Summary of Contents for WELLTECH SIP-Phone 302

  • Page 2: Table Of Contents

    Chapter 1 Overview of the SIP-Phone 302 ................4 1. Hardware Overview ................... 5 2. Software Features and Specification ..............8 Chapter 2 Configuring the SIP-Phone 302 through LCD Phone menu ......10 1. Initialize SIP-Phone 302 ..................10 2. LCD Menu Configuration ..................12 Chapter 3 Configuring the SIP-Phone 302 through Web Pages ........
  • Page 3 16. [tos] command ...................... 45 17. [bureau] command....................46 18. [rom] command..................... 46 19. [passwd] command....................47 Chapter 5 Upgrading Software on the SIP-Phone 302 ............49 1.From LCD Phone Menu................... 49 2. Web Management ....................50 3. Telnet command lines ..................... 51...
  • Page 4 Author Modified Contents Aug., 22 , 2004 Sabrina 1 Revision for IAD 161 162 SIP Gateway. Sep., 9 , 2004 Sabrina Modify typo error of Power supply and change picture of back view. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 5: Chapter 1 Overview Of The Sip-Phone 302

    Chapter 1 Overview of the SIP-Phone 302 SIP-Phone 302 is a full-featured IP-based telephone set for home telephony via Ethernet base communication. It supports SIP RFC3261 protocol. Two 10/100BaseT embedded switch/hub RJ-45 ports allow connect to office LAN and PC on your table. It is easily interface with ADSL/Cable Modem that is provided by ITSP, ISP or Carrier company to provide VoIP services to residential and SOHO application.

  • Page 6: Hardware Overview

    System Indication LED: When SIP-Phone didn’t register to Proxy server or having incoming call, system indication LED will be blinking. ♦ MENU: Press to enter LCD Menu when in standby mode; if already in LCD Menu, press this button can return to standby mode SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 7 5 Graphic Memory key: User press these keys to do speed dial according to phone book data 1-5 (please refer to LCD configuration-Phone Book, Configuring the SIP-Phone 302 through Telnet command lines - [pbook] command, or Web Configuration-Phone Book chapter).
  • Page 8 3.Specification 1. Ethernet Port¡ G Ethernet port is for connecting SIP-Phone to network, transmit rate supports 10/100 Base-T. Ethernet connector¡ ] LAN¡ ^ 2. Dimension: 200mm(W) x 79mm(H) x 210mm(D) 3. Weight: 830g SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 9: Software Features And Specification

    5 configurable speed dials Network Supported Fixed IP Dynamic Host Configuration Protocol (DHCP) PPPoE connection (When PPPoE disconnect, SIP-Phone 302 can automatically re-connect) Behind NAT IP Sharing Device Support QOS by setting DSCP (Differentiated Service Code Point) parameters of VoIP...
  • Page 10 Three easy ways for system configuration LCD Front Panel Web Browser TELNET Environmental Operating and storage Humidity: 10 to 95 % (Non-condensing) Operational Temperature: 0 to +40 °C Storage Temperature: -10 to 60¢ J Certification SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 11: Chapter 2 Configuring The Sip-Phone 302 Through Lcd Phone Menu

    Note: 1. Items marked with (**): May be not available yet, please contact with your distributor. 2. After any configuration has changed for the SIP-Phone 302, user has to do Reboot in the selection 7 “Reboot”. 3. We suggest user to set IP address via LCD menu 5¡ ÷ 2.3.4.5 first, then go to chapter 3 to do other configurations via web browser.
  • Page 12 3. Press MENU to enter configuration mode then press OK to enter sub menus; press FLASH can jump out current menu to previous level. Call List (**) Forward Phone Book Ringer Network Advanced Set (can be protected by password) Reboot SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 13: Lcd Menu Configuration

    There are 3 selections in Forward type, user must select under which condition to forward calls. (1) Busy When SIP-Phone 302 is in busy status, the incoming call will be forwarded to the assigned phone number. A. Activate Enter a forwarded phone number to activate busy forward function.
  • Page 14 Exit Return to upper level of LCD Menu 4. Ringer Volume User can adjust ring volume by press ¡ ¿ or ¡ ¶ on the keypad to decrease or increase ringer volume. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 15 Style There are three tone styles for SIP-Phone 302. Move the “>” symbol by press ¡ ¿ or ¡ ¶ on the keypad to select the tone style preferred, then press OK to confirm it. Exit Return to upper level of LCD Menu 5.
  • Page 16 MAC address of SIP-Phone. 2. User can also try to configure SIP-Phone via Telnet or Web browser with default IP address: 10.1.1.3. (If IP haven’t been changed) SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 17 There are two methods to download new version file, please move the “>“ symbol by press ¡ ¶ or ¡ ¿ on the keypad to select TFTP or FTP method, then press OK to confirm it. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 18 Return to upper level of LCD Menu 7. Reboot Reboot machine. It is necessary and important for user to reboot SIP-Phone 302 after any configurations has been made. SIP-Phone will ask user again before reboot. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 19: Chapter 3 Configuring The Sip-Phone 302 Through Web Pages

    The configuration function and steps are similar with the way through command line. Please refer to the chapter 4-Configuring the SIP-Phone 302 through Telnet command lines for more detail information. Below is a guide for user to configure via web interface.

  • Page 20: Step 1. Browse The Ip Address Predefined Via Keypad

    If user failed to set IP address via LCD menu, the default IP address of SIP-Phone is 10.1.1.3, user can also try to connect to SIP-Phone with this default IP via web interface. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 21: Step 2. Input The Login Name And Password

    4. Rom configuration: upgrade whole 2m software file Password (The same with TELNET): Null (just press confirm, no need to key in password in default value) Note: User can set password later in 8.PASSWORD via web interface. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 22: Step 3. Enter The Web Interface Main Screen

    Peer-to-Peer mode). Please remember to configure these commands before start to work with SIP-Phone. Note: After change any settings, please remember to reboot (in Reboot System) SIP-Phone so that changes can take effect. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 23: Network Interface

    1. Fixed IP: User has to assign a fixed IP to SIP-Phone. 2. DHCP: When DHCP function enables, SIP-Phone 302 will automatically search DHCP server after reboot. 3. PPPoE: If SIP-Phone is working with PPPoE connection, user have to set related parameters in “PPPoE Configure “page.
  • Page 24 Enable / Disable the Simple Network Time Protocol function SNTP Server Address: Set SNTP Server Address When SNTP server is available, enable SIP-Phone 302 SNTP function to point to SNTP server IP address so that SIP-Phone can get correct current time. GMT: Set time zone for SNTP Server time User can set different time zone according to the location of SIP-Phone.

  • Page 25: Sip Information

    Proxy server, and if there is a matched data in phone book, SIP-Phone will make call to related IP address. Prefix String: set prefix string. If user ID contains alphabets, user can set it as prefix SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 26 SIP-Phone will set out as abc123@”IP address of Proxy”. This function is for special proxy server. Line Number: identify one number for the SIP-Phone 302 to register to the Proxy. Line Account: set user name of SIP-Phone 302 for registering. User can set user name and password for registering.

  • Page 27: System Configuration

    SIP-Phone will dial out all number pressed. End of Dial Digit: select end of dialing key, e.g. set end of dial key as * button, after finished pressing dialing number then press * will dial out. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 28: Pppoe Configure

    SIP-Phone will keep trying to connect. After re-connected, SIP-Phone will also restart system. On the other hand, if user disables this function, SIP-Phone won’t reboot and keep trying to connect. Other items: for reference only, cannot allow to be configured. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 29: Voice Setting

    Buffer: Set Min. Delay and Max. Delay of Jitter Buffer for voice packets. Optimized Factor (Jitter): Set Optimized Factor of voice, this is for advanced user only, please contact with your distributor before making any change. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 30: Phone Book

    Name, IP Address and E.164 number of the destination device. From Telnet command line can set up to 100 sets of phone book data. Delete Date: User can delete any configured phone book data by assign index. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 31: Dscp Configuration

    Type-of-Service (TOS) octet in IPv4. The recommended DiffServ Codepoint is defined in RFC2597 to classify the traffic into different service classes. The mapping of Codepoint value of DS-field to egress traffic priorities is shown as follows. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
  • Page 32 010110 ====> 22 (Decimal System) 011110 ====> 30 (Decimal System) 100110 ====> 38 (Decimal System) 000000 ====> 0 (Decimal System) Please refer to RFC standard documents for more information about what is DSCP. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 33: Password

    “root”. If a user login with “administrator”, commands below are not functional: Password: set password of login: “root” users. Flash clean: clean all current configurations Rom configuration: upgrade boot sector Rom configuration: upgrade whole 2m software file SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 34: Rom Configuration

    1. After 2mb file download is finished, all configurations except IP address will change to default values, user has to configure again. 2. After upgrade Application, please remember to execute Flash Clean, which will clean all configurations become factory values except IP address. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 35: Flash Clean

    Press CLEAN will clean all configurations of SIP-Phone and reset to factory default value. Please reboot after flash clean. Note: User must re-configure all commands all over again (except Network Configure) once execute this function, SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 36: Reboot System

    Press reboot will reset SIP-Phone. Note: To execute reboot via web browser, SIP-Phone will automatically save all data before reboot. To execute reboot via TELNET command, please remember to do commit before reboot. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 37: Chapter 4 Configuring The Sip-Phone 302 Through Telnet Command Lines

    Chapter 4 Configuring the SIP-Phone 302 through Telnet command lines After setting the IP Address of SIP-Phone 302 and reboot, (please refer to LCD Menu: 5-3.4.5), user can enter into Telnet command lines. Note: 1. After user enter SIP-Phone configuration via telnet, please use login: ”root”, password: null, press enter to enter command lines.

  • Page 38: Quit] Command

    Type quit/exit/close will logout SIP-Phone 302 and Telnet Program. 3. [debug] command This command is for engineers to debug system of SIP-Phone 302. User can add debug flag via command debug –add “debug flags”, and then start debug function via command debug –open. When SIP-Phone 302 is working on screen will display related debug messages.

  • Page 39: Commit] Command

    (pbook –modify “index” name “X” ip “xxx.xxx.xxx.xxx” e164 “X”) 6. [commit] command Save any changes after configuring the SIP-Phone 302. 7. [ping] command Command ping can test which the IP address is reachable or not. Usage: ping “IP address”...

  • Page 40: Time] Command

    For example, in Taiwan the time zone should be set as 8,which means GMT+8. (GMT-8: ifaddr –timezone -8) 5. -ipsharing: If SIP-Phone 302 is behind a IP-sharing , user must enable IP sharing function and specify public IP address.(ifaddr –ipsharing 0/1 “public IP address of IP sharing”...

  • Page 41: Pppoe] Command

    SIP-Phone still can’t connect with server, SIP-Phone will keep trying to connect. On the other hand, if user disables this function, SIP-Phone won’t reboot and keep trying to connect. (pppoe –reboot 0/1) SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 42: Flash] Command

    1. After user upgrade new software version, suggested to execute this command to make sure new software work well on SIP-Phone 302. 2. To execute the command flash –clean, all configuration of SIP-Phone 302 stored in flash will be cleaned. It is authorized for the user whose login name is “root”...

  • Page 43: Sip] Command

    SIP-Phone will set out as abc123@”IP address of Proxy”. This function is for special proxy server. 7. –line: identify one number for the SIP-Phone 302 to register to the Proxy (SIP –line “line number”). Note: In proxy mode please remember to set user account information under security command.

  • Page 44: Security] Command

    14. [security] command 1. –print: display all current configurations. 2. -name: set user ID of SIP-Phone 302 for registering. User can set user name and password for registering. If password is no need, please set user name the same as line number or SIP-Phone won’t register successfully.
  • Page 45 7. -mindelay: set minimum delay of jitter buffer(0~150) 8. -maxdealy: set maximum delay of jitter buffer(0~150) Note: It is for advanced administrator use only. Please ask your distributor before changing any settings of this command. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 46: Tos] Command

    3. –siptype: set DSCP value of RTP packets from 0 to 63 Note: This command won’t be functional until whole network environment support DSCP function, e.g. all routers or switches in your network have enabled DSCP feature. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 47: Bureau] Command

    1. -print: display all current configurations. 2. –hotline: set hotline IP and remote phone number. If user has enable Hotline function, once SIP-Phone 302 been off-hook, it will automatically dial out to assigned IP and phone number. (bureau –hotline “IP of destination” “Phone number of destination”)

  • Page 48: Passwd] Command

    192.168.1.1, User has to input command as below: rom –app –s 192.168.1.1 –f lpsip.100 Command rom –print can show current version installed in SIP-Phone 302. (**) 19. [passwd] command For security protection, user has to input the password before entering application user/config mode.
  • Page 49 C. passwd –clean: clean up password restored before, and user can login :”root/administrator”, password: ”press enter”. D. flash –clean: clean all current configurations E. rom –boot: upgrade boot sector F. rom –boot2m: upgrade whole software file SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 50: Chapter 5 Upgrading Software On The Sip-Phone 302

    Chapter 5 Upgrading Software on the SIP-Phone 302 SIP-Phone 302 supports three methods to upgrade the new version. All methods are necessary to prepare the TFTP or FTP program on the host PC as TFTP/FTP server. After installing TFTP/FTP program on one PC and connecting to network, SIP-Phone 302 is ready to be upgraded.

  • Page 51: Web Management

    1. After 2mb file download is finished, all configurations might change to default values, user has to configure again. 2. After upgrade Application, please remember to execute Flash Clean, which will clean all configurations become factory values except IP address. SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...

  • Page 52: Telnet Command Lines

    7. –ftp: specify user name and password for FTP download method. For example: User prepares to upgrade the latest app rom file – lpsip.100, the TFTP server is 192.168.1.1, User has to input command as below: rom –app –s 192.168.1.1 –f lpsip.100 SIP-Phone 302 Administration Guide SIP-Phone 302 Ver:...
