iDect_V2_IFU_master.book Page 43 Friday, April 4, 2008 4:05 PM
Technical details
Standard
Frequency range
Channel bandwidth 1.728 MHz
Operating range
Operating time
Temperature range Operating 0 ºC to 40 ºC
Electrical power
Port specification The 9V AC port (connected to the
mains power supply) is a SELV port with respect to
EN41003.
The port (connected to the telephone line) is a TNV port
with respect to EN41003.
PBX compatibility Timed break recall: adjustable to
85 ms, 100 ms (default), or 250 ms.
Pause length (using the button): 3 seconds.
Signalling type: DTMF (dual-tone multifrequency, also
called tone dialling); or loop disconnect (pulse dialling).
Network connection This equipment is intended to be
used in the UK only. Operation on other countries' PSTN
termination points cannot be guaranteed.
Binatone Telecom plc operates a policy of continuous product
improvement, and so reserves the right to make changes to the
product and functions without notice.
Help Line: 0845 345 9677
Digital Enhanced Cordless
Telecommunications (DECT)
1.88 to 1.9 GHz
(bandwidth = 20 MHz)
up to 300 m outdoors; up to 50 m
indoors
standby: 100 hours approx.
talking: 9 hours approx.
battery charge time: 12–15 hours
Storage -20 ºC to 60 ºC
Handset — 550mA NiMH
rechargeable battery Pack
Base unit — 9V AC 300mA
Charger pod — 9V AC 300mA
(Local Call rate)
43
