Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE... -
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions . -
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully. - Page 5 INTRODUCTION 5...
-
Page 6: Warnings And Cautions
6 INTRODUCTION WARNINGS AND CAUTIONS This manual contains WARNINGS against operating procedures, which could result in an accident or bodily injury. It also contains CAUTIONS against procedures, which could result in damage to your vehicle. If you do not read this entire manual, you may miss important information. -
Page 7: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death. -
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder . - Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disarm The System ....19 Security System Manual Override ...19 Illuminated Entry System —...
- Page 11 Reinstalling Storage Bin Cover Emergency Release ......45 Occupant Restraints ..... .46 Lap/Shoulder Belts .
-
Page 12: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer. Ask your dealer for these numbers and keep them in a safe place. - Page 13 Ignition Key Position NOTE: The power window switches, radio, power outlets, and removable console (if equipped), will remain active for up to 45 seconds after the ignition switch has been turned off. Opening a vehicle front door will cancel this feature. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! NEVER leave children alone in a vehicle.
-
Page 14: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder An alarm will sound to remind you if the key is left in the ignition and the driver’s door is opened. Locking Doors With The Key You can insert the key with either side up. To lock the door, turn the key rearward, to unlock the door, turn the key forward. -
Page 15: Automatic Transaxle Ignition Interlock System
Automatic Transaxle Ignition Interlock System This system prevents the key from being removed unless the shift lever is in PARK. It also prevents shifting out of PARK unless the key is in the ACC, or ON positions, and the brake pedal is depressed. SENTRY KEY —... -
Page 16: Shaft Lock Module (Vehicles Equipped With Premium Security System) - If Equipped
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Shaft Lock Module (Vehicles Equipped with Premium Security System) — If Equipped The shaft lock module is located inside the steering column. The module works in conjunction with the Sentry Key to prevent the steering shaft from rotating if someone inserts an invalid ignition key into the ignition lock cylinder in the instrument panel. -
Page 17: Customer Key Programming
NOTE: When having the Sentry Key Immobilizer System serviced, bring all vehicle keys with you to the dealer. Customer Key Programming You can program new sentry keys to the system if you have two valid sentry keys by performing the following procedure: 1. -
Page 18: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information The Sentry Key system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •... -
Page 19: To Disarm The System
NOTE: If the SECURITY light stays on continuously during vehicle operation, have the system checked by your dealer. To Disarm the System Use the Keyless Entry transmitter to unlock the door. If something has triggered the system in your absence, the horn will sound three times when you unlock the doors and the security lamp will flash for 30 seconds. -
Page 20: Illuminated Entry System - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ILLUMINATED ENTRY SYSTEM — IF EQUIPPED The courtesy lights will turn on when you use the keyless entry transmitter or open the doors. This feature is only available if you have Remote Keyless Entry. The lights will fade to off after about 30 seconds or they will immediately fade to off once the ignition switch is turned on. - Page 21 Three button transmitters will provide basic UNLOCK, LOCK and PANIC functions. Three Button Transmitter Six button transmitters will provide functions that allow the same basic operation as the three button, but may also be used to Open/Close the optional power liftgate, left power sliding door, or right power sliding door.
-
Page 22: To Unlock The Doors And Liftgate
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To unlock the doors and liftgate: Press and release the UNLOCK button on the transmitter once to unlock the driver’s door side of the vehicle, or twice to unlock all doors and liftgate. The illuminated entry system also turns on. -
Page 23: Using The Panic Alarm
Using The Panic Alarm: To turn the panic alarm feature ON or OFF, press and hold the PANIC button on the transmitter for at least one second and release. When the panic alarm is on, the headlights and park lights will flash, the horn will pulse on and off and the interior lights will turn on. - Page 24 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Open/Close Left Power Sliding Door — If Equipped Press the LEFT button twice within five seconds to open/close the left power sliding door. If the button is pushed while the door is being power closed, the door will reverse to the full open position.
-
Page 25: General Information
the procedure in the Electronic Vehicle Information Cen- ter (EVIC), Customer Programmable Features section on vehicles so equipped. The table below explains the Lamp Flash options. Function Which Turn Signal Lamps Lock Unlock 1st Left Side Press Unlock All Doors Left Side Left Side Right Side... -
Page 26: Transmitter Battery Service
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transmitter Battery Service The recommended replacement battery is one CR2032 battery. NOTE: Perchlorate Material — special handling may apply. www.dtsc.ca.gov/hazardouswaste/ perchlorate NOTE: Do not touch the battery terminals that are on the back housing or the printed circuit board. 1. -
Page 27: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To reassemble the transmitter case snap two halves together. -
Page 28: Power Door Locks - If Equipped
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the lock plunger is down when you shut the door, the door will lock. Therefore, make sure the keys are not inside the vehicle before closing the door. WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. - Page 29 If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate. This prevents you from acciden- tally locking your keys in the vehicle. Removing the key or closing the door will allow the locks to operate.
- Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Within 30 seconds, press the driver’s door lock switch in the LOCK direction. 6. A single chime will be heard to indicate the feature has been disabled. 7. To reactivate this feature, repeat the above steps. 8.
-
Page 31: Windows
5. Within 30 seconds, press the driver’s door lock switch in the UNLOCK direction. 6. A single chime will sound to indicate the feature has been changed. 7. Repeat the above steps to alternate the availability of this feature. 8. If a chime is not heard, program mode was canceled before the feature could be changed. -
Page 32: Power Vent Windows - If Equipped
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Vent Windows — If Equipped Switches on the driver’s door trim panel let the driver operate the two vent windows from the front seat. Power Vent Window Switches Power Windows — If Equipped You can control either front window using switches on the driver’s door trim panel. - Page 33 Auto Down Feature — If Equipped The driver’s window switch has an auto down feature. Press the window switch past the detent, release, and the window will go down automatically. To open the window part way, press the window switch part way and release it when you want the window to stop.
-
Page 34: Sliding Side Door
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SLIDING SIDE DOOR The sliding door may be opened from the inside or the outside. Pull out on the outside handle to open the sliding door from the outside. To open the sliding door from the inside, press the button on the grab handle and open the door. -
Page 35: Sliding Door Open Flash
NOTE: The driver’s side sliding door cannot be opened while the fuel door is open. This feature operates only when the sliding door is fully closed prior to opening the fuel door. Sliding Door Open Flash When the sliding door(s) are opened, the left and right exterior hazard lights will flash for 12 seconds to alert other drivers in the area that passenger(s) could be entering or exiting the vehicle. - Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power sliding door may also be opened by pressing the switches on the overhead console or the switch located on the trim panel just in front of the sliding door. To keep your door operating properly, observe the fol- lowing guidelines.
- Page 37 If the inside or outside door handles are used while the power sliding door is activated, the power sliding door feature will be canceled and the door must be opened or closed manually. To avoid unintentional operation of the power sliding doors from the rear seats, press the ON /OFF button located in the overhead console to disable the switches for the rear seat passengers.
-
Page 38: Child Protection Door Lock
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Protection Door Lock To provide a safer environment for small children riding in the rear seats, the sliding doors are equipped with a child protection door lock system. NOTE: When the child lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position. - Page 39 NOTE: • After engaging the child protection door lock system, always test the door from the inside to make certain it is in the desired position. • When the child lock system is engaged the door can be opened only by using the outside door handle, remote keyless entry transmitter, switches on the overhead console or the switches located on the trim panel just in front of the power sliding door, even though the...
-
Page 40: Liftgate
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • After setting the child protection door lock system, always test the door from the inside to make certain it is in the desired position. • The power sliding door switches will not operate if the vehicle is in gear or the vehicle speed is above 0 mph (0 km/h). -
Page 41: Power Liftgate - If Equipped
Liftgate Handle If the liftgate is locked and is not equipped with a powered liftgate, pressing the button on the remote keyless entry transmitter will result in the liftgate becom- ing unlocked for 30 seconds allowing you to manually access the liftgate area. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: On vehicles without power locks, the liftgate can only be opened using the vehicle keys. - Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power liftgate may also be opened by pressing the button located on the overhead console. Power Liftgate Button When the remote keyless entry transmitter button is pressed and the “Lamp Flash” feature is enabled, the tail lights will flash to signal that the liftgate is opening or closing.
- Page 43 • The power liftgate must be in the full open or close positions for any of the buttons to operate. If the liftgate is not in the full open or close positions it must be opened or closed manually. • If the liftgate release button is activated while the power liftgate is closing, the liftgate will reverse to the full open position.
-
Page 44: Seat Storage Bin Safety Warning
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. SEAT STORAGE BIN SAFETY WARNING WARNING! Always close the storage bin covers when your... -
Page 45: Reinstalling Storage Bin Cover Emergency Release
Storage Bin Cover Emergency Release Strap NOTE: In the event of an individual being locked inside the storage bin, the storage bin cover can be opened from inside of the bin by pulling on the glow-in-the-dark strap attached to the storage bin cover latching mechanism. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Reinstalling Storage Bin Cover Emergency Release... -
Page 46: Occupant Restraints
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Push the strap into the latch mechanism until it engages around the latch post. Reinstall Cover Strap NOTE: Do not use the storage bin emergency release to lift the storage bin cover. The strap is intended for emergency release only. -
Page 47: Lap/Shoulder Belts
WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. - Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
- Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is near the seatback of the front seats and next to your arm in the rear seats. Grasp the latch plate and pull out the belt.
- Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click”. Latch Plate To Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
- Page 51 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
- Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
-
Page 53: Lap/Shoulder Belt Untwisting Procedure
As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position. -
Page 54: Seat Belt Pretensioners
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too loose or too high is dangerous. • A belt worn too loose can allow you to slip down and under the belt in a collision. •... - Page 55 chime and flash the Seat Belt Warning Light for 96 seconds or until the driver’s or front passenger’s seat belt is buckled. The Enhanced Warning System (BeltAlert) will be reacti- vated if the driver’s or front passenger’s seat belt is unbuckled for more than 10 seconds and the vehicle speed is greater than 5 mph (8 km/h).
-
Page 56: Seat Belts And Pregnant Women
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Enhanced Warning System (BeltAlert) can be reacti- vated by repeating this procedure. NOTE: Although the Enhanced Warning System (BeltAlert) has been deactivated, the Seat Belt Warning Light will continue to illuminate while the driver’s or front passenger’s seat belt remains unbuckled. -
Page 57: Driver And Front Passenger Supplemental Restraint Systems (Srs) - Airbags
Driver And Front Passenger Supplemental Restraint Systems (SRS) — Airbags This vehicle has airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the center of the steering wheel. The passenger’s front airbag is mounted in the instrument panel, above the glove compartment. - Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The front airbags have a multi stage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size. Also, the front passenger airbag is certified to the Federal regulations that define Occupant Classification (Refer to “Occupant Classification System”...
- Page 59 WARNING! • Do not put anything on or around the airbag covers or attempt to manually open them. You may damage the airbags and you could be in- jured because the airbags are not there to protect you. These protective covers for the airbag cush- ions are designed to open only when the airbags are inflating.
- Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The passenger front airbag may not deploy even when the driver front airbag has if the Occupant Classi- fication System (refer to “Occupant Classification Sys- tem” in this section) has determined the seat is empty or is occupied by a child.
- Page 61 You should read the instructions provided with your child restraint to make sure that you are using it properly. 2. All occupants should wear their lap and shoulder belts properly. 3. The driver and front passenger seats should be moved back as far as practical to allow the front airbags room to inflate.
- Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag System Components The airbag system consists of the following: • Occupant Restraint Controller (ORC) • AIRBAG Light • Driver Airbag • Front Passenger Airbag • Supplemental Side Curtain Airbags (If Equipped) •...
- Page 63 proper rate of inflation. The front airbag inflators are designed to provide different rates of airbag inflation. • The ORC may modify the rate of inflation based on the occupant size provided by the Occupant Classification Module. • The ORC will not detect side, roll over, or rear impacts. •...
- Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Driver and Passenger Airbag/Inflator Units are located in the center of the steering wheel and the right side of the instrument panel. When the ORC and impact sensors detects a collision requiring the air- bags, it signals the inflator units.
- Page 65 • When the ORC and the side impact sensors (with side impact option) detects a collision requiring the Driver Inflatable Knee Blocker, it signals the inflator unit. A quantity of nontoxic gas is generated to inflate the Driver Inflatable Knee Blocker. The Driver Inflatable Knee Blocker inflates rearward towards the driver’s knees to help protect the knees and position you for the best interaction with the front airbag.
- Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and cushion needs to be serviced in any way (includ- ing removal or loosening/tightening of seat attach- ment bolts), take the vehicle to your authorized dealer. Only manufacturer approved seat accessories may be used.
- Page 67 indicator light comes on when an adult is in the passen- ger seat, have the passenger re-position themselves in the seat until the light goes out. Remember, if the PAD indicator light is illuminated the passenger front airbag will not inflate. For almost all properly installed child restraints, the “PAD Indicator Light”...
- Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE turned OFF. When the OCS system detects an adult the PAD indicator light will be off, and the airbag will be enabled. • The Belt Tension Sensor (BTS) — If Equipped is located at the outboard passenger lap belt anchor.
- Page 69 The following requirements must be strictly adhered to: • Do not modify the front passenger seat assembly or components in any way. • Do not modify the front seat center console or center position seat in any way. • Do not use prior or future model year seat covers not designated for the specific model being repaired.
- Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold.
- Page 71 Enhanced Accident Response If the airbags and seat belt pretensioners deploy after an impact and the electrical system remains functional, vehicles equipped with power door locks will unlock automatically. In addition, approximately 10 seconds after the vehicle has stopped moving, the interior lights will illuminate until the ignition switch is turned off.
- Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • You need proper knee impact protection in a collision. Do not mount or locate any aftermarket equipment on or behind the knee bolsters. • It is dangerous to try to repair any part of the airbag system yourself.
-
Page 73: Event Data Recorder (Edr)
Event Data Recorder (EDR) In the event of an airbag deployment, your vehicle is designed to record up to 2-seconds of specific vehicle data parameters (see list below) in an event data recorder prior to the moment of airbag deployment. Please note that such data are ONLY recorded if an airbag deploys, and are otherwise unavailable. -
Page 74: Daimlerchrysler Corporation Integrated Child Seat - If Equipped
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Used for research purposes, such as to match data with a particular crash record in an aggregate database, provided confidentiality of personal data is thereafter preserved 2. Used defense litigation DaimlerChrysler Corporation product 3. -
Page 75: Child Restraint
To obtain Integrated Child Seat replacement instructions: Use the order form at the back of this manual and specify publication number 81-016-1950. Child Restraint Everyone in your vehicle needs to be buckled up at all times — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. - Page 76 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and convertible child seats.
- Page 77 child’s back is against the seat back, they should use a belt-positioning booster seat. The child and booster seat are held in the vehicle by the lap/shoulder belt. Children Too Large For Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seatback, should use the lap/shoulder belt in a rear seat.
- Page 78 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips on getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
- Page 79 • Buckle the child into the seat according to the child restraint manufacturer’s directions. • When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle. Don’t leave it loose in the vehicle. In a sudden stop or collision, it could strike the occupants or seatbacks and cause serious personal injury.
- Page 80 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When using the tether anchorages in the outboard seat- ing positions, ensure that the strap is routed over the top of the seatback and under the head restraint between the head restraint posts. Except for bench seats with split seatbacks, when the tether anchorage is used in the center seating position, the strap should be positioned straight over the top of the seatback.
- Page 81 WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap. Child restraint systems having attachments designed to connect to the lower anchorages are now available.
- Page 82 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seat belt is tucked behind the child restraint and out of reach. If the buckled seat belt interferes with the child restraint installation, instead of tucking the seat belt behind the child restraint, route the seat belt through the child restraint belt path and then buckle it.
-
Page 83: Rear Seat Delete Feature (Commercial Vehicles Only) - If Equipped
In general, you will first loosen the adjusters on the lower straps and tether straps so that you can more easily attach the hook or connector to the lower anchorages and tether anchorages. Then tighten all three straps as you push the child restraint rearward and downward into the seat. -
Page 84: Restraining Infants And Small Children With Seat Delete Feature (Commercial Vehicles Only)
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE infant carrier in a vehicle without rear seats. In an accident, serious injury or death may occur from the deploying passenger air bag. This vehicle is equipped with a child restraint tether anchor located on the floor, behind the front passenger seat. - Page 85 FACING TO THE REAR IN A VEHICLE EQUIPPED WITH THE REAR SEAT DELETE FEATURE (Com- mercial Vehicles Only). When a convertible seat is properly installed forward facing, the vehicle seat should be adjusted to the rear most position. • Children more than 40 lbs (18 kg) should be secured in the passenger seat in a child restraint or belt- positioning booster seat with the seat adjusted to the rear most position.
- Page 86 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Extend the child restraint tether anchor forward to- wards the front passenger seat. Tether To Anchor 3. Follow the child restraint manufacturer’s directions for proper use of connecting the child restraint to the extended tether strap.
- Page 87 Tether Strap Mounting 6. Using the hook attached to the child restraint tether strap, attach the child restraint tether strap to the metal ring on the vehicle tether anchor. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 7. Following the child seat manufacturer’s instructions, tighten the child restraint tether strap.
-
Page 88: Engine Break-In Recommendations
88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! The vehicle tether anchor is designed to be used with a child restraint only. It should not be used for any other purpose. Before use inspect the tether anchor strap for nicks, abrasions, discoloration, and loose threads. -
Page 89: Safety Tips
SAFETY TIPS Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow the safety tips below. Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area. -
Page 90: Periodic Safety Checks You Should Make Outside The Vehicle
90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Light The light should come on and remain on for 6 to 8 seconds as a bulb check when the ignition switch is first turned ON. If the LED is not lit during starting, have it checked. -
Page 91: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......96 Inside Day/Night Mirror ....96 Automatic Dimming Mirror —... - Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Advanced Phone Connectivity ... . 115 Things You Should Know About Your UConnect™ System ......116 General Information .
- Page 93 Lights ....... 150 Interior Lights ..... . . 151 Park Lights .
- Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing ....166 Overhead Console — If Equipped ... 167 Courtesy/Reading Lights .
- Page 95 Rear Cupholders ..... . 188 Storage ......190 Front Seat Storage Bin —...
-
Page 96: Mirrors
