- Page 1 Automatic Washers Home Laundry W001C W001C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 38900R11 www.comlaundry.com June 2011...
-
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 38900 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 4: Replacement Parts
Shepard Street P.O. Box 990 Ripon, WI 54971-0990 Phone: (920) 748-3950 for the name and address of the nearest authorized parts distributor. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 5: Installation
71.1 cm (28 in.) 56.2 cm (22.13 in.) 1 cm 65 cm 71 cm (0.4 in.) (25.625 in.) (28 in.) TLW2075N *With leveling legs turned into base. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 6: Before You Start
827 kPa (20 to 120 pounds per square inch). For more detailed information, refer to section on Water Supply Requirements. D074I D074I Wrench Screwdriver Pliers Level Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 7: Installing The Washer
This will prevent damage to washer components. NOTE: Refer to your Operating Instructions for reinstalling shipping brace and shipping plug. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 8: Step 3: Connect Fill Hoses
All hoses should be checked on a monthly basis for any visible signs of deterioration. Any hose showing the signs of deterioration listed above should be replaced immediately. All hoses should be replaced every 5 years. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 9: Step 4: Connect Drain Hose To Drain Receptacle
Standpipe Adapter Tie-Down Strap Standpipe 5.08 cm (2 in.) or 4 cm (1-1/2 in.) W324I Diameter Retainer Clamp Drain Hose Sleeve Standpipe Adapter Figure 6 Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... - Page 10 562P3 Siphon Break Kit Standpipe Drain Hose TLW1962N Figure 8 TLW1962N Drain Hose Standpipe (Standpipes higher than 122 cm [4 feet] are not recommended) Tie-Down Strap Standpipe Adapter Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900...
-
Page 11: Sink Installation
W329I Tie-Down Strap (Tape if necessary) Standpipe Adapter TLW1963N Drain Hose Tie-Down Strap or Wire Tie Figure 10 Cabinet Top Hinge Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 12: Step 5: Position And Level The Washer
Figure 11 damaged. Verify that washer doesn’t rock. W179I Level Locknut Leveling Leg Rubber Cup Washer Base Figure 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 13: Step 6: Connect The Washer To Electrical Power
NOTE: The agitator should not be removed except for service. The washtub is designed to be self- cleaning. W391I W391I Figure 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 14: Electrical Requirements
Hertz the washer is designed to operate Round Grounding Prong on. Refer to Figure 18. Neutral Figure 17 DO NOT OPERATE OTHER APPLIANCES ON THE SAME CIRCUIT. DO NOT OVERLOAD CIRCUITS! © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 15: 120 Volt/50 Hertz
60 Hertz single-phase electrical circuit protected by a by a qualified electrician. 10 ampere fuse, equivalent fusetron or circuit breaker. DO NOT OPERATE OTHER APPLIANCES ON THE SAME CIRCUIT WHEN THE WASHER IS OPERATING. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... - Page 16 Standard IEC 60335-1, clauses 24.3 and 22.2. Gap is defined as the minimum contact separation of each pole in the switch between the “ON” and “OFF” positions. Figure 19 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900...
-
Page 17: Water Supply Requirements
WATER the washer. MIXING VALVE W187I Water Supply Faucets Cold Water Connection Hot Water Connection Fill Hoses Figure 20 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 18: Risers
Refer to Figure 21. W005I W005I Risers (Air cushions) Water Supply Faucets Figure 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 38900... -
Page 20: Installer Checklist
Washer. Hoses. COLD TLW1988N TLW1988N W391I TLW2056N CHECK CHECK • Connect Drain Hose • Check Lid Switch. to Drain Receptacle. W376I W376IE0A CHECK CHECK W315IE0A W315IE0A © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
