  • Page 1 2 0 0 7 O W N E R ’ S M A N U A L...

  • Page 2: Introduction 3

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 4 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .

  • Page 5: How To Use This Manual

    4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
  • Page 6 INTRODUCTION 5...

  • Page 7: Warnings And Cautions

    The vehicle identification number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN LOCATION Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.

  • Page 8: Vehicle Modifications / Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.

  • Page 10: Table Of Contents

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....11 Ignition Key Removal ....11 Key-In-Ignition Reminder .
  • Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Protection Door Lock ....23 Windows ......25 Power Windows .

  • Page 12: Things To Know Before Starting Your Vehicle 9

    A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. Vehicle Key The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer.

  • Page 13: Key-In-Ignition Reminder

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exit,” under “Personal Settings (Customer Program- mable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual. WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.

  • Page 14: Replacement Keys

    NOTE: A key, which has not been programmed, is also considered an invalid key even if it is cut to fit the ignition lock cylinder for that vehicle. During normal operation, after turning on the ignition switch, the Vehicle Security Alarm Indicator Light will turn on for three (3) seconds for a bulb check.

  • Page 15: Customer Key Programming

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE consists of programming a blank key to the vehicle electronics. A blank key is one, which has never been programmed. NOTE: When having the Sentry Key Immobilizer System serviced, bring all vehicle keys with you to the dealer.

  • Page 16: General Information

    General Information The Sentry Key system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference that may be received, including interference that may cause undes- ired operation.

  • Page 17: To Disarm The System

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disarm the System: Either press the UNLOCK button on the remote keyless entry transmitter or insert a valid sentry key into the ignition lock cylinder and turn the key to the ON/START position.

  • Page 18: Illuminated Entry System

    ILLUMINATED ENTRY SYSTEM The courtesy lights will turn on when you use the keyless entry transmitter or open the doors or liftgate. The lights will fade to off after about 30 seconds or they will immediately fade to off once the ignition switch is turned ON from the LOCK position.

  • Page 19: To Unlock The Doors

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To unlock the doors: Press and release the UNLOCK button on the transmitter once to unlock the driver’s door, or twice to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal.

  • Page 20: Using The Panic Alarm

    Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the transmitter. This feature can be enabled or disabled. For details on how to change the current setting, refer to “Sound Horn with Remote Key Lock,”...

  • Page 21: General Information

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Separate the two halves of the transmitter with a flat blade tool. Do not damage the rubber seal during re- moval. Separating Transmitter Halves 3. Remove and replace the battery. Avoid touching the new battery with your fingers.

  • Page 22: Door Locks

    DOOR LOCKS Manual Door Locks To lock each door, push the door lock plunger on each door trim panel downward. To unlock each door, pull the door lock plunger on each door trim panel upward. Door Lock Plunger If the door lock plunger is down when you shut the door, the door will lock.

  • Page 23: Power Door Locks

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks A power door lock switch is on each front door trim panel. Use this switch to lock or unlock the doors. Power Door Lock Switch If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate.

  • Page 24: Things To Know Before Starting Your Vehicle 23

    Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled. For details, refer to “Lock Doors Automatically at 15 mph (24 Km/h),” under “Personal Settings (Cus- tomer Programmable Features),” under “Electronic Ve- hicle Information Center (EVIC)” in Section 4 of this manual.
  • Page 25 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the tip of the vehicle’s ignition key or alike into the child lock control and pull it upward. Child Lock Control 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: When the child lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked...

  • Page 26: Windows

    To Disengage the Child Protection Door Lock 1. Open the rear door. 2. Insert the tip of the vehicle’s ignition key or alike into the child lock control and pull it downward. Child Lock Control 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: After disengaging the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
  • Page 27 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the win- dows while operating the power window switches. Such entrapment may result in serious injury or death.
  • Page 28 Power Off to Accessories Until Exit,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4 of this manual. NOTE: • If the window runs into any obstacle during auto- closure, it will reverse direction and then stop. Remove the obstacle and use the window switch again to close the window.

  • Page 29: Wind Buffeting

    28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Reset Any time the vehicle battery is disconnected, or goes dead, the auto-up function will be disabled. To reactivate the auto-up feature, perform the following steps after vehicle power is restored: 1. Pull the window switch up to close window com- pletely and continue to hold the switch up for an additional two seconds after the window is closed.
  • Page 30 Once unlocked, the liftgate can be opened or closed. To open the liftgate, depress the liftgate release switch located in the exterior handle and pull the liftgate open with one fluid motion. Liftgate Release Switch The liftgate will not open manually if the gear selector is moved out of the PARK position or the vehicle speed is above 0 mph (0 km/h).

  • Page 31: Occupant Restraints

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Driving with the liftgate open can allow poison- ous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle.

  • Page 32: Lap/Shoulder Belts

    Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision that includes you. This can happen far away from home or on your own street. Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision.
  • Page 33 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt.
  • Page 34 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you as well. In a sudden stop, you could move too far forward, increasing the possibility of injury.
  • Page 35 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
  • Page 36 activated. To reset this feature you must let all of the belt webbing return into the retractor. You will not be able to pull out more webbing until all of the webbing has been returned back into the retractor. WARNING! The rear center lap/shoulder belt is equipped with a lock-out feature to ensure that the rear seat back is in the fully upright and locked position when occu-...

  • Page 37: Lap/Shoulder Belt Untwisting Procedure

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In the rear seat, move toward the center of the seat to position the belt away from your neck. Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt.
  • Page 38 if the driver’s seat belt is unbuckled for more than 10 seconds and the vehicle speed is greater than 5 mph (8 km/h). BeltAlert Programming The Enhanced Warning System (BeltAlert) can be en- abled or disabled by your authorized dealer or by performing the following steps: NOTE: DaimlerChrysler does not recommend deacti- vating the Enhanced Warning System (BeltAlert).

  • Page 39: Automatic Locking Mode - If Equipped

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. However, the belt will still retract to remove slack in the shoulder belt. Use The Automatic Locking Mode any time a child safety seat is installed in a seating position that has a seat belt with this feature.

  • Page 40: Driver And Front Passenger Supplemental

    WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug, and in the recommended seating positions.
  • Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This vehicle may also be equipped with side curtain airbags to protect the driver and passengers sitting next to a window. If the vehicle is equipped with side curtain airbags, they are located above the side windows. Their covers are also labeled SRS AIRBAG.
  • Page 42 NOTE: Do not use a clothing bar mounted to the coat hooks in this vehicle. A clothing bar will impede the proper performance of the curtain airbags. Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger.
  • Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. The driver and front passenger seats should be moved back as far as practical to allow the airbags time to inflate. 9. If your vehicle has side curtain airbags do not lean against the door, airbags will inflate forcefully into the space between you and the door.
  • Page 44 • Airbag Warning Light • Driver Airbag • Front Passenger Airbag • Supplemental Side Curtain Airbags above Side Win- dows (if equipped) • Steering Wheel and Column • Instrument Panel • Interconnecting Wiring • Seatbelt Reminder Light • Knee Impact Bolsters •...
  • Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Ignoring the AIRBAG Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
  • Page 46 • The Knee Impact Bolsters help protect the knees of the driver and the front passenger, and position every- one for the best interaction with the front airbag. If A Deployment Occurs The airbag system is designed to deploy when the ACM detects a moderate-to-severe collision, to help restrain the driver and front passenger, and then to immediately deflate.
  • Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Deployed airbags can’t protect you in another colli- sion. Have the airbags replaced by an authorized dealer as soon as possible. Enhanced Accident Response Feature If the airbags deploy after an impact and the electrical system remains functional, vehicles equipped with power door locks will unlock automatically.

  • Page 48: Event Data Recorder (Edr)

    Airbag Warning Light You will want to have the airbags ready to inflate for your protection in an impact. While the airbag system is designed to be mainte- nance free, if any of the following occurs, have an authorized dealer service the system promptly: •...

  • Page 49: Child Restraint

    48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE treated confidentially. Confidential data will not be dis- closed by DaimlerChrysler to any third party except when: 1. Used for research purposes, such as to match data with a particular crash record in an aggregate database, provided confidentiality of personal data is thereafter preserved 2.
  • Page 50 WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are. The child and others could be badly injured.
  • Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Older Children and Child Restraints Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
  • Page 52 WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint. •...
  • Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle structure. LATCH-compatible child restraint systems are now avail- able. However, because the lower anchorages are to be introduced over a period of years, child restraint systems having attachments for those anchorages will continue to have features for installation using the vehicle’s seat...
  • Page 54 Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.
  • Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of reach of children. It is recommended that before installing the child restraint, buckle the seat belt so the seat belt is tucked behind the child restraint and out of reach. If the buckled seat belt interferes with the child restraint installation, instead of tucking the seat belt behind the child restraint, route the seat belt through the child restraint belt path and then buckle it.
  • Page 56 Tighten webbing. To release, simply unbuckle the seat belt by depressing the button, allowing the webbing to retract into the retractor. In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint.

  • Page 57: Break-In Recommendations

    56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.

  • Page 58: Safety Tips

    CAUTION! Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered as a normal part of the break-in and not interpreted as an indication of difficulty.

  • Page 59: Safety Checks You Should Make Inside The Vehicle

    58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If it is necessary to sit in a parked vehicle with the engine running, adjust your heating or cooling controls to force outside air into the vehicle. Set the blower at high speed. The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.

  • Page 60: Periodic Safety Checks You Should Make Outside The Vehicle

    Front seat belt assemblies must be replaced after a collision. Rear seat belt assemblies must be replaced after a collision if they have been damaged (bent retractor, torn webbing, etc. If there is any question regarding belt or retractor condition, replace the belt. Airbag Warning Light The light should come on and remain on for 6 to 8 seconds as a bulb check when the ignition switch is first...

  • Page 62: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......64 Inside Day/Night Mirror ....64 Automatic Dimming Inside Mirror —...
  • Page 63 62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats ......89 Folding Rear Seat ..... .91 To Open And Close The Hood .
  • Page 64 Overhead Console ..... 106 Courtesy/Reading Lights ....106 Sunglasses Storage .

  • Page 65: Mirrors

    64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjusting Rearview Mirror Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).

  • Page 66: Outside Mirrors

    CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic and a slight overlap of the view obtained from the inside mirror.

  • Page 67: Power Remote-Control Mirrors

    66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Remote-Control Mirrors The power mirror switch is located on the driver’s door trim panel next to the power door lock switch. A rotary knob selects the left mirror, right mirror, or off position. After selecting a mirror, move the knob in the same direction you want the mirror to move.

  • Page 68: Hands-Free Communication (Uconnect™)

    HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED UConnect™ is a voice-activated, hands-free, in- vehicle communications system. UConnect™ allows you to dial a phone number with your cellular phone using simple voice commands (e.g., Call” “Mike” ”Work or Dial” “248-555-1212 ). Your cellular phone’s audio is trans- mitted through your vehicle’s audio system;...

  • Page 69: Operations

    68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The rearview mirror contains the microphone for the system and the control buttons that will enable you to access the system. UConnect™ Switches The UConnect™ system can be used with any Hands- Free Profile certified Bluetooth™ cellular phone. See www.chrysler.com/uconnect for supported phones.
  • Page 70 • For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing. • For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command, when you are asked for it.
  • Page 71 70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing and follow the audible prompts.
  • Page 72 Call/Dial by Saying a Number • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Dial. • System will prompt you to say the number you want call. • For example, you can say 234-567-8901. •...
  • Page 73 72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, enter the number designation (e.g., Home, Work, Mobile, or Pager ). This will allow you to store multiple numbers for each phonebook entry, if desired. • When prompted, recite the phone number for the phonebook entry that you are adding.
  • Page 74 • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Phonebook Delete. • After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete.

  • Page 75: Phone Call Features

    74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The UConnect™ system will then prompt you as to number designation you wish to call. • The selected number will be dialed. Phone Call Features The following features can be accessed through the UConnect™...
  • Page 76 Place/Retrieve a Call from Hold To put a call on hold, press the Phone’ button until you hear a single beep. This indicates that the call is on hold. To bring the call back from hold, press and hold the Phone’...

  • Page 77: Uconnect™ System Features

    76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After ignition key is switched off, a call can continue on the UConnect™ system either until the call ends or until the vehicle battery condition dictates cessation of the call on the UConnect™ system and transfer of the call to the mobile phone.
  • Page 78 NOTE: The emergency number dialed is based on the Country where the vehicle is purchased (911 for USA and Canada and 060 for Mexico). The number dialed may not be applicable with the available cellular service and area. The UConnect™ system does slightly lower your chances of successfully making a phone call as to that for the cell phone directly.
  • Page 79 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Working with Automated Systems This method is designed to be used in instances where one generally has to press numbers on the cellular phone keypad while navigating through an automated tele- phone system. You can use your UConnect™...
  • Page 80 your cell phone, the UConnect™ system will provide notification to inform you of your phone and network status when you are attempting to make a phone call using UConnect™. The status is given for roaming net- work signal strength, phone battery strength, etc. Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™...

  • Page 81: Advanced Phone Connectivity

    80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect™ system allows on going calls to be transferred from your cellular phone to the UConnect™ system without terminating the call. To transfer an ongo- ing call from your UConnect™...

  • Page 82: Things You Should Know About Your Uconnect™ System

    • You can also press the Voice Recognition’ button anytime while the list is being played, and then choose the phone that you wish to select. • The selected phone will be used for the next phone call. If the selected phone is not available, the UCon- nect™...
  • Page 83 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. • When navigating through an automated system, such as voice mail, or when sending a page at the end of speaking the digit string, make sure to say send.
  • Page 84 Bluetooth Communication Link Occasionally, Cellular phones have been found to lose connection to the UConnect™ system. When this hap- pens, the connection can generally be re-established by switching the phone off/on. Your cell phone is recom- mended to remain in Bluetooth on mode. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Power-Up After switching the ignition key from OFF to either ON...
  • Page 85 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85...
  • Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...

  • Page 88: Seats

    North American English Primary Alternate(s) Zero Add location Add new All of them Confirmation prompts Confirmations prompts Delete a name Delete Language Select language List names List all List paired phones List phones Pager Beeper Phone pairing Pairing Phonebook Phone book Return to main menu Return.

  • Page 89: Power Reclining Seats

    88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 90: Lumbar Support

    Lumbar Support This feature allows you to increase or decrease the amount of lumbar support. Turn the control lever for- ward to increase and rearward to decrease the desired amount of lumbar support. Lumbar Support Control Lever Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear.
  • Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The controls for each heater are located near the bottom center of the instrument panel. After turning on the ignition, you can choose from High, Off, or Low heat settings. Amber LEDs in the top portion of each switch indicate the level of heat in use.

  • Page 92: Folding Rear Seat

    Folding Rear Seat Folding Rear Seats The rear seatbacks can be folded forward to provide an additional storage area. Pull on the loops shown in the illustration to fold down either or both seatbacks. These loops can be tucked away when not in use. When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap.

  • Page 93: To Open And Close The Hood

    92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. First, pull the hood release lever located under the left side of the instrument panel. Hood Release Lever Next, move to the outside of the vehicle and push the safety catch to the left.

  • Page 94: Lights

    WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. You could have a collision. Be sure all hood latches are fully latched before driving. LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel.

  • Page 95: Automatic Headlights - If Equipped

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped This system automatically turns the headlights ON or OFF according to ambient light levels. To turn the system ON, rotate the headlight switch counter-clockwise to the AUTO (A) position. When the system is ON, the Head- light Time Delay feature is also ON.

  • Page 96: Daytime Running Lights (Canada Only)

    To activate the delay feature, turn off the ignition switch while the headlights are still on. Then, turn off the headlights within 45 seconds. The delay interval begins when headlight switch is turned off. If you turn the headlights, park lights, or ignition switch on again, the system will cancel the delay.

  • Page 97: Multi-Function Lever

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Multi-Function Lever The multi-function lever controls the operation of the turn signals, headlight beam selection, and passing lights. The lever is located on the left side of the steering column. Multi-Function Lever Turn Signals Move the Multi-Function Lever up or down and the corresponding turn signal indicator in the instrument cluster flashes to show proper operation of the front and...

  • Page 98: Overhead Console Map/Reading Lights

    Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console. Each light is turned ON by pressing the lens. Press the lens a second time to turn OFF the light. These lights also turn on when a door is opened, or when the unlock button on the remote keyless entry transmitter is pressed, or when the dimmer control is turned fully upward, past the second detent.

  • Page 99: Windshield Wipers And Washers

    98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior light Defeat (OFF) Rotate the dimmer control to the extreme bottom “OFF” position. The interior lights will remain off when the doors are open. Parade Mode (Daytime Brightness Feature) Rotate the dimmer control upward to the first detent. This feature brightens all text displays such as the odometer, Electronic Vehicle Information Center (EVIC), and radio when the parking lights or headlights are on.

  • Page 100: Intermittent Wiper System

    CAUTION! Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper switch is left in any position other than OFF. Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle with a variable pause be- tween cycles desirable.

  • Page 101: Headlights On With Wipers (Available With Auto Headlights Only)

    100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you activate the washer while the windshield wiper control is in the delay range, the wipers will operate for two wipe cycles after releasing the lever and then resume the intermittent interval previously selected. If you activate the washer while the windshield wiper is turned OFF, the wipers will operate for two wipe cycles and then turn OFF.

  • Page 102: Tilt/Telescoping Steering Column

    The fluid reservoir will hold nearly 1 gallon (4 liters) of washer fluid when the message “Low Washer Fluid” appears in the Electronic Vehicle Information Center (EVIC). WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.

  • Page 103: Adjustable Pedals - If Equipped

    102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To unlock the steering column, pull the control handle outward. To tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired.

  • Page 104: Electronic Speed Control

    Press the switch forward to move the pedals forward (toward the front of the vehicle). Press the switch rearward to move the pedals rearward (toward the driver). • The pedals can be adjusted with the ignition OFF. • The pedals can be adjusted while driving. •...

  • Page 105: To Activate

    104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate: Push the speed control lever inward (toward the steering column) and release (“ON/OFF”). The indicator light in the lever (and in the instrument cluster on some models) will illu- minate to show that the speed control system is ON. To turn the system OFF, push the lever inward (toward the steering column) again and release.

  • Page 106: To Vary The Speed Setting

    speed. To do so, push the lever up and release (RES/ ACCEL), and then remove your foot from the accelerator pedal. To Vary the Speed Setting: When the speed control is set, you can increase speed by pushing the lever up and holding (“RES/ACCEL”). When the lever is released, a new set speed will be established.

  • Page 107: Overhead Console

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE The overhead console contains courtesy/reading lights, an optional universal garage door opener (HomeLink ), storage for sunglasses, and an optional power sunroof switch. Overhead Console Courtesy/Reading Lights At the forward end of the console are two courtesy/ reading lights.

  • Page 108: Garage Door Opener (Homelink )

    GARAGE DOOR OPENER (HomeLink ) — IF EQUIPPED The HomeLink Universal Transceiver replaces up to three remote controls (hand held transmitters) that oper- ate devices such as garage door openers, motorized gates, or home lighting. It triggers these devices at the push of a button.

  • Page 109: Programming Homelink

    108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink NOTE: When programming a garage door opener, it is advised to park outside the garage. It is also recom- mended that you install a new battery in the hand-held transmitter of the device being programmed. This will allow for quicker training and accurate transmission of the radio-frequency signal.
  • Page 110 1. Press and hold the two outer HomeLink buttons. Release the buttons only when the EVIC displays “Chan- nels Cleared” (after 20 seconds); however, do not hold the buttons for longer than 30 seconds. Do not repeat this step if programming a second or third hand-held trans- mitter to the remaining HomeLink buttons.

  • Page 111: Canadian Programming/Gate Programming

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If your garage door opener fails to respond to the programmed HomeLink Universal Transceiver, and your garage door opener is manufactured after 1995, it may have a multiple security code system (rolling code system).

  • Page 112: Using Homelink

    NOTE: If programming a garage door opener or gate operator, it is advised to unplug the device during the cycling process to prevent possible overheating. 3. Continue to press and hold the HomeLink button while you press and release your hand-held transmitter every two seconds until the frequency signal is accepted successfully by HomeLink.

  • Page 113: Security

    112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For questions or comments, contact HomeLink at: www.homelink.com or 1-800-355-3515. Security If you sell your vehicle, be sure to erase the frequencies by following the “Erasing HomeLink Buttons” instruc- tions in this section. This device complies with part 15 of FCC rules and with RSS-210 of Industry Canada.

  • Page 114: Opening Sunroof - Express

    WARNING! • Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. •...

  • Page 115: Pinch Protect Override

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold for two seconds after the reversal occurs. This allows the sunroof to move towards the closed position. NOTE: Pinch protection is disabled while the switch is pressed.

  • Page 116: Sunroof Fully Closed

    Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4 of this manual. Sunroof Fully Closed Press the switch forward and release to ensure that the sunroof is fully closed. ELECTRICAL POWER OUTLETS There are three 12-volt electrical outlets on this vehicle. All of the outlets are protected by fuses.
  • Page 117 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console outlet is powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent engine starting. Center Console Power Outlet The auxiliary outlet is also powered directly from the battery (power available at all times).

  • Page 118: Electrical Outlet Use With Engine Off

    Electrical Outlet Use With Engine Off CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.

  • Page 119: Rear Seat Cup Holders

    118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seat Cup Holders The rear seat cup holders are located in the center armrest between the rear seats. The cup holders are positioned forward in the armrest and side-by-side to provide convenient access to beverage cans or bottles while maintaining a resting place for the rear occupants’...

  • Page 120: Cargo Management System - If Equipped

    Cargo Management System — If Equipped The cargo area has an upper and lower load floor. Additional innovative features in the cargo area are the two molded-in bins in the quarter trim panels. Each bin will hold a gallon of milk and a 2-liter bottle of pop. A cargo management system that stores on the lower load floor below the bi-level cargo floor is optional.
  • Page 121 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Load Floor Handle Load Floor Partially Folded...
  • Page 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Rollaway Tonneau Cover — If Equipped The removable rollaway tonneau cover mounts in the cargo area behind the top of the rear seats. Load Floor Fully Folded...
  • Page 123 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The tonneau cover, when extended, covers the cargo area to keep items out of sight. Notches in the trim panels near the liftgate opening secure the extended tonneau cover in place. The tonneau cover rolls away neatly inside its housing when not in use.
  • Page 124 Then, insert the spring-loaded post on the opposite end of the tonneau cover housing into the remaining front attachment point. Next, grab the tonneau cover handle and pull the cover toward you. As the cover nears the liftgate opening, guide the rear attachment posts (on both ends of the cover) into the notches in the trim panels.
  • Page 125 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Organizer The optional cargo organizer can also be placed into the lower load floor. Lift the handle and pull to open the cargo organizer. Cargo Organizer Handle...
  • Page 126 Cargo Tie-Down Hooks The tie-downs located on cargo area floor and on the rear trim panels should be used to safely secure loads when vehicle is moving. WARNING! • Cargo tie-down hooks are not safe anchors for a child seat tether strap. In a sudden stop or colli- sion, a hook could pull loose and allow the child seat to come loose.

  • Page 127: Roof Luggage Rack - If Equipped

    126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED The roof luggage rack consists of side rails and adjustable crossbars. The roof luggage rack is designed to carry up to 150 lbs (68 kg) of cargo uniformly distributed over both crossbars.
  • Page 128 4. Pick up the crossbar and move it to the desired location. Do not place the crossbar directly over the sunroof glass (if equipped). 5. Turn the lower clamp until the round side of the clamp completely faces the side rail. 6.

  • Page 129: Load Leveling System

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in personal injury or property damage. Follow the Roof Rack Cautions when carrying cargo on your roof rack.

  • Page 130: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Controls ... . 133 Premium Instrument Cluster ....134 Instrument Cluster Descriptions .
  • Page 131 130 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode ..156 Operation Instructions - CD Mode ..159 Operation Instructions - Auxiliary Mode ..160 Operating Instructions - Hands Free Phone —...
  • Page 132 Audio Clock Display ....176 Video Entertainment System (Sales Code XRV) — If Equipped ......177 Kicker Mobile Surround (Kms1) .
  • Page 133 132 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Wiper Operation ....197 Rear Washer Operation ....197 Adding Washer Fluid .

  • Page 134: Instrument Panel And Controls

    INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — Rear Wiper/Washer Switch 4 — Hazard Switch 5 — Electronic Stability Program Off Button* / Traction Control System Off Button* UNDERSTANDING YOUR INSTRUMENT PANEL 133 6 — Glove Box 7 —...

  • Page 135: Premium Instrument Cluster

    134 UNDERSTANDING YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...

  • Page 136: Instrument Cluster Descriptions

    INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Press this button to change the display from odometer to either of two trip odometer settings.
  • Page 137 136 UNDERSTANDING YOUR INSTRUMENT PANEL engine running, your vehicle will usually be drivable. However, see your dealer for service as soon as possible. If the light is flashing when the engine is running, immediate service is required. In this case, you may experience reduced performance, an elevated/rough idle or engine stall, and your vehicle may require towing.
  • Page 138 9. Turn Signal Indicators The arrow will flash with the exterior turn signal when the turn signal lever is operated. NOTE: A continuous chime will sound if the vehicle is driven more than 1 mile (1.6 km) with either turn signal NOTE: Check for a defective outside light bulb if either indicator flashes at a rapid rate.
  • Page 139 138 UNDERSTANDING YOUR INSTRUMENT PANEL cycles, and the vehicle has been driven several miles at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible to have the problem diagnosed and corrected. (See page 222 for more information.) 14.
  • Page 140 Loose Fuel Filler Cap If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the Electronic Vehicle Information Center (EVIC). Tighten the fuel filler cap properly and press the odometer reset button to turn off the message.
  • Page 141 140 UNDERSTANDING YOUR INSTRUMENT PANEL turn on in the event of an EBD failure. Immediate repair of the ABS system is required in the event of an EBD failure. The operation of the Brake Warning Light can be checked by turning the ignition switch from the OFF position to the ON position.
  • Page 142 Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. The Tire Pressure Monitoring Telltale Light will illumi- nate in the instrument cluster, and an audible chime will be activated when one or more tire pressures is low.
  • Page 143 142 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Anti-Lock Brake Light This light monitors the Anti-Lock Brake System. The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required.

  • Page 144: Electronic Vehicle Information Center (Evic)

    ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) Electronic Vehicle Information Center The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display. It is located in the instrument cluster below the speedometer. Vehicles equipped with steering wheel mounted buttons (de- scribed in this section) are also equipped with the EVIC. The EVIC consists of the following: •...

  • Page 145: Electronic Vehicle Information Center (Evic) Displays

    144 UNDERSTANDING YOUR INSTRUMENT PANEL Press the FUNCTION SELECT button to accept a selection. The FUNCTION SELECT button also advances the radio to the next preset station, changes the side of the tape being FUNC- played (if so equipped), or changes the current TION CD track being played (if so equipped) when SELECT...

  • Page 146: Trip Functions

    • Left/Right Front Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km]) • Left/Right Rear Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km]) •...
  • Page 147 146 UNDERSTANDING YOUR INSTRUMENT PANEL • Elapsed Time • Display Units of Measure in Press the SCROLL button to cycle through all the Trip Computer functions. The Trip Functions mode displays the following: • Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET”...

  • Page 148: Compass Display

    • Display Units of Measure in: To make your selection, press and release the FUNC- TION SELECT button until “US” or “METRIC” appears. To Reset The Display Reset will only occur while a resettable function is being displayed. Press and release the FUNCTION SELECT button once to clear the resettable function being dis- played.
  • Page 149 148 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Variance Compass Variance is the difference between magnetic North and Geographic North. In some areas of the country, the difference between magnetic and geographic North is great enough to cause the compass to give false readings.

  • Page 150: Telephone - If Equipped

    1. Turn the ignition switch ON. 2. Press and hold the compass button for approximately 2 seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4. Press and release FUNCTION SELECT button until the proper variance zone is selected according to the map.
  • Page 151 150 UNDERSTANDING YOUR INSTRUMENT PANEL The EVIC displays this symbol to indicate that the UConnect™ phone is currently in analog mode. Analog The EVIC displays this symbol to indicate that the UConnect™ phone is currently roaming. Roam- The EVIC displays this symbol to indicate that you have voice mail.

  • Page 152: Navigation - If Equipped

    Navigation — If Equipped Navigation Display Control Press and release the MENU button until Navigation displays in the EVIC. When the Navigation System is On, the steering wheel buttons can be used to select the Map or Menu display on the Navigation Unit. When the Menu display is active, the SCROLL button can be used to scroll through the list, the FUNCTION SELECT button can be used to select an item, and the AUDIO MODE button can...
  • Page 153 152 UNDERSTANDING YOUR INSTRUMENT PANEL Use the SCROLL button to display one of the following choices: “Language” When in this display you may select one of five lan- guages for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the FUNCTION SELECT button while in this display to select English, Espanol, Deutsch, Italiano, or Francais.
  • Page 154 on lock/unlock feature. To make your selection, press and release the FUNCTION SELECT button until “ON” or “OFF” appears. “Flash Lights with Remote Key Lock” When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the remote keyless entry transmitter.

  • Page 155: Radio General Information

    154 UNDERSTANDING YOUR INSTRUMENT PANEL door will cancel this feature. To make your selection, press and release the FUNCTION SELECT button until “Off,” “45 sec.,” “5 min.,” “10 min.,” “30 min.,” or “60 min.” appears. “Confirmation of Voice Commands” — If Equipped When ON is selected, all voice commands from the UConnect™...

  • Page 156: Am Reception

    and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal. AM Reception AM sound is based on wave amplitude, so AM reception can be disrupted by such things as lightning, power lines and neon signs.

  • Page 157: Operating Instructions - Radio Mode

    156 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio.
  • Page 158 (if equipped) frequencies, pausing for 5 seconds at each listenable station before continuing to the next. To stop the search, press SCAN a second time. PSCAN Button (Radio Mode) Pressing the PSCAN button causes the tuner to scan through preset stations in either, AM, FM, or Satellite (if equipped) frequencies, pausing for 5 seconds at each preset station before continuing to the next.
  • Page 159 158 UNDERSTANDING YOUR INSTRUMENT PANEL Press the rotary TUNE control a third time and TREB will display. Turn the TUNE control to the right or left to increase or decrease the Treble tones. Press the rotary TUNE control a fourth time and BAL will display.

  • Page 160: Operation Instructions - Cd Mode

    Operation Instructions - CD Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Inserting The Compact Disc (Single CD Player) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD Player and the CD icon will illuminate on the radio display.

  • Page 161: Operation Instructions - Auxiliary Mode

    160 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (CD Mode) Press this button to change the display from elapsed CD playing time to time of day. The time of day will display for 5 seconds. RW/FF (CD Mode) Press and hold the FF (Fast Forward) and the CD player will begin to fast forward until FF is released.

  • Page 162: Operating Instructions - Hands Free Phone - If Equipped

    MUTE Button (Auxiliary Mode) Press the MUTE button to cancel the sound from the speakers. MUTE will display. Press the MUTE button a second time and the sound from the speakers will return. Rotating the volume control or turning OFF the ignition will also return the sound from the speakers.

  • Page 163: Sales Code Rak - Am/Fm/Cassette/Cd (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, Video, Mp3, And Wma Capabilities

    162 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAK – AM/FM/CASSETTE/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, VIDEO, MP3, and WMA CAPABILITIES NOTE: The radio sales code is located on the lower right side of your radio faceplate. RAK Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
  • Page 164 Press the right side of the button to seek up and the left side to seek down. The radio will remained tuned to the new station until you make another selection. Holding the button and will bypass stations without stopping until you release it.
  • Page 165 164 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM Button (Radio Mode) Press the button to select AM or FM Modes. Setting the Tone, Balance, and Fade Press the rotary TUNE control and BASS will display. Turn the TUNE control to the right or left to increase or decrease the Bass tones.

  • Page 166: Operating Instructions - Tape Player

    Soft Rock Top 40 Country Oldies Soft Nostalgia Jazz Classical Rhythm and Blues Rhythm_and_Blues Soft Rhythm and Blues Foreign Language Foreign_Language Religious Music Religious_Music Religious Talk Religious_Talk Personality Public College Unassigned Weather By pressing the SEEK button when the PTY icon is displayed, the radio will be tuned to the next frequency UNDERSTANDING YOUR INSTRUMENT PANEL 165 station with the same selected PTY name.

  • Page 167: Seek Button

    166 UNDERSTANDING YOUR INSTRUMENT PANEL Seek Button Press the SEEK button up for the next selection on the tape and down to return to the beginning of the current selection. Press the SEEK button up or down to move the track number to skip forward or backward 1 to 6 selections.

  • Page 168: Noise Reduction

    Noise Reduction The Dolby Noise Reduction System* is on whenever the tape player is on, but may be switched off. To turn off the Dolby Noise reduction System: Press Preset 1 after you insert the tape. The NR light in the display will go off when the Dolby System is off.

  • Page 169: Load/Eject Button (Cd Mode For Cd Audio Play)

    168 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (CD MODE for CD Audio Play) Press the Scan button to scan through each track on the CD currently playing. LOAD/EJECT Button (CD Mode for CD Audio Play) LOAD/EJECT - Load Press the LOAD/EJT button and the push- button with the corresponding number where the CD is being loaded.

  • Page 170: Notes On Playing Mp3 Files

    RW/FF (CD MODE for CD Audio Play) Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed. The RW (Reverse) button works in a similar manner. TUNE Control (CD MODE for CD Audio Play) Pressing the TUNE control allows the setting of the Tone, Fade, and Balance.
  • Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL files properly and may be unable to play the file nor- mally. UDF and Apple HFS formats are not supported. The radio uses the following limits for file systems: • Maximum number of directory levels: 15 •...

  • Page 172: Operation Instructions - (Cd Mode For Mp3 And Wma Audio Play)

    ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios. Playlist files are not supported. MP3 Pro files are not supported. Playback of MP3 and WMA Files When a medium containing MP3 data is loaded, the radio checks all files on the medium.
  • Page 173 172 UNDERSTANDING YOUR INSTRUMENT PANEL The radio display will show LOADING DISC when the disc is loading. LOAD/EJT - Eject Press the LOAD/EJT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal.

  • Page 174: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System

    RND/PTY Button (CD Mode for MP3 Play) Pressing this button plays files randomly. SET/DIR Button (CD Mode for MP3 Play) Press the SET/DIR Button to display folders, when playing an MP3 discs that have a file/folder structure. Turn the TUNE control to display available folders or move through available folders.

  • Page 175: Operating Instructions - Satellite Radio (If Equipped)

    174 UNDERSTANDING YOUR INSTRUMENT PANEL screen to provide maps, turn identification, selection menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD changer with MP3 capability. Mapping information for navigation is supplied on a DVD that is loaded into the unit.
  • Page 176 4. To turn daylight savings on or off, select “Daylight Savings” and press ENTER. Select “On” or “Off” and press ENTER. 5. Select DONE to exit from the clock setting mode. Press ENTER to save your changes. If you press CANCEL or NAV then your changes will not be saved.

  • Page 177: Audio Clock Display

    176 UNDERSTANDING YOUR INSTRUMENT PANEL 4. To increase the clock by minutes, make sure “MIN +” is highlighted and press ENTER. Press ENTER again to increase the clock by another minute. 5. To decrease the clock by minutes, use the Select Encoder to highlight the “-“...

  • Page 178: Video Entertainment System (Sales Code Xrv) - If Equipped

    3. To switch the clock to the small clock, quickly press TIME again. 4. To toggle back to the large clock, simply press TIME. UNDERSTANDING YOUR INSTRUMENT PANEL 177 VIDEO ENTERTAINMENT SYSTEM (SALES CODE XRV) — IF EQUIPPED The optional VES™ (Video Entertainment System) con- sists of a DVD player and LCD (liquid crystal display) screen, a battery-powered remote control, and two head- sets.
  • Page 179 178 UNDERSTANDING YOUR INSTRUMENT PANEL Raising The DVD Screen Remote Control Location...

  • Page 180: Kicker Mobile Surround (Kms1)

    Kicker Mobile Surround (KMS1) The VES for this vehicle comes equipped with Kicker Mobile Surround (KMS1). This feature offers the ultimate movie experience by providing surround sound uniquely equalized for the interior space of your vehicle. The KMS1 activates whenever a DVD is in the VES player, and the radio mode is set to VES, and the video screen is powered up.

  • Page 181: Electronic Serial Number/Sirius Identification Number (Esn/Sid)

    180 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification Number (ESN/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access With REF Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and Time buttons simultaneously for 3 seconds.

  • Page 182: Selecting A Channel

    Selecting Satellite Mode — RAQ and RAK Radio Press the MODE button repeatedly until the word SAT appears in the display. These radios will also display the current station name and program type. For more information, such as song title and artist press the MSG or INFO button. A CD or tape may remain in the radio while in the Satellite radio mode.

  • Page 183: Pty Button Seek

    182 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Pressing the SEEK or SCAN button, while performing a music type scan, will change the channel by one and stop the search. Pressing a pre-set memory button during a music type scan, will call up the memory channel and stop the search.

  • Page 184: Remote Sound System Controls

    REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the surface of the steering wheel at the 3 and 9 o’clock positions. Electronic Vehicle Information Center Vehicles equipped with steering wheel mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC).

  • Page 185: Radio Operation

    184 UNDERSTANDING YOUR INSTRUMENT PANEL When the EVIC is in the Compass/Temp/ Audio screen, press the FUNCTION SELECT button to advance the radio to the next preset station, to change the side of the tape being FUNC- played (if so equipped), or to change the cur- TION rent CD track being played (if so equipped).

  • Page 186: Satellite Radio Operation

    Press either the top or bottom of the SCROLL button twice to listen to the second track on the CD, three times to listen to the third track, and so forth. Satellite Radio Operation Press the top of the SCROLL button once to SEEK the next listenable station up from the current setting.

  • Page 187: Cd/Dvd Disc Maintenance

    186 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE To keep the CD/DVD discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge.

  • Page 188: Manual Air Conditioning And Heating System

    Manual Air Conditioning and Heating System Manual Temperature Controls Blower Control The rotary knob on the left controls the blower. The control has an OFF posi- tion and four speed settings. The blower will remain on until the con- trol is turned to the OFF position or the ignition is turned OFF.
  • Page 189 188 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: To improve fuel economy, leave in defrost only when necessary. • Defrost/Floor Air flows through the front and rear floor outlets and the outlets at the base of the windshield. Air is also directed to the front door windows through the side window demister grilles.

  • Page 190: Automatic Temperature Control - If Equipped

    Air Conditioning Control Press this button to turn on and turn off the air conditioning. When the air conditioning is turned on, cool dehumidified air will flow through the outlets selected with the mode control. Press this button a second time to turn off the air conditioning. An LED in the button will illuminate when compressor operation is selected.
  • Page 191 190 UNDERSTANDING YOUR INSTRUMENT PANEL the Blower Control knob (on the left) to either LO AUTO or HI AUTO. The LO AUTO position should be used for front seat occupants only. The HI AUTO position should be used when more airflow is desired, or when rear seat occupants are present.
  • Page 192 NOTE: • The surface of the climate control panel and the top center of the instrument panel should be kept free of debris due to the location of the climate control sensors. Mud on the windshield may also cause poor operation of this system.
  • Page 193 192 UNDERSTANDING YOUR INSTRUMENT PANEL...
  • Page 194 The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Defrost Air is directed to the windshield through the outlets at the base of the windshield. Air is also directed to the front door windows through the side window demister grilles.

  • Page 195: Operating Tips

    194 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. • Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
  • Page 196 Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e. vacation) for two weeks or more, run the air condi- tioning system at idle for about five minutes in the fresh air and high blower setting. This will insure adequate system lubrication to minimize the possibility of com- pressor damage when the system is started again.
  • Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...

  • Page 198: Rear Window Features

    REAR WINDOW FEATURES Rear Wiper Operation The rear wiper is operated by the rear wiper/ washer switch. The switch is located near the top center of the instrument panel. An indicator in the switch illuminates when the rear wiper is on. Rear Wiper/Washer Switch To use the rear wiper, push the left side of the rear wiper/washer switch in and release.
  • Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL Adding Washer Fluid The windshield washer and rear window washer share the same fluid reservoir. The reservoir is located in the front of the engine compartment on the passenger side of the vehicle. Be sure to check the fluid level at regular intervals.
  • Page 200 UNDERSTANDING YOUR INSTRUMENT PANEL 199 CAUTION! To avoid damaging the electrical conductors of the rear window defroster, do not use scrapers, sharp instruments, or abrasive window cleaners on the interior surface of the window. Labels can be peeled off after soaking with warm water.

  • Page 202: Starting And Operating

    STARTING AND OPERATING CONTENTS Starting Procedures ....204 Automatic Transmission ....205 Normal Starting .
  • Page 203 202 STARTING AND OPERATING Electronic Brake Control System ... 222 ABS (Anti-Lock Brake System) ... . 222 TCS (Traction Control System) ... . 223 BAS (Brake Assist System) .
  • Page 204 6.1L Engine ......253 Reformulated Gasoline ....254 Gasoline/Oxygenate Blends .

  • Page 205: Starting And Operating

    204 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.

  • Page 206: Automatic Transmission

    Automatic Transmission The gear selector must be in the NEUTRAL or PARK position before you can start the engine. Apply the brakes before shifting into any driving gear. Normal Starting Normal Starting of either a cold or a warm engine is obtained without pumping or depressing the accelerator pedal.

  • Page 207: After Starting

    206 STARTING AND OPERATING WARNING! • Never pour fuel or other flammable liquid into the throttle body air inlet opening in an attempt to start the vehicle. This could result in flash fire causing serious personal injury. • Do not attempt to push or tow your vehicle to get it started.

  • Page 208: Engine Block Heater - If Equipped

    ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 volt AC electrical outlet with a grounded, three-wire extension cord. The engine block heater cord is routed under the hood on the driver side of the vehicle.

  • Page 209: Automatic Transmission - General Information

    208 STARTING AND OPERATING WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in re- verse.
  • Page 210 The selector lever is automatically locked while in the P (Park) position. To move the selector lever out of the P (Park) position, the brake pedal must be firmly depressed before the shift lock will release. Shift the selector lever to the desired position only when the engine is idling normally and the brake pedal is applied.

  • Page 211: Brake/Transmission Shift Interlock System

    210 STARTING AND OPERATING Brake/Transmission Shift Interlock System This vehicle is equipped with a brake transmission shift interlock system (BTSI) that holds the selector lever in the P (Park) position when the ignition switch is in the LOCK position. To move the gear selector lever out of the P (Park) position, the ignition switch must be turned to the ON position, and the brake pedal must be depressed.

  • Page 212: Speed Automatic Transmission

    5 Speed Automatic Transmission Shifting from D (Drive) to P (Park) or R (Reverse) (or from P or R to D) should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake when moving the selector lever between these gears.
  • Page 213 212 STARTING AND OPERATING The following indicators should be used to ensure that you have engaged the selector lever into the P (Park) position: • When shifting into P (Park) move the lever all the way forward until it stops, and is fully seated. •...
  • Page 214 D (Drive) This range should be used for most city and highway driving. It provides the smoothest upshifts and down- shifts and best fuel economy. The transmission automatically upshifts through fifth gear. The D (Drive) position provides optimum driving characteristics under all normal operating conditions. When frequent transmission shifting occurs when using the Overdrive range, such as when operating the vehicle under heavy loading conditions (in hilly terrain, travel-...
  • Page 215 214 STARTING AND OPERATING Delayed Shifts in Cold Temperatures During cold temperature operation, you may notice delayed upshifts depending on engine and transmission temperature as well as vehicle speed. This feature im- proves warm up time of the engine and transmission to achieve maximum efficiency.

  • Page 216: Autostick

    times. Follow the reset procedure described under “Tem- porary Transmission Limp Home Mode” in this section. In Permanent Limp Home Mode, P (Park), R (Reverse), and N (Neutral) will continue to operate. Second gear will operate in the D (Drive) shifter position. The mal- function indicator light may illuminate.

  • Page 217: Autostick General Information

    216 STARTING AND OPERATING right for at least one second. The transmission will now operate automatically, shifting between the five available gears. Autostick General Information • You can start out in first or second gear. The system will ignore attempts to upshift at too low of a vehicle speed.

  • Page 218: Parking Brake

    partial or complete loss of vehicle control and stopping ability. To reduce this possibility, the following precau- tions should be observed: 1. Slow down during rainstorms or when the roads are slushy. 2. Slow down if road has standing water or puddles. 3.
  • Page 219 218 STARTING AND OPERATING The foot operated parking brake is positioned below the lower left corner of the instrument panel. To apply the parking brake, push the parking brake pedal down and then remove your foot from the pedal. To release the parking brake, push down on the parking brake pedal and then release.

  • Page 220: Brake System

    BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic systems loses normal capability, the remaining system will still function. There will be some loss of overall braking effectiveness. This may be evident by increased pedal travel during application, greater pedal force required to slow or stop, and potential activation of the Brake Warning Light.
  • Page 221 220 STARTING AND OPERATING You also may experience the following when the brake system goes into Anti-lock: • The ABS motor running (it may continue to run for a short time after the stop), • the clicking sound of solenoid valves, •...

  • Page 222: Power Steering

    All vehicle wheels and tires must be the same size and type and tires must be properly inflated to produce accurate signals for the computer. Anti-Lock Brake Light The ABS light monitors the Anti-Lock Brake Sys- tem. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds.

  • Page 223: Electronic Brake Control System

    222 STARTING AND OPERATING WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and it should be avoided when possible.

  • Page 224: Tcs (Traction Control System)

    WARNING! The ABS (Anti-Lock Brake System) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. The ABS cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.

  • Page 225: Esp (Electronic Stability Program)

    224 STARTING AND OPERATING WARNING! The BAS (Brake Assist System) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevail- ing road conditions. The BAS cannot prevent acci- dents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
  • Page 226 WARNING! The ESP (Electronic Stability Program) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
  • Page 227 226 STARTING AND OPERATING Full Off This mode is intended for off-highway or off-road use only and should not be used on any public roadways. In this mode, all TCS and ESP stability features are turned off. To enter the “Full Off” mode, depress and hold the “ESP OFF”...

  • Page 228: Synchronizing Esp

    WARNING! With the ESP switched off, the enhanced vehicle stability offered by ESP is unavailable. In an emer- gency evasive maneuver, the ESP system will not engage to assist in maintaining stability. The “Full Off” ESP mode is intended for off-highway or off- road only.

  • Page 229: Tire Safety Information

    228 STARTING AND OPERATING NOTE: • The ESP/TCS Indicator Light and the ESP/BAS Malfunction Indicator Light will turn on momentarily each time the ignition switch is turned ON. • Each time the ignition is turned ON, the ESP System will be ON even if it was turned off previously. •...
  • Page 230 NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width.
  • Page 231 230 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
  • Page 232 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions.

  • Page 233: Tire Identification Number (Tin)

    232 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire.

  • Page 234: Tire Loading And Tire Pressure

    Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 233 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the:...
  • Page 235 234 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
  • Page 236 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. NOTE: The following table shows examples on how to calculate total load, cargo/luggage, and towing capaci- ties of your vehicle with varying seating configurations STARTING AND OPERATING 235...
  • Page 237 236 STARTING AND OPERATING...

  • Page 238: Tires - General Information

    WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 239: Tire Inflation Pressures

    238 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
  • Page 240 when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.

  • Page 241: Radial-Ply Tires

    240 STARTING AND OPERATING WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Don’t drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).

  • Page 242: Tread Wear Indicators

    Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 inch (2 mm).

  • Page 243: Replacement Tires

    242 STARTING AND OPERATING Replacement Tires The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance when replacement is needed (refer to the paragraph on “Tread Wear Indicators”).

  • Page 244: Alignment And Balance

    CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer read- ings. Alignment And Balance Poor suspension alignment may result in: • Fast tire wear. • Uneven tire wear, such as feathering and one-sided wear.

  • Page 245: Snow Tires

    244 STARTING AND OPERATING CAUTION! To avoid damage to your vehicle or tires, observe the following precautions: • Because of restricted chain clearance between tires and other suspension components, it is important that only chains in good condition are used. Broken chains can cause serious damage.

  • Page 246: Tire Rotation Recommendations

    Snow tires generally have lower speed ratings than what was originally equipped with your vehicle and should not be operated at sustained speeds over 75 mph (120 km/h). TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions.

  • Page 247: Tire Rotation - All Season Tires

    246 STARTING AND OPERATING Tire Rotation — All Season Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram. TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED • The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold placard pressure.
  • Page 248 • The TPM System will warn the driver of a low tire pressure if the tire pressure falls below the low- pressure warning limit for any reason, including low temperature effects. • The TPM System will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above the recommended cold placard pressure.
  • Page 249 248 STARTING AND OPERATING CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.

  • Page 250: Base System - If Equipped

    Base System — If Equipped The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the Receiver Module. NOTE: It is particularly important for you to check the tire pressure in all of the tires on your vehicle regularly and to maintain the proper pressure.

  • Page 251: Premium System - If Equipped

    250 STARTING AND OPERATING warning limit in any of the four active road tires. The vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning The Tire Pressure Monitoring Telltale Light will flash on and off for 60 seconds and an audible chime will sound...
  • Page 252 values flashing. Should this occur, you should stop as soon as possible, and inflate the tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the Tire Pressure Monitoring Telltale Light will turn off.
  • Page 253 252 STARTING AND OPERATING of a road tire that has a pressure below the low- pressure warning limit, the Tire Pressure Monitoring Telltale Light will remain ON and a chime will still sound each ignition key cycle. In addition, the EVIC will still display a low-pressure message and a flash- ing pressure value in the graphic display.

  • Page 254: General Information

    NOTE: You can change the pressure units to display in PSI, kPA, or BAR. Refer to “Language,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4 of this manual for details. If the ignition key is cycled, this sequence will repeat, providing the system fault still exists.

  • Page 255: Reformulated Gasoline

    254 STARTING AND OPERATING Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) which define fuel properties necessary to deliver enhanced emissions, engine performance, and durability for your vehicle.

  • Page 256: Mmt In Gasoline

    MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase the octane num- ber. Gasolines blended with MMT offer no performance advantage beyond gasolines of the same octane number without MMT. Gasolines blended with MMT have shown to reduce spark plug life and reduce emission system performance in some vehicles.

  • Page 257: Carbon Monoxide Warnings

    256 STARTING AND OPERATING • The use of fuel additives, which are now being sold as octane enhancers, are not recommended. Most of these products contain high concentrations of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives are not the responsibility of the manufacturer.

  • Page 258: Adding Fuel

    ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. Push in on the left side (near the edge) of the fuel filler door to access the fuel filler cap. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.
  • Page 259 258 STARTING AND OPERATING CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel tank filler tube cap (gas cap). • A poorly fitting gas cap could let impurities into the fuel system. •...

  • Page 260: Loose Fuel Filler Cap Message

    Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the Electronic Vehicle Information Center (EVIC). If this occurs, tighten the fuel filler cap properly and press the odometer reset button to turn off the message.

  • Page 261: Gross Vehicle Weight Rating (Gvwr)

    260 STARTING AND OPERATING • Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the Vehicle Identification Number (VIN). Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, and cargo.

  • Page 262: Loading

    Loading To load your vehicle properly, first figure out its empty weight, axle by axle and side by side. Store heavier items down low and be sure you distribute their weight as evenly as possible. Stow all loose items securely before driving.

  • Page 263: Trailer Towing

    262 STARTING AND OPERATING NOTE: Refer to the “Vehicle Certification Label” at- tached to the rear of the driver’s door for your vehicle’s GVWR and GAWRs. This table is only an example. TRAILER TOWING In this section, you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle.
  • Page 264 WARNING! It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Tongue Weight (TW) Tongue weight (TW) is the downward force exerted on the hitch ball by the trailer.
  • Page 265 264 STARTING AND OPERATING WARNING! • An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking performance, and could result in an acci- dent. • Weight Distributing Systems may not be compat- ible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional infor- mation.

  • Page 266: Trailer Hitch Classification

    Improper Adjustment of Weight Distributing System Trailer Hitch Classification Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your authorized dealer for package content. The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can STARTING AND OPERATING 265...

  • Page 267: Trailer And Tongue Weight

    266 STARTING AND OPERATING Engine/Transmission 6.1L Automatic Refer to local laws for maximum trailer towing speeds. NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the “Tire and Loading Information”...

  • Page 268: Towing Requirements

    Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer. • The weight of any other type of cargo or equipment put in or on your vehicle. • The weight of the driver and all passengers. NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle.
  • Page 269 268 STARTING AND OPERATING WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
  • Page 270 − Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to “Tires–General Information” in this section for infor- mation on tire pressures and for proper tire inflation procedures. − Also, check the trailer tires for proper tire inflation pressures before trailer usage.
  • Page 271 270 STARTING AND OPERATING WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.

  • Page 272: Towing Tips

    STARTING AND OPERATING 271 Towing Tips Before setting out on a trip, practice turning, stopping, and backing the trailer in an area located away from heavy traffic. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the “3”...
  • Page 273 272 STARTING AND OPERATING Towing Tips — Electronic Speed Control (If Equipped) − Don’t use in hilly terrain or with heavy loads. − When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.

  • Page 274: Recreational Towing (Behind Motorhome, Etc.)

    RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground) Recreational towing for this vehicle is not recommended. NOTE: If the vehicle requires towing, make sure all four wheels are off the ground. STARTING AND OPERATING 273 GROUND CLEARANCE CAUTION!

  • Page 276: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....276 If Your Engine Overheats ....276 TIREFIT Tire Repair .

  • Page 277: Hazard Warning Flasher

    276 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The hazard flasher switch is located in the center of the instrument panel below the center air outlets. Hazard Flasher Switch To engage the Hazard Warning Flashers, depress the switch on the instrument panel. When the Hazard Warn- ing Switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emer- gency.

  • Page 278: Tirefit Tire Repair

    NOTE: There are steps that you can take to slow down an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to the engine cooling system and turning off the A/C removes this heat.
  • Page 279 278 WHAT TO DO IN EMERGENCIES TIREFIT contents TIREFIT Location 1. Air pump hose 2. Power plug and cable 3. Air pump switch 4. Pressure gauge 5. TIREFIT sealant bottle 6. TIREFIT sealant hose...
  • Page 280 WARNING! • Do not attempt to repair a tire on the side of the vehicle close to traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or repairing a tire. • Cuts or punctures larger than approximately 0.16 in.
  • Page 281 280 WHAT TO DO IN EMERGENCIES 5. Unscrew the valve cap from the valve on the deflated tire. 6. Screw the fitting at the end of TIREFIT sealant hose (6) coming from the sealant bottle (5) onto the tire valve. 7.
  • Page 282 19. With a tire pressure of no less than 26 psi (1.8 bar) press the air pump switch (3) to 0 (OFF) and turn off the engine. Then, disconnect the TIREFIT system from the tire and place it back in the vehicle. 20.

  • Page 283: Jump-Starting Procedures

    282 WHAT TO DO IN EMERGENCIES • Do not operate the electric air pump for more than eight minutes to avoid overheating. The air pump may be used again once it has cooled down. • Replace the TIREFIT sealant bottle (5) once every four years to assure optimum operation of the system.
  • Page 284 NOTE: The battery is stored under a hinged access cover in the load floor in the cargo area. Remote battery terminals are located in the engine compartment for jump-starting. 1. Wear eye protection and remove any metal jewelry such as watchbands or bracelets that might make an inadvertent electrical contact.
  • Page 285 284 WHAT TO DO IN EMERGENCIES 6. Connect the other cable, first to the negative terminal of the booster battery and then to the engine ground (-) of the vehicle with the discharged battery. Make sure you have a good contact on the engine ground. Refer to the following illustration for jump-starting connections.

  • Page 286: Freeing A Stuck Vehicle

    8. When removing the jumper cables, reverse the above sequence exactly. Be careful of the moving belts and fan. WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion;...

  • Page 287: Towing A Disabled Vehicle

    286 WHAT TO DO IN EMERGENCIES CAUTION! • When “rocking” a stuck vehicle by moving be- tween “First” and R (Reverse), do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Racing the engine or spinning the wheels too fast may lead to transmission overheating and failure.

  • Page 288: Towing This Vehicle Behind Another Vehicle With A Tow Dolly

    operative, or if the vehicle is to be towed more than 30 miles (48 km), the vehicle must be transported using a flat bed truck. CAUTION! • Do not attempt to tow this vehicle from the front with sling type towing equipment. Damage to the front fascia will result.

  • Page 290: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS 6.1L Engine Compartment ....291 Onboard Diagnostic System — OBD II ..292 Loose Fuel Filler Cap ....292 Emissions Inspection And Maintenance Programs .
  • Page 291 290 MAINTAINING YOUR VEHICLE Windshield Washers/Rear Window Washer . . . 305 Exhaust System ..... . 306 Cooling System ..... . . 307 Hoses And Vacuum/Vapor Harnesses .

  • Page 292: 6.1L Engine Compartment

    MAINTAINING YOUR VEHICLE 291 6.1L ENGINE COMPARTMENT...

  • Page 293: Onboard Diagnostic System - Obd Ii

    292 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.

  • Page 294: Emissions Inspection And Maintenance Programs

    A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration.

  • Page 295: Replacement Parts

    294 MAINTAINING YOUR VEHICLE b. The MIL will not flash at all and will remain fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is ready and you can proceed to the I/M station.

  • Page 296: Maintenance Procedures

    WARNING! You can be badly injured working on or around a motor vehicle. Only do service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
  • Page 297 296 MAINTAINING YOUR VEHICLE Engine Oil Dipstick CAUTION! Overfilling or underfilling will cause oil aeration or loss of oil pressure. This could damage your engine. Change Engine Oil Road conditions and your kind of driving affect the interval at which your oil should be changed. Check the following list to see if any apply to you.
  • Page 298 NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or 6 months, whichever comes first. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and meet the requirements of DaimlerChrysler Material Standard MS-10725.

  • Page 299: Engine Oil Filter

    298 MAINTAINING YOUR VEHICLE Disposing of Used Engine Oil and Oil Filters Care should be taken in disposing of used engine oil and oil filters from your vehicle. Used oil and oil filters, indiscriminately discarded, can present a problem to the environment.

  • Page 300: Engine Air Cleaner Filter

    Engine Air Cleaner Filter For normal driving conditions, inspect and replace the engine air cleaner filter at the intervals shown on Sched- ule “A.” For vehicles driven frequently in dusty or under severe conditions, inspect and replace the engine air cleaner filter at the intervals shown on Schedule “B.”...
  • Page 301 300 MAINTAINING YOUR VEHICLE CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and the...

  • Page 302: Maintenance-Free Battery

    • Do not try to start engine by pushing or towing the vehicle. • Do not idle the engine with any spark plug wires disconnected or removed, such as when diagnostic testing, or for prolonged periods during very rough idling or malfunctioning operating conditions. Maintenance-Free Battery The top of the MAINTENANCE-FREE battery is perma- nently sealed.

  • Page 303: Air Conditioner Maintenance

    302 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.

  • Page 304: A/C Air Filter - If Equipped

    WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information book for further warranty information.

  • Page 305: Power Steering - Fluid Check

    304 MAINTAINING YOUR VEHICLE Refer to the “Maintenance Schedule” in this manual for the recommended air conditioning filter replacement intervals. Power Steering — Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated.

  • Page 306: Wiper Blades

    The external lock cylinders should be lubricated twice a year, preferably in the fall and spring. Apply a small amount of a high quality lubricant such as Mopar Lock Cylinder Lubricant or equivalent directly into the lock cylinder. Wiper Blades Clean the rubber edges of the wiper blades and the windshield and rear window periodically with a sponge or soft cloth and a mild nonabrasive cleaner.

  • Page 307: Exhaust System

    306 MAINTAINING YOUR VEHICLE Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken,...

  • Page 308: Cooling System

    Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the OFF position. The fan is temperature controlled and can start at any time the ignition switch is in the ON position. •...
  • Page 309 308 MAINTAINING YOUR VEHICLE Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown on the Maintenance Schedule. If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner.
  • Page 310 Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to 5 Years or 100,000 miles (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
  • Page 311 310 MAINTAINING YOUR VEHICLE WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine.

  • Page 312: Hoses And Vacuum/Vapor Harnesses

    humidity accumulating on the radiator and being vapor- ized when the thermostat opens, allowing hot coolant to enter the radiator. If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be safely driven. The vapor will soon dissipate. •...

  • Page 313: Fuel System

    312 MAINTAINING YOUR VEHICLE Insure nylon tubing in these areas has not melted or collapsed. Inspect all hose connections such as clamps and cou- plings to make sure they are secure and no leaks are present. Components should be replaced immediately if there is any evidence of wear or damage that could cause failure.
  • Page 314 Insure nylon tubing in these areas has not melted or collapsed. Inspect all hose connections such as clamps and cou- plings to make sure they are secure and no leaks are present. NOTE: • Often, fluid such as oil, power steering fluid, and brake fluid are used during assembly plant operations to facilitate the assembly of hoses to couplings.

  • Page 315: Automatic Transmission

    314 MAINTAINING YOUR VEHICLE brakes, fluid level can be expected to fall as the brake pads wear. However, low fluid level may be caused by a leak and a checkup may be needed. Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts”...

  • Page 316: Front And Rear Wheel Bearings

    CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than that recommended by the manufac- turer will result in more frequent fluid and filter changes.

  • Page 317: Appearance Care And Protection From Corrosion

    316 MAINTAINING YOUR VEHICLE Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and chemicals that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
  • Page 318 CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces. Special Care • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month.
  • Page 319 318 MAINTAINING YOUR VEHICLE Interior Care Use Mopar Fabric Cleaner or equivalent to clean fabric upholstery and Mopar Carpet Cleaner for carpeting. Interior Trim should be cleaned starting with a damp cloth, or Mopar Satin Select. Do not use harsh cleaners or Armorall.

  • Page 320: Cleaning The Center Console Cup Holders

    cleaner. Use caution when cleaning the inside rear win- dow equipped with electric defrosters or the right rear quarter window equipped with the radio antenna. Do not use scrapers or other sharp instruments, which may scratch the elements. When cleaning the rear view mirror, spray cleaner on the towel or rag that you are using.

  • Page 321: Fuses (Power Distribution Centers)

    320 MAINTAINING YOUR VEHICLE • Carefully tuck the front, followed by the rear, then side edges of the cup holder into the center console. FUSES (POWER DISTRIBUTION CENTERS) Fuses (Front Power Distribution Center) A power distribution center is located in the engine compartment.
  • Page 322 Cavity Car- Mini Description tridge Fuse Fuse — 25 Amp Auto Shutdown/ Clear Powertrain Control Module (PCM) — — — — — — — 25 Amp Powertrain Control Clear Module (PCM) — 20 Amp Injectors, Ignition Coils Yellow — — —...

  • Page 323: Fuses (Rear Power Distribution Center)

    322 MAINTAINING YOUR VEHICLE CAUTION! • When installing the Power Distribution Center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Power Distribu- tion Center, and possibly result in a electrical system failure.
  • Page 324 Cavity Car- Mini Description tridge Fuse Fuse 60 Amp — Ignition Off Draw (IOD) Yellow 40 Amp — Battery Green — — — 40 Amp — Battery Green 40 Amp — Heated Seats - if Green equipped — 20 Amp Fuel Pump Yellow —...
  • Page 325 324 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse — — — — — — — — — — — — — 10 Amp Airbag/Airbag Control Module (ACM) — 10 Amp Curtain Airbag - if equipped — 5 Amp Anti-lock Brakes Orange Module/Cluster/Front...
  • Page 326 Cavity Car- Mini Description tridge Fuse Fuse — 5 Amp Overhead Console Orange — 10 Amp Heated Mirrors - if equipped — 10 Amp Heated Seats - if equipped/Inside Rear- view Mirror — 10 Amp Tire Pressure Monitoring - if equipped 30 Amp —...

  • Page 327: Vehicle Storage

    326 MAINTAINING YOUR VEHICLE VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days, you may want to take steps to protect your battery. You may: • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e.

  • Page 328: Bulb Replacement

    LIGHT BULBS — Exterior Low Beam Headlight ..... 9006 High Beam Headlight..... 9005 Front Park/Turn Light .
  • Page 329 328 MAINTAINING YOUR VEHICLE 3 — Park/Turn Light Bulb CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. Tail/Stop, Turn Signal Light, and Backup Light 1.
  • Page 330 6. Remove 2 push pin fasteners under the liftgate with a flat blade tool. MAINTAINING YOUR VEHICLE 329 7. Pull tail light assembly clear from vehicle to access bulbs. 8. Turn the appropriate bulb and socket assembly counter-clockwise to remove it from the tail light assem- bly.
  • Page 331 330 MAINTAINING YOUR VEHICLE 2 — Turn Signal Light Bulb 3 — Backup Light Bulb 9. Pull the bulb out of the socket assembly. 10. Push the replacement bulb into the socket assembly. 11. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise.

  • Page 332: License Light

    License Light 1. Remove the screws securing the light to the rear fascia. 2. Remove the bulb and socket assembly. 3. Pull the bulb out of the socket assembly. 1 — License Light Bulb 2 — Socket 4. Push the replacement bulb into the socket assembly. 5.

  • Page 333: Fluids, Lubricants, And Genuine Parts

    332 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (6.1 Liter) Oil Filter (6.1 Liter) Spark Plugs Fuel Selection (6.1 Liter) Fluids, Lubricants, and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that...

  • Page 334: Chassis

    Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Rear Axle Fluids, Lubricants, and Genuine Parts Mopar ATF+4 Automatic Transmission Fluid. Mopar DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids.
  • Page 336 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..336 Maintenance Schedules ....336 Schedule “B” ......339 Schedule “A”...

  • Page 337: Emission Control System Maintenance

    336 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
  • Page 338 • Taxi, police, or delivery service (commercial ser- vice). • Off-road or desert operation. NOTE: If ANY of these apply to you, then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first, and follow the maintenance rec- ommendations in Schedule “B”...
  • Page 339 338 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery, and clean, and tighten the termi- nals as required. • Check the fluid levels of coolant reservoir and brake master cylinder, and add as needed.

  • Page 340: Schedule "B" 339

    SCHEDULE “B” Follow Schedule “B” if you usually operate your vehicle under one or more of the following conditions. Change the automatic transmission fluid and filter every 60,000 miles (100 000 km) if the vehicle is usually operated under one or more of the conditions marked with an •...
  • Page 341 340 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors.
  • Page 342 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and replace, if necessary, the PCV valve.
  • Page 343 342 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors.
  • Page 344 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and tensioner.
  • Page 345 344 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors.
  • Page 346 Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the spark plugs.
  • Page 347 346 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and replace, if necessary, the PCV valve.
  • Page 348 Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and ten- sioner.
  • Page 349 348 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Change the rear axle fluid.

  • Page 350: Schedule "A" 349

    SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the air conditioning filter. Rotate the tires.
  • Page 351 350 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and tensioner.
  • Page 352 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and ten- sioner.
  • Page 353 352 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and ten- sioner.
  • Page 354 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the air conditioning filter. Rotate the tires. * This maintenance is recommended by the manufacturer to the owner but is not required to maintain the emis- sions warranty.

  • Page 356: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......356 Prepare For The Appointment .

  • Page 357: Suggestions For Obtaining Service For Your Vehicle

    We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
  • Page 358 • If for some reason you are still not satisfied, talk to the general manager or owner of the dealership. They want to know if you need assistance. • If your dealership is unable to resolve the concern, you may contact the Manufacturer’s Customer Center. Any communication to the Manufacturer’s Customer Center should include the following information: •...

  • Page 359: Warranty Information (U.s. Vehicles Only)

    358 IF YOU NEED CONSUMER ASSISTANCE Service Contract You may have purchased a service contract for your vehicle to help protect you from the high cost of unex- pected repairs after your manufacturer’s new vehicle limited warranty expires. The manufacturer stands be- hind only the manufacturer’s Service Contracts.

  • Page 360: Reporting Safety Defects

    REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect, which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra- tion (NHTSA) in addition to notifying the manufacturer.

  • Page 361: Department Of Transportation Uniform Tire Quality Grades

    360 IF YOU NEED CONSUMER ASSISTANCE Corporation vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward language with illustrations, dia- grams, and charts. • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features.

  • Page 362: Treadwear

    Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled con- ditions on a specified government test course. For ex- ample, a tire graded 150 would wear one and a half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 363 362 IF YOU NEED CONSUMER ASSISTANCE WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, under inflation, or excessive load- ing, either separately or in combination, can cause heat buildup and possible tire failure.
  • Page 364 INDEX...
  • Page 365 364 INDEX ABS (Anti-Lock Brake System) ... . . 219 Adding Engine Coolant (Antifreeze) ..309 Adding Fuel ......257 Adding Rear Washer Fluid .
  • Page 366 Fluid Change ......315 Fluid Level Check ..... 314 Fluid Type .
  • Page 367 366 INDEX Rollaway Tonneau Cover ....121 Tri-Fold Load Floor ....119 Waterproof Liner .
  • Page 368 Data Recorder, Event ..... 47 Daytime Running Lights ....95 Dealer Service .
  • Page 369 368 INDEX Oil Filler Cap ......297 Oil Selection ..... . 297,331 Overheating .
  • Page 370 Hoses ......312 Methanol ......254 Octane Rating .
  • Page 371 370 INDEX HomeLink (Garage Door Opener) Transmitter ......107 Hood Release ......92 Hoses .
  • Page 372 Anti-Lock ......142,221 Automatic Headlights ....94 Brake Assist Warning .
  • Page 373 372 INDEX Child Protection ..... . . 23 Door ....... 21 Power Door .
  • Page 374 Dipstick ......295 Disposal ......298 Filter .
  • Page 375 374 INDEX Radio, Navigation ..... . 173 Radio Operation ....155,162,186 Radio Remote Controls .
  • Page 376 Front Seat ......31,32 Operating Instructions ....32 Pretensioners .
  • Page 377 376 INDEX Steering Wheel Mounted Sound System Controls ......183 Storage ......118,326 Storage, Vehicle .
  • Page 378 Behind a Motor Home ....273 Disabled Vehicle ..... . 286 Guide .
  • Page 379 378 INDEX Video Entertainment System (Rear Seat Video System) ......177 Warning Flasher, Hazard ....276 Warning Lights (Instrument Cluster Description) .
  • Page 380 81-226-0722 First Edition Printed in U.S.A.

Table of Contents

Save PDF
