ACTpro 3000
Product Overview
The ACTpro 3000 is a two door controller extending
to a total of sixteen doors via ACTpro 100/200 door
expanders. In turn up to 128 ACTpro 3000s may be
networked via a PC interface to facilitate up to
2000 doors. The ACTpro 3000 can be configured
and be maintained standalone or through ACTWin
pro PC software. The ACTpro 3000 may be
networked via RS485 or the built in TCP/IP
capability.
Main Features
2 door controller expandable to 16 doors via
●
a network of ACTpro 100/200 door expanders
The ACTpro 3000 may be in turn networked with
●
other ACTpro 3000s to create a network of up to
2000 doors
Built in TCP/IP 10 Base-T Ethernet
●
RS485 output to network ACTpro
●
100/200 door expanders
RS485 input to network with other ACTpro 3000s
●
30,000 users
●
1000 user groups
●
256 time zones
●
Flash upgradeable firmware
●
Timed anti passback
●
Entry and exit reader support
●
DDA individual timer facility
●
Installation / Specification Guidelines
The ACTpro 3000 requires a 12 volt dc supply
●
The controller may not be installed outdoors
●
unless it is in a sealed and heated cabinet
The ACTpro 3000 is expanded from 2 to 16
●
doors via single door ACTpro 100/200 expanders
The ACTpro 3000 controller may be networked
●
via RS485 to expand the system up to 2000
doors maximum
The maximum amount of ACTpro 3000s per
●
RS485 output is 32 (ACT supply a 4x485 or
1x485 interface for PC networks)
The ACTpro 3000 is compatible with ACTWin
●
pro and ACTWin pro Lite software packages
The ACTpro 3000 will operate standalone
●
or can be connected to a PC
For comparisons to our other controllers please
●
check the comparison chart on the back page
Card access door controller
LAN / Ethernet
Server
3000
100
200
ACTpro 3000
Client
3000
100
200
8
IOM
8
ACTpro 1000/2000/3000 Controllers and ACTpro 100
expander require a 12 volts DC supply
ACTpro 3000 System Schematic
3000
3000
100
200
8
IOM
8
