Chapter 1 Cisco SRST SNMP MIB Support
Table 1-3 Common Tables or Elements for the CCME and SRST MIBs (continued)
Common Table or Element
Ephone-DN history stats
Common Ephone statistics
Total number of Ephones present
This refers to total number of Skinny
phones registered to SRST
This refers to the total number of Ephone
call legs routed through SRST
Trap
Trap
Trap
Read/Write object
Dependencies of the SRST MIB
When using an SRST router, you can get information regarding Ephones, Ephone-dns, and related
statistics from the CCME MIB. For example:
•
OL-7959-01
Table or Element
ccmeEphoneDnChStatsHistoryTable
ccmeEphoneDnChNum
ccmeEphoneDnChIncoming
ccmeEphoneDnChIncoming
ccmeEphoneDnChOutbound
ccmeEphoneDnChOutAnswered
ccmeEphoneDnChOutBusy
ccmeEphoneDnChDiscAtConn
ccmeEphoneDnChDiscAtAlert
ccmeEphoneDnChDiscAtHold
ccmeEphoneDnChDiscAtRing
ccmeEphoneDnChDiscAtCauseNearEnd
ccmeEphoneDnChDiscCauseFarEnd
ccmeActiveStats
ccmeEphoneTot
EphoneTotalRegistered
EphoneCallLegs
ccmeEphoneTotKeyPhConfigured
ccmeEphoneTotKeyPhRegistered
EphoneUnRegistrationThresholdExceed
EphoneFailRegistration
ccmeEphoneDeceased
EphoneUnRegistrationThreshold
To retrieve the total number of SCCP phones registered (EphoneTotalRegistered) to the SRST
router, get the total number of SCCP registered from the CCME MIB.
Scope of Objects
This table contents apply to ccme and
srst
ccme and srst
ccme and srst
ccme and srst
ccme
ccme
ccme and srst mode
ccme and srst mode
ccme and srst mode
ccme and srst mode
