ACT ACTSMART CONTROLLER Installation Manual

Power
Supply Unit
TAMPER
MAINS
+12V
PRESENT
+
12V DC
-
0V
Note:
Tamper and Mains Present
are not used.

LED Functionality:

Red LED indicates the status of communications with the PC.
Green LED indicates the status of communications with the ACTSmart Units.
Normally they flash rapidly.
If there is a problem they will flash slowly (about once a second).
ACTSmart Controller Installation
ACTSmart Controller
OP3 OP4 0V IP1 IP2 IP3
5A 250VAC
5A 30VDC
1 2 3 4 5 6 7 8
On
N ADDRESS

FACTORY DEFAULT

This unit should be reset to its
factory default condition before
installation. To do this, power
the unit up with ALL switches in
the OFF position. The two LED's
will illuminate for about 2 sec.
The correct switch settings may
then be set.
3metres Direct Connect Cable (Supplied)
SERIAL NETWORK
DTR RX TX 0V B A
A
B
0V
Shield
To connect to PC set
8
DIP 8 to the ON position
On
Continue daisy chain to
remaining ACTSmart2
units (maximum 8).
www.accesscontrol.ie

ACTWinSmart Software

Network cable is single
shielded twisted pair,
Belden 9501 or similar
ACTSmart2 Unit

Total cable length

maximum 1.4km
5A
5A
O N OM R
B
A
Aux I/O 2
Programmable Input
Aux I/O 1
Shield
See ACTSmart2 Installation
Manual for connection details.
12V DC
0V
N/O
COMM
N/C
Tamper
18-00036
