__________________________________________________________________________________________
The Hayward TriStar Pump is specifically engineered for the demanding requirements of today's in-ground swimming pool/spa that is
equipped with large capacity filters, heaters, and pool cleaning equipment. The TriStar is a self-priming pump that includes an
improved seal and impeller design that will provide many years of efficient, dependable, corrosion-free service. The advanced design
provides superior performance while reducing maintenance requirements. NOTE - To prevent potential injury and to avoid
unnecessary service calls, read this manual carefully and completely.
IMPORTANT – READ CAREFULLY
NOTE - The TriStar is a high performance, high
efficiency pump. When replacing most existing
pumps, you can use a TriStar pump with a lower
horsepower rating than the existing pump.
Required:
2" plumbing minimum
Recommended: 2 ½" plumbing or larger
OWNER'S MANUAL
INSTALLATION, OPERATION, & PARTS
TriStar
SAVE THIS INSTRUCTION MANUAL
HAYWARD POOL PRODUCTS
620 DIVISION STREET ELIZABETH, NJ 07207 (908) 351-5400
WWW.HAYWARDPOOL.COM
®
Pump Series
TriStar Pump Replacement Guide
TriStar
TriStar
Model No.
Model No.
Full Rated
Max Rated
---
SP3207X10
SP3207EE
SP3210X15
SP3210EE
SP3215X20
SP3215EE
SP3220X25
SP3220EE
SP3225X30
SP3230EE
*50HZ Models are not UL Listed.
Super II
Model No.
Full Rated
SP3007EEAZ
SP3010EEAZ
SP3015EEAZ
SP3020EEAZ
SP3025EEAZ
---
---
P/N: IS3200
Rev. F
Super II
Model No.
Max Rated
SP3007X10AZ
SP3010X15AZ
SP3015X20AZ
SP3020X25AZ
SP3025X30AZ
---
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hayward TriStar
Summary of Contents for Hayward TriStar
- Page 1 The Hayward TriStar Pump is specifically engineered for the demanding requirements of today’s in-ground swimming pool/spa that is equipped with large capacity filters, heaters, and pool cleaning equipment. The TriStar is a self-priming pump that includes an improved seal and impeller design that will provide many years of efficient, dependable, corrosion-free service. The advanced design provides superior performance while reducing maintenance requirements.
-
Page 2: Important Safety Instructions
All electrical wiring MUST be in conformance with all applicable local codes, regulations, and the National Electric Code (NEC). Use of non-Hayward replacement parts voids warranty. ATTENTION INSTALLER – THIS MANUAL CONTAINS IMPORTANT INFORMATION ABOUT THE INSTALLATION, OPERATION, AND SAFE USE OF THIS PUMP THAT MUST BE FURNISHED TO THE END USER OF THIS PRODUCT. - Page 3 - In addition to two or more suction outlets per pump installed in accordance with latest IAF (formerly NSPI) standards and CPSC guidelines, follow all national, state, and local codes applicable. - Installation of a vacuum release or vent system, which relieves entrapping suction, is recommended. WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 4: Product Benefits
It is the first to feature a Tri-Lock cam and ramp strainer cover design that closes with less than a quarter turn, and the TriStar’s super-sized, smooth no-rib basket with extra leaf-holding capacity is easy to clean. TriStar has a variety of bases available to seamlessly retrofit to existing filtration systems. -
Page 5: Installation Instructions
* NOTE - It is recommended that a minimum length of straight piping (shown as “L” in above diagram), equivalent to 5 pipe size diameters, be used between the pump suction inlet and any plumbing fittings (elbows, valves, etc.). WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 6 (except gas piping), and conduit within 5 ft. (1.5 m) of inside walls of swimming pool, spa, or hot tub. WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 7: Start-Up And Operation
4. Allow no more than 50 psi (345 kPa) at a water temperature no higher than 100° F (38° C). 5. Run pressure test for no longer than 24 hours. Immediately inspect all parts to verify they are intact and functioning properly. WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 8: Starting/Priming The Pump
If pump does NOT prime within five minutes, stop motor and determine cause. Be sure all suction and discharge valves are open when pump is running. See Troubleshooting Guide. WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 9: Maintenance
Keep motor clean. Insure motor air vents are free from obstruction to avoid damage. Do NOT use water to hose off motor. Occasionally, shaft seals must be replaced, due to wear or damage. Replace with genuine Hayward seal assembly kit. See “Shaft Seal Change Instructions” in this manual. - Page 10 15. Fasten assembly to pump/strainer housing (item #3) using the six (6) 5/16" x 2" bolts (item #17). (Be sure housing gasket (item #14) is in place, and lubricated. Replace if damaged). Tighten bolts alternately and evenly to 185 inch- pounds according to housing bolt torque pattern detail. WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 11: Replacement Parts
Strainer Cover Kit (Includes Strainer Cover, Lock Ring, O-Ring) SPX3200DLSB Strainer Cover Kit (Biguanide Sanitizer Applications Only; NOT Pressure Testable) SPX3200S Strainer Cover O-Ring SPX3200M Strainer Basket SPX3200Z8 Diffuser Screw SPX4000Z1 Diffuser O-Ring SPX3200B3 Diffuser SPX3200Z1 Impeller Screw SPX3021R Impeller Ring WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 12 * STA-RITE is a registered trademark of Sta-Rite Industries, Inc. and WHISPERFLO is a registered trademark of Pentair Water Pool & Spa, Inc., which are used herein for identification purposes only. These are retrofit bases for existing STA-RITE and WHISPERFLO pump installations. Sta-Rite Industries, Inc. and Pentair Water Pool & Spa, Inc. are not affiliated with Hayward Pool Products. WWW.HAYWARDPOOL.COM...
-
Page 13: Troubleshooting
Solution: Contact qualified professional to check that the wiring gauge is heavy enough. NOTE: Your Hayward pump motor is equipped with an “automatic thermal overload protector.” The motor will automatically shut off if power supply drops before heat damage can build up causing windings to burn out. The “thermal overload protector”... -
Page 14: Product Registration
© Hayward Pool Products, 2005 All rights reserved. PRODUCT REGISTRATION (Retain For Your Records) DATE OF INSTALLATION ____________________ INITIAL PRESSURE GAUGE READING (CLEAN FILTER) _______________________ PUMP MODEL ________________ HORSEPOWER _______________________ FILTER MODEL ________________ SERIAL NUMBER _______________________ WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 15: Warranty Registration Card
To obtain warranty replacements or repair, defective components or parts should be returned, transportation paid, to the place of purchase, or to the nearest authorized Hayward service center. For further Hayward dealer or service center information, contact Hayward customer service department. No returns may be made directly to the factory without the express written authorization of Hayward Pool Products.
