WELLTECH FXSO GATEWAY SIP 3701A Manual

Ip-based telephone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

L
A
N
P
L
A
N
P
U
s
e
U
s
e
h
o
n
e
1
h
o
n
e
1
r
M
a
n
r
M
a
n
0
1
/
2
0
1
0
1
/
2
0
1
u
a
l
u
a
l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FXSO GATEWAY SIP 3701A and is the answer not in the manual?

Questions and answers

Related Manuals for WELLTECH FXSO GATEWAY SIP 3701A

Summary of Contents for WELLTECH FXSO GATEWAY SIP 3701A

  • Page 2: Table Of Contents

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 1 Introduction .........................3 ＊Product Description........................4 1.Features and Specification ....................4 2.Appearance........................7 Chapter 2 Operating Procedure – LCD Display Configuration............11 1.Initialize LAN Phone 101/201 ....................11 2.LCD Configuration .........................12 Chapter 3 Advanced Configurations via Telnet .................19 1.
  • Page 3 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 5 Upgrade the LAN Phone 101/201 ..................55 ＊Download Procedure......................55 1.LCD Panel Control......................55 2.Remote Control: Telnet ....................56 3.Web Management......................57 LAN Phone Ver:lp2.100.

  • Page 4: Chapter 1 Introduction

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 1 Introduction The LAN Phone 101/201 is a full-featured IP-based telephone system, which provides VoIP service on LAN or any IP based environment. By using IP environment for voice communication, company or individual can save lots of expenses and make data and voice network converged.

  • Page 5: Product Description

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 ＊Product Description 1.Features and Specification Basic Features: ITU-T H.323 v3 compliance  DTMF detection/generation  TFTP/FTP software download  Remote configuration/reset via Telnet  LED indication for system status：Speaker, Hold ,Mute , Message , PSTN ...
  • Page 6 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Function Keys : Speaker , Redial , Mute , Hold , Transfer , Forward , Message , PSTN  Ten sets last Phone Number redial  Dial plan  Provide TOS(Type Of Service) function ...
  • Page 7 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0  Provide H.245 Out-band DTMF message Call Transfer (H.450.2)  Call Forward (H.450.3)  Call Hold (H.450.4)  Gain (Voice Volume) Settings  Provide Call Progress Tone: Dial tone, busy tone, call-holding tone and ring-back tone ...

  • Page 8: Appearance

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 2.Appearance 1.Front View and Keypad function  C: Cancel and Clear   : Move to left /previous and right/next .  OK: Press OK to confirm the modification.  Direct Line (DL) Button 1 – 10: User press DL button to do speed dial according to phone book data 1-10 (please refer to LCD configuration-Phone Address Book or Advanced Configurations via Telnet-[pbook] command ).
  • Page 9 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0  Number 1 –10, * and #: The function is as the same as the general phone set. Corresponding list of keypad and symbol: “Space” ; “,” ; “.” ; “!” ; “1” “A”...
  • Page 10 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 1. Transfer a call by H.450 transfer function. Press TRANSFER button in communication and press phone No. which user want to transferred to can transfer this call . 2. Change characters to be capital or lowercase: when press TRANSFER before press letters can switch type of letters.
  • Page 11 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 3.Specification of connector 1、Ethernet Port： Ethernet port is for connecting LAN Phone to network, transmit rate supports 10/100 Base-T. Ethernet connector（LAN） 2、RJ11connector： RJ11 connector is for connecting LAN Phone with PSTN. RJ11connector LAN Phone Ver:lp2.100.

  • Page 12: Chapter 2 Operating Procedure - Lcd Display Configuration

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 2 Operating Procedure – LCD Display Configuration 1.Initialize LAN Phone 101/201 1. When power on the LAN Phone 101/201, the LCD screen shows as below. IP-Phone Board Start Booting 2. Wait around one minute until the LAN Phone 101/201 finishes boot program initialization. 3.

  • Page 13: Lcd Configuration

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Note: LCD Panel of LAN Phone 101/201 is operated manually by moving  or  on the keypad. Press OK to enter separate configuration menu. Press C to go back to the main menu.
  • Page 14 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 normally, LAN Phone can refer to secondary DNS. (6) GateKeeper User has to offer one available GateKeeper server IP Address and set this IP Address on the LAN Phone keypad. (7) Second GateKeeper LAN Phone provide alternative GateKeeper feature, if LAN Phone can’t register to Main GateKeeper for 10 times, it will try to register to the Second GateKeeper.
  • Page 15 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 this password (B)H.235 security: To set RRQ/ARQ authentication token password. If LAN Phone wants to register to a GateKeeper, which implement H.235 security token feature, LAN Phone has to set a RRQ/ARQ authentication token password, which is provided by GateKeeper manager.
  • Page 16 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 LAN Phone keypad. The IP Address is necessary for upgrading Lan Phone new application rom file. (3) Set FTP user account User has to press user name and password for FTP server login .It is necessary for upgrading Lan Phone new application rom file in FTP method.
  • Page 17 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 (2) Line Number 2 (3) Line Number 3 (4) Line Number 4 (5) Line Number 5 (6) Line Number 6 (7) Line Number 7 (8) Line Number 8 (9) Line Number 9 (10) Line Number 10 Note: User can set six zero “000000”...
  • Page 18 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 It is included the above two types. Whether the LAN Phone is in which status, it will be automatically forwarded to the assigned phone number. (2).Deactivate : choose under which situation to deactivate forward function. After selection, please press OK , then user can see LINE NUMBER of the endpoint which is already configured to forward to, now press OK again.
  • Page 19 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Note Information PPPoE IP address Destination Host DNS Primary Subnet Mask Authentication Protocol Device LAN Phone Ver:lp2.100.

  • Page 20: Chapter 3 Advanced Configurations Via Telnet

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 3 Advanced Configurations via Telnet After initializing the LAN Phone 101/201 IP Address setting (please refer to LCD Configuration: 1.Connect Configuration), user can enter into configuration mode via telnet. There are 18 commands listed below.

  • Page 21: Quit] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 2. [quit] command Type quit/exit/close will logout LAN Phone 101/201 and Telnet Program. 3. [reboot] command After typing commit command, type reboot to restart the LAN Phone 101/201. Sometimes after user type reboot, on terminal screen will display :"Data modified, commit to flash rom?", which means LAN Phone will record call history or not.(ex.

  • Page 22: Commit] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 5. [commit] command Save any changes after configuring the LAN Phone 101/201. 6. [ifaddr] command Configure and display the LAN Phone 101/201 IP information. 1. -ip, -mask, -gate: Set LAN Phone 101/201 IP Address, subnet mask and default gateway respectively.

  • Page 23: Time] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Note: management center is optional software to help user can easily configure products, please contact your reseller to know more about it. 7. [time] command When sntp server is established as well as the sntp function of LAN Phone 101/201 is enabled, type time command should show the current time what is retrieved from the assigned sntp server.

  • Page 24: Pbook] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 9. [pbook] command The command is for Peer-to-Peer Mode use only. Therefore, VoIP products such as LAN Phone 101/201 that support Peer-to-Peer Mode are also available to be addressed on the LAN Phone 101/201 phone book.

  • Page 25: Ddns] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 10.[ddns] command This function is for Dynamic Domain Name Server service. Once user register to one DDNS server, he can specify domain name for the LAN Phone. When LAN Phone reboot, it will automatically update it’s IP address to DDNS server.

  • Page 26: Pppoe] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Note: 1. For now we only support DDNS server as www.dyndns.org 2. User must register to www.dynsns.org first, and specify user name and password in ddns -id and ddns –passwd. 3. The default IP address of DDNS login server is member.dyndns.org, which is login server of www.dyndns.org 4.

  • Page 27: Sysconf] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 12.[sysconf] command This command displays the system information and configuration. 1. -print: display system overall information and configuration. 2. -plan: It is for setting dial numbering plan. While e164 number is three digits, the plan should be set as 3 or 0.

  • Page 28: H323] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 13. [h323] command 1. –print: display H.323 stack information and configuration. 2. –mode: configure LAN Phone 101/201 as GateKeeper or Peer-to-Peer Mode. Usage:h323 –mode 0/1(0 for GateKeeper mode ,1 for Peer-to-Peer mode) 3.
  • Page 29 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 200 –e164-2 300….) User can disable one number and the number after this one. Ex. from set 1-5 is configured, if user set the third number as “x”, from third to fifth number will be disabled at the mean time.

  • Page 30: Voice] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 command). 14. [voice] command The voice command is associated with the voice codec setting information. 1.-print: display voice codec information and configuration. There are five voice codecs included in LAN Phone 101/201:G.723.1, G.711u, G.711A, G.729a, G.729.

  • Page 31: Tos] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 7.-mindelay:set minimum delay of jitter buffer(0~150) 8.-maxdealy:set maximum delay of jitter buffer(0~150) Note: It is for advanced administrator use only. Please ask your distributor before changing any settings of this command. 15.

  • Page 32: Tone] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 with TOS function. 2. Only special version has this function, normal version with PPPoE function doesn’t include TOS command. 16. [tone] command LAN Phone 101/201 is configurable of busy tone, reorder tone, ring tone and dial tone. However, only ring tone and dial tone is functional for now, busy tone and reorder tone are reserved for future feature.

  • Page 33: Support] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 17. [support] command 1.-print : display current SUPPORT values configurations. 2.-fstart: enable or disable fast start (support –fstart 0/1 , 0 for disable and 1 for enable.) Note: When fast start function is enabled, if user wants to send DTMF message after connection, LAN Phone will send out Q.931 message.

  • Page 34: Rom] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 execute hold function when connecting with LAN Phone 101/201, user will hear hold tone from LAN Phone 101/201. (0 for off ,1 for on) 19.[rom] command 1. -print: show versions of all rom files. 2.
  • Page 35 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Command rom –print can show current version installed in LAN Phone 101/201. LAN Phone Ver:lp2.100.

  • Page 36: Passwd] Command

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 20.[passwd] command For security protection, user has to input the password before entering application user/config mode. Two configurations of login name/password are supported by the system. 1. –set: set password of “root” users or “administrator” users. (password –set root/administrator “password”) 2.–clean: clean up password restored before, and user can login :”root/adminstrator”, password:”press enter”.

  • Page 37: Chapter 4 Web Configuration

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 4 Web Configuration The initial version for HTTPD web management interface provides user to configure easily rather than command operating method through RS-232 / TELNET. The configuration function and step is similar with the way through command line. Basically this version is not the finalized version for web interface.

  • Page 38: Step 2. Input The Login Name And Password

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Step 2. Input the login name and password  Login name: root / administrator  Password: None (just press Enter in default value) Step 3. The web interface main screen LAN Phone Ver:lp2.100.

  • Page 39: Step 4. Start Configure

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Step 4. Start configure Most of all commands displayed in console / telnet are transfer to web interface. The most important commands are Network Interface, H323 Information, Commit Data Reboot System. The method is as the same as command mode.
  • Page 40 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 LAN Phone Ver:lp2.100.

  • Page 41: H323 Information

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 2. H323 Information Please refer to chapter 3.12 [h323] command Mode: Select GK mode or Peer-to-Peer mode Gatekeeper IP Address: Set Gatekeeper IP Address Gatekeeper IP: Set Redundancy Gatekeeper IP Address Gatekeeper Id: Set GateKeeper ID Gatekeeper Discovery:...
  • Page 42 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 LAN Phone Ver:lp2.100.

  • Page 43: System Configure

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 3. System Configure Please refer to chapter 3.11 [sysconf] command Keypad Type: Select different DTMF Keypad Type (For Advanced User) Dial Plan: Set DTMF digit limitation (0 is for any digits) Call Alive: Enable the function to check connection (Both side must support) Inter Digit Time:...

  • Page 44: Pppoe Configure

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 4. PPPoE Configure Please refer to chapter 3.10 [pppoe] command Device: Enable/Disable PPPoE function User Name: Set PPPoE Connection User Name Password: Set PPPoE Connection password Reboot After Remote Host Disconnection: Enable/Disable auto reboot after PPPoE disconnection Other items:...
  • Page 45 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 5. Voice Setting (For Advanced User) Please refer to chapter 3.13 [voice] command Codec Priority: It got wrong order with “Frame Size”. Select the packet size in sending process. (For Advanced User) Sending Packet Size: Select the Codec Priority.
  • Page 46 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 6. Tone Setting (For Advanced User) Please refer to chapter 3.15 [tone] command Busy Tone: Reorder Tone: Ring Tone 1 Ring Tone 2 Dial Tone:. Set the above tone Frequency , Level and On/Off time LAN Phone Ver:lp2.100.
  • Page 47 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 7. Bureau Setting Please refer to chapter 3.17 [bureau] command Hold Tone Generation(using PCM file): Enable/Disable hold tone generation LAN Phone Ver:lp2.100.
  • Page 48 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 8. Support Functions (Both side must support) Please refer to chapter 3.16 [support] command Fast Start: Enable to do Fast Start H.245 Tunneling: Enable to open H.245 Tunneling H.245 Separate Channel: Enable/Disable open H.245 channel after fast start connection LAN Phone Ver:lp2.100.
  • Page 49 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 9. Phone Book (For Peer-to-Peer mode only) Please refer to chapter 3.9 [phone] command Input the Name, IP Address and E.164 No. of the destination device. Please Note: The E.164 No. will not be carried together to the destination side. It is said if the destination side is requested to match its E.164 No.
  • Page 50 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 10. Password Please refer to chapter 3.19 [password] command First select login name as root or administrator, then enter current password , new password and confirm new password again. LAN Phone Ver:lp2.100.
  • Page 51 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 11. ROM Upgrade Please refer to chapter 3.18 [rom] command TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Server IP Address: Set FTP server IP address FTP Login:...
  • Page 52 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 12. Flash Clean Please refer to chapter 3.4 [flash] command Press CLEAN will clean all configurations of LAN Phone and reset to factory default value. Please be noted: Once execute this function, user must re-configure all commands all over again.
  • Page 53 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 13. Commit Data Please refer to chapter 3.5 [commit] command After configuration, user has to commit data then reboot machine. LAN Phone Ver:lp2.100.
  • Page 54 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 14. Reboot System Please refer to chapter 3.3 [reboot] command LAN Phone Ver:lp2.100.
  • Page 55 LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 15. Version Information Please refer to chapter 3.18 [rom] command User can see all S/W versions. Note: If there is item can’t be found on web site, please configure them by telnet. LAN Phone Ver:lp2.100.

  • Page 56: Chapter 5 Upgrade The Lan Phone 101/201

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 Chapter 5 Upgrade the LAN Phone 101/201 LAN Phone 101/201 supports two methods to upgrade the new version. Both methods are necessary to prepare the TFTP program on the host PC as TFTP server. After installing TFTP program on one PC and connecting to network, LAN Phone 101/201 is ready to be upgraded.

  • Page 57: Remote Control: Telnet

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 2.Remote Control: Telnet Associated with the Chapter 3.18 [rom] command: 1. -print: show versions of all rom files. 2. -app,-boot, -dsptest, -dspcore, -dspapp, -rbpcm and -htpcm: upgrade main boot code, main application code, DSP testing code, DSP kernel code, DSP application code, Ring Back Tone PCM file and Hold Tone .

  • Page 58: Web Management

    LAN Phone 101/201 User Manual Guide Document Ver.: 2.0 3.Web Management Please refer to chapter 3.18 [rom] command TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Server IP Address: Set FTP server IP address FTP Login:...
