Page 1 Washer-Extractor Refer to Page 11 for Model Numbers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. F8615401ENR4 www.alliancelaundry.com May 2019...
Page 3 Any problems or conditions not understood should be reported to the dealer, distributor, service agent or the manufacturer. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 4: Table Of Contents
Special Vend....................20 © Copyright 2019, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
Page 5 Vend Price #4 AtS 4..................46 Vend Price #5 AtS 5 ..................46 Vend Price #6 AtS 6 ..................47 Vend Price #7 AtS 7..................47 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 6 Special Vend 1 Price #8 SP1 18 ..............73 Special Vend 1 Price #9 SP1 19..............73 Special Vend 1 Wash Status Agitate Steps Added Minutes SP1 20....73 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 7 OPL Mode Enable oPL 1................115 OPL Delayed Start oPL 2................. 115 OPL Display Power Save oPL 3..............116 Drop Off Mode droP..................116 Out of Order oUt..................117 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 8 Machine Configuration #4 Display Test d 32 ..........140 Machine Configuration #5 Display Test d 33..........151 Low Level Pressure Switch Test (Heat Models) d 43........151 Factory Test Cycle................... 151 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 9 Error Codes..................157 Manual Rapid Advance...............167 How to Enter Rapid Advance............... 167 How to Exit Rapid Advance Feature............. 167 Default Cycles..................168 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 10: Introduction
SCL020NC SCT020NX SCZ020WT SCA020NH SCH020WF SCL020ND SCT020NY SCZ020WV SCA020NL SCH020WH SCL020NE SCT020WC SCZ020WX SCA020NQ SCH020WL SCL020NF SCT020WD SCZ020WY SCA020NT SCH020WQ SCL020NH SCT020WE SCA020NV Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 11 DCJ030WY SCH030NL SCK030NY SCL030WH SCT030WX SCA030NC SCH030NQ SCK030WC SCL030WL SCT030WY SCA030ND SCH030NT SCK030WD SCL030WQ SCA030NE SCH030NV SCK030WE SCL030WT SCA030NF SCH030NX SCK030WF SCL030WV SCA030NH Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 12 DCJ040WY SCH040NL SCK040NY SCL040WH SCT040WX SCA040NC SCH040NQ SCK040WC SCL040WL SCT040WY SCA040ND SCH040NT SCK040WD SCL040WQ SCA040NE SCH040NV SCK040WE SCL040WT SCA040NF SCH040NX SCK040WF SCL040WV SCA040NH Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 13 SCH080WQ SCK080WQ SCT080WT DCJ080WT SCA080WT SCH080WT SCK080WT SCT080WQ DCJ080WV SCA080WV SCH080WV SCK080WV SCT080WV DCJ080WX SCA080WX SCH080WX SCK080WX SCT080WX DCJ080WY SCA080WY SCH080WY SCK080WY SCT080WY Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 14 DCJ100WQ SCA100WQ SCH100WQ SCK100WQ SCT100WT DCJ100WT SCA100WT SCH100WT SCK100WT SCT100WQ DCJ100WV SCA100WV SCH100WV SCK100WV SCT100WV DCJ100WX SCA100WX SCH100WX SCK100WX SCT100WX DCJ100WY SCA100WY SCH100WY SCK100WY SCT100WY © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 15: Serial Plate Location
Alliance Laun- dry Systems at +1 (920) 748-3950 for the name and address of the nearest authorized parts distributor. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 16: Glossary Of Terms
This network link allows an owner to program, collect data and run diagnostics on any machine. For detailed information on network communications, refer to the network instructions. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 17: Control Identification
Features available include an added prewash, extra wash time, an added extra rinse, extra rinse time and a warm rinse temperature. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 18 13. Ultra 14. Deluxe 15. START (enter) 16. Delicates Bulky 17. Cold 18. Permanent Press 19. Warm 20. Normal 21. Hot 22. Regular Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 19: Display Identification
Deluxe LED Deluxe LED is lit when the Option Deluxe modifier is selected. Ultra LED Ultra LED is lit when the Option Ultra modifier is selected. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 20: Special Features
This feature allows the owner to return the control back to the Ready Mode if the full vend price has not yet been satisfied, while in Partial Vend Mode. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 21: Low Power/Auto-Shutdown Option
If the Suds Removal Routine Extra Time parameter is disabled, the cycle time will continue to count down while in a Suds Re- moval Routine. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 22: Machine Operation
After the first Fill Step, all key presses will be ignored al- lowing the machine to go through the complete cycle. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 23: Door Unlocking Mode
Any coin entered after the first Fill step will be added to the total coin counter, but the user will not be able to change cycles or cycle modifiers. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 24: Pause Mode
If the control continues to see an overflow level after five (5) minutes has been reached with the door locked, the control will enter Machine Error Mode with an Over- flow Error. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 25: Lockout Mode
For details on enabling OPL Mode, refer to OPL Parameters oPL-. For more detailed information on using the Communications Mode feature, refer to Communications. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 26: Opening The Top Cover
15 seconds to begin programming. If the appropriate keypads CHM1357R_SVG 1. Top Cover Lock 2. Top Cover 3. Top Cover Hinge 4. Peg Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 27: Entering The Manual Mode
The features in the group cannot be entered. Press the Warm (<) keypad until the control returns to the mode that was active before Manual Mode was entered. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 28 Manual Reset Manual Reset Mode. diAg Press the START keypad to Diagnostic enter Diagnostic Tests. Refer to Tests Diagnostic Tests flowchart. CHM1903REN_SVG Figure 4 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 29: Programming Control
Start Pulse Mode oFF, 128, 192 PLSNod Programmable Output 0-13 AtyPE Type Default Cycle dFtCyC Card Reader Display CArd on/oFF Control (If Equipped) Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 30 — E Sd- Error Menu (1) E Sd 1 Slow Drain Detection on/oFF (2) E Sd 2 Slow Drain Detection 0-255 Adjust Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 31 CooLdn perature (Heat Models) Low Water Level 1-30 FL Lo Medium Water Level 1-30 FL NEd High Water Level 1-30 FL Hi Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 32 Refer to Table 9 SP1 1 Week Enable Special Vend 1 Start Mi- 0-59 SP1 2 nute Special Vend 1 Start 0-23 SP1 3 Hour Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 33 Special Vend 1 Ultra 0-65,535 SP1 24 Vend Price Special Vend 1 Deluxe 0-31 SP1 25 Options Special Vend 1 Ultra 0-31 SP1 26 Options Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 34 — CyCLE5 Cycle 6 — — CyCLE6 Cycle 7 — — CyCLE7 Cycle 8 — — CyCLE8 Cycle 9 — — CyCLE9 Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 35 Auxiliary Valve Present — 0, 1 MCP 5 Unused — MCP 6 Unused — MCP 7 Thermistor Present — 0, 1 MCP 8 Table 1 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 36 OPL Display Power oPL 3 on/oFF Save Drop Off Mode droP on/oFF Out of Order on/oFF * Defaults may very according to market. Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 37: Manual Programming Navigation
Vend Price #7 Coin #1 Value AtS 8 dEn 2 Vend Price #8 Coin #2 Value AtS 9 continued Vend Price #9 CHM1886R_SVG Figure 5 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 38 E nF- E nF 1 No Water Flow Error No Water Flow Error E nF 2 No Water Flow Error Time continued CHM1801R_SVG Figure 6 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 39 Open Thermistor Error Display (Heater Models) E SH Shorted Thermistor Sensor Error Display (Heat Models) E StHt Slow to Heat Error (Heat Models) continued CHM1730R_SVG Figure 7 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 40 Programming Control Figure 8 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 41 Start Hour dLS 6 End Month dLS 7 End Day of Week dLS 8 End Week of Month dLS 9 continued End Hour CHM1732R_SVG Figure 9 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 42 Special Vend 1 Price #3 Special Vend 1 Heavy Options SP1 14 SP1 27 Special Vend 1 Price #4 Special Vend 1 Extract Speed Limit continued CHM1888R_SVG Figure 10 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 43 Programmable Cycle CyCLE7 Custom Message #2 Time Display Enable Cycle 7 CyCLE8 nCyCtd Cycle 8 No Cycle Time Display CyCLE9 Cycle 9 continued CHM1889_SVG Figure 11 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 44 MCP 7 Unused MCP- Machine Configuration Parameters Menu MCP 8 Thermistor Present continued CHM1835R_SVG Figure 12 Ht dP © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 Heating Indicator Decimal DO NOT COPY or TRANSMIT Point Enable (Heat Models)
Page 45 3 AtS do OPL Display Power Save Vend Price Display Override oPL- OPL Parameters droP Drop Off Mode Out of Order CHM1846R_SVG Figure 13 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 46: Vend Price #1 Ats 1
The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 47: Vend Price #5 Ats 5
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 48: Vend Price #8 Ats 8
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 49: Cycle Modifyer Ultra Vend Price Adder Acnp 2
5. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 50: Coin #1 Value Den 1
5. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 51: Start Pulse Mode Plsnod
7. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 52: Default Cycle Dftcyc
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 53: Card Reader Display Control (If Equipped) Card
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 54: Audio Signal Audio
Audio Signal (AUdio) Chart Coin/Card Start Mode/ Serial or Net- Vend or Start Signal Value Remove Card work Vend Pulse End of Cycle Key Pressed Table 5 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 55 Start Mode/ Serial or Net- Vend or Start Signal Value Remove Card work Vend Pulse End of Cycle Key Pressed *Factory default setting Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 56: Network Node Number Node
9. Press the START (enter) keypad when the correct status ap- pears in the display. The next Error Code Programming op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 57 Helps til another keypad has been pressed or one (1) allow for locations with poor minute passes. draining conditions. Table 6 continues... Table 6 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 58 Shown after the door is opened or a key is pressed. This error will remain displayed un- til another keypad has been pressed or one minute passes. Table 6 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 59: Temperature Fahrenheit/Celsius (Heat Models) Tp F C
The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 60: Cool Down Water Temperature (Heat Models) Cooldn
The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 61: Flush Out Drain Valves For Fill Steps (Models With Pump Drain) Flsh V
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 62: Tub Fill Delay (If Equipped) Tubfld
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 63: Daylight Savings Option Menu Dls
7. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 64: Special Vend 1 Days Of Week Enable Sp1 1
A number will appear in the display that corresponds days and enter the number found in the value column. SP1 1, E Ld 1 and LUC 1 VALUE THUR ON/OFF Table 9 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 65 Programming Control SP1 1, E Ld 1 and LUC 1 VALUE THUR ON/OFF Table 9 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 66 Programming Control SP1 1, E Ld 1 and LUC 1 VALUE THUR ON/OFF Table 9 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 67 Programming Control SP1 1, E Ld 1 and LUC 1 VALUE THUR ON/OFF Table 9 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 68 Programming Control SP1 1, E Ld 1 and LUC 1 VALUE THUR ON/OFF Table 9 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 69: Special Vend 1 Start Minute Sp1 2
4. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 70: Special Vend 1 Start Date Sp1 4
4. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 71: Special Vend 1 End Date Sp1 8
4. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 72 The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 73 4. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 74: Special Vend 1 Wash Status Agitate Steps Added Minutes Sp1 20
4. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 75: Special Vend 1 Deluxe Vend Price Sp1 23
The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 76: Special Vend 1 Extract Speed Limit Sp1 27
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 77: Special Vend 4 Days Of Week Enable Sp4
8. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 78: Cycle Modifier Deluxe Options Cnp 2
Extra Rinse Extra Wash Configuration Warm Final Steps Agitate Steps Agitate Value Rinse (1) Time (2) Time (3) Extra Rinse (4) Prewash (5) Table 11 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 79 (4) Modifier #2 Active Steps Enabled; turns on all Cycle Steps with Active State set to Nod 2 (5) Modifier #1 Active Steps Enabled; turns on all Cycle Steps with Active State set to Nod 1 Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 80: Cycle Modifier Ultra Options Cnp 3
Extra Rinse Extra Wash Configuration Warm Final Steps Agitate Steps Agitate Value Rinse (1) Time (2) Time (3) Extra Rinse (4) Prewash (5) Table 12 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 81: Cycle Modifier Deluxe Additional Wash Time Cnp 4
The new value is saved and the next op- display. tion will appear in the display. 4. When CNP- appears in the display, press the START (enter) keypad. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 82: Cycle Modifier Deluxe Additional Rinse Time Cnp 5
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 83: Cycle Modifier Ultra Additional Rinse Time Cnp 7
CyCEnd will not be displayed. To in- sert a step at the end of the cycle, first go to this display and then press the Regular key pad. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 84 Step 50 up a location. Step 50 is reset as an invalid step. Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 85: Cycle Programming Cycle
3-255 Motor On Time (seconds) rotAtE XXFi09 3-255 Motor Off Time (seconds) PAUSE XXFi10 Table 14 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 86 XXFi15 on/oFF Cold Hard Fill Valve (if so equipped) C HArd XXFi16 on/oFF Auxiliary Fill Valve (if so equipped) AUX FL XXFi17 on/oFF Table 14 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 87 3-255 Motor On Time (seconds) rotAtE XXFi09 3-255 Motor Off Time (seconds) PAUSE XXFi10 Table 15 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 88 XXFi15 on/oFF Cold Hard Fill Valve (if so equipped) C HArd XXFi16 on/oFF Auxiliary Fill Valve (if so equipped) AUX FL XXFi17 on/oFF Table 15 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 89 CoMP 1 XXSU15 on/oFF Compartment 2 CoMP 2 XXSU16 on/oFF Compartment 3 CoMP 3 XXSU17 on/oFF Compartment 4 CoMP 4 XXSU18 on/oFF Table 16 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 90 Step 2 Agitate Step Step 3 Supply Step Acts as own step Step 4 Supply Step Acts as own step Step 5 Extract Step Table 17 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 91 0.06-1.27 for 80 pound • 0.06-1.27 for 100 pound Reversing rEvErS XXAg10 rEv on/no rEv Drain #1 drAin1 XXAg11 on/oFF Drain #2 drAin2 XXAg12 on/oFF Table 19 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 92 XXAg15 on/oFF External Output #2 oUtP 2 XXAg16 on/oFF External Output #3 oUtP 3 XXAg17 on/oFF External Output #4 oUtP 4 XXAg18 on/oFF Table 19 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 93 0.06-1.27 for 80 pound • 0.06-1.27 for 100 pound Reversing rEvErS XXSo10 rEv on/no rEv Drain #1 drAin1 XXSo11 on/oFF Drain #2 drAin2 XXSo12 on/oFF Table 20 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 94 XXSo15 on/oFF External Output #2 oUtP 2 XXSo16 on/oFF External Output #3 oUtP 3 XXSo17 on/oFF External Output #4 oUtP 4 XXSo18 on/oFF Table 20 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 95 Cold Hard Fill Valve (if so equipped) C HArd XXCL14 on/oFF Auxiliary Fill Valve (if so equipped) AUX FL XXCL15 on/oFF Table 21 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 96 XXCL16 on/oFF External Output #2 oUtP 2 XXCL17 on/oFF External Output #3 oUtP 3 XXCL18 on/oFF External Output #4 oUtP 4 XXCL19 on/oFF Table 21 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 97 XXdr11 on/oFF External Output #2 oUtP 2 XXdr12 on/oFF External Output #3 oUtP 3 XXdr13 on/oFF External Output #4 oUtP 4 XXdr14 on/oFF Table 22 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 98 For this reason all tion. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 99 It is recommended not to reduce spin times within the default cy- cles. Better machine performance is achieved with the default spin times. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 100 This step may be used to allow the machine to be rinsed out be- fore adding the next load. An additional vend could be charged © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 101 Modifier Key programmed to enable steps to perform this functionality by setting the steps as Mod 1 or Mod 2. Refer to Cycle Modifier Programming Menu CNP-. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 102 XXAU06 on/oFF External Output #2 oUtP 2 XXAU07 on/oFF External Output #3 oUtP 3 XXAU08 on/oFF External Output #4 oUtP 4 XXAU09 on/oFF Table 25 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 103: Hold Step Custom Messages Menu Cness
8. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 104: No Cycle Time Display Ncyctd
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 105: Cycle Pause Resume Cycpau
The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 106: Low Power/Auto Shutdown 2 Days Enable Lpas 2
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 107: Low Power/Auto Shutdown 4 Days Enable Lpas 4
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 108: Ir Access Enable Ira En
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 109: Manual Diagnostics Enable Diagen
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 110: Machine Configuration Parameters Menu Mcp
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 111: Heating Indicator Decimal Point Enable (Heat Models) Ht Dp
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 112: Water Temperature Indicator Tp Ind
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 113: Programmable Close Door Display Pcdl
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 114: Programmable Open Door Display Podl
6. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 115: Opl Parameters Opl
8. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 116: Opl Delayed Start Opl 2
8. Press the START (enter) keypad when the correct value ap- pears in the display. The new value is saved and the next op- tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 117: Drop Off Mode Drop
The new value is saved and the next op- tion will appear in the display. tion will appear in the display. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 118: Collecting Audit Information
Cycles Total Number of Run Hours rUnHrS Resettable Coin #1 Count rCoin1 Resettable Coin #2 Count rCoin2 Resettable machine Cycle rCyCLE Count Table 29 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 119: Manual Reset
6 Cycle 7 rCyC 7 Cycle 8 rCyC 8 Cycle 9 rCyC 9 All Cycles ALLCyC All Cycles and Global Pro- gramming Parameters Table 30 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 120: Machine Diagnostic Functions
CLoSE/ door/ FbS oP/ FbS CL External Output Test d 23 ES X/ ES Xon Water Purge Test CLoSE/ door/ PUrgE / FLUSH d 24 Table 31 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 121 Machine Configuration #5 Display Test d 33 E XXX Low Level Pressure Switch Test (Heat d 43 CLoSE/ door/ LP oP/ LP CL Models) Table 31 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 122: Diagnostics
FL XXX C1 XX d 18 Show Drain Time Test d 11 Coin Drop #2 Input Test dr XXX C2 XX continued CHM1914R_SVG Figure 14 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 123 Machine Configuration #5 Display Test Water Leak Detection Test E XXX d 43 d 26 Low Level Pressure Switch Test Water Level Test (Heat Models) CHM1737R_SVG Figure 15 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 124: Diagnostic Test Descriptions
# of coins counter that is accessed in the audit feature. To exit the test, press the Warm (<) keypad. The control will re- turn to the Testing Mode. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 125: Vend Header Present Status Test D 12
To enter, press the START (enter) keypad. The display will show the switch is open or FbS CL if the switch is closed. FL XXX. The XXX will be the average fill time in seconds. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 126: External Output Test D 23
L XXX where XXX is the water level in 0.1 inch precision where a value of 05 equals 0.5 inches. If the rightmost decimal point is lit, the value is negative. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 127: Dc Bus Voltage Test D 27
Each column of the table below contains a unique combination of the words YES and NO that indicates if that column’s connection is present. Table 32 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 128 Machine Diagnostic Functions Table 32 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 129 Machine Diagnostic Functions Table 32 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 130: Machine Configuration #2 Display Test D 30
Refer to Table 33 . 60 Pound Cabinet Hardmount 80 Pound Cabinet Hardmount 100 Pound Cabinet Hardmount Table 33 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 131: Machine Configuration #3 Display Test D 31
Testing Mode. Refer to How to Enter Di- to Table 34 . agnostic Testing Feature at the beginning of this section. Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 132 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 133 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 134 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 135 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 136 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 137 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 138 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 139 Machine Diagnostic Functions Table 34 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 140 Machine Diagnostic Functions *0 = Not Present, 1 = Present Table 34 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 141: Machine Configuration #4 Display Test D 32
XXX with XXX representing a configuration value as shown in is set on or off when the value is displayed. Table 35 . Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 142 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 143 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 144 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 145 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 146 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 147 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 148 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 149 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 150 Machine Diagnostic Functions Table 35 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 151: Machine Configuration #5 Display Test D 33
Once the door is closed the display will show LP oP if the switch is open or LP CL if the switch is closed. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 152: Factory Test Cycle
Coin Drop Test 1st x is number of Coin Drop #1 coins. CxCx 2nd x is number of Coin Drop #2 coins. Table 36 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 153 Auxiliary Fill Auxiliary fill valve is turned on. Test skip- AU vAL ped if not equipped with valve. Table 36 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 154 The user cannot navigate to a previous step. Table 36 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 155 This test is skipped if the load did not bal- ance for the speed or the machine is model does not allow this speed. Table 36 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 156 Power Down Test Disconnect then reconnect power to the machine to exit the factory test. The user cannot navigate to a previous step. Table 36 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 157 No Card Reader Communication Communication failure. Power down, power up and try again. If er- EC19 ror persists, replace control or card reader. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 158 The control sounds an alarm tone for 15 seconds. To clear the error, disconnect and then reconnect power to the ma- chine. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 159 The decimal point can be cleared by pressing the START (en- ter) keypad 3 times in a period of 5 seconds, or by cycling the power to the machine. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 160 Correct in- operative door locking system. Power down machine to clear error. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 161 The control sounds an alarm tone for 15 seconds. To clear the error, wait 1 minute, open the door, or press any key- pad. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 162 The control sounds an alarm tone for 15 seconds. To clear this error either power down the machine or simultaneous- ly press the Normal and Warm keypads. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 163 The control sounds an alarm tone for 15 seconds. Eio 45 To clear this error either power down the machine or simultaneous- ly press the Normal and Warm keypads. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 164 The control sounds an alarm tone for 15 seconds. Eio 57 To clear this error either power down the machine or simultaneous- ly press the Normal and Warm keypads. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 165 Power down to clear error. Check for lint build-up on heat sink on drive board. Replace drive board if error persists. Table 37 continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 166 E d 66 error persists. Motor Initialization Error Hardware failure. Power down to clear error. Replace drive board if E d 67 error persists. Table 37 © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 167 NOTE: The Rapid Advance option must be turned on for Rapid Advance to work. How to Exit Rapid Advance Feature Advance through the cycles until reaching the Ready Mode. © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 168 (Mod1 Supply Hold ES1, Delay Time ex- pires Agitate Main- Refill Hold tain Heat Cool- Cold Evac down Global Drain Evac Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 169 21 Ds Fill Cold Hold Flush 3 (Dis- Level abled) 22 Ds Agitate Refill Hold 23 Ds Drain Evac 24 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 170 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 171 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 172 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 173 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 174 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 175 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 176 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 177 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 178 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 179 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 180 Supply Hold ES3, Delay ES4, Time ex- pires 28 En Agitate Refill Hold Final 29 En Extract Evac tract Shake- 30 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 181 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 182 Supply Hold ES3, Delay ES4, Time ex- pires 29 En Agitate Refill Hold Final 30 En Extract Evac tract Shake- 31 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 183 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 184 Supply Hold ES3, Delay ES4, Time ex- pires 29 En Agitate Refill Hold Final 30 En Extract Evac tract Shake- 31 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 185 Extract Evac Rinse 13 En Fill Cold Hold Flush Level 14 En Agitate Refill Hold 15 En Drain Evac 16 Ds Extract Evac Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...
Page 186 Supply Hold ES3, Delay ES4, Time ex- pires 29 En Agitate Refill Hold Final 30 En Extract Evac tract Shake- 31 En Agitate Evac Refill © Copyright, Alliance Laundry Systems LLC - Part No. F8615401ENR4 DO NOT COPY or TRANSMIT...

This manual is also suitable for:

Dcj020nc Dcj020nd Dcj020ne Dcj020nf Dcj020nh Dcj020nl ... Show all

Alliance Laundry Systems DCG020ND Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems DCG020ND

Summary of Contents for Alliance Laundry Systems DCG020ND

This manual is also suitable for:

Table of Contents
