DC) 0.2 amp max.(-48V DC) Power Consumption: 3 watts typical, 4 watts max. 3.7 PXES4P, DC-powered, -48VDC, 24VDC and 12VDC Installation This section describes the proper connection of the -48VDC leads (or 24VDC, 12VDC leads) to the Direct DC power terminal block on the PXES4P hardened media converter (as shown in Figure above). - Page 35 PXES4P Switches Installation and User Guide (10/06) The connection procedure is straightforward. Simply insert the DC leads to the PXES4PH’s power terminals, positive (+) and negative (-) screws. The use of Ground (GND) is optional; it connects to the PXES4PH chassis. Ensure that each lead is securely tightened from the top, as shown here.
-
Page 36: Connecting Twisted Pair (Rj-45 Ports)
Installation and User Guide (10/06) 3.8 Connecting Twisted Pair (RJ-45 ports) The PXES4P Series Switches can be connected to only one media type with two different speed i.e. 100BASE-TX and 10BASE-T. CAT 5 cables should be used when making 100BASE-TX connections. When the ports are used as 10BASE-T ports, CAT 3 may be used. -
Page 37: Or Shielded
For Port # 1 or 1SW, if the LINK LED is not illuminated, move the switch which has a cross-over or up-link for linking to another hub or Switch. -
Page 38: Connections To Nics Which Support Auto-Negotiation, Rj-45 Ports
3.8.2 Connections to NICs which support Auto-Negotiation, RJ-45 ports The copper ports of PXES4P Series Switches will function properly with NICs (Network Interface Cards) which support Auto-Negotiation, and the Fast Link Pulse (FLP) coding for the 100BASE-TX signaling system. When connecting a NIC to the PXES4P- Sereis, it may be necessary to reload the NIC drivers on the user device if the NIC has been communicating with a protocol other than 100BASE-TX (such as 10BASE-T). -
Page 39: Rear). The Architecture Supports A Dual Speed Switching Environment, With Auto-Negotiation Capability
100Mbps Ethernet, and can communicate with 10 Mb domain too. PXES4P Series is plug-and-play device. There is no software configuring to be done at installation or for maintenance. The internal functions of both are described below. - Page 40 Packets needed for maintaining the operation of the network (such as occasional multi-cast packets) are forwarded to all ports. The PXES4P Series Switches operate in the store-and-forward switching mode, which eliminates bad packets and enables peak performance.
-
Page 41: Auto-Cross (Mdix), Auto-Negotiation And Speed-Sensing
Installation and User Guide (10/06) Switching, Address Learning The PXES4P Series units have address table capacity of 2K node addresses, and are suitable for use in large networks. They are self-learning, so that as nodes are added or changed, the PXES4P Series automatically keeps up with node locations. -
Page 42: Dual Leds, Front-Panel And Side-Panel (Pxes4P Series)
IEEE 802.3u standard. Depending upon the devices connected, this will result in agreement to operate at either 10 Mbps or 100Mbps speed, and full- or half-duplex mode. 4.3: Dual LEDs, Front-panel and side-panel (PXES4P Series) Description Illuminates GREEN to indicate power applied. - Page 43 PXES4P Switches Installation and User Guide (10/06) LK/ ACT Steady ON for LINK w/no traffic, blinking for activity per port. LINK will turn off in the event connectivity is lost between the ends of the twisted pair segment or a loss of power occurs in the unit or remote device. The Link ports are also represented by LA1, LA2, LA3, &...
-
Page 44: Troubleshooting
However, if you are unsure of the procedures described in this section or if the PXES4P Series 10/100 Mb/s Switch is not performing as expected, do not attempt to repair the unit; instead contact your supplier for... -
Page 45: Before Calling For Assistance
(About 90% of network downtime can be attributed to wiring and connector problems.) Make sure that an AC power cord is properly attached to each PXES4P Series unit. Be certain that each AC power cord is plugged into a functioning electrical outlet. -
Page 46: When Calling For Assistance
Installation and User Guide (10/06) If the problem continues after completing Step 4 above, contact your supplier of the PXES4P Series 10/100 Mb/s Switch unit or if unknown, contact EATON, Inc 5.2 When Calling for Assistance Please be prepared to provide the following information. - Page 47 PXES4P Switches Installation and User Guide (10/06) A record of changes that have been made to your network configuration prior to the occurrence of the problem. Any changes to system administration procedures should all be noted in this record. 5.3 Return Material Authorization (RMA) Procedure All returns for repair must be accompanied by a Return Material Authorization (RMA) number.
- Page 48 PXES4P Switches Installation and User Guide (10/06) EATON will carefully test and evaluate all returned products, will repair products that are under warranty at no charge, and will return the warranty-repaired units to the sender with shipping charges prepaid (see Warranty Information, Appendix A, for complete details). However, if the problem or condition causing the return cannot be duplicated by EATON, the unit will be returned as: No Problem Found.
- Page 49 2. Clearly mark the Return Material Authorization (RMA) number on the outside of the shipping container. 3. EATON is not responsible for your return shipping charges. 4. Ship the package to: EATON ELECTRICAL, INC 1000 Cherrington Parkway Moon Township, PA 15108 Phone: 1.800.525.2000...
-
Page 50: Appendix A: Warranty Information
PXES4P Switches Installation and User Guide (10/06) Appendix A: WARRANTY INFORMATION This product offered by Eaton Corporation, is warranted against defects in material and workmanship for a period of three years from the date of shipment, under normal use and service. - Page 51 PXES4P Switches Installation and User Guide (10/06) NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. EATON CORPORATION SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A APRTICULAR PURPOSE. Warranty Repair If you believe your equipment is in need of repair, call Eaton Corporation and ask for a customer service representative.
- Page 52 PXES4P Switches Installation and User Guide (10/06) If the warranty period has expired, we offer repair services for equipment you have purchased from Eaton Corporation. Call and ask for a Customer service agent. It is important to contact us first as many problems may be resolved with a phone call. Please have the serial number of the unit and nature of the problem available before you call.
