Alliance Laundry Systems DWA021*A Service

Hide thumbs
Table of Contents

Advertisement

Quick Links

Automatic
Washers
Refer to Page 6 for Model Numbers
W138P
Part No. 37593R1
www.comlaundry.com
July 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWA021*A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems DWA021*A

Summary of Contents for Alliance Laundry Systems DWA021*A

  • Page 1 Automatic Washers Refer to Page 6 for Model Numbers W138P Part No. 37593R1 www.comlaundry.com July 2004...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 4 Timer No. 31111 Cycle Sequence (Short Cycle)...90 Timer No. 34601P Cycle Sequence (Long Cycle).91 Timer No. 34602 Cycle Sequence (Long Cycle)...92 Section 9 – Internal Wiring of Washer Motor Switch ..............93 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 5: Section 1 - Safety Information

    • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the product is properly grounded and to reduce the risk of fire, electric shock, serious injury or death. W006R2 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 6: Locating An Authorized Servicer

    Locating an Authorized Servicer Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs. Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician and using authorized factory parts.

  • Page 7: Section 2 - Introduction

    Model and serial numbers are located on nameplate(s) as shown. Nameplate NOTE: Coin slide and coin drawer shown for illustration purposes only. W233SE3A 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 8: Model Identification

    EA2921*A EA3820*A EA3821*A EA3920*A EA3921*A JA0110* ZA2020*A ZA2110*A ZA2120*A ZA3820*A ZA3821*A * Add suffix letter to model number to designate color. L – Almond W – White © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 9: Section 3 - Troubleshooting

    • Test switch and replace if inoperative. Clogged pressure hose. • Remove and clean or replace hose. Broken, loose or incorrect wiring. • Refer to appropriate wiring diagram. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 10: No Warm Water

    Drain hose fits tight in standpipe or drain. Water in pressure hose. • Blow air through hose to remove water. Broken, loose, shorted or incorrect wiring. • Refer to appropriate wiring diagram. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 11: Timer Does Not Advance (Mechanical Timer Models Only)

    • Timer is designed to pause when going from spin into rinse to allow the washtub to stop spinning before filling. Make sure that timer has advanced into fill portion of rinse cycle. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 12: Motor Does Not Run

    • Refer to Paragraph 9. Bind in pump. • Replace pump. Loading door is open or door switch is inoperative. • Close door or test switch and replace if inoperative. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 13: Constant Agitation

    Check that all these components are able to move freely. will not turn. Correct binding component. Incorrect voltage. Contact local utility company, or have a qualified electrician check power supply. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 14: Slow Spin Or No Spin

    Excessive wear on brake pads, or missing brake Replace brake pads and brake assembly. pads. Shorted or incorrect wiring. Refer to appropriate wiring diagram. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 15: Washer Stops In Cycle; Quits After A Couple Loads; Is Intermittent

    Drain hose out of clamp in back of cabinet. • Remove washer front panel and install drain hose into clamp. Inoperative water pump. • Replace pump. Obstruction in outer tub outlet hose. • Remove obstruction. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 16: Excessive Vibration

    • Replace gasket. Obstruction in drain causing water to come over top • Remove obstruction. of outer drain tub cover. Tub-to-pump hose leaking at clamp. • Tighten clamp. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 17: Troubleshooting Coin Drop

    IMPORTANT: Do not bend or damage mechanical parts within coin drop. Additional coins following path to sensor Coin in Coin Slot Coin Drop Sensor DRY2B Figure 1 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 18 Refer to Paragraph 63 prevent coins from for instructions on following through cleaning drop. required check stages of drop.) Replace coin drop TLW305S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 19: Electronic Control Models

    NOTE: If replacing an inoperative electronic control due to burnt pin(s) on the 6-pin wire harness connector block, it may be due to damaged terminals in the harness connector. Replace the control wire harness with the control to avoid repeated damage. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 20: Cannot Perform Infrared Communication

    Check the following: – (IR) disabled by manual prog. – Is the (IR) on the control covered or blocked? – If needed, change electronic W367S control board. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 21: Coins Ignored When Entered

    Retest again, if not successful run test again. run test again. the following is the problem: – Replace coin drop. If the problem still exists: – Replace electronic control. W368S 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 22: Electronic Control Has No Visible Display

    "FS2" the electrical outlet to the electronic control. white? NOTE: This voltage check confirms that main power is present to the control. Replace electronic control. W369S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 23 Section 3 Troubleshooting (Electronic Control Models) Notes 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 24: No Fill Analysis

    On mixing valve check and replace: – Inlet screens. – Wiring and connections. – Replace coils or mixing valve. – Check thermal protect and wiring W370S from thermal protect to "H3-3" © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 25: Electronic Control

    H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR W371S 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 26: No Motor Run - Agitate Analysis

    BLU "H3-4" to "H3-2" refer to Section 7 RED "H3-6" to BRN or Paragraph 6. "H3-2" is there voltage? Replace electronic control board. W372S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 27 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR W373S 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 28: No Motor Run - Spin Analysis

    BLU "H3-4" to "H3-6" refer to Section 7 BRN "H3-2" to "H3-6", or Paragraph 6. is there voltage? Replace electronic control board. W374S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 29 "OFF" WHEN MACHINE "OFF" WHEN MACHINE IS RUNNING IS RUNNING SCHEMATIC SCHEMATIC SERVICE SERVICE DOOR DOOR COIN DROP COIN DROP COIN VAULT COIN VAULT SENSOR SENSOR W375S 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 30: Overflow Analysis

    If this happens, replace the mixing valve. Check for a locked open mixing valve. W376S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 31 H3-6 START AGITATE AUDIT CONTROL H3-2 SPIN CIRCUIT H3-3 AVAILABLE OUTPUT TRANSISTOR IS "OFF" WHEN MACHINE IS RUNNING SCHEMATIC SERVICE DOOR COIN DROP COIN VAULT SENSOR W377S 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT\...

  • Page 32: Audit Switch Function Analysis

    – Machine/cycle var reports. Check for proper wiring and connections. After wiring has been confirmed correct, replace electronic control board. D216S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 33: Section 4 - Grounding

    W011GE3A Figure 2 28. POWER CORD TO CONTROL HOOD, CONTROL HOOD TO THE CONTROL PANEL FRAME Refer to Figure 3. Ground Wires Ground W285SE3A Wires Figure 3 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 34: Control Hood Wire Harness To Top Left Rear Corner Gusset Of Cabinet

    Corner Wire Gusset Ground Screw Ground Wires W013GE3A Figure 4 30. WIRE HARNESS TO MOTOR Refer to Figure 5. Ground Wire Harness Connection Block W329SE3C Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 35: Section 5 - Service Procedures

    NOTE: Refer to appropriate wiring diagram when reconnecting wire harnesses, ground and switch leads. W284SE1A Figure 6 Disconnect Blocks Pressure Ground Ground Disconnect Switch Wires Wires Blocks Indicator Light W285SE3B Figure 7 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 36 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 37 (2) Press in on locking tabs and unplug harness disconnect blocks from backside of electronic control assembly. Refer to Figure 9. Electronic Control Control Attaching Screws (2 per side) W493SE3A Figure 9 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 38 NOTE: Refer to appropriate wiring diagram when rewiring switches and indicator lights. (5) Remove control panel overlay by peeling it from control panel frame. NOTE: Control panel overlay has an adhesive backing. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 39: Timer Assembly

    (located on each side of terminal block plug). Refer to Figure 11. Then pull terminal block plug away from timer. (5) Disconnect ground wire from terminal on timer. Refer to Figure 11. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 40 Lockwasher Timer Plate Attaching Screw Setscrew Timer Knob Screws Clutch W238SE1A Timer Case Figure 12 Timer Attaching Timer Screw W239SE1A Figure 13 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 41: Meter Or Timer Case Assembly

    (8) Remove carriage bolts and locknuts holding meter case to cabinet top. (9) Carefully remove meter case and gasket from cabinet top. Timer Case Screw Timer Case Attaching Hardware W240SE1A Figure 14 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 42: Coin Drop

    Use a 7/16 inch socket with No. 310P4 1/4 inch Ratchet Extension Tool and remove two locknuts holding coin drop to front of meter case. Refer to Figure 16. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 43 Use a 7/16 inch socket with No. 310P4 1/4 inch Ratchet Extension Tool and remove two Coin Drawer locknuts holding coin drop to front of meter Housing W410SE3A case. Refer to Figure 18. Figure 19 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 44 Carefully pull front of coin drop up and forward, so the drop’s front face plate clears the W413SE1A meter case’s door switch bracket. Refer to Figure 22 Figure 23. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 45 Reconnect wires by referring to the wiring W416SE1A diagram located inside the control hood. Figure 25 j. Reinstall service door switch and wire harness into meter case bracket. Refer to Figure 17. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 46 Reinstall multiplier and reconnect wires. Refer to Figure 18. l. Close and lock service door. Coin Drop Front Face Plate Front Plate of Meter Case W417SE1A Figure 26 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 47: Drain Hose Elbow

    NOTE: Reverse procedures when installing loading door. Loading Door Hinge Attaching Screws Elbow Attaching Screws Hose Drain Clamp W242SE1A Hose Figure 27 Right Left Hinge Hinge W287SE1A Figure 28 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 48 Section 5 Service Procedures PROCEDURE ONE Door Front W288SE3A PROCEDURE TWO Door Front W289SE3A PROCEDURE THREE Door Front W290SE3A Figure 29 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 49: Front Panel

    If idler spring is overstretched, washer and remove brace. operation will be affected. Cabinet Top Hold Down Screws Hold-Down Clip Front Panel Screws W292SE3A Figure 30 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 50 Figure 33. Clamps W305SE1A d. Tighten three screws to 35 inch pounds max. Figure 31 DO NOT overtighten screws! e. Reinstall motor and pump assembly into washer. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 51: Idler Lever And Pulley

    Figure 31. the out-of-balance switch. This condition will persist until lubricant is removed. Switch Attaching Screw Locking Motor Mount Motor Connection Attaching Screws Switch Block W333SE3A Figure 32 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 52: Motor Drive Pulley

    Lay motor assembly on its side. NOTE: To remove pulley, support motor shaft (to prevent bending shaft) and drive out pulley roll pin. Refer to Figure 34. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 53 Pump Legs Motor Motor Embosses Shaft (Clean shaft and apply a thin film of lubricant, No. 03637P) Motor Emboss Motor Assembly W272SE3A Figure 33 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 54 Motor Mount Post Shoulder Bolt Locknut Idler Spring Idler Clip Shaft Belt Washer (Agitate and (Felt) Spin) Washer (Nylatron) Pump Retainer Assembly Ring Screw W263PE3C Figure 34 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 55: Motor Switch

    37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 56: Agitator

    NOTE: Cabinet top is self supporting, however, a small chain may be used for additional support. Refer to Figure 36. Chain Agitator W247SE1A Figure 35 W252SE1A Figure 36 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 57: Cabinet Top Assembly Removal

    (bending) corner gusset of washer cabinet, disconnect out-of-balance switch lever. Corner Gusset Pressure Ground Hose Wire Mixing Valve Wire Harness Disconnect Blocks W253SE3A Figure 37 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 58: Agitator Drive Bell And Seal Kit, No. 39508P

    Refer to IMPORTANT: If large nut is turned clockwise Figure 38. when pulling drive bell, you will twist off the quarter inch bolt. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 59 (3) Grasping bottom of seal, pull straight up freeing upper seal bead. W295SE1B Transmission Output Shaft Figure 42 Washer Assembly Bronze Hub Shoulder Bearing W294SE1A Figure 41 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 60 Bottom to lock under bottom edge of drive bell. Seal Flange W297SE1A NOTE: Do not push agitator onto drive bell any Figure 44 further than necessary. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 61: Out-Of-Balance Switch Assembly

    Refer to Figure 45. i. Tighten tapping screws using an 1/4 in. open- Push end wrench. Here Cabinet Switch Lever W171SE1A Figure 46 Tapping Screws W273SE1A Figure 45 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 62: Mixing Valve Assembly

    Refer to Figure 47. NOTE: Refer to appropriate wiring diagram when rewiring solenoid. Wire Harness Disconnect Hose Terminals Clamp W322SE1A Figure 47 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 63: Outer Tub Cover And Clothes Guard

    Part No. 273P4, insert two Refer to Figure 49. prongs of tool underneath each side of tandem tabs. Refer to Figure 48. Tilt tool toward center 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 64 Tub Cover 273P4 Gasket Tub Cover Tool Press Gasket Into Groove Using Your Fingers Hold-Down Hold-Down Tabs Tabs W208SE3B Figure 49 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 65 W255SE3A cover off tub flange. Figure 50 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 66 Slots Washtub Screws Clothes Washtub Guard Screws Pins W209SE3A Figure 51 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 67: Hub And Seal Kit, No. 495P3

    No. 495P3 Hub and Seal Kit. water leak. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 68 Apply Bead Of No. 27615P Apply Bead Of Sealant Here No. 27615P (Step "f") Sealant Here (Step "f") Insert Sleeve From W180SE3A Bottom Side Of Seal Figure 53 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 69: Outer Tub Assembly

    IMPORTANT: Setting washer to spin allows petroleum jelly (applied to bronze portion of water seal) a chance to cover seal surface before water is added to washer. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 70 Mark the word “FRONT” on front side of outer tub so complete tub module can be reinstalled Centering in same position. Hose Spring W308SE1A Figure 54 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 71 Brake Pivot Dome Assembly Attaching Screws Pivot Dome Lower Bearing Housing Drive Pulley Transmission Assembly Plate Screw Balance Ring W257SE3A Figure 55 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 72: Drive Pulley And Helix

    This condition will persist until lubricant is removed. Drive Pulley Washer Cap Screw Helix W271SE3A Figure 56 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 73 Apply Lubricant Here Drive Pulley Apply Lubricant Washer Here Helix Cap Screw Pivot Dome DO NOT LUBRICATE Washer Base Snubber Pad and Isolator Assembly W183SE3C Figure 57 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 74: Brake Assembly

    Any lubricant on pivot dome or snubber pad and isolator assembly will cause premature tripping of the out-of-balance switch. This condition will persist until lubricant is removed. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 75: Lower Bearing Housing

    DO NOT DROP OR LOWER TRANSMISSION ASSEMBLY INTO POSITION TOO HARD, this can cause bearing to move within bearing housing which will cause vibration, noise, wear or no spin. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 76 Place assembly back into vise (cover end up) and remove three screws and lockwashers. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 77 IMPORTANT: Be sure mating surfaces of in contact with bearings and seals in transmission transmission cover and case are free of oil or any case and/or cover. other foreign material. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 78 Remove complete transmission assembly from vise. q. Apply anti-seize compound, No. 27604P, to smooth area of both transmission tubes that will be contacting upper and lower bearings. Refer to Figure 58. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 79 Reduction Shaft Pinion Gear (Input) Identification Groove Agitator Pinion Dowel Rack Slide Transmission Cover Assembly Screw Dowel W186SE3C Sealant (Use between Transmission Case and Cover) Figure 59 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 80: Balance Ring

    Ball Bearing Cap Screw Outer Upper Bearing Flinger Housing Upper (If Present) Flinger Bearing (If Present) Housing W196SE3A Figure 60 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 81: Snubber Pad And Isolator Assembly

    (not kinked or twisted). If it is not, loosen hose recess of washer base. clamp and straighten hose. Starting Edge Isolator Elongated Strip Hole Dome Area Of Washer Base W220SE3B Figure 61 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 82 NOTE: Washer must be run through a complete k. Reinstall washer front panel. cycle to make sure it is operating properly. Pressure Hose Tape Pressure W335SE3A Bulb Figure 62 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 83: Section 6 - Adjustments

    Washer Base Locknut Leveling Rubber Foot Front Panel Screws Figure 63 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 84: Pressure Switch

    If tub module is not Centering centered within opening, centering spring(s) may Spring W308SE1B have been overstretched. Replace necessary spring(s) and recheck centering. Refer to Figure 66. Figure 66 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 85: Idler Spring Tension

    Refer to Figure 68. Reinstall the idler spring. CORRECT Green Clip W020BE3B Figure 67 INCORRECT Green Clip W021BE3B Figure 68 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 86: Cleaning Coin Drop

    Figure 69. Save pin for reinstallation when cleaning is complete. f. Move metal clip closer to sensor so that it comes off frame. Refer to Figure 69. Cotton Swab DRY5B Figure 71 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
  • Page 87 It may be necessary to lift drop to allow coin to follow through sensor. o. Reinstall coin drop into machine. Refer to Figure 34. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 88 Section 6 Adjustments Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 89: Section 7 - Test Procedures

    VIOLET WIRE. LOW SPEED TERMINALS MANUALLY DEPRESS ACTUATOR. CONTINUITY EXISTS INOPERATIVE LOW SPEED SWITCH. BETWEEN SWITCH TERMINAL P REPLACE SWITCH. AND VIOLET WIRE. MOTOR SWITCH CHECKS OK. 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 90: Emerson Motor Windings

    INDICATE WHETHER YES, MOTOR PASSED THIS TEST OR, NO IT FAILED THIS TEST Washer Motor Failure Motor Switch Motor Windings Start Terminals: Start Winding: High Speed Winding: High Speed Terminals: Low Speed Winding: Protector/Common Lead: Low Speed Terminals: © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 91: Timer No. 28716 Cycle Sequence (Long Cycle - Kingston)

    X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 28716 CYCLE SEQUENCE (LONG CYCLE – KINGSTON) 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 92: Timer No. 31111 Cycle Sequence (Short Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 31111P CYCLE SEQUENCE (SHORT CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 93: Timer No. 34601P Cycle Sequence (Long Cycle).91

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34601P CYCLE SEQUENCE (LONG CYCLE) 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 94: Timer No. 34602 Cycle Sequence (Long Cycle)

    C = COLD X = INDICATOR LIGHT GLOWS N = NORMAL CYCLE *ON SINGLE SPEED MODEL WASHERS, ALL SPEEDS ARE FAST. TIMER NO. 34602 CYCLE SEQUENCE (LONG CYCLE) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...

  • Page 95: Section 9 - Internal Wiring Of Washer Motor Switch

    W003 White Brown Blue Yellow W310SE3A 4P M YELLOW OVERLOAD PROTECTOR AUX. W211SE3A MOTOR ASSEMBLY (1 SPEED MOTORS) 37593 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 96 W003 Wire Harness Connection Block White Blue Brown Violet Yellow W311SE3B 4P M YELLOW 6P M OVERLOAD PROTECTOR AUX. W224SE3A MOTOR ASSEMBLY (2 SPEED MOTORS) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 37593...
