Inside . . .
Safety Information . . . 3
Operation . . . . . . . . . . . 6
Clothing Care . . . . . . . 18
Maintenance . . . . . . . 27
Troubleshooting . . . .30
Para bajar una copia de estas instrucciones
en español, visite www.comlaundry.com.
for your
frontload
washer
www.comlaundry.com
Part No. 802753R2
May 2008
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems DRY2033N
Summary of Contents for Alliance Laundry Systems DRY2033N
-
Page 1: Table Of Contents
frontload Inside . . . Safety Information . . . 3 Operation ... 6 Clothing Care ..18 Maintenance ..27 Troubleshooting . - Page 2 W A R N I N G For your safety and to reduce the risk of fire or an explosion, do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 3: Safety Information
4. Do not add gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water. These substances give off vapors that could ignite or explode. © Copyright 2008, Alliance Laundry Systems LLC of the publisher. 802753 W A R N I N G... - Page 4 5. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using a washing machine or combination washer-dryer, turn on all hot water faucets and let the water flow from...
- Page 5 25. Always read and follow manufacturer’s instructions on packages of laundry and cleaning aids. Heed all warnings or precautions. To reduce the risk of poisoning or chemical burns, keep them out of the reach of children at all times (preferably in a locked cabinet).
-
Page 6: Operation
Operation Before Washing Prepare Wash Load Empty Pockets and Cuffs Make sure all pockets are empty and turn them inside out. One bobby pin, metal or plastic toy, nail or sharp object in a load can catch laundry, cause tears and plug the pump. Facial tissue left in a pocket will produce extreme “lint”. -
Page 7: Loading The Washer
W A R N I N G Do not wash or dry items soiled with vegetable or cooking oils. Some oils may remain after washing and may cause the fabric to catch on fire by itself. Loading the Washer Load Articles •... - Page 8 Cold Water The Cold Wash is ideal for delicate items. Although its cleaning abilities are not as great with hot or warm water, it is useful for colors that bleed easily and for sensitive fabrics. The Cold Rinse is optional in every cycle and is the most beneficial for fabrics.
-
Page 9: Operating Your Washer
Operating Your Washer W A R N I N G To reduce the risk of fire, electric shock, serious injury or death to persons, read the Safety Information section before operating your washer. NOTE: Always follow manufacturer’ s care labels. Determine Proper Cycle NOTE: The cycle times might be longer if a Boosted Hot Wash, if available, is selected. - Page 10 To Wash Clothes IMPORTANT: Before using your new washer, make sure the washer cord is plugged into an appropriate electrical outlet that has the proper grounding (earthing) and polarity. Refer to the washer nameplate and Installation Instructions for proper voltage and Hertz the washer is designed to operate on.
- Page 11 When washing bulky items such as blankets and comforters, use the HANDWASH/DELICATE cycle. The cycle includes 12 minutes of gentle agitation to clean items delicately and thoroughly. The extra rinse cycle may be selected to ensure complete removal of soap residue. A final spin extracts the moisture at a low speed to maintain the load’s balance and minimize wear to the articles.
- Page 12 If items need to be added or removed after a cycle has started, turn the cycle selector knob to the OFF position. Wait until the DOOR light goes off (approximately 45 seconds after cycle has been stopped), open door, add or remove items, and start the cycle again.
- Page 13 DOOR Light When the washer is started, the DOOR light will come on after a short delay. The light will turn off approximately 45 seconds after the cycle is complete. WASH Light This light comes on during the wash part of each cycle.
-
Page 14: Available Washing Cycles
Available Washing Cycles The cycles of your washer include several different settings. Refer to the table below for what can be expected during the cycles that you select. Wash Spin Rinse Spin Extra Rinse (Optional) Spin Final Rinse Spin Spin Final Spin Fluff Wash... -
Page 15: Common Washer Sounds
Wash Spin Rinse Spin Extra Rinse (Optional) Spin Final Rinse Spin Final Spin Fluff Rinse Spin Spin Final Spin Fluff NOTE: The Rinse setting will give a cold rinse when the optional Extra Rinse is selected. Common Washer Sounds Sounds Accelerating Tapping Thumping... - Page 16 Using Your Dispenser Drawer Detergent Bleach Fabric Softener Detergent Compartment The detergent compartment is located on the right side of the dispenser drawer. Refer to compartment 1 of illustration. Use low sudsing, high efficiency (HE) powdered or liquid detergents that are recommended for use with frontload washers.
-
Page 17: Fabric Softener Compartment
Fabric Softener Compartment The fabric softener compartment is located in the left rear corner of the dispenser drawer. Refer to compartment 3 of illustration. Use no more than the maximum level indicated for the fabric softener compartment. Adding more than the maximum amount could result in early dispensing of the product and possible staining of fabrics. -
Page 18: Clothing Care
TLW2019N bleach (when needed) IRON Iron - Dry or Steam Iron High Medium TLW2022N TLW2027N TLW2023N Tumble Dry Cycle Normal DRY2033N Warning Signs High Medium DRY2039N DRY2038N Special Instructions Do not wash TLW2013N TLW2014N Line dry/ Drip dry Hang to dry... -
Page 19: Washing Special Items
Washing Special Items NOTE: Always Follow Manufacturer’ s Care Label Instructions. Bedding Diapers Draperies, Curtains, Slip Covers Pillows (Feather and Down) Rugs Slips and Nightgowns Shoes Small Items Cotton Knits Rayon Knits Synthetic Fiber Knits Knits of Manufactured Fibers • Warm wash and warm rinse. •... - Page 20 Sweaters of Manufactured Fibers Wool Items Permanent Press NOTE: We do not recommend starching in this washer. • Follow directions for comparable knits. • Button sweaters and turn inside out. • Stretch to shape after washing. • Avoid pulling when wet. •...
-
Page 21: Clothing Concerns
Clothing Concerns To keep clothes looking white or bright, use good washing practices at all times to prevent a gradual build-up of soil or water hardness minerals on them. If you notice that your clothes are not as bright as they should be, take corrective measures immediately. - Page 22 Laundry Products Laundry Aids Soak/Pretreat • Use a pretreating agent and soak overnight to remove Products stains and soils. • Always follow manufacturer’s instructions with any pretreat product (Spray ‘N Wash, Shout*, etc.). Detergents/Soaps • Use low-sudsing, high efficiency (HE) detergent (recommended for frontload washers) in your washer.
-
Page 23: Stain Removal
Stain Removal • Many soils will not become stains if treated promptly. Older stains may be difficult or impossible to remove. Hot water will set some stains, particularly protein based stains. Use cold or warm water on these before washing in hot water. •... - Page 24 Stain Chewing Gum Chocolate or Cocoa Coffee, Tea Copier Toner Crayon Deodorants and Anti-Perspirants Egg, Gravy Eye and Face Make-up Fabric Softener Felt-Tip Marker Fruit Juices Glue Grass Grease, Oil Iodine Rub with ice and scrape off excess gum. Place face down on paper towels and sponge with a pretreat product.
- Page 25 Stain Jam, Jelly Ketchup, Tomato-Based Products Lipstick Lotion (Hand, Body, Suntan) Mildew Milk and Milk Products Mustard Nail Polish Paint Perspiration Rust Salad Dressing, Mayonnaise Scorching Shoe Polish Soft Drinks Soy Sauce Scrape off excess. Rinse with cold water. Rub dampened stain with detergent. Apply a pretreat product and launder with an enzyme soaking product.
- Page 26 Stain Tobacco Toothpaste Urine Vomit Wine *Brand names are trademarks of their respective manufacturers. Dampen stain and rub with bar soap. Rinse. If necessary, soak in an all-fabric bleach solution. If stain remains, wash with chlorine bleach (if safe for fabric). Scrape off excess.
-
Page 27: Maintenance
Maintenance Lubrication • All moving parts are sealed in a permanent supply of lubricant or are equipped with oilless bearings. Additional lubrication will not be necessary. Cold Weather Care • If the washer is delivered on a cold day (below freezing), or is stored in an unheated room or area during the cold months, do not attempt to operate it until the washer has had a... -
Page 28: Reinstallation Of Shipping Materials
Filter Screens Check the filter screens in the fill hoses for debris or damage annually. Clean or replace them if necessary. If the washer is filling with water slower than normal, check the filter screens. Clean or replace them if necessary. Order filter screen Part No. -
Page 29: Preventative Maintenance
Preventative Maintenance Follow these guidelines to ensure the washer operates properly. Call for service if you observe any of the following: water of any amount on the floor, an increase in operating noise or water remaining in the wash basket after a cycle. Frequency 1. -
Page 30: Troubleshooting
Troubleshooting Try these troubleshooting tips before making a service call. You may save time and money! Washer Symptom Won’t Fill • Make sure power cord is plugged all the way into the electrical outlet. • Make sure hot and cold water faucets are turned on. •... - Page 31 Washer Symptom Too Many Soap Suds • Laundry load may be oversudsing. Make sure you are using low sudsing, high efficiency • Make sure you are using the amount of detergent recommended on the detergent’s label. • Laundry load may be overloaded. Make sure you are using proper load sizes. Vibrates/Moves Slightly •...
-
Page 32: Contact Information
If you are unable to locate an authorized service center or are unsatisfied with the service performed on your unit, contact: Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, Wisconsin 54971-0990 www.comlaundry.com...
