Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 Roll Over Warning ..... 4 How To Use This Manual .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5: How To Use This Manual
Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year, and could reduce disabling injuries by 2 million annually.
Page 6 6 INTRODUCTION...
Page 7: Warnings And Cautions
INTRODUCTION 7 WARNINGS AND CAUTIONS This manual contains WARNINGS against operating procedures which could result in an accident or bodily injury. It also contains CAUTIONS against procedures which could result in damage to your vehicle. If you do not read this entire manual you may miss important information.
Page 8: Vehicle Modifications / Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Locking Doors With The Key .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information ....22 Programming Additional Transmitters ..23 Battery Replacement .
Page 11 Seat Belt Extender ..... .50 Driver And Right Front Passenger Supplemental Restraint System (SRS)—Airbags ...51 Event Data Recorder (EDR) .
Page 12: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer. Ask your dealer for these numbers and keep them in a safe place.
Page 13: Locking Doors With The Key
NOTE: If you try to remove the key before you place the lever in PARK, the key may become trapped temporarily in the ignition cylinder. If this occurs, rotate the key to the right slightly, then remove the key as described. If a malfunction occurs, the system will trap the key in the ignition cylinder to warn you that this safety feature is inoperable.
Page 14: Ignition Accessory Delay Feature
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE inserted or withdrawn only in the LOCK position. Push in on the key in the ignition lock cylinder to rotate to the LOCK position. Ignition Switch Positions WARNING! The key cannot be turned to LOCK until the selector is in the PARK position.
Page 15: Sentry Key - If Equipped
For vehicles equipped with the Electronic Vehicle Infor- mation Center (EVIC), the power window switches, radio, hands–free system (if equipped), and power out- lets will remain active for up to 10 minutes after the ignition switch is turned off. Opening either front door will cancel this feature.
Page 16: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the Vehicle Security Alarm Indicator Light turns on during normal vehicle operation (vehicle running for longer than 10 seconds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle ser- viced as soon as possible.
Page 17: General Information
4. Insert a blank Sentry Key into the ignition switch and turn the ignition switch ON within 60 seconds. After 10 seconds a single chime will sound and the Vehicle Theft Alarm Indicator Light will stop flashing, turn on again for 3 seconds, and then turn off.
Page 18: To Set The Alarm
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Set the Alarm: The alarm will set when you use the power door locks or use the Keyless Entry transmitter to lock the doors. After all the doors are locked and closed the security light in the instrument cluster will flash rapidly to signal that the system is arming.
Page 19: Illuminated Entry
UNLOCK button or by inserting a programmed Sentry Key into the ignition and turning the key to the ON position. ILLUMINATED ENTRY Vehicles Equipped With Power Door Locks All interior lights will illuminate in the vehicle when the doors are unlocked using the key fob. The interior lights will remain on for 30 seconds after the last door is closed, or until all doors are closed and either the ignition is turned to the ON position or a key fob...
Page 20: To Unlock The Doors And Liftgate
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Your vehicle’s keyfob may have three, four or five buttons (shown), depending on the optional features purchased with your vehicle. This system allows you to lock or unlock the doors and liftgate or activate the panic alarm from distances a minimum of 66 feet (20 meters) using a hand held radio transmitter.
Page 21: To Lock The Doors And Liftgate
5. If the desired programming was not achieved or to reactivate this feature, repeat the above steps. To lock the doors and liftgate: Press and release the LOCK button on the key fob to lock all doors and liftgate. If the ignition is OFF, when the doors are locked, the parking lights will flash on once and the horn will chirp once.
Page 22: Using The Panic Alarm
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Test the flash lamps with LOCK feature while outside of the vehicle, by pressing the LOCK button on the key fob with the ignition in the OFF position, and the key removed.
Page 23: Programming Additional Transmitters
Changes or modifications not expressly ap- NOTE: proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your Remote Lock Control fails to operate from a normal distance, check for these two conditions. 1.
Page 24 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Press and hold the UNLOCK button on the key fob. 6. After holding the UNLOCK button for four seconds, also press the PANIC button within 6 seconds. 7. When a single chime is heard release both buttons. The chime is an indication that you have successfully entered program mode.
Page 25: Battery Replacement
Battery Replacement The recommended replacement battery is CR2032. 1. If the key fob is equipped with a screw, remove the screw. With the transmitter buttons facing down, use a flat blade to pry the two halves of the transmitter apart. Make sure not to damage the elastomer seal during removal.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remote start your vehicle, press the REMOTE START button on the key fob twice within three seconds. To indicate that the vehicle is about to start, the parking lights will flash and the horn will sound briefly. Remote Start Transmitter Once the vehicle has started, the engine will run for 15 minutes.
Page 27: Door Locks
The vehicle can be started remotely up to a maximum of two times. The vehicle is also allowed a maximum of one failed start, where the remote start sequence was initiated but cancelled before the engine begins to crank. After either of these conditions, or if the Vehicle Theft Alarm is alarming, or if the PANIC button was pressed, the vehicle must be reset by inserting a valid key into the ignition...
Page 28: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks A power door lock switch is on each front door trim panel. Use this switch to lock or unlock the doors. Power Door Lock Switch If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate.
Page 29 3. Place the key into the ignition. 4. Within 10 seconds, cycle the key from the OFF position to the ON position a minimum of four times; ending in the ON position. (do not start the engine). 5. Within 30 seconds, press the driver’s door lock switch in the LOCK direction.
Page 30: Child Protection Door Lock
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Within 30 seconds, press the driver’s door lock switch in the UNLOCK direction. 6. A single chime will sound to indicate the feature has been changed. 7. Repeat the above steps to alternate the availability of this feature.
Page 31: Windows
WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: After setting the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
Page 32: Auto Down
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE windows will operate only when the ignition switch is turned to the ON position and for ten minutes after the ignition is turned OFF or the driver’s door is opened. This feature can be turned off by your authorized dealer. NOTE: The Power Accessory Delay feature will allow the power windows to operate for ten minutes after the ignition it turned OFF.
Page 33: Window Lockout Switch
NOTE: If the window runs into any obstacle during the auto-closure it will reverse direction and then stop. Re- move the obstacle and use the window switch again to close the window. Any impact due to rough road condi- tions may trigger the auto reverse function unexpectedly during auto closure.
Page 34: Liftgate
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE The liftgate can be unlocked using the remote keyless entry transmitter or by activating the power door lock switches located on the front doors. NOTE: When the engine is running from a Remote Start (if equipped), the vehicle must first be unlocked by pressing the remote transmitter UNLOCK button prior to activating the Power Liftgate otherwise the engine will...
Page 35: Power Liftgate - If Equipped
Once unlocked, the liftgate can be opened or closed. To open the liftgate, depress the liftgate release switch located in the exterior handle and pull the liftgate open with one fluid motion. The liftgate will not manually open if the vehicle is in gear or the vehicle speed is above 0 mph (0 km/h).
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • In the event of a power malfunction to the liftgate, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the lift- gate trim panel.
Page 37 • The power liftgate must be in the full open position for any of the buttons to operate. If the liftgate is not fully open, press the remote keyless entry transmitter or overhead console button to fully open the liftgate and then press again to close.
Page 38: Occupant Restraints
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Driving with the liftgate open can allow poison- ous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle.
Page 39: Lap/Shoulder Belts
WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
Page 41 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. Pulling Out Belt and Latchplate 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 plate and pull out the belt.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. •...
Page 43 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as pos- sible and keep it snug.
Page 44: Adjustable Upper Shoulder Belt Anchorage
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the front and second row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck. Push in on the anchorage release button to release the anchorage, and then move it up or down to the position that serves you best.
Page 45: Rear 60/40 Seat Third Row Center Three Point Belt - If Equipped
When sitting in this seating location, ensure the seatback is fully engaged with the seatback latch by pushing rearward on the center seatback until you hear a click that signals latch engagement. Automatic Locking Mode To convert from the normal emergency locking mode to the automatic locking mode, grasp the shoulder belt portion and pull all of the webbing out of the retractor.
Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • If the small (keyed buckle) latch plate and keyed buckle are not properly connected when the seat belt is used by an occupant, the seat belt will not be able to provide the proper restraint and will increase the risk of injury in a collision.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 To reattach the seat belt to the third row center seat, pull the small (keyed buckle) latch plate forward from the headliner slots and insert it into the keyed buckle until there is an audible click. Refer to the previous section for the proper seat belt usage.
Page 48: Seat Belt Pretensioners
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove any slack from the seat belt system in the event of a collision.
Page 49 The Enhanced Warning System (BeltAlert) can be en- abled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position.
Page 50: Seat Belts And Pregnant Women
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts and Pregnant Women We recommend that pregnant women use seat belts throughout their pregnancies. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug against the hips as possible.
Page 51: Driver And Right Front Passenger Supplemental Restraint System (Srs)-Airbags
Driver And Right Front Passenger Supplemental Restraint System (SRS)—Airbags This vehicle has airbags for both the driver and right front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the steering wheel. The passenger front airbag is mounted in THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 the instrument panel, above the glove compartment.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Do not put anything on or around the front airbag covers or attempt to manually open them. You may damage the airbags and you could be injured be- cause the airbags are no longer functional. These protective covers for the airbag cushions are de- signed to open only when the airbags are inflating.
Page 53 Here are some simple steps you can follow to minimize the risk of harm from a deploying airbag. 1. Children 12 years and under should always ride buckled up in a rear seat in an appropriate child restraint. Infants in rear-facing child restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 55 How the Airbag System Works • The Occupant Restraint Controller (ORC) determines if a frontal collision is severe enough to require the airbags to inflate. The front airbag inflators are de- signed to provide different rates of airbag inflation from direction provided by the ORC. The ORC will not detect roll over.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Driver and Passenger Airbag/Inflator Units are located in the center of the steering wheel and the right side of the instrument panel. When the ORC detects a collision requiring the airbags, it signals the inflator units.
Page 57 The following requirements must be strictly adhered to: • Do not modify the front seat center console or center position seat in any way. • Do not use prior or future model year seat covers not designated for the specific model being repaired. Al- ways use the correct seat cover specified for the vehicle.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor immediately. As the airbags deflate you may see some smoke-like particles. The particles are a normal by- product of the process that generates the nontoxic gas used for airbag inflation.
Page 59 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 60: Event Data Recorder (Edr)
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The light flickers or comes on and remains on while driving. NOTE: If the speedometer, tachometer or any engine related gauges are not working, the airbag control mod- ule may also be disabled. The airbags may not be ready to inflate for your protection.
Page 61 may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states. Data of a potentially sensitive nature, such as would identify a particular driver, ve- hicle, or crash, will be treated confidentially. Confidential data will not be disclosed by DaimlerChrysler Corpora- tion to any third party except when: 1.
Page 62: Child Restraint
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint Everyone in your vehicle needs to be buckled up all the time - babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 63 LATCH child restraint anchorage system. (See the LATCH - Child Seat Anchorage System section.) • Rearward-facing child seats must NEVER be used in the front seat of a vehicle with a front passenger airbag. An airbag deployment could cause severe injury or death to infants in this position.
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm. WARNING! •...
Page 65 around the child restraint so that it is not necessary to use a locking clip. If the seat belt has a cinching latch plate, pulling up on the shoulder portion of the lap/shoulder belt will tighten the belt. The cinching latch plate will keep the belt tight, however, any seat belt system will loosen with time, so check the belt occasionally and pull it tight if necessary.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and hooks for connection to the top tether anchorages have been available for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retro-fit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle.
Page 67 Second Row Seat Right Side Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 were provided with the child restraint system.
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE anchorages. Next attach the lower hooks or connectors over the top of the anchorage bars, pushing aside the seat cover material. Then attach the tether strap to the anchor- age located on the back of the seat, being careful to route the tether strap to provide the most direct path between the anchor and the child restraint.
Page 69 Installing Child Restraints Using the Vehicle Seat Belt The second and third row seats have either cinching latch plates or automatic locking retractors which are designed to keep the lap portion tight around the child restraint so that it is not necessary to use a locking clip. If the seat belt has a cinching latch plate, pulling up on the shoulder portion of the lap/shoulder belt will tighten the belt.
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.
Page 71: Engine Break-In Recommendations
WARNING! An incorrectly anchored tether strap could lead to seat failure and injury to the child. In a collision, the seat could come loose and allow the child to crash into the inside of the vehicle or other passengers, or even be thrown from the vehicle.
Page 72: Safety Tips
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and is not an indication of difficulty. SAFETY TIPS Exhaust System WARNING! Exhaust gases contain carbon monoxide, an ex-...
Page 73: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside The Vehicle Heater Defroster Ducts Inspect the heater defroster ducts for proper operation. Check for proper air flow through all defroster ducts. If there are any question regarding the operation of your heater defroster ducts, have the system checked by an authorized dealer Seat Belts Inspect the belt system periodically, checking for cuts,...
Page 74 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lights Check the operation of all exterior lights. Check turn signal and high beam indicator lights on the instrument panel. Door Latches Check for positive closing, latching and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, water, oil, or other fluid leaks.
Page 75: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......79 Inside Day/Night Mirror ....79 Automatic Dimming Mirror —...
Page 76 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats ....... . 108 Front Seat Manual Seat Adjustment .
Page 77 Headlight Delay ..... . 133 Automatic Headlights — If Equipped ..133 Headlights, Parking Lights, Panel Lights ..133 Illuminated Entry .
Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console With Electronic Vehicle Information Center (EVIC) — If Equipped ..151 Dome/Reading Lights ....151 Electronic Vehicle Information Center (EVIC) —...
Page 79: Mirrors
MIRRORS Inside Day/Night Mirror The mirror should be adjusted to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Day/Night Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of truck).
Page 80: Automatic Dimming Mirror - If Equipped
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror will automatically adjust for annoying head- light glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror.
Page 81: Outside Mirrors
CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror.
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mirror Directions To adjust a mirror, turn the control wand toward the left or right mirror positions indicated. Tilt the control wand in the direction you want the mirror to move. When finished adjusting the mirror, turn the control to the center position to prevent accidentally moving a mirror.
Page 83: Illuminated Vanity Mirrors - If Equipped
Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on automati- cally. Closing the mirror cover turns off the light. Lighted Vanity Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Heated Mirrors —...
Page 84: Hands-Free Communication (Uconnect™) - If Equipped
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED UConnect™ is a voice-activated, hands-free, in- vehicle communications system. UConnect™ allows you to dial a phone number with your cellular phone using simple voice commands (e.g., Call” “Mike” ”Work or Dial” “248-555-1212 ).
Page 85: Operations
The rearview mirror contains the microphone for the system and the control buttons that will enable you to access the system. UConnect™ Switches The UConnect™ system can be used with any Hands- Free Profile certified Bluetooth™ cellular phone. See www.chrysler.com/uconnect for supported phones. If UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 your cellular phone supports a different profile (e.g., Headset Profile), you may not be able to use any UCon-...
Page 86 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect™ system prompts. You will be prompted for a specific command and then guided through the available options. • Prior to giving a voice command, one must wait for the voice on beep, which follows the Ready prompt or another prompt.
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin.
Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For identification purposes, you will be prompted to give the UConnect™ system a name for your cellular phone. Each cellular phone that is paired should be given a unique phone name. • You will then be asked to give your cellular phone a priority level between 1 and 7, 1 being the highest priority.
Page 89 • System will prompt you to say the name of the person you want call. • After the Ready prompt and the following beep, say the name of the person you want to call. For example, you can say John Doe, where John Doe is a previ- ously stored name entry in the UConnect™...
Page 90 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The UConnect™ system will allow you to enter up to 32 names in the phonebook with each name having up to four associated phone numbers and designations. Each language has a separate 32-name phonebook accessible only in that language.
Page 91 • After the Ready prompt and the following beep, say Phonebook Delete. • After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete. You can either say the name of a phonebook entry that you wish to delete or you can say List Names to hear a list of the entries in the phonebook from which you choose.
Page 92: Phone Call Features
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The UConnect™ system will play the names of all the phonebook entries. • To call one of the names in the list, press the Voice Recognition’ button during the playing of the desired name, and then say Call.
Page 93 Making a Second Call while Current Call in Progress To make a second call while you are currently in a call, press the ’Voice Recognition’ button and say Dial or Call followed by the phone number or phonebook entry you wish to call. The first call will be on hold while the second call is in progress.
Page 94: Uconnect™ System Features
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Termination To end a call in progress, momentarily press the Phone’ button. Only the active call(s) will be terminated and if there is a call on hold, it will become the new active call. Redial •...
Page 95 • After the Ready prompt and the following beep, say the name of the language you wish to switch to (English, Espanol, or Francais, if so equipped). • Continue to follow the system prompts to complete language selection. After selecting one of the languages, all prompts and voice commands will be in that language.
Page 96 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Your phone must be turned on and paired to the UCon- nect™ system to allow use of this vehicle feature in emergency situations when the cell phone has network coverage and stays paired to the UConnect™ system. Towing Assistance If you need towing assistance, •...
Page 97 When calling a number with your UConnect™ system that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can push the ’Voice Recognition’ button and say the sequence you wish to enter followed by the word Send. For example, if required to enter your pin number followed with a pound 3 7 4 6 #, you can press the ’Voice Recognition’...
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™ system (while dialing via the cell phone keypad, the user must exercise caution and take precautionary safety measures).
Page 99: Advanced Phone Connectivity
Information Service When using AT&T Wireless Service, dialing to phone number #121, you can access voice activated automated system to receive news, weather, stocks, traffic, etc. related information. Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect™ system allows on going calls to be transferred from your cellular phone to the UConnect™...
Page 100: Things You Should Know About Your Uconnect™ System
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Select another Cellular Phone This feature allows you to select and start using another phone with the UConnect™ system. The phone must have been previously paired to the UConnect™ system that you want to use it with. •...
Page 101 • Press and hold the ‘Voice Recognition’ button for 5 seconds until the session begins, or • Press the ‘Voice Recognition’ button and say Setup, Voice Training command. Repeat the words and phrases when prompted by the UConnect System. For best results, the Voice Training session should be completed when the vehicle is parked, engine running, all windows closed, and the blower fan switched off.
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When navigating through an automated system, such as voice mail, or when sending a page at the end of speaking the digit string, make sure to say send. • Storing names in phonebook when vehicle is not in motion is recommended.
Page 103 Bluetooth Communication Link Occasionally, Cellular phones have been found to lose connection to the UConnect™ system. When this hap- pens, the connection can generally be re-established by switching the phone off/on. Your cell phone is recom- mended to remain in Bluetooth on mode. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Power-Up After switching the ignition key from OFF to either ON...
Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105...
Page 106 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 107 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 call cancel confirmation prompts continue delete dial edit emergency English erase all Espanol Fancais help home language...
Page 108: Seats
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial return to main menu return or main menu select phone select send set up phone settings or phone set up towing assistance...
Page 109: Front Seats Manual Seat Recliners
Manual Seat Adjuster UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 110: Manual Lumbar Support Adjustment - If Equipped
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 111: Way Driver's Power Seat - If Equipped
To lower the head restraint, depress the release button located at the base of the head restraint and push down on the head restraint. Head Restraint Adjustment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 8 - Way Driver’s Power Seat — If Equipped The driver power seat switches are located on the left side of the driver seat lower side trim.
Page 112: Way Passenger's Power Seat - If Equipped
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4 - Way Passenger’s Power Seat — If Equipped The front passenger’s power seat switches are located on the right side of the passenger seat lower side trim. The bottom switch controls forward/rearward adjustment. The top switch controls the seatback recline adjustment.
Page 113 The front heated seat system allows the driver and front passenger to select from two different levels of supple- mental electrical seat heating, or no seat heating to suit their individual comfort requirements. With the ignition switch in the RUN position, depressing the heated seat switch rocker to its momentary high or low position provides power to the heated seat element and maintains the requested temperature setting.
Page 114 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE off. Both of the indicators on identifies High heat level. The lower indicator on only, identifies Low heat level. NOTE: The high heat setting will operate for approxi- mately 30 minutes. After 30 minutes, the system will automatically transition to the low heat setting.
Page 115: Second Row Bucket Seats - Fold And Tumble
Second Row Bucket Seats — Fold and Tumble Second row bucket seats have seatback recliners on both seating positions. Raising the lever allows the seatback to be reclined an additional 11 degrees. The second row bucket seats can be folded and tumbled forward for easy access to the third seat or rear cargo area.
Page 116 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Pull up on the release handle and lift to tumble the seat fully forward. If the seat contacts the rear of the front seat, move the front seat forward. Tumbling the Seat Forward To relatch the seat, tilt the seat rearward and push down firmly to engage the rear attachments.
Page 117: Second Row 40/20/40 Seat - Fold And Tumble
WARNING! In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor attachments. Always be sure the seats are fully latched. Second Row 40/20/40 Seat — Fold and Tumble The 40/20/40 seat configuration is standard on all mod- els.
Page 118 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To fold the 20% seatback, pull the strap forward to release the seatback. Fold the seatback down for use as an armrest or to carry cargo. When returning the seatback to the upright position, push the seatback rearward to latch the seatback.
Page 119 To Tumble the 40% seat, fully raise the lever on the side of the seat to release the floor latches and tumble the seat. WARNING! Do not drive the vehicle with the outer 40% second row seats in the tumbled position. The outer 40% second row seats are only intended to be tumbled for entry and exit to the third row seat.
Page 120: Third Row Seat Bench - If Equipped
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Third Row Seat Bench — If Equipped To Fold The Seats Folding the third seat occurs in two stages: First the cushion is lifted and moved forward from the pockets at the front of the cushion. The cushion will rest onto the floor directly behind the second row seat.
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Seat Cushion Movement Up And Forward Rear Seat Folded CAUTION! When loading cargo into the rear of you vehicle with the 3rd row seat folded flat, be careful not to damage the material on the head restraints.
Page 122: Third Row 60/40 Folding - If Equipped
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The seat belt buckles are hinged to fold with the seat back. WARNING! Do not sit in the third row seat unless the cushion and back are properly engaged. Proper engagement can be verified by pushing/pulling on the upright seatback.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Third Row Seat 40% Seatback Fold Third Row Seat Features...
Page 124: Driver Memory System - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Third Row Seat Folded Forward Third Row Seat Return Pull Strap DRIVER MEMORY SYSTEM — IF EQUIPPED Once programmed, the memory buttons 1 and 2 on the driver’s door panel can be used to recall the driver’s seat position, driver’s outside mirror position, adjustable brake and accelerator pedals position, Automatic Tem- perature Control (ATC) temperature and radio station...
Page 125: Setting Memory Positions And Linking Remote
preset settings. Your Remote Keyless Entry transmitters can also be programmed to recall the same positions when the UNLOCK button is pressed. Your vehicle was delivered with two Remote Keyless Entry transmitters. One or both transmitters can be linked to either memory position. The memory system UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 can accommodate up to two transmitters, each transmit- ter linked to either of the two memory positions.
Page 126: Memory Position Recall
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Adjust the Automatic Temperature Control (ATC) while the ATC is in Auto mode. 5. Press and release the SET (S) button located on the driver’s door. 6. Within 5 seconds, press and release memory button 1 or 2 on the driver’s door.
Page 127: To Disable A Transmitter Linked To Memory
To recall the memory setting for driver two, press memory button number 2 on the driver’s door or the Unlock button on the Remote Keyless Entry transmitter linked to memory position 2. A recall can be cancelled by pressing any of the memory buttons on the drivers door during a recall (S, 1, or 2), or pressing any one of the power seat buttons, or pressing the adjustable pedals button, or pressing either the LOCK...
Page 128: Self-Limiting Control
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Self-Limiting Control To improve vehicle reliability, the memory system in- cludes a self-limiting control for full travel positioning of power seat and Adjustable Pedal movement (all direc- tions). This self-limiting control may however develop an unintended movement limitation if an obstruction is encountered at sometime during usage.
Page 129: To Open And Close The Hood
“Overhead Console with Electronic Vehicle Information Center (EVIC)” in Section 3 of this manual. TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. First pull the hood release lever located under the left side of the instrument panel.
Page 130: Lights
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Ensure hood prop rod is fully seated into clip before closing hood to prevent damage to grille. WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. Be sure all hood latches are fully latched before driving.
Page 131: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Interior Lights Headlight Switch Dimmer Control Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the right side of the switch) is rotated to the second upward detent position, or when the UNLOCK button is pressed on the key fob.
Page 132: Battery Saver
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE and the interior lights are on, rotating the dimmer control all the way down to the OFF detent will cause all the interior lights to go out. This allows the doors to stay open for extended periods of time without discharging the vehicle’s battery.
Page 133: Headlight Delay
Headlight Delay To aid in your exit, your vehicle is equipped with a headlight delay that will leave the headlights on for 90 seconds. This delay is initiated when the ignition is cycled off while the headlight switch is on, and then the headlight switch is cycled off.
Page 134: Illuminated Entry
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution fol- lowed by rinsing. Do not use abrasive cleaning components, solvents, steel wool or other abrasive materials to clean the lenses.
Page 135: Fog Lights - If Equipped
Fog Lights — If Equipped Fog Light Switch The fog lights are turned ON by placing the headlight rotary control in the parking light, headlight, or Auto position and pressing the fog light button. The fog lights will operate only when the parking lights are ON or when the vehicle headlights are ON low beam.
Page 136 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If a defective bulb or wiring circuit is detected for the turn signal system, the arrow indicators will flash at a faster rate. You can signal a lane change by moving the lever partially up or down.
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Turn Signal Auto-Mode Tap the multi-function control lever once and the turn signal (left or right) will flash 3 times, and automatically turn off. Passing Light You can signal another vehicle with your headlights by partially pulling the multifunction lever toward the steer- ing wheel.
Page 138: Windshield Wipers And Washers
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wipers Windshield Wiper Switch The wipers and washers are operated by a switch in the multifunction control lever. Turn the end of the handle to select the desired wiper speed. Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle,...
Page 139 WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 140: Windshield Washers
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers To use the washer, push in on the washer knob on the end of the multifunction control lever and hold while spray is desired. If the washer knob is depressed while in the delay range, the wiper will operate for several seconds after the washer knob is released.
Page 141: Tilt Steering Column
TILT STEERING COLUMN To tilt the column, pull rearward on the lever below the turn signal control and move the wheel up or down, as desired. Push the lever forward to lock the column firmly in place. Tilt Steering Column Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 WARNING! Tilting the steering column while the vehicle is...
Page 142: Driver Adjustable Pedals - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE DRIVER ADJUSTABLE PEDALS — IF EQUIPPED Adjustable Pedals Switch The power adjustable accelerator and brake pedals allow the driver to establish a comfortable position relative to the steering wheel and pedals. Adjustment 1. Position the driver seat so that you are at least 10 inches (254 mm) away from the airbag located in the center of the steering wheel.
Page 143: Electronic Speed Control - If Equipped
CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become limited if movement is stopped by an obstruction in the adjustable pedal’s path. ELECTRONIC SPEED CONTROL —...
Page 144: To Set At A Desired Speed
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Push the ON/OFF button to the ON position. In the instrument cluster, the word “CRUISE” illuminates when the system is on. To Set At A Desired Speed When the vehicle has reached the desired speed, press and release the SET button.
Page 145 Tapping the ACCEL button once will result in a speed increase (refer to the table below for the speed for your specific engine). Each time the button is tapped, speed increases so that tapping the button three times will increase speed by three increments. Tapping the DECEL button once will result in a speed decrease (refer to the table below for the speed for your specific engine).
Page 146: To Accelerate For Passing
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. NOTE: When driving uphill, at elevations above 2,000 feet (610 meters), or when the vehicle is heavily loaded (especially when towing) the vehicle may slow below the SET speed.
Page 147: Rear Park Assist System - If Equipped
REAR PARK ASSIST SYSTEM — IF EQUIPPED NOTE: The manufacturer suggest disabling the Rear Park Assist System when towing a trailer. Refer to Overhead Console with Electronic Vehicle Information (EVIC) – If Equipped, Personal Settings (Customer Pro- grammable Features) in section 3 of this Owner Manual. This system is used to help drivers determine if an obstacle is in the way of the vehicle while it is backing up in addition to the use of inside rearview and outside...
Page 148 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The system dimly illuminates the two outer most yellow LEDs when it is ON and detecting no obstacles. The WARNING DISPLAY DISTANCES DISPLAY LED OBSTACLE DISTANCE FROM: REAR CORNERS 1st LED 2nd LED 3rd LED 4th LED 31.5 in.
Page 149 WARNING! • Drivers must be careful when backing up even when using the Rear Park Assist System. Always check carefully behind your vehicle, look behind you, and be sure to check for pedestrians, animals, other vehicles, obstructions, and blind spots before backing up. You are responsible for safety and must continue to pay attention to your surroundings.
Page 150: Overhead Console
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • Ensure that the rear bumper is free of dirt and debris to keep the system operating properly. • Jackhammers, large trucks, and other vibrations could affect the performance of the system. If “Service Park Assist System”...
Page 151: Courtesy/Reading Lights
Courtesy/Reading Lights Near the front of the console are two courtesy/reading lights. Both lights illuminate as courtesy lights when a door is opened, when the dimmer control is rotated to the courtesy light position (fully upward position), or when the UNLOCK button is pressed on the Remote Keyless Entry transmitter, if so equipped.
Page 152: Electronic Vehicle Information Center (Evic) - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The dome/reading lights will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle. Electronic Vehicle Information Center (EVIC) — If Equipped Pressing the menu button will change the display to one of the following features:...
Page 153 • AVG. MPG – Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will show dashes for two seconds. Then the history information will be erased, and the averaging will continue from the last fuel average reading before the reset.
Page 154 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE System Status (EVIC Displays) When the appropriate conditions exist, the Electronic Vehicle Information Center (EVIC) displays the following messages: • TURN SIGNALS ON (with a continuous warning chime) • RKE BATTERY LOW (with a single chime) •...
Page 155 Personal Settings (Customer Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK. If the trans- mission is not in PARK the EVIC will display NOT AVAILABLE and VEHICLE NOT IN PARK. Press and release the menu button until the Personal Settings displays on the EVIC.
Page 156 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “RKE UNLOCK ALL DR 1ST” – When All ALL DR 1ST is selected, all of the doors will unlock on the first press of the remote keyless entry unlock button. To make your selection, press and release the RESET button until “All DR 1st”...
Page 157 • EASY EXIT SEAT > YES – When ON is selected, and the key is removed from the ignition, the driver’s seat will automatically move rearward to allow easy exit. • TILT MIRRORS IN “R” > YES – When On is selected, and the transmission is put in reverse, the outside mirrors will tilt downward.
Page 158: Compass/Temperature Button
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “COMPASS CALIBRATE > YES” – Press the RESET button to manually calibrate the compass. Refer to Manual Compass Calibration, in this section for addi- tional information. Compass/Temperature Button Pressing the Compass/Temperature button will return the display to the normal compass/ temperature display.
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 4. Press and release the RESET button to start the cali- bration. The message “CAL” will display on the compass temperature screen in the EVIC. 5. Complete one or more 360° turns (in an area free from large metal or metallic objects) until the “CAL”...
Page 160: Garage Door Opener - If Equipped
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Turn the ignition switch to the ON/RUN position. 2. Press the menu button until Personal Set- tings is displayed. 3. Press the STEP button until “Compass Variance” is displayed. 4. Press and release RESET button until the proper variance zone is selected according to the map.
Page 161 WARNING! A moving garage door can cause injury to people and pets in the path of the door. People or pets could be seriously or fatally injured. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 162: Programming Homelink
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink The Electronic Vehicle Information Center (EVIC) fea- tures a driver–interactive display which includes HomeLink system messages. The EVIC display is located in the overhead console. NOTE: When programming a garage door opener, it is advised to park outside the garage.
Page 163 3. Simultaneously press and hold both the HomeLink button that you want to train and the hand-held trans- mitter button. Do not release the buttons until step 4 has been completed. The EVIC will display “CHANNEL X TRAINING”, once the transmitter is programmed the EVIC will display “CHANNEL X TRAINED”.
Page 164: Canadian Programming/Gate Programming
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Firmly press and release the learn or smart button. (The name and color of the button may vary by manu- facturer.) NOTE: There are 30 seconds in which to initiate step eight. 7.
Page 165: Using Homelink
NOTE: If programming a garage door opener or gate operator, it is advised to unplug the device during the cycling process to prevent possible overheating. Using HomeLink To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device (i.e.
Page 166: Security
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For questions or comments, contact HomeLink at: www.homelink.com or 1-800-355-3515. Security Garage Door Opener Operation with Security Alarm (if equipped) If your vehicle is equipped with the Security Alarm feature, the operation of the HomeLink feature will be purposely inhibited if the Security Alarm is Armed .
Page 167: Power Sunroof - If Equipped
In the event that you are still having programming difficulties, questions, or comments, call toll free 1–800– 355–3515, or on the internet at www.homelink.com for information or assistance. HomeLink is a trademark owned by Johnson Controls, Inc. POWER SUNROOF — IF EQUIPPED The power sunroof control is located between the sun visors on the overhead console.
Page 168: Wind Buffeting
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE condition until the switch is pushed forward again. To close fully, hold the switch in the forward position until the glass movement has stopped. The sunshade can be opened manually. It will also open as the sunroof opens.
Page 169: Sunroof Maintenance
the rear windows open, open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window. Sunroof Maintenance Use only a nonabrasive cleaner and a soft cloth to clean the glass panel.
Page 170: 115V Inverter Outlet - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115V Inverter Outlet – If Equipped This vehicle may also be equipped with a 115 Volt (150 Watts Maximum) outlet on the rear of the front center console. These outlets can power cell phones, electronics and other low power devices.
Page 171: Electrical Outlet Use With Engine Off (Battery Fed Configuration)
115V Inverter Plug UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Electrical Outlet Use With Engine OFF (Battery Fed Configuration) CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
Page 172: Floor Console
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reconfiguring Power Outlets To reconfigure the outlets, be sure the ignition is OFF before removing the fuse. The reconfigurable fuse loca- tion is a special design that allows the fuse to be installed in two different ways.
Page 173 • Portable phone storage bin • Portable phone cord routing between lid and base on forward edge • 12 Volt reconfigurable power outlet inside storage compartment • Side open armrest lid • Tissue holder & pen holder • Coin slots •...
Page 174: Rear Floor Console Features - If Equipped
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Outlet and Portable Phone Storage The console is equipped with a power outlet, portable phone storage bin, and phone cord routing. The phone storage bin can be used when easy access to the phone is needed.
Page 175: Factory Installed Roof Luggage Rack
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 FACTORY INSTALLED ROOF LUGGAGE RACK Rear Floor Console To access the storage bin, lift up on the console door latch. The load carried on the roof when equipped with a luggage rack must not exceed 68 kg (150 lbs.), and should be uniformly distributed over the cargo area.
Page 176 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Crossbars are offered by Mopar accessories. External racks do not increase the total load carrying capacity of the vehicle. Be sure that the total occupant and luggage load inside the vehicle, plus the load on the luggage rack, do not exceed the maximum vehicle load capacity.
Page 177: Cargo Management System-If Equipped
WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in personal injury or property damage. Follow the roof rack Cautions when carrying cargo on your roof rack. CARGO MANAGEMENT SYSTEM—IF EQUIPPED The cargo management system consists of a removable cargo liner and removable cargo organizer.
Page 178 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open the main cover, pull up on the latch, and attach the cord to the rear seat head restraint post. To open the Cargo divider, lift up on the cargo divider handles, raising the doors to the full open position. Raise the side panels until they engage into the doors.
Page 179 INSTRUMENT PANEL AND CONTROLS CONTENTS Instruments And Controls ....183 Instrument Cluster ..... . 184 Instrument Cluster Description .
Page 180 180 INSTRUMENT PANEL AND CONTROLS Operating Instructions - Satellite Radio — If Equipped ......205 Sales Code RAQ –...
Page 181 Storing And Selecting Pre-Set Channels ..226 Using The PTY (Program Type) Button (If Equipped) ......226 PTY Button Scan .
Page 182 182 INSTRUMENT PANEL AND CONTROLS Front Unit To Rear Unit Chart ... . 242 Operating Tips ..... . . 242 Operating Tips Chart .
Page 183: Instruments And Controls
INSTRUMENT PANEL AND CONTROLS 183 INSTRUMENTS AND CONTROLS...
Page 184: Instrument Cluster
184 INSTRUMENT PANEL AND CONTROLS Instrument Cluster...
Page 185: Instrument Cluster Description
INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gage The fuel gauge shows level of fuel in tank when ignition switch is in the ON position. 2. Temperature Gage The temperature gage indicates engine coolant temperature. Any reading within the normal range indicates that the cooling system is operat- ing satisfactorily.
Page 186 186 INSTRUMENT PANEL AND CONTROLS left/right turn signal is left on with the engine RPM vehicle speed greater than 15 mph (24 km/h) for more than one mile. 4. Low Fuel Warning Light This indicator lights when the fuel gauge reads 1/8 of a tank or less.
Page 187 CAUTION! Driving with a hot engine cooling system could damage your vehicle. If the temperature light is on, safely pull over and stop the vehicle. Idle the vehicle in neutral with the air conditioner turned off until the light turns off. If the if the light remains on, turn the engine off immediately, and call for service.
Page 188 188 INSTRUMENT PANEL AND CONTROLS 11. Security Light This light will flash rapidly for approximately 15 seconds when the vehicle theft alarm is arming. The light will flash at a slower speed continuously after the alarm is set. The security light will also come on for about three seconds when the ignition is first turned on.
Page 189 15. Gear Selector The electronic gear selector display is self-contained within the instrument cluster. It displays the position of the automatic transmission shift lever, and the relation of each position to all other positions. For a good signal the display will place a box around the selected transmission range (PRND21).
Page 190 190 INSTRUMENT PANEL AND CONTROLS replacement, be sure to keep a record of the reading before and after the service so that the correct mileage can be determined. 18. Electronic Stability Program (ESP) Indicator Light The yellow ESP indicator light in the speedom- eter area illuminates with the key in the igni- tion switch turned to the ON/RUN position.
Page 191 on for 15 seconds as a bulb check. If the light does not come on during starting, have the system checked by an authorized dealer. 21. BRAKE System Warning Light The red “BRAKE” warning light will come on when the ignition key is first turned on, and stay on briefly as a bulb check.
Page 192 192 INSTRUMENT PANEL AND CONTROLS km/h), see your authorized dealer as soon as possible. NOTE: • The ESP/TCS Indicator Light and the ESP/ BAS Warning Lamp come on momentarily each time the ignition switch is turned ON. • The ESP Control System will make buzzing or clicking sounds when it is actively operating.
Page 193 24. Tire Pressure Monitoring Telltale Light Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those...
Page 194 194 INSTRUMENT PANEL AND CONTROLS CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system op- eration or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 195: Electronic Digital Clock
29. TOW/HAUL The TOW/HAUL button is located at the end of the gear shift lever. This light will illuminate when the TOW/ HAUL button has been selected. 30. 4LOW Indicator Indicates transfer case is in 4LOW position. 31. Odometer/Trip Odometer Button Press this button to toggle between the odometer and the trip odometer display.
Page 196: Radio General Information
196 INSTRUMENT PANEL AND CONTROLS 5. To exit, press any button/knob or wait approximately 5 seconds. RADIO GENERAL INFORMATION Radio Broadcast Signals Your new radio will provide excellent reception under most operating conditions. Like any system, however, car radios have performance limitations, due to mobile op- eration and natural phenomena, which might lead you to believe your sound system is malfunctioning.
Page 197: Fm Reception
FM Reception Because FM transmission is based on frequency varia- tions, interference that consists of amplitude variations can be filtered out, leaving the reception relatively clear, which is the major feature of FM radio. NOTE: The radio, steering wheel radio controls (if equipped), and 6 disc CD/DVD changer (if equipped) will remain active for up to 10 minutes after the ignition switch has been turned off.
Page 198 198 INSTRUMENT PANEL AND CONTROLS Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the volume control to the right increases the volume and to the left decreases it.
Page 199 SCAN Button (Radio Mode) Pressing the SCAN button causes the tuner to search for the next listenable station in either, AM, FM, or Satellite (if equipped) frequencies, pausing for 5 seconds at each listenable station before continuing to the next. To stop the search, press SCAN a second time.
Page 200 200 INSTRUMENT PANEL AND CONTROLS AM/FM Button (Radio Mode) Press the button to select AM or FM Modes. Setting the Tone, Balance, and Fade Press the rotary TUNE control and BASS will display. Turn the TUNE control to the right or left to increase or decrease the Bass tones.
Page 201: Operation Instructions - Cd Mode
the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM. This allows a total of 12 AM, 12 FM, and 12 Satellite (if equipped) stations to be stored into push-button memory.
Page 202 202 INSTRUMENT PANEL AND CONTROLS • If you insert a disc with the ignition ON and the radio OFF, the CD will automatically be pulled into the CD Player. • This radio does not play discs with MP3 tracks. SEEK Button (CD Mode) Press the right side of the SEEK button for the next track on the CD.
Page 203: Operation Instructions - Auxiliary Mode
RND/SET Button (Random Play Button) (CD Mode) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the SEEK button to move to the next randomly selected track.
Page 204: Operating Instructions - Hands Free Phone - If Equipped
204 INSTRUMENT PANEL AND CONTROLS MUTE Button (Auxiliary Mode) Press the MUTE button to cancel the sound from the speakers. MUTE will display. Press the MUTE button a second time and the sound from the speakers will return. Rotating the volume control or turning OFF the ignition will also return the sound from the speakers.
Page 205: Operating Instructions - Satellite Radio - If Equipped
Operating Instructions - Satellite Radio — If Equipped Refer to the “Satellite Radio” section of the Owner’s Manual. SALES CODE RAQ – AM/FM/CD (6-DISC) RADIO WITH OPTIONAL SATELLITE RADIO, HANDS FREE PHONE, AND VEHICLE ENTERTAINMENT SYSTEMS (VES) CAPABILITIES NOTE: The radio sales code is located on the lower right side of your radio faceplate.
Page 206 206 INSTRUMENT PANEL AND CONTROLS Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the volume control to the right increases the volume and to the left decreases it.
Page 207 SCAN Button (Radio Mode) Pressing the SCAN button causes the tuner to search for the next listenable station, in either AM, FM or Satellite (if equipped) frequencies, pausing for 5 seconds at each listenable station before continuing to the next. To stop the search, press SCAN a second time.
Page 208 208 INSTRUMENT PANEL AND CONTROLS AM/FM Button (Radio Mode) Press the button to select AM or FM Modes. Setting the Tone, Balance, and Fade Press the rotary TUNE control and BASS will display. Turn the TUNE control to the right or left to increase or decrease the Bass tones.
Page 209 Toggle the PTY button to select the following format types: 16 Digit-Character Dis- Program Type No program type or un- defined Adult Hits Adult_Hits Alert Alert Alert Alert Classical Classic Rock Classic_Rock College Country Emergency Test Emergency Test Foreign Language Foreign_Language Information Information...
Page 210: Operation Instructions - (Cd Mode For Cd Audio Play)
210 INSTRUMENT PANEL AND CONTROLS station with the same selected PTY name. The PTY function only operates when in the FM mode. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
Page 211 NOTE: Note: This Radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW) compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 212: Load/Eject Button (Cd Mode For Cd Audio Play)
212 INSTRUMENT PANEL AND CONTROLS will return. Rotating the volume control, turning the radio ON/OFF, or turning OFF the ignition will also return the sound from the speakers. SCAN Button (CD MODE for CD Audio Play) Press the Scan button to scan through each track on the CD currently playing.
Page 213 radio, the radio will remain in CD mode and display INSERT DISC” for 10 seconds. If no discs are inserted within 10 seconds “NO DISCS LOADED” will be dis- played. On some vehicles a disc can be ejected with the radio and ignition OFF.
Page 214: Notes On Playing Mp3 Files
214 INSTRUMENT PANEL AND CONTROLS Notes On Playing MP3 Files The radio can play MP3 files, however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CD-ROM, CD-R and CD-RW.
Page 215 Supported MP3 File Formats The radio will recognize only files with the *.mp3 exten- sion as MP3 files. Non-MP3 files named with the *.mp3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 216: Operation Instructions
216 INSTRUMENT PANEL AND CONTROLS contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: • Media - CD-RW media may take longer to load than CD-R media •...
Page 217 LOAD / EJECT - Eject Press the LOAD/ EJECT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 218 218 INSTRUMENT PANEL AND CONTROLS AM/FM Button (CD Mode for MP3 Play) Switches back to Radio mode. RND/ PTY Button (CD Mode for MP3 Play) Pressing this button plays files randomly. SET/DIR Button (CD Mode for MP3 Play) Press the SET/DIR Button to display folders, when playing an MP3 discs that have a file/folder structure.
Page 219: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System
SALES CODE REC — AM/FM/CD (6–DISC) RADIO WITH NAVIGATION SYSTEM REC Radio Satellite Navigation Radio with CD Player with MP3 Capability (REC) - combines a Global-Positioning System-based navigation system with an integrated color screen to provide maps, turn identification, selection INSTRUMENT PANEL AND CONTROLS 219 menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD...
Page 220 220 INSTRUMENT PANEL AND CONTROLS the worldwide standard for time. This makes the sys- tem’s clock very accurate once the appropriate time zone and daylight savings information is set. 1. At the Main Menu screen, highlight “Clock Setup” and press ENTER OR press and hold for 3 seconds the TIME button on the unit’s faceplate.
Page 221: Audio Clock Display
2. To increase the clock by hours, make sure “HR +” is highlighted and press ENTER. Press ENTER again to increase the clock by another hour. You will see on the “User Defined Time” display the number of hours you have increased the clock by.
Page 222 222 INSTRUMENT PANEL AND CONTROLS 1. When you are at an audio screen, quickly press the TIME button on the navigation faceplate. 2. In this example the large clock appears on the screen. 4. To toggle back to the large clock, simply press TIME. 3.
Page 223: Video Entertainment System (Sales Code Xrv) - If Equipped
VIDEO ENTERTAINMENT SYSTEM (SALES CODE XRV) — IF EQUIPPED The optional VES™ (Video Entertainment System) con- sists of a DVD player and LCD (liquid crystal display) screen, a battery-powered remote control, and two head- sets. The system is located in the headliner behind the front row seat.
Page 224: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
224 INSTRUMENT PANEL AND CONTROLS Electronic Serial Number/Sirius Identification Number (ESN/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access With REF Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and Time buttons simultaneously for 3 seconds.
Page 225: Selecting Satellite Mode In Ref, Raq, And Rak Radios
Selecting Satellite Mode in REF, RAQ, and RAK Radios Selecting Satellite Mode — REF Radio Press the MODE button repeatedly until the word SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode.
Page 226: Storing And Selecting Pre-Set Channels
226 INSTRUMENT PANEL AND CONTROLS Storing and Selecting Pre-Set Channels In addition to the 12 AM and 12 FM pre-set stations, you may also commit 12 satellite stations to push button memory. These satellite channel pre-set stations will not erase any AM or FM pre-set memory stations. Follow the memory pre-set procedures that apply to your radio.
Page 227: Reception Quality
Reception Quality Satellite reception may be interrupted due to one of the following reasons. • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception in the form of short audio mutes. •...
Page 228: Radio Operation
228 INSTRUMENT PANEL AND CONTROLS The right hand control is a rocker type switch with a push button in the center. Pressing the top of the switch will increase the volume and pressing the bottom of the switch will decrease the volume. The button located in the center of the right hand control will switch modes to Radio or CD.
Page 229: Compact Disc Maintenance
COMPACT DISC MAINTENANCE To keep the compact discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge. 3.
Page 230: Climate Controls
230 INSTRUMENT PANEL AND CONTROLS CLIMATE CONTROLS Manual Control The Air Conditioning and Heating System is designed to make you comfortable in all types of weather. The following describes its operation: Air Conditioning Operation To turn the air conditioning On or Off perform the following steps: •...
Page 231: Front Blower Control
engine speed or power may be noticed when the com- pressor cycles. This is a normal occurrence since the compressor will cycle on and off to maintain comfort and improve fuel economy. Front Blower Control The Front Blower controls the amount of air delivered to the passenger There are four blower speeds.
Page 232 232 INSTRUMENT PANEL AND CONTROLS Recirculation Mode (Panel or Bi-Level) Select either the Panel or Bi-Level mode positions when the outside air contains smoke, odors, high humidity, or if rapid cooling of the interior is desired. This feature allows for recir- culation of interior air only, when ei- ther of these positions are selected.
Page 233 INSTRUMENT PANEL AND CONTROLS 233 NOTE: The air conditioning compressor operates in both Mix and Defrost or a blend of these modes, even if the A/C button has not been pressed. This dehumidifies the air to help dry the windshield. Temperature Control The temperature of the air is controlled by a slide located on the top center of the control panel.
Page 234: Rear Temperature Control - If Equipped
234 INSTRUMENT PANEL AND CONTROLS Rear Temperature Control — If Equipped Rotating this knob left to the “REAR CONTROL” position allows the passengers in the second and third row seats to control the blower speed and temperature by means of the rear control located in the rear of the center floor console as described under “Rear Zone...
Page 235: Automatic Temperature Control (Atc) - If Equipped
Automatic Temperature Control (ATC) — If Equipped The control can be turned on by pressing the POWER knob. When the control is turned on, it will be in the last mode prior to being turned off. Pressing the POWER knob again will turn off the control. The control can also be turned on by pressing any button and it will display the corresponding operation mode for that button.
Page 236: Level Of Automatic Control
236 INSTRUMENT PANEL AND CONTROLS located in the overhead console to measure the tem- perature of the driver and passengers. Based on the sensor input, the system will automatically ocntrol comfort by varying the temperature, fan speed, and mode. This maintains a comfortable temperature, even under changing conditions.
Page 237: Manual Control (Atc)
Manual Control (ATC) You also may choose to customize your comfort by selecting the fan speed and mode manually. Turning the fan speed knob or any mode button places the system into manual operation. While in manual operation there are six fan speeds available and the choice of any mode.
Page 238 238 INSTRUMENT PANEL AND CONTROLS Manual control of Recirculation is possible only in Panel, Floor, and Bi-Level modes. It will not operate in Mix, or Defrost modes. The recirculation symbol will flash three times indicating recirculation is not available in these modes.
Page 239 the A/C snowflake button has not been pressed. This dehumidifies the air to help dry the windshield. Rear Temperature Control (ATC) The “REAR” button cycles through the following modes: Rear Control from Front This allows the driver or passenger to control the rear blower speeds rotating the POWER / FAN knob and the rear temperature using the pass/rear TEMP +/- rocker switch.
Page 240: Rear Zone Climate Control - If Equipped
240 INSTRUMENT PANEL AND CONTROLS REAR AUTO Rear Zone Climate Control — If Equipped This mode places the rear system in automatic tempera- ture control. Rear temperature can be set as desired (72 recommended for average person) and will be displayed digitally on the front control when in rear mode.
Page 241: Rear Rotary Temperature Control
Headliner air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vane knobs on the outlets to one side will shut off the airflow. The rear compartment control uses two rotary knobs: one for the temperature control and the other for the fan speed control.
Page 242: Front Unit To Rear Unit Chart
242 INSTRUMENT PANEL AND CONTROLS To change the temperature in the rear of the vehicle, rotate the temperature control knob to the right or left. The blue area indicates cooler temperatures while the red area indicates warmer temperatures. NOTE: For best operation, make sure that ventilation grilles located in the rear storage area are not obstructed by stowed articles.
Page 243 and adjust the temperature control and blower speed as necessary to maintain comfort. For high humidity condi- tions it may be necessary to remain in the Recirculation mode to maintain comfort. Window Fogging Windows will fog on the inside when the humidity inside the vehicle is high.
Page 244: Operating Tips Chart
244 INSTRUMENT PANEL AND CONTROLS Operating Tips Chart...
Page 245: Rear Window Features
REAR WINDOW FEATURES Rear Window Wiper/Washer INSTRUMENT PANEL AND CONTROLS 245 A rotating switch located on the climate control panel turns the rear wiper On or Off. Pressing the rotating switch inward activates the rear window washer. Rotating the switch will enable one of five intermittent delay times for the rear wiper.
Page 246: Rear Window Defrosting
246 INSTRUMENT PANEL AND CONTROLS If the rear wiper is operating when the ignition is turned off, the wiper will automatically return to the “Park” position. When the vehicle is restarted, the wiper will resume operation. Rear Window Defrosting A push-button type switch is located in the climate control panel.
Page 247: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 251 Automatic Transmission ....251 Normal Starting .
Page 248 248 STARTING AND OPERATING Electronic Brake Control System ... . 275 ABS (Anti-Lock Brake System) ... . 275 BAS (Brake Assist System) ....276 TCS (Traction Control System) .
Page 249 Tire Chains ......303 Snow Tires ......304 Tire Rotation Recommendations .
Page 250 Snowplow ......336 Dodge Durango Or Chrysler Aspen Models . . 336 Recreational Towing (Behind Motorhome, Etc.) . . 337 Recreational Towing 2WD Models .
Page 251: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Be sure to turn off the engine if you want to rest or sleep in your car. Accidents can be caused by inad- vertently moving the gear selection lever or by pressing the accelerator pedal.
Page 252 252 STARTING AND OPERATING ’Start’ position until the vehicle starts, but can release the key (still in the ignition) and the vehicle will continue through the start cycle. • Turn the ignition key to the START position, until the start motor engages. •...
Page 253: Engine Block Heater - If Equipped
WARNING! Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic trans- mission cannot be started this way. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle.
Page 254: Automatic Transmission
254 STARTING AND OPERATING The 3.7L/4.7L engine block heater cord is located at the front of the engine compartment near the radiator cap. The 5.7L engine block heater cord is located on the left side of the engine compartment and rearward of the power distribution center.
Page 255 “P” Park Supplements parking brake by locking the transmission. Engine can be started in this range. Never use Park while vehicle is in motion. Apply parking brake when leaving vehicle in this range. Always apply parking brake first, then place selector in Park position. WARNING! Your vehicle could move and injure you and others if it is not completely in P (Park).
Page 256 256 STARTING AND OPERATING WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in re- verse.
Page 257 “1” First For driving up very steep hills and for engine braking at low speeds 25 mph (40 km/h) or less when going down hill. To prevent excessive engine speed do not exceed 25 mph (40 km/h) in this range. Overdrive Operation The overdrive automatic transmission contains an elec- tronically controlled fourth and fifth (if equipped) speed...
Page 258 258 STARTING AND OPERATING The transmission will downshift from Overdrive to Drive if the accelerator pedal is fully depressed at vehicle speeds above approximately 35 mph (56 km/h). When To Use “TOW/HAUL” Mode When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting oc- curs, press the “TOW/HAUL”...
Page 259: Four-Wheel Drive Operation
light throttle. It engages at higher speeds under heavier acceleration. This may result in a slightly different feeling or response during normal operation in high gear. When the vehicle speed drops below a calibrated speed, or during acceleration, the clutch automatically and smoothly disengages.
Page 260 260 STARTING AND OPERATING When additional traction is required, the transfer case 4WD LOCK position can be used to lock the front and rear driveshafts together and force the front and rear wheels to rotate at the same speed. This is accomplished by rotating the 4WD Control Switch to the 4WD LOCK position - see Shifting Procedure section for specific shifting instructions.
Page 261 shift to take place. Shifting while only the front or rear wheels are spinning can cause damage to the transfer case. Proper operation of four-wheel-drive vehicles depends on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the transfer case.
Page 262: Shifting Procedure - Nv 144 Transfer Case
262 STARTING AND OPERATING Shifting Procedure - NV 144 Transfer Case 4WD to 4WD LOCK or 4WD LOCK to 4WD With the key ON and the engine either OFF or RUN- NING, rotate the transfer case switch, located on the instrument panel to the desired position.
Page 263: Nv 244 Generation Ii Transfer Case Operating Information / Precautions
If the key is not ON then the shift will not take place and no position indicator lights will be on or flashing. NV 244 Generation II Transfer Case Operating Information / Precautions The NV 244 Generation II is an electric shift transfer case and is operated by the 4WD Control Switch, which is located on the instrument panel.
Page 264 264 STARTING AND OPERATING NOTE: The transfer case Neutral (N) position is to be used for recreational towing only. See Recreational Tow- ing section for specific procedures on shifting into and out of Neutral (N). Transfer Case Position Indicator Lights Transfer case position indicator lights are located on the instrument cluster.
Page 265 4WD LOCK positions at a given road speed. Take care not to overspeed the engine and do not exceed 40 km/h (25 mph). Proper operation of four-wheel-drive vehicles depends on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the transfer case.
Page 266 266 STARTING AND OPERATING For additional information on the appropriate use of each transfer case mode position see the following informa- tion: Normal Four-Wheel-Drive High Range - Employs inter- axle differential. Allows front and rear wheels to rotate at different speeds. All road surfaces. 4WD LOCK Four-Wheel-Drive Lock (4WD LOCK)- Locks the transfer case inter-axle differential.
Page 267: Shifting Procedure - Nv 244 Generation Ii
Shifting Procedure - NV 244 Generation II Transfer Case NOTE: The 4x4 system will not allow shifts between 4WD/ 4WD LOCK if the rear wheels are spinning (no traction). In this situation a position indicator light will flash and the original position indicator light will remain ON.
Page 268: Driving On Slippery Surfaces
268 STARTING AND OPERATING 3. While still rolling, rotate the transfer case control switch to the desired position. 4. After the position indicator light has stopped flashing, shift the transmission back into gear. Alternate Procedure 1. Bring the vehicle to complete stop. 2.
Page 269: Parking Brake
3. Replace tires when tread wear indicators first become visible. 4. Keep tires properly inflated. 5. Maintain sufficient distance between your vehicle and the car in front to avoid a collision in a sudden stop. PARKING BRAKE The foot operated parking brake is positioned below the lower left corner of the instrument panel.
Page 270 270 STARTING AND OPERATING NOTE: The instrument cluster brake warning light indicates only that the parking brake is applied. You must be sure the parking brake is fully applied before leaving the vehicle. When parking on a hill, turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade.
Page 271: Brake System
BRAKE SYSTEM In the event power assist is lost for any reason, (for example, repeated brake applications with the engine off), the brakes will still function. The effort required to brake the vehicle will be significantly increased over that required with the power system operating. If either the front or rear hydraulic systems lose normal capability, the remaining system will still function with some loss of braking effectiveness.
Page 272 272 STARTING AND OPERATING At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pulsation.
Page 273: Power Steering
WARNING! • Anti-lock system (ABS) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction afforded. •...
Page 274 274 STARTING AND OPERATING If for some reason, the power assist is interrupted, it will still be possible to steer your vehicle. Under these condi- tions you will observe a substantial increase in steering effort, especially at very low vehicle speeds and during parking maneuvers.
Page 275: Electronic Brake Control System
ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system that includes ABS (Anti-Lock Brake System), BAS (Brake Assist System), TCS (Traction Con- trol System), ERM (Electronic Roll Mitigation), ESP (Elec- tronic Stability Program) and TSC (Trailer Sway Control). All six systems work together to enhance vehicle stability and control in various driving conditions, and are com- monly referred to as ESP.
Page 276: Bas (Brake Assist System)
276 STARTING AND OPERATING BAS (Brake Assist System) ESP Off Switch Location The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The system detects an emergency braking situation by sens- ing the rate and amount of brake application and then applies optimum pressure to the brakes.
Page 277: Tcs (Traction Control System)
WARNING! • BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. • The BAS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or hydro- planing.
Page 278: Erm (Electronic Roll Mitigation)
278 STARTING AND OPERATING ERM (Electronic Roll Mitigation) This system anticipates the potential for wheel lift by monitoring the driver’s steering wheel input and the speed of the vehicle. When ERM determines that the rate of change of the steering wheel angle and vehicles speed are sufficient to potentially cause wheel lift, it applies the appropriate brake and may reduce engine power to lessen the chance that wheel lift will occur.
Page 279: Esp (Electronic Stability Program)
ESP (Electronic Stability Program) This system enhances directional control and stability of the vehicle under various driving conditions. ESP cor- rects for over/under steering of the vehicle by applying the brake of the appropriate wheel to assist in counter- acting the over/under steer condition. Engine power may also be reduced to help the vehicle maintain the desired path.
Page 280 280 STARTING AND OPERATING WARNING! • ESP (Electronic Stability Program) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. • ESP cannot prevent accidents, including those resulting from excessive speed in turns, or hydro- planing.
Page 281 conditions and more wheel spin than ESP would nor- mally allow is required to gain traction. TSC (Trailer Sway Control) is not available when the system is in the Partial Off mode. To turn ESP on again, momentarily depress the “ESP-Control OFF” Control Switch. This will restore the normal “ON”...
Page 282 282 STARTING AND OPERATING with off road driving but ESP function returns to provide the stability feature at speeds above 30 mph (48 km/h). The ABS is in a special Off-Road mode that allows wheels to lock at lower speeds if gravel is detected to shorten stopping distances.
Page 283: Multi Displacement System (Mds) - 5.7L Engine Only
several miles at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible to have the problem diagnosed and corrected. NOTE: • The “ESP Indicator Light” and the “ESP/BAS Warning Lamp” come on momentarily each time the ignition switch is turned ON.
Page 284: Rocking The Vehicle
284 STARTING AND OPERATING ROCKING THE VEHICLE If vehicle becomes stuck in snow, sand, or mud, it can often be moved by a rocking motion. Move the gear selector rhythmically between FIRST and REVERSE, while applying slight pressure to the accelerator. The least amount of accelerator pedal pressure to main- tain the rocking motion without spinning the wheels or racing the engine is most effective.
Page 285 • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation. Example: 215/65R15 96H •...
Page 286 286 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
Page 287 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions.
Page 288: Tire Identification Number (Tin)
288 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 289: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 289 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the:...
Page 290 290 STARTING AND OPERATING 3) the tire size designed for your vehicle 4) the cold tire inflation pressures for the front, rear and spare tires. Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading...
Page 291 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1400 lbs. and there will be five 150 lb. passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs. (since 5 x 150 = 750, and 1400 –...
Page 292 292 STARTING AND OPERATING...
Page 293: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 294: Tire Inflation Pressures
294 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
Page 295 check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.
Page 296 296 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 297: Radial-Ply Tires
Radial-Ply Tires WARNING! Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle poorly. The instability could cause an accident. Al- ways use radial ply tires in sets of four (or 6, in case of trucks with dual rear wheels).
Page 298: Limited Use Spare - If Equipped
298 STARTING AND OPERATING Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare. Do not install more than one compact spare tire/wheel on the vehicle at any given time.
Page 299: Tire Spinning
WARNING! The limited use spare tires are for emergency use only. Installation of this limited use spare tire affects vehicle handling. With this tire, do not drive more than 60 mph (100 km/h). Keep inflated to the cold tire inflation pressure listed on either your tire placard or limited use spare tire and wheel assembly.
Page 300: Tread Wear Indicators
300 STARTING AND OPERATING Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 inch (2 mm).
Page 301: Replacement Tires
WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident result- ing in serious injury or death. Keep dismounted tires in a cool, dry place with as little exposure to light as possible.
Page 302: Alignment And Balance
302 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspen- sion dimensions and performance characteristics, resulting in changes to steering, handling, and brak- ing of your vehicle.
Page 303: Supplemental Tire Pressure Information - If Equipped
Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SUPPLEMENTAL TIRE PRESSURE INFORMATION – IF EQUIPPED A light load vehicle condition is defined as two passen- gers {150 lbs (68 kg) each} plus 200 lbs (91kg) of cargo.
Page 304: Snow Tires
304 STARTING AND OPERATING These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires of your truck. NOTE: The use of class “S” chains is permitted on your vehicle with P245/70R17 tires.
Page 305: Tire Rotation Recommendations
TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates and tend to develop irregular wear pat- terns. These effects can be reduced by timely rotation of tires.
Page 306: Tire Pressure Monitor System (Tpms) - If Equipped
306 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED The Tire Pressure Monitoring System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold placard pressure (the placard is lo- cated on the drivers side B-pillar). The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C).
Page 307: Base System - If Equipped
Base System – If Equipped The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the Receiver Module. NOTE: It is particularly important, for you to check the tire pressure in all of your tires regularly and to maintain the proper pressure.
Page 308 308 STARTING AND OPERATING when a system fault is detected. The flash cycle will repeat every ten minutes, without an audible chime, until the fault condition no longer exists. If the ignition key is cycled, this sequence will repeat, providing the system fault still exists.
Page 309: General Information
CAUTION! After inspecting or adjusting the tire pressure al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the wheel rim sensor. NOTE: • The TPMS is not intended to replace normal tire care and maintenance, or to provide warning of a tire failure or condition.
Page 310: Fuel Requirements
310 STARTING AND OPERATING FUEL REQUIREMENTS All engines (except 5.7L engines) are de- signed to meet all emissions regulations and provide excellent fuel economy and performance when using high quality un- leaded “regular” gasoline having an oc- tane rating of 87. The routine use of pre- mium gasoline is not recommended.
Page 311: Reformulated Gasoline
Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as “Reformulated Gasoline.” Reformulated gasolines contain oxygenates, and are spe- cifically blended to reduce vehicle emissions and im- prove air quality. We strongly support the use of reformulated gasolines. Properly blended reformulated gasolines will provide excellent performance and durability for the engine and fuel system components.
Page 312: Mmt In Gasoline
312 STARTING AND OPERATING MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane. Gasolines blended with MMT provide no performance advantage beyond gasolines of the same octane number without MMT. Gasolines blended with MMT reduce spark plug life and reduce emission system performance.
Page 313: Fuel System Cautions
Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s performance: • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance, damage the emission control system. • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat.
Page 314: Carbon Monoxide Warnings
314 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
Page 315 CAUTION! A poorly fitting gas cap may cause the Malfunction Indicator Light to turn on. CAUTION! To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling. NOTE: When the fuel nozzle “clicks” or shuts off, the fuel tank is full.
Page 316: Loose Fuel Filler Cap Message
316 STARTING AND OPERATING WARNING! A fire may result if gasoline is pumped into a portable container that is inside of a vehicle. You could be burned. Always place gas containers on the ground while filling. Loose Fuel Filler Cap Message After fuel is added, the vehicle diagnostic system can determine if the fuel filler cap is loose, improperly installed, or damaged.
Page 317: Flexible Fuel
WARNING! • Never add fuel when the engine is running. • Never have any smoking materials lit in or near the vehicle when the fuel cap is removed or the tank filled. FLEXIBLE FUEL E-85 General Information The information in this section is for Flexible Fuel ve- hicles only.
Page 318: Fuel Requirements
318 STARTING AND OPERATING Fuel Requirements Your vehicle will operate on both unleaded gasoline with an octane rating of 87, or E-85 fuel, or any mixture of these two. For best results, a refueling pattern that alternates be- tween E-85 and unleaded gasoline should be avoided. When you do switch fuels, it is recommended that •...
Page 319: Cruising Range
Cruising Range Because E-85 fuel contains less energy per gallon than gasoline, you will experience an increase in fuel con- sumption. You can expect your MPG and your driving range to decrease by about 30% compared to gasoline operation. Replacement Parts Many components in your Flexible Fuel Vehicle (FFV) are designed to be compatible with ethanol.
Page 320: Vehicle Loading
320 STARTING AND OPERATING VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration Regulations, your vehicle has a certification label affixed to the driver’s side door. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 321: Curb Weight
Gross Axle Weight Rating (GAWR) The GAWR is the maximum permissible load on the front and rear axles. The load must be distributed in the cargo area so that the GAWR of each axle is not exceeded. Each axle GAWR is determined by the component in the system with the lowest load carrying capacity (axle, springs, tires, or wheels).
Page 322 322 STARTING AND OPERATING then be determined separately to be sure that the load is properly distributed over front and rear axle. Weighing the vehicle may show that the GAWR of either the front or rear axles has been exceeded but the total load is within the specified GVWR.
Page 323: Trailer Towing
after the vehicle has been weighed both in its curb weight condition, and in its loaded and ready for operation condition. Gross Vehicle Weight Rating (GVWR) 6500 LBS. STARTING AND OPERATING 323 TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle.
Page 324 324 STARTING AND OPERATING Gross Trailer Weight (GTW) The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its loaded and ready for operation condition. The recom- mended way to measure GTW is to put your fully loaded trailer on a vehicle scale.
Page 325 Frontal Area The maximum height and maximum width of the front of a trailer. TSC (Trailer Sway Control) – If Equipped • Trailer Sway Control – Electronic TSC uses sensors in the vehicle to recognize a swaying trailer and will take the appropriate actions to attempt to stop the sway.
Page 326 326 STARTING AND OPERATING used in accordance with the manufacturers’ directions, it provides for a more level ride, offering more consistent steering and brake control thereby enhancing towing safety. The addition of a friction / hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability.
Page 327 STARTING AND OPERATING 327 Weight Distributing Hitch System Improper Adjustment of Weight Distributing System Fifth-Wheel Hitch A special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. Connects a vehicle and fifth-wheel trailer with a coupling king pin.
Page 328: Trailer Hitch Classification
328 STARTING AND OPERATING Gooseneck Hitch The gooseneck hitch employs a pivoted coupling arm which attaches to a ball mounted in the bed of a pickup truck. The coupling arm connects to the hitch mounted over the rear axle in the truck bed. Trailer Hitch Classification The rear bumper is intended to tow trailers up to 2,000 lbs (907 kg) without added equipment or alterations to...
Page 329: Trailer Towing Weights (Maximum Trailer Weight Ratings)
• http:// www.dodge.com/towing. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 330: Towing Requirements
330 STARTING AND OPERATING • The weight of any other type of cargo or equipment put in or on your vehicle. • The weight of the driver and all passengers. NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle.
Page 331 WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 332 332 STARTING AND OPERATING 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements —...
Page 333 actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. − Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
Page 334: Towing Tips
334 STARTING AND OPERATING NOTE: Do not cut or splice wiring into the vehicles wiring harness. The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 4 - Pin Connector 7- Pin Connector Towing Tips...
Page 335 If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the “TOW HAUL”...
Page 336: Snowplow
Maintenance section of this manual for more informa- tion. SNOWPLOW Dodge Durango or Chrysler Aspen Models NOTE: Do not use Dodge Durango or Chrysler Aspen Models for snowplow applications. WARNING! Snowplows, winches, and other aftermarket equip- ment should not be added to the front end or your vehicle.
Page 337: Recreational Towing (Behind Motorhome, Etc.)
CAUTION! Using this vehicle for snowplow applications can cause damage to the vehicle. WARNING! Attaching a snowplow to this vehicle could ad- versely affect performance of the airbag system in an accident. Do not expect that the airbag will perform as described earlier in this manual STARTING AND OPERATING 337 RECREATIONAL TOWING (BEHIND...
Page 338 338 STARTING AND OPERATING WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake. The transfer case Neutral (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move despite the transmission position.
Page 339 2. Shut engine OFF. 3. Turn the ignition key to the ON position without starting the engine. 4. Depress brake pedal. 5. Shift automatic transmission to Neutral (N). 6. Using the point of a ballpoint pen or similar object, depress the recessed transfer case Neutral (N) button for 4 seconds.
Page 340 340 STARTING AND OPERATING NOTE: The ignition key must be ON for a shift to take place and for the position indicator lights to be operable. If the key is not ON, the shift will not take place and no position indicator lights will be on or flashing.
Page 341: Equipment Identification Plate
NOTE: Items 1 through 5 are requirements that must be met prior to depressing the Neutral (N) selection button, and must continue to be met until 1 second elapses and the shift has been completed. If any of these requirements are not met prior to depress- ing the Neutral (N) button or are no longer met during the 1 second time, then all of the position indicator lights will flash continuously until all requirements are met or...
Page 343: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....344 Jacking And Tire Changing ....345 Jack Location .
Page 344: Hazard Warning Flasher
344 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The flasher switch is on the top of the steering column, just behind the steering wheel. Press the flasher switch and all front and rear directional signals will flash intermittently. Press the switch a second time to turn off the emergency flashers.
Page 345: Jacking And Tire Changing
JACKING AND TIRE CHANGING WARNING! • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. Never start or run the engine while the vehicle is on a jack.
Page 346: Jacking Instructions
346 WHAT TO DO IN EMERGENCIES JACKING INSTRUCTIONS Removing The Spare Tire The spare tire on your vehicle is located underneath the vehicle in the rear. Remove the spare tire before attempting to jack the truck. 1. Remove the rubber plug from the floor in the cargo area.
Page 347: Tire Changing Procedure
It is recommended that you stow the flat or spare to avoid tangling the loose cable. CAUTION! The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and can damage the winch.
Page 348 348 WHAT TO DO IN EMERGENCIES Preparations Park the vehicle on a firm level surface, avoiding ice or slippery areas. Set the parking brake and place the gear selector in PARK (automatic transmission). On Four Wheel Drive vehicles, shift the transfer case to the “4L” position.
Page 349 3. When changing a front wheel, place the jack under the frame rail behind the wheel. Locate the jack as far forward as possible on the straight part of the frame (prior to inboard transition. Operate the jack using the jack drive tube and the wheel wrench - the tube exten- sion, may be used but is not required.
Page 350 350 WHAT TO DO IN EMERGENCIES Rear Right Jacking Location Before raising the wheel off the ground, make sure that the jack will not damage surrounding truck parts and adjust the jack position as required. 4. By rotating the wheel wrench clockwise, raise the vehicle until the wheel just clears the surface.
Page 351 correct tightness, have them checked with a torque wrench by your dealer or at a service station. WARNING! A loose tire or jack thrown forward in a collision or hard stop could injure someone in the vehicle. Always stow the jack, tools and the extra tire and wheel in the places provided.
Page 352 352 WHAT TO DO IN EMERGENCIES WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle. •...
Page 353: Jump Starting Procedures
JUMP STARTING PROCEDURES WARNING! • Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or cloth- ing. Don’t lean over battery when attaching clamps or allow the clamps to touch each other. If acid splashes in eyes or on skin, flush the con- taminated area immediately with large quantities of water.
Page 354 354 WHAT TO DO IN EMERGENCIES 4. Connect one end of a jumper cable to the positive terminal of the booster battery. Connect the other end of the same cable to the positive terminal of the discharged battery. WARNING! Do not permit vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 355: Emergency Tow Hooks - If Equipped
WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle. EMERGENCY TOW HOOKS —...
Page 356: Towing A Disabled Vehicle
356 WHAT TO DO IN EMERGENCIES CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow truck hookup or highway towing. You could damage your vehicle. TOWING A DISABLED VEHICLE Proper towing or lifting equipment is required to prevent damage to your vehicle.
Page 357: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment 3.7L V6 ....360 Engine Compartment 4.7L V-8 ....361 Engine Compartment 5.7L HEMI V-8 .
Page 358 358 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance ... . . 375 Power Steering — Fluid Check ... . 377 Front Suspension Ball Joints ....377 Drive Shaft Constant Velocity Joints .
Page 359 License Lights ......413 Center High-Mounted Stoplight ... 414 Fog Lights .
Page 360: Engine Compartment 3.7L V6
360 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 3.7L V6...
Page 361: Engine Compartment 4.7L V-8
MAINTAINING YOUR VEHICLE 361 ENGINE COMPARTMENT 4.7L V-8...
Page 362: Engine Compartment 5.7L Hemi V-8
362 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 5.7L HEMI V-8...
Page 363: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 364: Emissions Inspection And Maintenance Programs
364 MAINTAINING YOUR VEHICLE cap until a clicking sound is heard. This is an indication that the gas cap is properly tightened. Press the odometer reset button to turn the message off. If the problem persists, the message will appear the next time the vehicle is started.
Page 365: Replacement Parts
3. As soon as you turn your key to the ON position, you will see your MIL symbol come on as part of a normal bulb check. 4. Approximately 15 seconds later, one of two things will happen: a. The MIL light will blink for approximately 5 sec- onds and then remain on until the first engine crank or the key is turned off.
Page 366: Dealer Service
366 MAINTAINING YOUR VEHICLE DEALER SERVICE Your dealer has the qualified service personnel, special tools and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 367: Engine Oil
could adversely affect the engine or vehicle performance. These items should be inspected if a malfunction is observed or suspected. Engine Oil Checking Oil Level To assure proper lubrication of your vehicle’s engine, the engine oil must be maintained at the correct level. The best time to check the engine oil level is about 5 minutes after a fully warmed up engine is shut off or before starting the engine after it has sat overnight.
Page 368 368 MAINTAINING YOUR VEHICLE Change Engine Oil Road conditions and your style of driving affect the interval at which your oil should be changed. Check the following to determine if ANY apply to you: • Day or night temperatures are below 32°F (0°C). •...
Page 369 Dusty Conditions Driving through dust-laden air increases the problems of keeping abrasive materials out of the engine. Under these conditions, special attention should be given to the engine air cleaner and the crankcase inlet air cleaner. The crankcase ventilation system should also be checked periodically.
Page 370: Engine Oil Filter
370 MAINTAINING YOUR VEHICLE Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Synthetic Engine Oils You may use synthetic engine oils provided the recom- mended oil quality requirements are met, and the recom- mended maintenance intervals for oil and filter changes are followed.
Page 371: Drive Belts - Check Condition And Tension
Drive Belts — Check Condition and Tension Belt tension is controlled by means of an automatic tensioner. No belt tension adjustments are required. However, belt and belt tensioner condition should be inspected at the specified intervals, and replaced if re- quired.
Page 372: Engine Air Cleaner Filter
372 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Under normal driving conditions, replace the air filter at the intervals shown on Schedule “A”. If, however, you drive the vehicle frequently under dusty or severe con- ditions, the filter element should be inspected periodi- cally and replaced if necessary at the intervals shown on Schedule “B”.
Page 373: Catalytic Converter
Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 374: Maintenance Free Battery
374 MAINTAINING YOUR VEHICLE WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your ex- haust system. Do not park or operate your vehicle in areas where your exhaust system can contact any- thing that can burn.
Page 375: Air Conditioner Maintenance
WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 376 376 MAINTAINING YOUR VEHICLE include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time. WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system.
Page 377: Power Steering - Fluid Check
Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocar- bon (HFC) that is endorsed by the Environmental Pro- tection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by dealers or other service facilities using recovery and recycling equipment.
Page 378: Drive Shaft Constant Velocity Joints
378 MAINTAINING YOUR VEHICLE Drive Shaft Constant Velocity Joints All four wheel drive models are equipped with four constant velocity joints. Periodic lubrication of these joints is not required. However, the joint boot should be inspected for external leakage or damage periodically. If external leakage or damage is evident, the joint boot and grease should be replaced immediately.
Page 379: Windshield Washers
Avoid using the wiper blades to remove frost or ice from the windshield. Keep the blade rubber out of contact with petroleum products such as engine oil, gasoline, etc. Windshield Washers The fluid reservoir should be checked for fluid level at regular intervals.
Page 380: Exhaust System
380 MAINTAINING YOUR VEHICLE Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken,...
Page 381: Cooling System
Cooling System WARNING! You or others can be badly burned by hot coolant or steam from your radiator. If you see or hear steam coming from under the hood, don’t open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radia- tor is hot.
Page 382 382 MAINTAINING YOUR VEHICLE If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough rinsing to remove all deposits and chemicals. Properly dispose of old antifreeze solution.
Page 383 Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to 5 Years or 100,000 miles before replacement. To prevent reducing this extended mainte- nance period, it is important that you use the same coolant throughout the life of your vehicle.
Page 384 384 MAINTAINING YOUR VEHICLE WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine.
Page 385 When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill. Points To Remember NOTE: When the vehicle is stopped after a few miles (a few kilometers) of operation, you may observe vapor coming from the front of the engine compartment.
Page 386: Emission Related Components
386 MAINTAINING YOUR VEHICLE • Do not change the thermostat for summer or winter operation. If replacement is ever necessary, install ONLY the correct type thermostat. Other designs may result in unsatisfactory coolant performance, poor gas mileage, and increased emissions. Emission Related Components Fuel System Hoses And Vapor/Vacuum Harnesses When the vehicle is serviced for scheduled maintenance,...
Page 387: Brake System
Positive Crankcase Ventilation (PCV) Valve Proper operation of the crankcase ventilation system requires that the PCV valve be free of sticking or plug- ging because of deposits. Deposits can accumulate in the PCV valve and passage with increasing mileage. Have the PCV valve, hoses, and passages checked for proper operation at the intervals specified.
Page 388 388 MAINTAINING YOUR VEHICLE WARNING! Use of brake fluid that may have a lower initial boiling point, or is unidentified, as to specifications may result in sudden brake failure during hard prolonged braking. You could have an accident. WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching on fire.
Page 389: Automatic Transmission
WARNING! Worn brake hoses can burst and cause brake failure. You could have an accident. If you see any sign of cracking, scuffing, or worn spots, have the brake hoses replaced immediately. Automatic Transmission Fluid Level Check Check the fluid level while the transmission is at normal operating temperature 180°F (82°C).
Page 390 390 MAINTAINING YOUR VEHICLE a minimum of two (2) minutes for the oil to fully drain into the transmission before rechecking the fluid level. NOTE: If it is necessary to check the transmission below the operating temperature, the fluid level should be between the two “COLD”...
Page 391: Transfer Case
CAUTION! Using a transmission fluid other than the manufac- turers recommended fluid may cause deterioration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than the manufacturers recommended fluid will result in more frequent fluid and filter changes. Refer to Fluids, Lubricants and Genuine Parts for correct fluid type.
Page 392: Axles
392 MAINTAINING YOUR VEHICLE Axles Refer to Fluids, Lubricants and Genuine Parts for correct fluid type. The manufacturer does not recommend regularly sched- uled oil changes for axles in vehicles whose operation is classified as normal truck service. NOTE: The presence of water in the gear lubricant will result in corrosion and possible failure of differential components.
Page 393: Appearance Care And Protection From Corrosion
be used for chassis lubrication. Use only those greases that have the NLGI symbol on the container along with the proper quality level for your application. Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 394 394 MAINTAINING YOUR VEHICLE • Use Mopar auto polish to remove road film and stains and to polish your vehicle. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 395 • Use Mopar touch up paint on scratches as soon as possible. Your dealer has touch up paint to match the color of your vehicle. Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
Page 396 396 MAINTAINING YOUR VEHICLE Mopar Total Clean is specifically recommended for leather upholstery. Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth.
Page 397 Glass Surfaces All glass surfaces should be cleaned on a regular basis with any commercial household-type glass cleaner. Never use an abrasive type cleaner. Use caution when cleaning inside rear windows equipped with electric defrosters or windshields equipped with a windshield wiper de-icer.
Page 398: Fuse Block
398 MAINTAINING YOUR VEHICLE FUSE BLOCK CAUTION! When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it suggests a problem in the circuit that must be corrected.
Page 399 MAINTAINING YOUR VEHICLE 399...
Page 400 400 MAINTAINING YOUR VEHICLE Cavity Mini Fuse/Color 15 Amp Blue 10 Amp Red 10 Amp Red 10 Amp Red Description Instrument Clus- ter Battery Feed Spare Ignition Run/ Start for Next Generation Con- troller (NGC), Integrated Power Module (IPM), AC Relay and Fuel Pump Relay Door Node and...
Page 401 10 Amp Red Heated Mirrors Cluster Battery 20 Amp Yellow Feed Ignition Run HVAC Module/ 10 Amp Red Heated Rear Glass (EBL) Re- ABS Module Ig- 10 Amp Red nition Run Battery Feed Blue Tooth, Compass/Trip 15 Amp Blue Computer (CMTC), Sentry Key Diagnostics Reconfigurable...
Page 402: Fuses (Power Distribution Center)
402 MAINTAINING YOUR VEHICLE Fuses (Power Distribution Center) Power Distribution Center Your vehicle is equipped with an electrical power distri- bution center located in the left side of the engine compartment. This center contains cartridge fuses, mini fuses and relays. A description of each fuse and component may be stamped on the inside cover otherwise the cavity number of each fuse is stamped on the inside cover that corre- sponds to the following chart.
Page 403 Cartridge Mini Cavity Fuse / Description Fuse Relay 40 Amp Blower Motor Relay Green Feed 40 Amp JB Feed Acc Delay Green Spare 30 Amp Pink 40 Amp Power Liftgate ( If Green Equipped) 40 Amp JB Feed / Heated Green Rear Glass (EBL)/ T Case Brake...
Page 404 404 MAINTAINING YOUR VEHICLE Cartridge Mini Cavity Fuse / Fuse Relay 20 Amp Trailer Tow Yellow 15 Amp A/C Clutch Blue 15 Amp Stop Lamp Switch Blue Spare 20 Amp Run/Start Relay Feed Yellow Spare Relay Run Start Relay Run Remote Spare Relay Starter...
Page 405: Fuses (Integrated Power Module)
Fuses (Integrated Power Module) Integrated Power Module An integrated Power Module is located in the left side of the engine compartment. This center contains cartridge fuses, mini fuses and relays. A description of each fuse and component may be stamped on the inside cover MAINTAINING YOUR VEHICLE 405 otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
Page 406 406 MAINTAINING YOUR VEHICLE Cartridge Cavity Fuse / Mini Fuse Relay Relay 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- 20 Amp Yel- Description Cavity Radiator Fan Hi Rly Front Control Module (FCM) Batt #4 Front Control Module...
Page 407: Vehicle Storage
VEHICLE STORAGE If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: • Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse located in the Power Distribution Center (PDC). The I.O.D.
Page 408: Bulb Replacement
408 MAINTAINING YOUR VEHICLE BULB REPLACEMENT Headlights/Parking/Turn Signal 1. Remove the two bolts attaching the headlight to the upper fender reinforcement (hood must be open to access bolts). 2. Remove one nut that attaches the headlight to the inner fender panel. Access to the nut is possible by opening the fender panel access door which is located in the wheel liner.
Page 409: Rear Side Marker, Tail Lights, Turn Signals And Backup Lights - Replacement
4. While firmly holding the headlight in your hands disconnect all connectors by following the procedure described in step number 5 below. 5. Remove the bulb connector from the headlight making sure to pull and release the red tab on all connectors. Loosen the connector by pressing down on the black and/or green release which is located below or above the red tab.
Page 410 410 MAINTAINING YOUR VEHICLE 2. Rotate the light to the outboard side of the vehicle and remove.
Page 411 MAINTAINING YOUR VEHICLE 411 3. Unlock and remove electrical connector. 4. Remove the three screws holding the bulb strip to the back of the tail lamp.
Page 412 412 MAINTAINING YOUR VEHICLE 5. Remove the bulb strip from the tail light lens. 6. Remove bulbs from bulb strip by pulling the bulb straight out.
Page 413 MAINTAINING YOUR VEHICLE 413 License Lights 1. Remove the two screws securing the lens to the liftgate.
Page 414 414 MAINTAINING YOUR VEHICLE 2. Rotate the socket 1/4 turn counterclockwise. 3. Pull bulb from socket. Center High-Mounted Stoplight 1. Remove two screws securing stoplight housing assem- bly to the liftgate.
Page 415 2. Turn socket 1/4 counterclockwise and free from hous- ing. 3. Pull bulb straight from socket to remove. MAINTAINING YOUR VEHICLE 415 Fog Lights 1 – (3) Wheel liner screws 2 – (1) Air dam screw...
Page 416 416 MAINTAINING YOUR VEHICLE To replace the left foglamp bulb: 1. Remove the three wheel liner screws 2. Remove the remove the far left air dam screw at the bottom of the fascia. 3. Peel back the liner and access the foglamp 4.
Page 417 FLUIDS AND CAPACITIES Fuel 3.7L/4.7L, 87 Octane 5.7L, 89 Octane Engine Oil (with filter) 3.7L, SAE 5W-20, API Certified 4.7L, SAE 5W-20, API Certified 5.7L, SAE 5W-20, API Certified Cooling System (includes 2.1 Qts./2L for coolant bottle 3.7L without Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 3.7L with Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 4.7L without Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 4.7L with Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula)
Page 418 418 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant 3.7/4.7L Engine Oil 5.7L Engine Oil Engine Oil Filter Spark Plugs Fuel Selection 3.7L/4.7L Fuel Selection 5.7L Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent.
Page 419 Chassis Component Automatic Transmission Transfer Case Front Axle Rear Axle Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts. Mopar ATF+4, Automatic Transmission Fluid. Mopar ATF+4, Automatic Transmission Fluid. SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant or equivalent. SAE 75W-140 Synthetic Gear Lubricant or equivalent.
Page 421 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..422 Maintenance Schedules ....422 Schedule “B” ......425 Schedule “A”...
Page 422: Emission Control System Maintenance
422 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type on the following pages must be done at the times or mileages specified to assure the continued proper func- tioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 423 • Off-road or desert operation. • If equipped for and operating with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule “B” of the Maintenance Schedules section of this manual.
Page 424 424 MAINTENANCE SCHEDULES At Each Stop for Fuel • Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accu- racy of the oil level reading.
Page 425: Schedule "B" 425
At Each Oil Change • Change the engine oil filter. • Inspect the exhaust system. • Inspect the brake hoses. • Inspect the CV joints (if equipped) and front suspen- sion components. • Check the automatic transmission fluid level. • Check the coolant level, hoses, and clamps. SCHEDULE “B”...
Page 426 426 SCHEDULE “B” • If equipped for and operating with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule “B” of the Maintenance Schedules section of this manual.
Page 427 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect engine air cleaner filter, replace if neces- sary.
Page 428 428 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Check transfer case fluid level (4X4). Inspect brake linings.
Page 429 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 430 430 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 431 Miles (Kilometers) Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your ve- hicle is used for police, taxi, fleet, or frequent trailer towing. Drain and refill automatic transmission fluid and change main sump filter (4.7L/5.7L only). This ap- plies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing.
Page 432 432 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 433 Miles (Kilometers ) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Check transfer case fluid level (4X4). Inspect brake linings.
Page 434 434 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Flush and replace engine coolant, if not replaced at 60 months.
Page 435 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if necessary.
Page 436 436 SCHEDULE “B” Miles (Kilometers) Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or fre- quent trailer towing. Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter if equipped.
Page 437 Miles (Kilometers) Change engine oil and engine oil filter at in- terval shown or 3 months, whichever comes first. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Lubricate outer tie rod ends (4X4). Change front and rear axle fluid (4X4).
Page 438 438 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Lubricate Front Drive Shaft Fitting (4X4). Rotate tires. Check spare tire for proper pressure and correct stowage. Lubricate outer tie rod ends (4X4) models only. Drain and refill transfer case fluid (4X4).
Page 439 Miles (Kilometers) Drain and refill automatic transmission fluid and change main sump and spin-on cooler return filter (if equipped). Flush and replace engine coolant if not replaced at 120,000 miles (200 000 km). Inspection and service should also be performed anytime a malfunction is observed or suspected.
Page 440: Schedule "A
440 SCHEDULE “A” Schedule “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Check transfer case fluid level (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace as neces- sary.
Page 441 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Check transfer case fluid level (4X4). Flush and replace engine coolant at 60 months, if not replaced at 102,000 miles (170 000 km).
Page 442 442 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Check transfer case fluid level (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 443 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Drain and refill transfer case fluid (4X4). Flush and replace engine coolant, if not replaced at 60 months. Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km).
Page 444 444 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Drain and refill transfer case fluid (4X4). Lubricate Front Drive Shaft Fitting (4X4). Flush and replace engine coolant, if not replaced at 120,000 miles (200 000 km).
Page 445 Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts. * This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions warranty. SCHEDULE “A” 445 WARNING! You can be badly injured working on or around a motor vehicle.
Page 447: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......448 Prepare For The Appointment .
Page 448: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 449 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 450 450 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 451: Warranty Information (U.s. Vehicles Only)
WARRANTY INFORMATION (U.S. Vehicles Only) See the Warranty Information Booklet for the terms and provisions of DaimlerChrysler’s warranties applicable to this vehicle. MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best.
Page 452: Publication Order Forms
452 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 453 • Owner’s Manuals. These manuals have been prepared with the assistance of service and engineering specialists to acquaint you with specific Chrysler group vehicles. Included are starting, operating, emergency and maintenance pro- cedures as well as specifications, capabilities and safety tips. IF YOU NEED CONSUMER ASSISTANCE 453 Call Toll Free at: •...
Page 454: Department Of Transportation Uniform Tire Quality Grades
454 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 455: Temperature Grades
Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 457 INDEX...
Page 458 458 INDEX ABS (Anti-Lock Brake System) ... . 188,271 Adding Fuel ......314 Air Cleaner, Engine (Engine Air Cleaner Filter) .
Page 459 Axle Lubrication (Axle Fluid) ....392 Ball Joints ......377 Battery .
Page 460 460 INDEX Carbon Monoxide Warning ... . 72,161,314 Cargo Management System ....177 Cargo Organizer ..... . . 177 Cargo Organizer .
Page 461 Pressure Cap ......383 Radiator Cap ......383 Selection of Coolant (Antifreeze) .
Page 462 462 INDEX Emergency, In Case of Freeing Vehicle When Stuck ....284 Jacking ......347 Tow Hooks .
Page 463 Flashers Hazard Warning ..... . . 344 Turn Signal ..... 135,185,409 Flat Tire Stowage .
Page 464 464 INDEX Fuses ......172,398,402,405 Garage Door Opener (HomeLink ) ... 160 Gas Cap (Fuel Filler Cap) .
Page 465 Hitches Trailer Towing ......328 HomeLink (Garage Door Opener) Transmitter . . . 160 Hood Release ......129 Hoses .
Page 466 466 INDEX Lane Change and Turn Signals ..135,185,409 Lap/Shoulder Belts ..... 39,44 LATCH (Lower Anchors and Tether for CHildren) .
Page 467 Traction Control ..... . . 279 Turn Signal ......135,409 Warning (Instrument Cluster Description) .
Page 468 468 INDEX Rearview ......79 Vanity ....... 83 Modifications/Alterations, Vehicle .
Page 469 Parking On Hill ......269 Passing Light ......137 Pedals, Adjustable .
Page 470 470 INDEX Rear Cup Holder ......174 Rear Liftgate ......34 Rear Window Defroster .
Page 471 Seat Belt Reminder ..... . . 48 Seat Belts ......38,39,73 And Pregnant Women .
Page 472 472 INDEX Snow Plow ......336 Snow Tires ......304 Spare Tire .
Page 473 Tire Safety Information ....284 Tires ......73,293,454 Aging (Life of Tires) .
Page 474 474 INDEX Trailer Towing ......323 Cooling System Tips ....336 Hitches .
Page 475 Vehicle Storage ......407 Video Entertainment System (Rear Seat Video System) ......223 Warning Lights (Instrument Cluster Description) Warning, Roll Over .

This manual is also suitable for:

2007 hb durango

Dodge 2007 Durango Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Instrument Panel and Controls

Starting and Operating

What to Do in Emergencies

Quick Links

INTRODUCTION

Chapters

Related Manuals for Dodge 2007 Durango

Summary of Contents for Dodge 2007 Durango
