Integrated System Configuration Guide

Product Code: SBHG2X, MM#: 880672
1. "Model 1" Integrated Systems are configured with the following:
1 Chassis (2U, Rack Mount)
1 Baseboard (includes: 1 Y Cable and 2 sockets for the Itanium® 2 processor, on-board Ultra 320
SCSI controller, 8 DDR RAM DIMM sockets, 4 USB ports (2 in front, 2 in back), 1 Serial port, 2
Video ports (1 in front, 1 in back), and 10/100/1000 Intel 82546EB Ethernet Embedded Network
Controller
1 I/O Riser board with 3 PCI-X slots (1x 133MHz, 2x 100MHz), and Baseboard Management
Controller (BMC)
1 Power Distribution Board
1 SCSI Hot Swap Backplane
1 Front Panel Board
2 350W TPS Power Supply
6 60mm Variable Speed Fans
2 SCSI Disk Drive Carriers
0 DVD / CDROM R-W Combo Drive
1 Front Bezel (color: Raven Black)
2 1.6G/3M Itanium® 2 processors with heatsinks
2 Processor Power Pods
4 1GB memory DIMMs (total of 4GB memory)
1 73G SCSI HDD
1 Rackmount Slide Rail Kit
1 Resource Kit containing the following on CDROM: Documents: Product Guide and Product
Quick Start Guide; Utilities: SDR Viewer, SEL Viewer, FRU/SDR Loader, System Maintenance
Utility (SMU), EFI Platform Diagnostics, EFI Configuration Tool, and LSI Logic SCSI and Intel
82546EB drivers for Windows† 2003 Server, Red Hat Advanced Server 2.1, and SuSE.
2. "Model 1" does NOT contain the following items:
External Power Cords
rd
3 Power Supply
Optical device (eg, DVD/CD ROM)
Cable Management Arm
3. To order these items, use the following table:
Product Codes
AGFTPS350
ATGDVDCDRW
ABHCBLARM
Additional Hard Disk Drives
Additional Memory
1
See "Reference Information" section on page 7 for details on available documents
Copyright © Intel Corporation 2004.
*Other brands and names are the property of their respective owners.
MM# Min Order
Qty
882215 1
854858 1
853965 1
N/A N/A
N/A N/A
Description
Power Supply, TPS 350W, hot swap
Liteon * DVD / CDROM RW Combo drive
Cable Management Arm
OEMs purchase directly from vendors. See Intel's list of
1
supported drives
OEMs purchase directly from vendors. See Intel's list of
1
qualified memory DIMMs .
Intel Confidential
Note: Dual-Core Intel® Itanium®
2 9000 series processors are not
available with the integrated SKU
SBHG2X. Please use Model 0 SKU
SBHG2 with Dual-Core Intel®
Itanium® 2 9000 series processors.
