WELLTECH WILLGATE26XX - RELEASE NOTE V106A User Manual

1. When WAN port is set to DHCP mode and the cable is not connected, the system will boot failed and
LAN port cannot get IP address from DHCP server.
2. Fixed the DHCP renew failure.
3. Improved session timer algorithm.
4. Fixed when FXS no voltage is turned on and FXS is not registered or network failed, the FXS still
provides line feed power.
5. Fixed the SIP domain name need to be a resolvable DNS name instead of SIP domain. The system will
refer the Proxy IP address as outbound address.
6. Fixed that when only representative number is set to register, FXO routing plan is not to be used for
routing. Now the system will hunt based on the FXO routing plan.
7. Fixed a potential problem on detecting the FXS on hook event which might cause the FXS is still in off
hook state.
8. Fixed a potential problem on detecting ringing event.
9. Fixed the fax bypass is not working issue.
10. Fixed the t.38 fax failure when 26xx is setting behind NAT.
11. Fixed the AP crash when receive a invalided SDP content.
1. Added watchdog feature to improve the system stability.
2. Improve VOIP and Data processing priority to ensure the VOIP can get highest priority to be processed.
1. Call handling policy was changed:
- When PABX mode is turned on and the incoming FXO is routed to FXS. This call will not able to be
transferred.
- When anyone port (2680; 2644) is set to register, all calls will be sending to Proxy instead of local routing.
2. In SIP Setting web page, the max length of Proxy IP address and domain name was extended to 64
characters.
3. Allowed the alphabet in the Hot line field.
4. Remove FXS No voltage from System Settings. (telnet is added instead)
WELLTECH WEB Site:http://www.welltech.com
Firmware Download: http://www.welltech.com/support/26xx_cht.htm
User Manual: http://www.welltech.com/support/26xx_cht.htm
