Chapter 1 Cisco SRST SNMP MIB Support
Table 1-6 SRST MIB Object Groups and Descriptions (continued)
MIB Group
OL-7959-01
MIB Object
csrstSipProxySrvMonitor
csrstSipProxySrvAltIpAddr
csrstSipDefaultPreference
csrstSipVoRegPoolAppl
csrstSipVoRegNumberListTa
g
csrstSipVoRegNumberPatter
n
csrstSipVoRegNumberPref
csrstSipVoRegNumberHunts
topEnabled
csrstSipEndpointTag
csrstSipVoRegPoolEdptTag
csrstSipEndpointIpAddrType read-only
Max
Access Description
read-only Cisco SIP SRST monitoring protocol of the proxy
server configured for the SIP voice register pool. This
monitoring protocol can be ICMP ping or RTR probes.
icmp (1),
rtr (2)
read-only Cisco SIP SRST monitoring of an alternate IP address
other than the proxy configured for the SIP voice
register pool. The type of IP address used here is
indicated by the csrstSipVoRegPoolIpAddrType
object.
read-only This object indicates the default preference of the
proxy dial-peers created in the voice register pool If
csrstSipProxySrvPref object is not set, the default
preference is applied to the dial-peers created. A value
of 0 has the highest preference.
read-only Application for the SIP dial-peers configured under
voice register pool.
read-only This object indicates the particular index of the
number list configured for the corresponding voice
register pool.
read-only This object indicates the number pattern that the
registrar permits to handle the register message from
the SIP phone. This number pattern is a fully qualified
E.164 number.
read-only This object indicates the preference of the number
pattern configured for the corresponding voice register
pool.
read-only This object indicates huntstop is enabled (true) or
disabled (false) for the number pattern configured for
the corresponding voice register pool. If enabled, the
incoming call will stop hunting if the dial-peer is busy.
If disabled, the incoming call will hunt further for
dial-peers.
not-accessi This object is a number that indicates a SIP endpoint
ble configured on this SRST router
read-only This object indicates the voice register pool tag from
which the corresponding SIP endpoint (dial-peer) is
created.
Internet address type governing the address type
format for one or more InetAddress objects in this
MIB. The associated InetAddress objects' description
will refer back to this type object as appropriate.
Cisco SRST SNMP MIB Release 3.4 Guide
CISCO-SRST-MIB Object Groups
1-41
