  • Page 1 Disconnect Switches Product Guide Rotary Switches Operating Mechanisms Non-fused Accessories Fused Enclosed Rotary...

  • Page 2: Table Of Contents

    Technical Characteristics ........16 , 17 Enclosed Rotary Disconnect Switches....... 18 - 23 Product Selection .

  • Page 3: Features, Benefits And Functions

    Rotary Disconnect Switches Product Description Product Description Non-fused ■ R & W frame, 30A – 80A, non-fusible 600V AC , suitable for use in equipment or machinery as a motor disconnect. ■ Manual motor controller suitable for motor disconnect, horsepower and Amp rated, load break rated, meeting requirements of CSA C22.2 No 14 CEC...
  • Page 4 This exclusive design is also available in a 4 and 4X rating. Toggle Option Available for internal panel mounting. Rotary Disconnect Switches Product Description Figure 1. Padlocking Capability (Type G Pistol Handle is Shown) Figure 2. Door Interlocking Figure 3. Interlocking Defeater...

  • Page 5: Product Selection

    Horsepower Rating 240V 480V 600V DIN Rail / Base Mounted Rotary Switch R-, W-Frame with Brass Collar DIN Rail / Base Mounted Toggle Switch R-, W-Frame DIN Rail / Base Mounted Rotary Switch C-Frame Base Mounted Rotary Switch V-Frame Base Mounted Rotary Switch S-Frame...

  • Page 6: Handles And Shafts

    1, 3R, 12 Red/Yellow 1, 3R, 12 Black Rotary Switch Selector Shaft 5 x 5 mm (For Selector Handle and R- and W-Frames) Rotary Switch Selector Shaft 5 x 5 mm (For Selector Handle and C-Frames) Black Pistol Handle (Type D) NEMA...

  • Page 7: Handles And Shafts

    Rotary Disconnect Switches Product Selection – Handles and Shafts Table 5. Handles and Shafts (Continued) Black Pistol Handle (Type G) NEMA Defeatable Padlockable Color Rating Pistol Handle Type G (For use with R-, W- and C-Frames with 5 x 5 shaft and V-Frame below 100A with 10 x 10 shaft)

  • Page 8: Accessories

    Extension Support Replacement Brass Collar R and W-Frames Door Mounting Kit R and W-Frames Rotary Switches The mechanism is reversed on these contacts. Rotary Disconnect Switches Fusible/Non-Fusible – Accessories Table 4. Accessories — C, S, V, F-Frames Catalogue Description Number...

  • Page 9: Technical Data And Specifications

    Frame Ampere Rating 30 – 40 2.00 (50.8) 60 – 125 2.09 (53.1) Note: Frame is designated by the sixth character in the switch Catalogue number. 2.75 (69.9) 2.68 (68.1) 1.65 (41.9) 3.35 (85.1) 2.88 (73.2) 1.69 (42.9) For more information visit us at: www.eatonelectrical.ca December 2004 0.34...

  • Page 10: C-Frame

    (115.8) (65.8) 3-Pole 3.78 4.56 3.28 (96.0) (115.8) (83.3) 3-Pole 4.13 4.56 3.89 (104.9) (115.8) (98.8) Rotary Disconnect Switches – Non-fused Technical Data and Specifications C-Frame — — — — 1.47 (37.3) — 5.19 — — 1.47 (131.8) (37.3) —...

  • Page 11: V-Frame

    Rotary Disconnect Switches – Non-fused Technical Data and Specifications V-Frame Dimensions in Inches (mm) C362UV60 C362UV100 C362UV200 Figure 6. Non-Fusible V-Frames Table 8. Dimensions in Inches (mm) Description 3-Pole 6.69 5.87 3.89 (169.9) (149.1) (98.8) 3-Pole 6.69 5.87 3.89 (169.9) (149.1)
  • Page 12 (149.1) (142.7) 3-Pole 8.26 7.19 5.63 (209.8) (182.6) (143.0) 3-Pole 9.44 8.13 6.00 (239.8) (206.5) (152.4) Rotary Disconnect Switches – Fusible Technical Data and Specifications V-Frame 1.14 (29.0) (10.2) (127.0) 1.14 (29.0) (10.2) (127.0) — — — 1.14 2.38 (29.0) (60.5)

  • Page 13: V-Frame

    Rotary Disconnect Switches – Fusible Technical Data and Specifications V-Frame Dimensions in Inches (mm) C363UV400JT / C363UV400J Figure 8. Fusible V-Frames (Continued) Table 10. Dimensions in Inches (mm) Description 3-Pole 11.93 14.31 5.56 (303.0) (363.5) (141.2) 1.14 (29.0) (10.2) (127.0) 5.28...

  • Page 14: S-Frame

    5.51 (371.9) (330.2) (140.0) C362US1200 when used with optional terminal lugs CUS1200LN. C362US800 and C362US1000 and when used with optional terminal lugs CUS1000LN. Rotary Disconnect Switches – Non-Fusible Technical Data and Specifications S-Frame 3.42 (86.9) ø 1.3 2.36 (59.9) ø (33.0) 2.36 (59.9)

  • Page 15: F-Frame

    Rotary Disconnect Switches – Fusible Technical Data and Specifications F-Frame Dimensions in Inches (mm) C363UF600J C363UF800L 4.17 (105.9) Figure 10. Fusible F-Frames Table 12. Dimensions in Inches (mm) Description 3-Pole 17.18 14.25 12.87 (436.4) (362.0) (326.9) C363UF800L when used with optional terminal lugs CUS1000LN.

  • Page 16: Handles

    (50) 2.78 (70.5) ø 4.98 1-1/4" (126.5) (31) Figure 12. Pistol Handle — Type G and Type GL Figure 13. Mounting Depth Rotary Disconnect Switches Technical Data and Specifications – Handles ø 1/16" 2.58 (1.6) (65.5) 2.48 (63) ø 7/8"...

  • Page 17: Technical Characteristics

    Rotary Disconnect Switches Technical Characteristics Table 14. CSA Technical Characteristics Description Rating Ampere CSA C22.2#14/CEC Rule 28-602/ (3)(b) Short Circuit Rating kA with Fuses Fuse Class Fuse Rating (A) Maximum CSA 120V AC Horsepower 208V AC Ratings (3-Phase) 220 – 240V AC 440 –...

  • Page 18: Technical Characteristics

    December 2004 Table 16. IEC Non-Fusible/Fusible Disconnect Switches from 32 to 1250 A Description Catalogue Number C362UC30 C363UV30C C362UC30CT C363UV30J C363UC30JT C363UV30CT C363UV30JT Rating Ampere Rated Insulation Voltage Ui (V) Rated Impulse 8 kV 8 kV Voltage (Uimp) Operation Current (A) 400 V AC –...
  • Page 19 Accepts auxiliary contacts ■ Capability to signal PLC controller ■ 10 kVA short circuit rating when used in conjunction with Class J fusing Table 17. Rotary Disconnect Switches - Enclosed Switches Ampere Type 12/3R Type 4X Enclosure Enc losure Stainless Steel...
  • Page 20 CDR303UD CDR304UD 5.19 [132 MM] .31 [8 MM] 6.04 [153 MM] NOTE: 1. WIRE RANGE OF SWITCH LUGS IS #4-#14 COPPER. WIRE RANGE OF GROUND LUGS IS #2-#14 COPPER OR ALUMINUM. CDR303 Rotary Disconnect Switches – Enclosed Switches – Variable Depth I ON .312 DIA.
  • Page 21 Rotary Disconnect Switches – Enclosed Switches December 2004 CDR306UD CDR380UD 7.69 [195 MM] 5.00 [127 MM] 4.82 [122 MM] .312 DIA. [8 MM] 6.26 [159 MM] 8.54 [217 MM] TYPE 12/3R ENCLOSURE. SCREW TO BE REMOVED WHEN USED AS A TYPE 3R DEVICE.
  • Page 22 Type 4X Stainless Enclosure 5.19 [132 MM] 6.04 [153 MM] NOTE: 1. WIRE RANGE OF SWITCH LUGS IS #4-#14 COPPER. WIRE RANGE OF GROUND LUGS IS #2-#14 COPPER OR ALUMINUM. Rotary Disconnect Switches – Enclosed Switches .312 DIA. [8 MM] 4.54 [115 MM]...
  • Page 23 Rotary Disconnect Switches – Enclosed Switches December 2004 – Flange Mounted – Fixed Depth CDR3080UW CDR3060UW Type 4X Stainless Enclosure 7.69 [195 MM] 5.00 [127 MM] 4.70 [119 MM] .31 [8 MM] .312 DIA. [8 MM] 7.42 [188 MM] 8.54 [217 MM] NOTE: 1.
  • Page 24 Type 4X Non-Metallic Enclosure 2.00 [51 MM] 3.00 [76 MM] 5.44 [138 MM] 5.50 [140 MM] NOTE: 1. WIRE RANGE OF SWITCH LUGS IS #4-#14 COPPER. WIRE RANGE OF GROUND LUGS IS #2-#14 COPPER OR ALUMINUM. CDR3060UX CDR3080UX Type 4X Non-Metallic Enclosure NOTE: 1.

  • Page 25: Product Description

    Operating Mechanisms with Disconnect Switches – Variable Depth Complete Operating Handle Only — Mechanism — C361NE1 C361H1 Table 3. Operating Mechanism Variable Depth with Disconnect Switch — Right-Hand Mounting Disconnect Variable Maximum Horsepower Ratings Switch Size Depth (Amperes) Mounting AC System Volts...

  • Page 26: Technical Data And Specifications

    30 Ampere #2 – 14 Cu/Al 60 Ampere #2 – 14 Cu/Al 100 Ampere 1/0 – 14 Cu/Al 200 Ampere 250 kcmil – #6 Cu/Al Operating Mechanisms with Disconnect Switches – Variable Depth Datum Datum 1.62 (41.1) Min. 1.56 4.00 3.50...
  • Page 27 Operating Mechanisms with Disconnect Switches – Flange Mounted – Fixed Depth Table 25. Operating Mechanism Fixed Depth with Disconnect Switch — Right-Hand Mounting Disconnect Maximum Horsepower Ratings Switch Size (Amperes) AC System Volts (Motor Volts) (200) (230) (460) (575) 7-1/2 7-1/2 Refers to rating of switch only.

  • Page 28: Product Selection

    Fuse clip “R” rejection members for use with Class R fuses are supplied loose in the Fuse Clip Kits. Note: Kits do not include fuses. NEMA 12 Safety Door Hardware Operating Mechanisms with Disconnect Switches Accessories Fuse Clip Kit for Field Installation with...
  • Page 29 Kit included in 600 through 1200 ampere mechanisms. Catalogue Number C371CS6 Table 31. Connecting Rods Increase Maximum Allowable Depth by 5 Inches Application Catalogue Number Disconnect Switches C371CS1 30 , 60, 100, 200 Ampere Circuit Breakers 150, 250, 400 Ampere...
  • Page 30 December 2004 Mounting Dimension Requirements Dimension A = 0.75 in. plus the required wire bending spacing selected from Article 430-10 of the National Electrical Code. Dimension B = Minimum or maximum depth from inside of flange holding operating handle to panel where Circuit Breaker is mounted. (variable depth, see page 22) Dimension C = 150 Ampere Size –...
  • Page 31 Notes NOTES December 2004 For more information visit us at: www.eatonelectrical.ca...
  • Page 32 Notes December 2004 For more information visit us at: www.eatonelectrical.ca...
  • Page 33 Notes December 2004 For more information visit us at: www.eatonelectrical.ca...
  • Page 34 Eaton Corporation is a diversified industrial manufacturer with 2003 sales of $8.1 billion. Eaton is a global leader in fluid power systems and services for industrial, mobile and aircraft equipment; electrical systems and components for power quality,distribution and control; automotive engine air management systems, powertrain solutions and specialty controls for performance, fuel economy and safety;...
