Installation Instructions
for Stacked Washers and Dryers
Inside......................................
Dimensions........................................................................
Before You Start................................................................
Installation.........................................................................
Installer Checklist ............................................ Back Cover
Date Purchased _____________________________
Model Number _____________________________
Serial Number ______________________________
Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com.
Keep these instructions for future reference.
(If this machine changes ownership, this manual must accompany machine.)
3
4
5
www.comlaundry.com
Part No. 802715R3
May 2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems Dishwasher
Summary of Contents for Alliance Laundry Systems Dishwasher
-
Page 1: Installation Instructions
Installation Instructions for Stacked Washers and Dryers Inside... Dimensions... Before You Start... Installation... Installer Checklist ... Back Cover Date Purchased _____________________________ Model Number _____________________________ Serial Number ______________________________ Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com. Keep these instructions for future reference. (If this machine changes ownership, this manual must accompany machine.) www.comlaundry.com Part No. - Page 2 All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING...
-
Page 3: Dimensions
*With leveling legs turned into base. NOTE: Exhaust openings are 4 inch (10.2 cm) metal ducting. 3/8 in. NPT Gas Connection 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 8.0 in. 26.875 in. (68.3 cm) 2.0 in. -
Page 4: Before You Start
5/16 Inch Socket Wrench Duct Tape Teflon Tape (Gas Models) Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Any disassembly requiring the use of tools must be performed by a suitably qualified service person. -
Page 5: Installation
Exhaust Duct Clearance to Combustible Materials NOTE: Shaded areas indicate adjacent structure. 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: For best performance and to minimize vibration or movement, install washer on a solid, sturdy and level floor. - Page 6 Refer to Figure 4. Loosen the locknuts and adjust legs by screwing into or out of unit base. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Wood Block Make sure that the unit does not rock. When unit is level and does not rock, tighten locknuts securely against bottom of unit base.
-
Page 7: Step 3: Connect Fill Hoses
802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: When installing in newly constructed or renovated buildings, it is very important to flush the lines since build-up may have occurred during construction. - Page 8 No. 20617 Fill Hose (8 feet) (2.44 m) No. 20618 Fill Hose (10 feet) (3.05 m) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Risers Risers (or air cushions) may have to be installed if the pipes knock or pound when flow of water stops.
-
Page 9: Step 4: Connect Drain Hose To Drain Receptacle
Refer to Figure 9. 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: End of drain hose must not be below 24 in. (61 cm). -
Page 10: Step 5: (Gas Dryer Only) Connect Gas Supply Pipe
For proper operation at altitudes above 3000 feet (915 m) the natural gas valve spud orifice size must be reduced to ensure complete combustion. Refer to Table 1. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Natural Gas Altitude Adjustments Altitude feet... -
Page 11: Step 6: (Electric Dryer Only) Connect Electrical Plug
NOTE: The wiring diagram is located behind the control panel, inside the control cabinet. 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To reduce the risk of fire, electric shock, serious injury or death, all wiring and... -
Page 12: Grounding Information
208 Volt. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: Branch circuit wire size requirements to laundry room outlet are shown in Table 3 and Table 4. -
Page 13: Connecting Power Cord With Three-Wire Plug
Neutral Wire 1. Disconnect power to dryer. 2. Remove access cover from rear of dryer. Figure 13 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT POWER SUPPLY INTERMEDIATE FUSE BOX (may be omitted if service entrance... -
Page 14: Connecting Power Cord With Four-Wire Plug
8. Reinstall access cover and screw. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Connecting Power Cord with Four-Wire Plug NOTE: Four-wire cord is required for mobile homes or where codes do not permit grounding through neutral. - Page 15 4. Use a strain relief and insert end of power cord through power supply hole. Figure 19 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5. Attach power cord ground (green) wire to rear bulkhead using ground screw removed in Step 3. D697I 6.
-
Page 16: Step 7: Connect Dryer Exhaust System
Refer to Figure 21. DON’T Figure 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT • Locate dryer so exhaust duct is as short as possible. • Be certain old ducts are cleaned before installing your new dryer. -
Page 17: Exhaust Direction
7.87 ft. (2.4 m), as required to meet UL2158, clause 7.3.2A. 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Exhaust System For best drying results, recommended maximum length of exhaust system is shown in Table 5. -
Page 18: Step 8: (Washer Only) Remove The Shock Sleeves And Shipping Brace
Bolts and Lockwashers Figure 22 Reinstall front access panel. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: DO NOT tip washer more than 6 inches (152.4 mm) in any direction after shipping brace has been removed. Shock absorbers may separate and damage to unit may result. -
Page 19: Step 10: Plug In The Washer And Dryer
Use separately fused 15 amp circuits. 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT The dryer is designed to be operated on a separate branch, polarized, three-wire, effectively grounded, 120 Volt, 60 Hertz, AC (alternating current) circuit protected by a 15 Ampere fuse, equivalent fusetron or circuit breaker. - Page 20 Neutral Side Round Grounding Prong Figure 26 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Washer - All Models Except LTSA7A*N2989 Washer requires 120 Volt, 60 Hertz electrical supply and comes equipped with a 3-prong grounding plug.
- Page 21 802715 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: Have a qualified electrician check the polarity of the wall receptacle. If a voltage reading is measured other than that in Figure 27, the qualified electrician should correct the problem.
- Page 22 4. Reinstall the lower front panel. Air Shutter Lockscrew Appliance Main Gas Valve © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING For personal safety, lower front panel must be in place during normal operation.
-
Page 24: Installer Checklist
• Connect Gas Supply Pipe. • Check for Gas Leaks. CHECK Electric Only • Connect Electrical Cords. CHECK © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT • Connect Dryer Washer Only • Remove the Shock SWD833N SWD833N Plain...
